CNC Machining Center

Homag GENIUS BAZ 20/30/14/3/D(2)

Condition: excellent (used), Year of construction: 1998, pressing force: 125 t, Hydraulic press brake Fab. EHT Typ. VARIOPRESS 125-3550 Fgodjr Epr Ujpfx Adusk Year 1998 Technical data Make: EHT Type: Variopress 125-3550 Year of construction: 1998 Capacity: 125 t Effective length: 3550 mm Machine column: 2550 mm Projection: 300 mm Stroke: 240 mm Installation height: 640 mm Oil volume 250 L Dimensions: approx. L 3.90 x W 1.80 x H 3.00 m Weight: approx. 12 t Equipment - Control system: Cybelec DNC 80 2D graphics - Automatic upper tool clamping - Lower tool clamping 90mm and 13mm - controlled axes: Y1, Y2, X1, X2, R, Z1, Z2 - motorized crowning - 6 x V block die length 3,500, segmented: with V12/30°, V40/80°, V24/80°, V10/30°, V24/30°, V16/30° - Punch straight, H 350mm / approx. 70°, length 3060 mm, segmented All data without guarantee. A demonstration under power is possible at any time in our exhibition hall.

Condition: used, Year of construction: 1988, Technical details: turning diameter over bed: 360 mm turning dia. over face-slide: 160 mm Fodpfxeu Rqabo Aduegk turning length: 800 mm longitudinal traverse (z-axis): 810 mm facing movement (x-axis): 205 mm control: TX-8 spindle passage: 60 mm revolution per minute: 63 - 3150 / 2 step U/min feed:: 10.000 mm/min. tool turret - number of stations: 8 operating hours - idle run: 8834 h tailstock taper ISO: SK30 DIN 2080 tailstock quill stroke: 105 mm operating pressure: 40 bar total power requirement: 38 kW Weight approx.: 3,1 t dimension machine xH: 1,8 x 3,3 x 1,8 m dimensions of hydaulic: 580 x 400 x 750 mm Equipment: Lathe chuck Ø 200 mm, hydraulic Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system control panel Accessories Fine adjustment device for tool set-up *

Condition: used, Year of construction: 1995, Technical details: sheet width: 3000 mm Fgodpfx Aevc Amteduek plate thickness: 12 mm distance between columns: 3500 mm control: Cybelec DNC 10 G back gauge: 1200 motorisch mm cutting angle: 1,2 - 2,73 ° cutting gap adjustment: ja mm cutting capacity : 66.000 daN daN Knife length: 3100 mm down holder: 17 Stück interface: RS232 Table dimensions: 3200 x 600 mm total connected load: 22 kW weight of the machine ca.: 11,0 + (1,0 to Anbauteile+Zubehör) t space requirements approx. LxWxH: ca. 4,5 x 2,6 x 2,1 m transport dimensions LxWxH: ca. 5,0 x 2,25 x 2,2 m The guillotine shear was put into operation for the first time in 1998. The DNC 10 G control unit was specially designed for guillotine shears. It has a numerical axis for controlling the backgauge and automatically calculates and regulates the cutting gap, the cutting angle and the cutting depth, taking into account the material to be cut. (Data from the manufacturer) Table with side stopL:930 x W:105 x H:42 mm 2 table extensions L:1600 x W:100 x 83 mm Angle fence (attached to table extension) Operation via control panel with swivel arm and foot control Equipment: Drain with rollers for clippings 2x protective grid *

Year of construction: 1974, condition: ready for operation (used), Working length: 3500mm, the pressure bar of the machine must be realigned. Fsdpfx Adei Acq Rsujgk

Condition: ready for operation (used), Press force: 10000kN, ram stroke: 350mm, stroke rate: 28rpm, overtravel: 102mm, overtravel time: 0.2s, safety distance: 330mm. On-site inspection is possible. Fgsdpewm Nndefx Adujk
