5-axis universal machining center

GROB G350 access-SERIE

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: U268893501006, travel distance X-axis: 600 mm, travel distance Y-axis: 770 mm, travel distance Z-axis: 805 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 640, spindle speed (max.): 16,000 rpm, coolant supply: 40 bar, number of slots in tool magazine: 90, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Highligts: - Powerful HSK-A 63 Motorizied spindle with 16.000 rpm - 90 tools in system - ready for automation ___ Basic machine G350-1006 access-SERIE Travel path X-axis: 600 mm Travel path Y-axis: 770 mm Travel path Z-axis: 805 mm Power supply 400 V, 50 Hz, TN-S Compressed air system, operating pressure 5 bar, minimum inlet pressure 5 bar Work area door, automatic, for manual and automatic loading/unloading Decentralized mist collector unit for the work area Machine protection concept for emulsion machining Work area lighting Machine paintwork according to GROB standard Machine cooling system with air-cooled cooling unit (4.0 kW) Operating/environmental conditions according to GROB standard Electrical equipment according to EU GROB standard Stainless-steel internal work area enclosure Fluid cabinet doors HEIDENHAIN TNC 640 machine control Control interface (HMI) in the German language Swivel axis calibration GSC Classic Interface (software and hardware) for connection of an automation system Tilting table unit (A'-axis) Rotary table with pallet clamping system GROB Motorized spindle HSK-A 63, 16,000 rpm, 159/206 Nm, 25/32 kW GROB spindle diagnosis GSD Compact double disk-type magazine HSK-A 63 with 90 tool pockets Tool cleaning device Laser measurement system LaserControl NT LC50-DIGILOG for milling tools Palette 400 x 400 mm, grid holes, without pallet changer hook Djdpfsw Eiw Njx Ac Hswd Premium package -Scraper conveyor, discharge height 1,100 mm -Cutting fluid filter system -Cutting fluid tank -High-pressure cutting fluid system (5-40 bar, IKZ) -Cutting fluid low-pressure system Compressed air feed through spindle center Oil skimmer for cutting fluid care Flushing unit for the base of the work area Flush gun at the work area Flushing unit (Z-axis) Machine status light, 3-colored Preparations for use of radio and infrared signal receiver (RENISHAW) Infrared probe OMP60 (RENISHAW) Remote machine diagnostics with access control switch 3-month warranty

Condition: ready for operation (used), Year of construction: 2021, Travel X/Y/Z: 630mm/530mm/465mm, tool holder: SK40, speed: 12000rpm, tool positions: 32, table dimensions X/Y/Z: 920mm/540mm, machine dimensions X/Y/Z: 2600mm/2350mm/2750mm, weight: approx. 6500kg. Documentation available. On-site inspection is possible. Dwsdpfxowm Nphj Ac Hsd

Condition: new, Fully automatic palletizing system HYDRA+ cobot palletizer: Dodpoi Emapefx Ac Howd 👉 up to 20 kg payload (optionally up to 25 kg) and 👉 up to 2 m palletizing height Depending on customer requirements, we offer different configurations of our palletising system. 💶 For full price details of the Cobot palletiser with 20 kg payload, please refer to the detailed price package (see attached PDF in EN 👉 8136716-2.pdf). The palletizing system includes: → Collaborative robot DOOSAN ROBOTICS Cobot H2017 for up to 20 kg payload; (optionally adaptable up to 25 kg payload with DOOSAN H2515) → Robot base and operating elements → Pallet frame for 2 Euro pallets → FJM suction pad for handling packages, construction as required → innovative palletizer software → individual design according to customer requirements → palletizing system, firmware and software up to date ❗ For logistical reasons, we only deliver within the DACH regions and countries bordering Austria. HYDRA cobot palletiser by FJ Mayer GmbH Developed and programmed by Franz Josef Mayer GmbH Austria. ©Franz Josef Mayer GmbH 2021

Condition: ready for operation (used), Year of construction: 2019, Travel X/Y/Z: 1530mm/530mm/465mm, spindle speed: 12000rpm, spindle power: 22kW, spindle torque: 120Nm, tool holder: SK40, tool positions: 54, rotary table diameter: 630mm, max. table load: 500kg, rapid traverse: 30m/min. Documentation available. On-site inspection is possible. Dwedpowm Npnjfx Ac Hjd

Condition: good (used), Year of construction: 2012, arm reach: 2,696 mm, controller model: KR C4, KUKA Robots Model: KR 90 R2700 pro Technical data Maximum reach: 2696 mm Rated payload: 90 kg Rated supplementary load, rotating column / link arm / arm: 0 kg / 0 kg / 50 kg Rated total load: 140 kg Pose repeatability (ISO 9283): -/+ 0,06mm Number of axes: 6 Mounting position: Floor Footprint: 830 mm x 830 mm Weight: approx. 1058 kg Axis data Motion range A1: -/+ 185 ° A2: -140 / -5 ° A3: -120 / 155 ° A4: -/+ 350 ° Dwjdpfetpwxljx Ac Hsd A5: -/+ 125 ° A6: -/+ 350 ° Speed with rated payload A1: 136 ° / s A2: 130 °/ s A3: 120 ° / s A4: 292 ° / s A5: 258 ° / s A6: 284 ° / s Operating conditions Ambient temperature during operation: 10 °C bis 55 °C (283 K bis 328 K) Controller: KR C4

Year of construction: 2019, condition: excellent (used), load capacity : max 360 kg Extendable : 700 mm x 1400 mm Dwsdpspu D Dzefx Ac Hed Angle of rotation around longitudinal pivot : 360`

Condition: used, Year of construction: 2000, x-travel 800 mm Dwjdpfot Hwyrex Ac Hed y-travel 500 mm z-travel 510 mm total power requirement 60 kW weight of the machine ca. 10 t dimensions of the machine ca. m
