Surface grinding machine

USED Jones and Shipman 540P Surface Grinder

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: BO 94392, A familair machine in any toolroom, this Jones and Shipman 540P is equipped with a 6″ x 18″ magnetic chuck, power rise and fall, coolant system and dust extraction. A toolroom institution: USED Jones & Shipman Model 540P Horizontal Spindle Surface Grinding Machine Specification Working Surface of the table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor-to-table height 1035mm Table traverse speed range per min 1.5 – 18m Cross-feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle centre to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 3000rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution Machine equipped with Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Gbsdpfx Asnxi R Ush Sew Lighting

Condition: excellent (used), Brand: KENT Model: KGS-250AHD Type : Tangential Work surface 460x200 mm Longitudinal course 540 mm Cross course 260 mm Distance form center to table 490 mm Max. Weight on the table including magnetic chuck 103 for series 250 kg 150 for series 818 kg Slote in T 14x 1 mm/N Gbedpfoh Ha Ipjx Ah Sew Longitudinal table speed 5- 23 m/min Crank cords feed 1 gra 0,02 mm - 1 rev 4 mm Automatic traerse feed per pass 0.1 -5.5 mm Automatic advance 50 Hz- 820 mm /min. - 60Hz 980 mm/min Wheel size 180 x 13 x 31. 75 mm Spindle speed 50 Hz 2850 rpm - 60 Hz 3480 rpm Upright crank 1 gra 0,01 mm - 1 rev 2 mm Automatic feed increment 0,002- 0,02 mm Spindle motor 2 x 2 HP X P Hoist motor NA kg x cm Hydraulic motor pump 1 X 6 HP X P Drain motor 1/8 X 2 HP X P Transverse agace engine 1/5 x 6 HP X P Machine height 1775 mm Machine dimension 3260 x 2460 mm Net weight 1300 kg Gross weight 1500 K

Condition: used, Year of construction: 1996, grinding length 600 mm grinding width 250 mm workpiece height ca. 385 mm table surface area 600 x 200 mm table speed -stepless- 2 - 35 m/min table load capacity max. 250 kg Gjdpfjt Tqrnex Ah Sjbw grinding wheel size ø 225 x 25 mm grinding wheel hole diameter 50,8 mm vertical feed autom. 0,001 - 0,099 mm rapid traverse vertical 600 mm/min cross feed of table continual 10 - 1000 mm/min rapid traverse cross 1000 mm/min total power requirement 6 kVA dimensions of machine L x W x H 2,65 x 1,70 x 2,28 m Accessories: DRO on Y-and Z-axis, magnetic plate 600 x 200 mm, grinding wheel with flange, wheel trueing attachment, wet grinding attachment with paper band filter

Condition: used, max. grinding length: 300 mm Gbodpfer Nyatjx Ah Ssw max. grinding width: 150 mm table movement - longitudinal: 2 - 20 m/min grinding plate rotations: 3000 Upm electrical connection: 380 V, 1,1 kW space needed: 1500 x 1100 x 1750 mm weight: 920 kg

Condition: excellent (used), Year of construction: 1971, functionality: fully functional, The machine was fully overhauled by ABA Ltd. in year 2000. Since that time is was barelly used. Working range 750 x 500 mm Table size 1150 x 400 mm Gbsdowd I Hajpfx Ah Ssw Distance between table surface and spindle center 610 mm Longitudinal travel (hydraulic) 800 mm Cross travel (hydraulic) 450 mm Dimensions of wheel D350 x 40 x d127 mm Spindle power 6,8 kW Weight 3500 kgs Place required cca 3200 x 1800 mm High 2600 mm Accessories - Magnet table 750 x 400 mm with demagnetization - Coolant tank - Hydraulic unit - Automatic vertical infeed - Automatic cross infeed - Integrated dressing unit - Some flanges with wheels - Manuals

Condition: used, Year of construction: 1985, grinding length 600 mm Gbsdpfjwd Tx Usx Ah Sew grinding width 200 mm total power requirement 7,5 kW weight of the machine ca. 2,3 t

Condition: ready for operation (used), Manufacturer: Jung Type: HF 50 Magnet table: 450x175mm Gsdpfx Ahjnr E Dxs Sobw

Condition: used, Year of construction: 1987, Technical details: grinding length: 600 mm grinding width: 350 mm workpiece height: 600 mm feed: 1 - 30 m/min magnetic plate size: 610 x 255 mm distance table - spindle center: min./max. 150 / 420 mm grinding spindle speed: 3000 U/min stroke of the table: min./max.: 200 / 650 mm total power requirement: ca. 4,0 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,5 x 1,9 x 2,0 m dimension coolant device LxWxH: 0,63 x 0,40 x 0,65 m Gbsdpfxou Ngico Ah Sew Headstock: -vertical travel Y = 0.002 - 0.06 mm -adjustment = 0,001 - 2mm Cross slide: -transverse travel Z = 360mm -feed adjustment = 1 - 60mm/stroke -rapid traverse = 1.2 m/min. Dressing manual Cooling water unit with capacity 140Liter Equipment: -3x support feet -machine lighting accessories: -alignment device for grinding wheel holder *

Condition: used, Capacity: 24″ x 8″ Serial No: Calibration: Metric c/ w magnet and coolant Power rise and fall to wheelhead Coolant Gedewga N Eepfx Ah Sjbw 2 Axis DRO system

Condition: good (used), Surface grinding machine GEIBEL & HOTZ FS 40 Primus SA, No. 920287, clamping surface 400 x 200 mm Gedpfxeunw Ilo Ah Sobw
