TRUMPF TruBend 7036

TRUMPF TruBend 7036

Condition: good (used), functionality: fully functional, Year of construction: 2018, operating hours: 7,238 h, Technical Data Press Force: 360 kN Bending Length: 1020 mm Useful Installation Height: 295 mm Clear Column Distance: 932 mm Throat Depth: 150 mm Working Height¹: 1150 mm Backgauge Axis Travel Values Y-axis Stroke: 120 mm X-axis Travel: 235 mm (max. backgauge area) X-direction: 500 mm R-axis Travel: 75 mm Control Basic Configuration: Windows XPe, PC-based control, Pentium M 1.1 GHz, 15" Connection Values Electrical Connection approx.: 6 kVA Dimensions and Weights Required Floor Space (length × width): 1805 × 1330 mm Height: 2380 mm Weight: 2600 kg Hjdpfxeyfxfns Afajnh Standard Equipment of the TruBend 7036 Machine Stable Machine Frame: Welded construction, stress-relieved heat-treated for both standing and seated operation, includes two side columns, table, and crossbeam. Press Beam: Stress-relieved heat-treated, deformation-optimized. Upper Drive: Highly dynamic, electromechanical direct drive (torque motor), max. working speed of 25 mm/s (depending on selected die width and operating cycle). Inductive Length Measuring System with Temperature Compensation Control Cabinet Air Conditioning Ergonomic Machine Design Backgauge System 3-Axis Rear Backgauge System (one gauge finger): Highly dynamic, safety 3-axis rear backgauge system. Rack-and-pinion drive, CNC-controlled X, R, and Z axes freely programmable, providing a highly adjustable gauging depth and height for maximum precision. Fiberglass gauge finger with hardened metal stop. Tool Clamping Upper Tool Clamping: Enables quick and precise tool change—vertical and horizontal; fixed, self-centering. Lower Tool Clamping: Individual V-dies are placed on a special plate. Clamping: by hand, hardened clamping bar and retainer bar. Safety Safety Devices: Safety ensured by emergency stop push button, 2-button foot pedal for both standing and seated operations, laterally sliding protective doors, as well as rear and side safety guards. The side safety guards are made of transparent, impact-resistant plastic. Control TRUMPF TASC 6000: The TRUMPF TASC6000 control system is based on Windows XPe OS, with 1.1 GHz Pentium M and 15" touchscreen, USB interface, and 1 GB RAM. Optional Equipment Levels Backgauge System 6-Axis Rear Backgauge System (2 gauge fingers) Tool Clamping Tool clamping for AMADA US-Style upper tools (manual) Safety BendGuard (with block laser): Optoelectronic safety device enabling fast and safe bending. Permitted press beam speed in foot mode: 220 mm/s Control Graphical Workplace Programming

Condition: good (used), functionality: fully functional, Year of construction: 1989, number of rollers: 3, Over roll 280mm, 12mm Prebending, capacity 18mm 3x top roll diam. Weight 7,100kg Hsdewtp Haspfx Afajnh

Condition: reconditioned (used), functionality: fully functional, Year of construction: 2016, control type: CNC control, degree of automation: semi-automatic, actuation type: electric, controller manufacturer: TRUMPF, controller model: TASC 6000, bending force (max.): 36 t, working width: 1,020 mm, throat depth: 150 mm, operating speed: 220 mm/s, number of axes: 6, type of crowning: CNC-controlled, overall weight: 2,600 kg, total length: 1,900 mm, Equipment: CE marking, documentation/manual, european tool clamping system, finger protection, The TruBend 7036 is designed to maximize productivity and is especially suitable for industries requiring flexible, precise, and fast bending of small sheet metal components, such as electronics, automotive, and precision engineering. Its ergonomic design minimizes operator fatigue and improves safety and efficiency. Hnodpfx Afsw D Uwxsajh

Condition: excellent (used), functionality: fully functional, Year of construction: 2016, operating hours: 30,979 h, machine/vehicle number: B0702A1678, control type: CNC control, bending force (max.): 36 t, working width: 1,020 mm, stroke length: 120 mm, throat depth: 150 mm, distance between stands: 932 mm, installation height: 2,390 mm, operating speed: 25 mm/s, reverse speed: 220 mm/s, number of axes: 6, table height: 955 mm, type of crowning: CNC-controlled, overall weight: 2,600 kg, total length: 1,900 mm, total width: 1,800 mm, total height: 2,390 mm, input voltage: 400 V, Equipment: CE marking, documentation/manual, emergency stop, european tool clamping system, foot remote control, Machine condition Technical condition: very good, fully operational Used in clean conditions, no structural damage Can be tested and inspected on site Hnjdjx Apgvjpfx Afaeh Full documentation available for inspection Key features and equipment Bending force: 36 t (360 kN) Bending length: 1020 mm Throat depth: 150 mm Beam stroke: 120 mm CNC control: TRUMPF TASC 6000 / Touchpoint TruBend Backgauge: 6-axis (X, R, Z1, Z2, Y1, Y2) Working speed: 25 mm/s Rapid return speed: 220 mm/s Technical data Distance between stands: 932 mm Installation height: 2390 mm Table height: 955 mm Rear stop range X: 600 mm Z-axis range: 0–1020 mm Weight: 2600 kg Installed power: 7 kW Power supply: 400 V

Condition: good (used), functionality: fully functional, Year of construction: 1995, working width: 4,100 mm, throat depth: 250 mm, overall weight: 20,000 kg, pressing force: 200 t, Hämmerle BM200-4100. The machine was dismantled at the old plant in 2023, but it was not reassembled or put into operation at the new site. Since then, the machine has been kept in storage. All accessories and documentation are included. The machine can be inspected at any time and is immediately available for loading. All data can be found in the pictures... No tools are included, as these were compatible with the new machine. Hjdpjwa S Dnofx Afaonh

Condition: good (used), Year of construction: 2008, pressing force: 36 t, Servo-electronic press brake Manufactured by TRUMPF Type. TruBend 7036 Year of manufacture: 2008 Technical specifications Make: TRUMPF Type: TruBend 7036 Year of manufacture: 2008 Capacity: 36 t Bending length: 1020 mm Working height approx. 1150 mm Space requirement: 1805 x 1330 x 2380 mm Weight: 2,600 kg Standard equipment - Sturdy machine frame - Press beam - Highly dynamic, electronic direct drive (torque motor) - Inductive length measuring system with temperature compensation - Control cabinet air conditioning - Ergonomic machine design Optional equipment - Tool clamping (Wila) top and bottom - Integrated TRUMPF TASC 6000 control system Hjdpfx Afewltursaenh - Front safety light barrier - Backgauge system: 6 axes: X1, X2 R1, R2, Z1, Z2 - Comfort support table - BendGuard (with block laser) Safety - Side-hinged safety doors - Rear protective cover - 2-button foot switch, for freestanding and seated operation - CE marking All information is subject to change without notice. Powered demonstrations are available at any time in our showroom.

Condition: excellent (used), functionality: fully functional, Year of construction: 2017, operating hours: 49,641 h, control type: CNC control, actuation type: hydraulic, controller manufacturer: Bystronic, bending force (max.): 40 t, working width: 60 mm, stroke length: 200 mm, oil tank capacity: 100 l, travel distance X-axis: 300 mm, back gauge speed R-axis: 500 mm/s, back gauge travel distance R-axis: 100 mm, back gauge travel distance Z-axis: 955 mm, Equipment: CE marking, documentation/manual, emergency stop, finger protection, safety light barrier, Used Bystronic Xpert 40ton x 1metre cnc pressbrake for sale Model: Xpert 40/1030 Hnedpjxtf A Isfx Afaoh Tonnage 400 kn Bending length 1030 mm Standard stroke [S] 200 mm Open height [D] 515mm Distance between side frames 1060mm Table Width 60mm Max. back gauge range X-axis 500mm X-axis travel 300 mm X-axis speed 1500 mm/s R-axis travel 100 mm R-axis speed 500 mm/s Z-axis travel 955 mm Z-axis speed 2000 mm/s Y-approach speed (up to) 300 mm/s Y-working speed (up to) 25 mm/s Accuracy Y-axis 0.004 mm Oil capacity 100 l Electric supply 7.5 kw Weight 4t Length, approx. [L] 1520 mm Width, approx. [W] 1584 mm Height, approx. [H] 2449 mm 1.1 Xpert 40/1030 1.2 ByVision Bending control with 22 Inch Full HD display and touch technology 1.3 Dynamic drive system (DDS) with Energy Saver 1.4 Automatic tool protection 1.5 Ergo foot switch 1.6 Rear protection sliding door electrically controlled 1.7 User manual (on CD) 1.8 Ambient air temperature 7°C up to 35°C 1.9 Voltage: 400/480 V, 50/60 cycles, 3 Ph (other parameters available on request)

Condition: used, Year of construction: 1989, Technical details: pressure: 100 t chamfer lenght: 2600 mm distance between columns: 2300 mm throat: 300 mm control for program: CNC-Steuerung DNC7000 dayligth: 830 mm max. stroke: 265 mm ajustment speed: 80 - 100 mm/sec back gauge: motorisch table-size: 2700 x 113 mm work height max.: 900 mm connection voltage: 380 V total power requirement: 15 kW weight of the machine ca.: 11,3 t Hodpfx Aju Icdmefajnh machine dimensions LxWxH: ca. 3,2 x 3,8 x 3,0 m 3-point BENDING - mould bending -Hydrocushion (for regular force adjustment over the entire working length) -Backstop: width 2200mm, 2x supports travel 1800mm and 4x stop travel W:2550xL:860mm -Control panel on the boom can be swivelled and/or control stand with two-hand and foot control various press brake tools available i.D. *

Condition: ready for operation (used), Year of construction: 2023, General Data Machine weight 1800 kg Measurements height 2200 mm Hodpfsx I S Rwjx Afaenh Dimensions Machine Length 1440 mm Main Drive Number of axis 3 Pressing force 220 Kn This 3-axis Coastone Cone C9 press brake was manufactured in 2023. It features a C-frame design, a pressing force of 220 kN, and a maximum bending length of 900 mm. Equipped with an Omron Touchscreen TC15-2D CNC control and Amada Promecam tool clamping system, it ensures precision and ease of use. Located in Slovenia, it comes with a complete bending tool set and a 36-month warranty. Consider the opportunity to buy this Coastone Cone C9 press brake. Contact us for more information. Application Types Bending

Condition: new, functionality: fully functional, Year of construction: 2025, throat depth: 400 mm, warranty duration: 24 months, Model: GB-4016E Bending pressure (KN): 400 Bending length (mm): 1600 Distance between columns (mm): 1320 Maximum opening height (mm): 430 Slider stroke (mm): 180 Throat depth (mm): 400 X-axis stroke (mm): 400 X-axis speed (mm/s): 400 R-axis stroke (mm): 140 R-axis speed (mm/s): 200 Z-axis stroke (mm): 1040 Z-axis speed (mm/s): 400 Hsdpfswzqx Hsx Afaenh Machine power (kw): 17.2 Dimensions (mm): 2090*1265*2290 Weight (kg): 3500
