Universal machining center

Matec 30HV

Condition: ready for operation (used), Year of construction: 2007, operating hours: 5,577 h, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,100 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, spindle speed (max.): 12,000 rpm, number of axes: 5, This 5-axis Matec HV 30 was manufactured in 2007, featuring a Heidenhain iTNC 530 control, a new spindle installed in August 2021 with 5,577 hours, and a spindle speed of 12,000 rpm SK40. It offers X-axis travel of 3000 mm, Y-axis travel of 1000 mm, and Z-axis travel of 1100 mm. Consider the opportunity to buy this Matec HV 30 vertical machining centre. Contact us for more information about this machine. • Operating hours: 83,000 h • Total spindle hours: 32,800 h • New spindle installed: Aug 2021 → current spindle hours: 5,577 h • Material history: ~95% aluminum machining • B-axis: ±105° • C-axis: 360° • Handwheel Pjdpfxoyfunro Agpjpl • Tool magazine: 60 positions, SK40 • Internal coolant supply Additional equipment • Oil mist extraction • Renishaw probe Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2009, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, This 5-axis Matec 30-HV was manufactured in 2009, featuring a versatile universal machining center with a large X-axis travel of 3000 mm and a Y-axis of 600 mm. It includes a high-speed range up to 12,000 rpm, a tool magazine for 36 tools, and a high-pressure cooling system (70 bar). Ideal for complex 3D machining with its powered CNC rotary table and Heidenhain iTNC 530 control. Contact us for more information about this machine. Additional information • Dimensions of Machine (LxWxH): X = 3000 mm (table 3500 mm), Y = 600 mm, Z = 800 mm Horizontal • Rapid traverse: 48 m/min in the X, Y, and Z axes • Powered CNC rotary table for 3D machining • Tool magazine for 36 tools • Tool length max: 380 mm Ppodpfjx D Rggox Agpel • 3D measuring probe with radio control and radio signal transmission • High-pressure cooling along and through the spindle (70 bar) • Coolant tank: 900 l • Automatic doors

Condition: excellent (used), Year of construction: 2013, 5-axis machining center (BAZ) Control: Heidenhain Pedpfx Agsyaba Dopepl Travel paths: X 2000 mm, Y 600 mm, Z = H 800 mm, V 700 mm. Max. clamping weight (rotary table): 1200 kg Max. spindle speed: 18,000 rpm

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 15,000 rpm, Matec 5000 Travel: 5000x800x800 mm Table size: 5000x850 mm Ppedpfxeych R Ij Agpjl Kessler spindle, 15,000 rpm Tool holder: SK40 Tool magazine: 45 tools

Condition: excellent (used), Year of construction: 2016, operating hours: 8,737 h, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, Matec 30HV 3000x800x800 mm NC swing head +/- 105° swiveling Heidenhain TNC640 Handwheel Motor spindle 15,000 rpm / 30 kW / 198 Nm Tool holder HSK 63A 48 tool pockets ICS (internal coolant supply) 40 bar Belt filter system 450 liters Air through spindle Oil mist extraction (left and right) Partition wall for pendulum operation Side loading door Prepared for additional NC axis 3D triggering probe Renishaw RMP60 Tool breakage control (laser) Clamping hydraulics 100 bar / 10 l/min 2 x clamping circuits, clamping, releasing, manual and via M-function Robot interface The machine has very low operating hours and has always been perfectly maintained. Podpsyaa Sfefx Agpepl The complete (maintenance) history is known to us. Tools and vices can be taken over if required.

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,100 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, spindle speed (min.): 20 rpm, spindle speed (max.): 12,000 rpm, spindle nose: VDI 40, number of slots in tool magazine: 36, Additional equipment: 4th axis IKZ (internal coolant supply) with 40 bar Ppsdpfex Sv A Ssx Agpjl Swivel head with 1° increment 3D wireless probe

Condition: ready for operation (used), Year of construction: 2000, General Data Machine weight 19000 kg Movement X-Axis Movement 4000 mm Y-Axis Movement 825 mm Z-Axis Movement 1100 mm Ppsdjx D D D Espfx Agpel Table Table load 4000 kg Turret Number of tool slots 48 Media Internal cooling Yes Additional Equipment Pneumatically opening doors Partition wall for two-field machining Ventilated measuring systems Optional: High-pressure pump (40 bar) and NC rotary table This 5-axis Matec 30 HV CNC vertical machining center was manufactured in 2000. It features a milling spindle with a speed range of 20-9,000 rpm and a drilling capacity in St 60 of 60mm. The machine boasts large travel distances with X-axis at 4000 mm, Y-axis at 825 mm, and Z-axis at 1100 mm. It supports a maximum table load of 4000 kg. If you are looking to get high-quality milling capabilities consider the Matec 30 HV machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2010, Movement X-Axis Movement 3000 mm Y-Axis Movement 600 mm Z-Axis Movement 800 mm B-Axis Movement ±105° C-Axis Movement 360° Additional Equipment Turning Package: Enables high-precision turning operations in combination with standard milling, facilitating turning and milling in a single setup. This 5-axis Matec 30 HV mill-turn centre was manufactured in 2010. It features a traveling column with 3,000 mm X-axis travel, 600 mm Y-axis, and 800 mm Z-axis. The B-axis swivels ±105° and the C-axis rotates 360°, supporting complex geometries. Equipped with a Bosch Rexroth IndraMotion 10 control unit and a rotary table speed of 500 RPM, it enables precise turning and milling operations. For more information about this mill-turn centre, please reach out to us. Pjdpfxox D Dy Hj Agpopl Application Types Milling

Condition: ready for operation (used), Year of construction: 2007, operating hours: 14,136 h, Control Unit Brand HEIDENHAIN Ppodpfx Agsx D Ix Tjpsl Model iTNC530 Main Drive Spindle speed range 15000 Spindle motor power 16 kW Tool taper HSK 63 Number of axis 4 Movement X-Axis Movement 1300 mm Y-Axis Movement 600 mm Z-Axis Movement 800 mm Table Table load 400 kg Tools Number of index 36 Type of tool holder SK40/DIN 69871 or HSK 63-A Media Chip conveyor Yes This 4-axis Matec MATEC 30 HV/K was manufactured in 2007, featuring a robust vertical machining center design. It includes a Rexroth control, a standard spindle with a speed range of 20-15,000 rpm, and a maximum torque of 100 Nm. The machine offers a tool changer with a capacity of 36 tools and a machine table that supports up to 400 kg. If you are looking to get high-quality milling capabilities consider the Matec MATEC 30 HV/K machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 2006, functionality: fully functional, machine/vehicle number: 0897, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, spindle speed (max.): 18,000 rpm, spindle motor power: 21,600 W, Matec 30 HV/S CNC Machining Center (2006) Heidenhain CNC Controller, Samsys+ Multi-3000 Barstock Loader Coolant Reclaim System, and Chip AugerMatec 30 HV/S CNC Machining Center Heidenhain Control 5-axis Spindle speed up to 18,000 RPM, spindle motor power 29 HP (21.6 kW) tool capacity 24 tools, travel 30 x 20 x 20 inches (762 x 508 x 508 mm) Ppedsx Ap Hvjpfx Agpjl includes SamSYS feeder Under maintenance parts missing Sublocation - Building 6
