The machine is offered ex-works.
MASTER-BEVEL is a machine with numerical control that allows the following machining operations: - Beveling (straight and/or curved) of the plate edge - Grinding (straight and/or curved) of the plate edge - Cutting with diamond wheel (straight only) - Cutting with knurl (straight and/or curved) - Writing on the plate surface - Writing on the plate edge.
TECHNICAL DETAILS
travels X / Y / Z: 3.430 / 2.310 / 180 mm
A-axis: +/- 15 mm
B axis: +/-15 mm
feed rate X ...
pressure:120 t
table length:600 mm
table width:600 mm
stroke max.:400 mm
dimensions:1070 x 2340 x 2800 mm
weight:4,2 t
pre-running speed:10 mm/sec
Nvf8p
:26 mm/sec
:200 l
Oil cooling (electric):1,5 kW (max)
table height:875 mm
Working height from to:500 mm
diameter of piston:230 mm
total power requirement:15 kW
pump capacity:24 Lt./sec
Pressure power:300 bar
:76 mm
:650 mm
capacity of ejector in table:20 t
:150 mm
Recommended oil:46er
THIRD FIRING COMPLETE PLANT
Screen printing decoration line ,4-colors, max size 60x70 cm, including:
N. 1 tile transport line 50 mt. long, 60 cm. large
N. 1 tile feeder 3 mt. long
N. 1 brush and vertical fan
N. 1 floor washing machine by wet system
N. 1horizontal fast dryers mod. BURNS 1/45. max 250°
N. 4 printing machines mod. STUDIO1 srl. for maximum size 60x75cm.
N. 3 vertical dryers mod. EVR 70/60/B with automatic temperature control, max 110°
N. 1 general electric panel board complete of c...
1. List of works on restoration of the furnace
New set of the heaters
New set of the thermocouple
Siemens control system.
New convection system for low-e glass heating
New set of Vesuvius ceramic rollers.
Replacement of all bearings and revision of conveyors
Restoration of rubber coating on shafts and replacement of Kevlar rope
2ly2coht
Revision of the tempering blowers.
2. Control system:
The main advantages of our control system:
- Improved planar characteristics of tempered glass, due ...
GranitoGrav photoengraving system for granite/gravestones and glass (also suitable for glasses and bottles)
The CNC photo engraving unit in glass and stone.
The CNC milling machine series High-Z/S-400T with CNC GranitoGrav module includes the software for an incredible price.
Whether on memorial plaques, tombstones, tile, mirror glass, glass...
Just simply load your black and white or colour photography into the specially developed module of the ConstruCAM-3D software, then only enter the siz...
Data:
- Type: GTG-A
Civsoix2g2
- Dimension:
o Length: 1300 mm
o Width: 800 mm
o Height: 900 mm
- Lay-on Height: 700 mm
- Lay-on Length: 1300 mm
- Own weight: 65 kg
- Carrying capacity: 1500 kg
- 40 pcs available
Price on request
Lamination oven for EVA, switchable and decorative panels fabrication
Size: 1600x2400mm/ 2000x3000mm/ 2000x4200mm
Bfmp7oc8
Control system Siemens with touchscreen panel
Make : SFDD
Type : 13 Pos and 180mm Pads
Ivr30a2aw
Year : 1997
Condition : Clean - good working - as it is
Serial Nr : 70
Description : Total outside dimensions: L4650 x W3230 x H2230mm
Catalog No. : 5636
Type: LPB-7320
Producer: Tema
Made in: 2001
Characteristic:
Service system: PLC
Maximum glass dimensions: 1
7 x 3
0 m
Consumption of compressed air: 150l/min
Space inside the furnace: 500 mm
Total power: 21 kW
27aet7on
Power supply: 380 V/60
NorthGlass
4 – 19 mm, 2000 x 3600 mm, Left – Right
Glass tempering furnace
Year: 2008
Connection value: 700 kW
Iux7kqkrq
With upper convection
Noise reduction cabin included
In very good working condition.
Annual technical inspections were performed each year.
Available: December 2023
Make : SFDD
Type : 14 Pos and 200mm pads
Year : 1999
Condition : Clean - Good working - As it is
Description : Total outside dimensions: L5300 x W3230 x H2230mm
Rd33h
Multiwire cutter by Keller with slug cutter, chamfering, with lath lifting and transportation of laths with bricks to the elevator, but cutter, lath 2,5m
Eeauiptzq
The FZM9325D Glass Folding Straight Line Grinder is equipped with 9 spindles. The front spindles move synchronously with the front beam when processing glass of different thicknesses. It is characterized by a very strong and stable structure (frame made of cast iron). This model has an LED display. The machine has no pneumatic system (except for the last disc).
🤑 For each ordered machine, we add a WHOLE SET of 9 discs for FREE!
Fpkpa0bj
Dial configuration:
✅ 5 pcs grinding wheel, 3 pcs polishi...
CMS EASYLNE 2040 is a water jet cutting system high-performance, versatile, easy to use - either pure water or abrasive waterjet cutting – which can be used for a wide variety of applications for the most diverse production demands in different application fields, delivering highly accurate cuts even in 3D.
AXES' MOTION
X (4000 mm): longitudinal motion – back and forward
Y (2000 mm): The cutting head cross motion – left and right
Revgl
Z (220 mm 3 axis head – 150 mm 5 axis head): vertical mo...
Straight line edgingmachine for glass, Delta MTL 8.
One of the spindles for bevel edge grinding has been disconnected as the motor on this is defective.
The machine needs minor adjustments to be optimal
Ce20gxrs
The dimensions of the machine are:
Length: 6500mm
Height: 2300mm
Depth: 1000mm
Weight: 2600 kg.
Weight load: 130kg
Can polish from 3-24mm glass, min. str. 40x40mm.
Shipping must be paid for by the buyer.
The latest generation product of Singip Intelligent Equipment Co., Ltd. - glass edging machine, model SZM-10SP.
SZM-10SP model has many functions, such as:
- intelligent learning function,
- real-time polishing function,
- polishing distance compensation function,
- tool change reminder,
-automatic tool alignment,
-One button activation.
Compared to traditional equipment, the SZM-10SP model has a much friendlier working environment. Solutions such as:
-LED lamps in the spindle section and in ...
CNC glass working center, 4 axis PRATICA PLUS 4000
Year of production: 2017
Maximum processable glass size: 4095 x 2320 mm
Electrospindle: 9,2 kW
Automatic tool storage with 16 positions
Dpmypwn
Types of processes:
- grinding/edging,
- polishing,
- milling,
- drilling/countersinking (two-sided available),
- writing/drawing,
- engraving (with C axis).
Tools and accessories included
Only ~2000 spindle working hours
Good working order
Excellent condition, as new
Immediate availability
The glass grinder is equipped with 9 spindles.
It features a very strong and stable construction
Spindles: 9pcs
Soephlgf
Glass thickness processing: 3-25mm
Angle of inclination: 45°
Minimum glass size: 80mm×80mm
Processing speed: 0.5 ~ 4.5 m/min
Dimension: 7000×1400×2500mm
5 spindles for straight edge
2 spindles per side forward and backward for chamfering
CNC glass working center, 3 axis BOTTERO PRATICA GLP
Year of production: 2015
Maximum processable glass size: 3150 x 1415 mm
Electrospindle: 9,2 kW
Automatic tool storage with 16 positions
Types of processes:
- grinding,
- polishing,
- milling,
- drilling/countersinking,
- writing/drawing.
Tools and accessories included
Ces3emce
Only ~400 spindle working hours
Good working order
Excellent condition, as new
Immediate availability
Total length: 10800mm
Inlet length: 4000mm
Cidbahnd9t
Length of washing system: 3500mm
Length spout: 3300mm
Working direction: left to right
8 washing brushes
Washing height: 2m
The body of the washing machine is made of stainless steel
Sanding equipment Ertl, year of man. 2005, with Fanuc robotic machine, cap. 7000 p/h, made in Germany, used.
We have also sanding equipment by Lingl for tunnel kiln cars 4,5-4,7 m.
Videessy8
Automatic vertical glass arrising line with washing machine LISEC KSL-25HV + KSR-25 + VHW-25/V8
Year of production: 2002 - 2005
Cidfgk8hvv
Very fast and efficient line (KSL for rectangular shapes while KSR for oval shaped glass processing)
Maximum glass height: 2500 mm
Working direction: from left to right
Line consists of:
- Inlet conveyors (3 pcs.),
- Vertical rectangular glass arrising machine KSL-25HV (2002),
- Outlet conveyor,
- Inlet conveyors (2 pcs.),
- Vertical shaped glass arrising mac...
Vertical straight line edging machine BAVELLONI GEMY 6
Year of production: 2002
Cup wheels - flat edge with arris
6 spindles
Maximum glass thickness 35 mm
Rddef
Very good condition
Availability immediate
Automatic vertical glass arrising machine BYSTRONIC first'arris 27
Year of production: 2005
Cusovlt
Maximum working height: 2700 mm
Working direction: from right to left
Minimum glass size: 190 x 370 mm
Glass thickness: 3 - 15 mm
Good condition
Working order
Availability immediate
Automatic spacer bar bending machine BYSTRONIC RB NTB AL/S
Year of production: 2005
Cbqralp0
Possible to bend shapes
Possible to bent aluminum, steel and plastic spacer bars
Videojet printer included
Good working order, tested
Very good and clean condition
Availability immediate
In-line shape glass cutting table with low-e grinding LISEC GFB-70/33RE
Year of production: 2010
Maximum glass size: 7000 x 3300 mm
Low-e deletion
Glass transportation by belts
In very good and clean condition
Gzly9o
Availability immediate
Shape glass cutting table LISEC BSK-37/26
Year of production: 2008
Maximum glass size: 3700 x 2600 mm
3 in 1 - with tilting, cutting and breaking
Good working order
Jyxd8y
In very good and clean condition
Availability immediate
Automatic butyl extrusion and desiccant filling station LISEC LBH-25ARS + A2RL-25/25R
Year of production: 1998
Consists of:
Ch832jalmf
- automatic butyl extruder LISEC LBH-25ARS,
- automatic desiccant filler LISEC A2RL-25/25R.
Frame trolley for desiccant filler included
Good condition and good working order
Availability immediate
