4 rol plate bender 3500 x 110 mm

Faccin 4HEl 3590

Condition: used, Year of construction: 1957, ram hammer weight 200 kg ram hammer stroke 525 mm no. of strokes 150 /min impact energy 420 kJ distance lower die block / ram gudeway 435 mm Throat 425 mm steel forging - rectangular up to 110 mm steel forging - diameter up to 125 mm power requirement 22,0 kW weight of hammer 3,9 t weight of anvil 3,0 t weight 6,9 t dimensions (WxDxH) 1,1 x 2,3 x 2,4 m Forging hammer Hodpfovzxpbex Amgel as is where is, WITHOUT putting into operation

Condition: used, mileage: 280,163 km, lifting height: 35,500 mm, Year of construction: 2014, operating hours: 7,979 h, Drivetrain Drive: Wheel Weights Empty weight: 31.787 kg Functional Lifting capacity: 15.000 kg Identification Serial number: 782002 Other information Front tyres / undercarriage remaining: 90 Rear tyres remaining : 90 Tyre brand: Bridgestone Carrier engine: - Hsdpfxsvf A Trj Amgjl Upper engine: - Counterweight: 0 Transport dimensions (LxWxH): 0x0x0 Additional information Please contact PFEIFER GROUP for more information

Condition: refurbished (used), Year of construction: 2021, functionality: fully functional, center height: 150 mm, workpiece weight (max.): 130 kg, grinding length: 1,500 mm, grinding wheel diameter: 500 mm, total width: 2,155 mm, total length: 5,465 mm, total height: 1,700 mm, grinding diameter: 300 mm, grinding wheel width: 63 mm, The cylindrical grinding machine was fully overhauled in 2021 and has hardly been used since. The condition of the machine is practically like new. Equipment as shown in the photos. The machine is connected to power and can be inspected at any time by prior arrangement. Technical specifications: Hodpfx Amex A Dfyegel Grinding diameter: 300 mm Grinding length: 1500 mm

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t dimensions of machine: 1800x1850x2500 mm dimensions electric cabinet: Nr. 1: 1930x400x1920 mm dimensions electric cabinet: Nr. 2: 800x230x1950 mm dimensions:: Abluftanlage: 1400x700x560 mm Hsdpfx Amovc Apbegjl dimension cooling device LxWxH: 1,2 x 1,0 x 0,45 m Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 77x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Condition: new, Year of construction: 2025, functionality: fully functional, The CNC BAYKAL Hybrid Press Brakes combines all the benefits of both hydraulic and all-electric press brake systems into one. If you’re looking for press brakes that are fast, accurate, and energy-efficient, BAYKAL is the way to go. The CNC BAYKAL Hybrid Press Brakes can significantly save energy, save fuel, improve bending efficiency, reduce the risk of oil leakage, reduce installation costs, extend the service life of consumables, improve bending accuracy, reduce noise, and improve the working environment. The CNC BAYKAL hybrid press brakes system are designed with an individual electro-hydraulic servo drive system and servo pumps to control the for each of the left and right cylinders. The servo motor controls the output flow of the oil pump according to the program setting, and then controls the movement speed and position positioning of the slider, and there is no throttling phenomenon in the whole process. Therefore, all the energy output by the oil pump is supplied to the left-right oil cylinder. This control method does not have any energy loss, and the energy-saving effect is very prominent. With this system the hydraulics run on demand when the foot pedal is activated, rather than having a pump running continuously. This results in lower energy usage than a standard hydraulic machine as well as faster cycle times and extremely high accuracy. Hjderq D Nispfx Amgol The flow and pressure of Y1 and Y2 oil cylinders are respectively controlled by two sets of servo bidirectional pump systems, and the oil in the upper chamber of the oil cylinder is directly pumped into the lower chamber of the oil cylinder through the oil pump to realize the lifting of the beam. The reverse rotation of the oil pump pumps the oil in the lower chamber of the oil cylinder directly into the lower chamber of the oil cylinder to realize the pressing and bending of the upper die. Applicable between from 100 Tons to 1250 Tons, the synchronization of the left and right of the upper beam of the CNC BAYKAL hybrid press brakes is controlled separately by two sets of servo bidirectional pumps.

Condition: good (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 11383, type of input current: three-phase, working range: 3,000 mm, overall weight: 17,000 kg, input voltage: 400 V, cutting speed: 2,000 mm/min, total width: 4,500 mm, total height: 5,500 mm, total length: 22,400 mm, track width: 1,400 mm, repeat accuracy: 1 mm, workpiece weight (max.): 30,000 kg, warranty duration: 6 months, input frequency: 50 Hz, open-circuit voltage: 400 V, ambient temperature (max.): 45 °C, Secondhand SPC3000 - HGG Profiling Equipment B.V. Hodpfx Ameri Slmsgol Are you ready to automate your workflow, but not ready for a heavy investment in pipe cutting machinery? We have an interesting opportunity for you. This 2014 SPC3000 (40 Ton) pipe cutting machine is highly versatile. The machine is capable of cutting pipes from 300mm - 3000mm diameter and is equipped with a lot of extra features: - 4x 10 Ton pipe trolleys (300-2500 mm OD) (1 of them is a driven pipe trolley) - 2x 20 Ton pipe support (2500-3000 mm OD) - Plasma marking system Kjellberg Finemarker - Punch marking system - Can handle 18 meter long pipes - Plasma cutting system Kjellberg FF450 - Oxyfuel cutting process - Additional touch screen remote control attached to main drive - 3 Point fume exhaust system The SPC3000 is used by our eXperience Center and maintained by our best engineers at our headquarters in The Netherlands. The machine has a proven record and is used to profile pipes for clients in several high demanding industries f.i offshore, piping, structural steel and the vessel industry. A lot of special projects have been profiled on this machine.

Condition: used, Year of construction: 1977, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±8 ° longitudinal feed of the table 1300 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 4,2 x 2,0 m Neu geliefert an Universität. 2018 übernommen. Dann komplett bei BEMA gewartet und an an Einmannbetrieb geliefert. Hodpfx Aeynmpgsmgjl Nun wird die Maschine nochmal gewartet und Tischgeometrie neu hergestellt. 2-Achsen-Digitalanzeige Fagor nachgerüstet. -Reitstock mit Feinverstellung -Innenschleifeinrichtung -Kühlmittelanlage Zubehör auf Anfrage

Condition: used, Year of construction: 1965, There are two WMW SU 315x3000 available, connected load machine 1/ 2: 12.6/ 12kW, weight machine 1/ 2: 8.2/ 9t, machines need overhauling. Hedpfxoxg Ihgo Amgel

Condition: used, Year of construction: 2006, functionality: fully functional, center height in crank: 1,100 mm, workpiece weight (max.): 180,000 kg, grinding length: 11,000 mm, grinding wheel diameter: 1,066 mm, total length: 11,700 mm, quill travel distance: 11,700 mm, workpiece weight between centers: 180,000 g, distance between centers: 11,700 mm, POMINI CNC Roll Grinder Model HD-425-2-7L Siemens 840D, 12 Axes. Built in 2006. Two flatbed system grinding and workpiece ways are separate. Machine accuracy. Straightness 0.001-0.002 mm/m. Roundness 0.001-0.002 mm. Eccentricity 0.002 mm. Profile for crown height up to 0.1 mm ±0.002 mm/m. Surface finishing without chatter marks and no feed marks after finishing grinding stage. On an independent bed: Auto Caliper Diameter 870 - 2,250 mm. Eddy current crack and bruise detector probe. Ultrasound depth probe up to 180 mm. High Pressure wheel cleaner. Wheel dynamic balancing electromagnetic automatically or manually. Wheel dressing device with diamond. 2 Hydrostatic Steadies. 2 Hydrodynamic Steadies. 4 Soft landing for roles. Wheel quick change device incl motor. Jib crane. Vibration Measurement, recording on: Headstock base Neckrests Foot stock Wheel head Wheel head back Carriage Lateral side. Working Capacity. Grinding length 11,000 mm Max diameter with 1,066 mm Grinding wheel 2,200 mm Hsdswdmy Sopfx Amgol Min diameter with 1.066 mm Grinding wheel 800 mm Center distance 11,700 mm Max Roll weight 80 Tons Max Roll weight with Steadies 180 Tons Min distance between wheel center and roll axis 845 mm Max distance between wheel center and roll axis 1,635 mm Carriage Axis Z, Hydrostatic Feeds, Infinitely variable 0-6,000 mm/min Oil film thickness 0.020 mm Distance between carriage ways 1,500 mm Ways width 160 mm Total length of the carriage on ways 3,385 mm Wheelhead on Carriage Axis X, Wheel Probe Axis A, Inspector Axis A1, Wheelhead cross travel Ballscrew, Axis X 940 mm Resolution axis X 0.0001 mm Wheel Spindle length 1,695 mm Spindle bearing, hydrostatic, diameter 254 mm Resolution Infeed micrometer handwheel, Axes X 0.00001 mm / division Continuous wheel infeed, U axis on radius 0 - 0.35 mm/min Rapid wheel indeed, axes X 0-830 mm/min Wheel motor, AC 130 kW Wheel Speed 400-1,100-1,600 rpm Wheel Cutting Speed infinitely variable Surface speed wheel diameter 1,066 mm 45 m/sec Surface speed wheel diameter 670 mm 45 m/sec Wheel hole, diameter 508 mm Wheel thickness 76 - 152 mm Wheel diameter 670 - 1,066 mm Crowning, Axis U. Max crown on the diameter 10 mm Max concavity on the diameter 10 etc Head stock Workpiece rotating speed 5 - 50 rpm Headstock motor 200 kW Max transmissible torque 76.5 kNm Faceplate control system V Belts Max Center diameter, metric type 160 mm Stroke of Quill 150 mm Length of headstock 3,110 mm Tail stock Quill diameter 260 mm Stroke of quill 750 mm Maximum center diameter, metric type 160 mm Taper Metric 5% on the diameter Tailstock length 1,300 mm Stroke of tailstock 8,000 mm Caliper, Arm Axis C, Carriage Axis V, Rotation Axis B. Max measurable diameter 2,250 mm My measurable diameter 870 mm Machine Dimensions. Machine weight 130 tons Length 19.5 m. Width 5.5 m. Height 3.2 m. Foundation depth 3.8 m.

Condition: used, Year of construction: 2017, pipe diameter (max.): 80 mm, mandrel length: 4,500 mm, Mandrel bending machine S8004 ----- For the production of dimensionally accurate pipe geometries with bending radii of up to 1.5XD → maximum bending performance pipe 76 x 4 mm (400 N/mm²) → maximum bending performance pipe 60 x 60 x 3 mm (400 N/mm²) → maximum bending performance pipe 76 x 2.9 mm (stainless steel) → total connected load 7 kW → pipe length 4.5 mtr Robust and durable steel construction in a force-locking connection - no construction susceptible to torsion due to, for example, the split construction of the bending head and mandrel carrier. Maintenance-free electromechanical drive of the bending axis. The touch display of the control enables simple and intuitive programming and use of the system. After the pipe has been pushed on, it is fixed in the carriage by the chuck. This enables the pipe to be positioned precisely and thus the creation of dimensionally accurate geometries. The standard also includes checking the pipe geometry before the bending process: If the bending process is started in the wrong position, the machine does not give permission for this. This prevents incorrect operation. Optional additional features provide more convenience and increase the output and thus the efficiency of the system. Data is exchanged from the optional pipe calculation program TBS-3D (PC version) via USB stick or via FTP access from the computer to the machine control system. USB or LAN connectors (RJ45) are available as standard. Existing pipe geometries can be converted quickly and easily, for example, using the STEP format. Standard equipment: → Electromechanical drive of the bending axis 4 kW → Speed 2.9 rpm (=17°/sec.) → Bending direction left → Bending angle resolution 0.1° → Max. bending radius 200 mm → Bending shaft diameter 50 mm → Electronic length measurement ±0.1mm → Electronic twist measurement ±0.1° → Manual stop system (overtravel stops in length) → Manual locking system (15° in twist) → Three-jaw chuck for locking the pipe in the carriage → External control panel PLC control: → Touchscreen 10.1" → ETH 10/100, X2X Link, USB → Foot switch operation → Data transfer via network (W)LAN or USB → Material database Unique graphic programming: Simple geometries can be calculated directly on the machine. The control calculates the feed values directly after entering the length and angle and the bending angles. Hydraulics: → Hydraulic power 3 kW → Hydraulic pipe clamping with adjustable clamping pressure → Programmable early mandrel retraction Hedpfsttah Rjx Amgjl Options (can be ordered as additional equipment): → Variable bending speed using frequency converters or servo motors → Automatic tool retraction (manual or controlled) → Pneumatic chuck → Automatic mandrel lubrication → Pneumatic stop system (length + twist) → Mobile version (rollers) → Radius extension Pictures show new machine
