Used Folding machines (motor-driven) over 4000mm for sale
3
6400x1,5 mm, 2,0 mm Alu, 1,25 mm VA, with hydr. motor shear, CNC controlled backgauge, 2 foot switches, control on swivel arm, bending without turning and reversing
Note:
Machine is currently still in the revision, the images were created before the revision.
Machine will be repaired, checked, cleaned and then fully functional by a specialist. Test run will be performed.
Dzkode
with backgauge
color: grey/blue
space requirement: 8500 x 2500 x 1950 mm
insertion depth: 1250 mm
machine weight: 73...
6
plate width: 6050 mm
plate thickness: 1,5 mm
distance between columns: 6114 mm
knife length: 6000 mm
stroke adjustment: Oberwange 250 mm
table height over floor: 750 mm
8c2m72v77
bending angle max.: 180 °
total power requirement: 4,2 kW
weight of the machine ca.: ca. 2,5 t
dimension machine xH: 7,2 x 0,9 x 1,52 m
transport measurements machine: L: 7,3 x B: 0,9 x H: 1,53 m
- program up to 8 working processes (8-step switch mechanism)
- adjustability of the bending cheek 100mm
- material clamping...
6
Thalmann long folding machine 8200 x 1.50 mm sheet steel/ 2.0 mm aluminum / 1.0 mm stainless steel
electric shear
controlled depth stop insertion depth 1250 mm
short length stop
machine is in perfect condition
available from September 2022
Pmof7tzl
incl. crane loading
Machine can be inspected on request
pressure 1,6 t
table length 5000 mm
table width 900 mm
Control Siemens
weight of the machine ca. 7,5 t
required space 5x2x2 m
CNC stretch bending machine
Control: Siemens
Bl7bxfmk
Year of construction: 2010
Table LxWxH: 5000x900x700 mm
Tower LxWxH: 1700x420x1700
Technical specifications
C-axis of rotation: 2 pieces
Max travels: -30 degrees / +90 degrees
Max. Torque: 8000Nm
Drive: servo motor
Interpolation: Simultaneously with other CNC axes
X-axis: 2 pieces
Max. Travel speed: 6 m / min
Ma...
15
- Control: RAS Reinhard Multibend 8000
specification:
- Bending length: 4060 mm
- Max. sheet thickness at 400 N/mm2: 3 mm
- Smallest permissible bending radius: 1.25 x sheet thickness
- Smallest permissible inner rim height: approx. 6 x sheet thickness
- Max. Opening width of the upper beam: 400 mm
- Adjustment range of bending and lower beam: 80 mm
- Bending angle: 0 - 180 °
- Max. bending speed Bending speed: 70 °/sec
- max. Upper beam speed UP: 44 mm/sec
- Max. upper beam speed Upper beam spe...
5
sheet width:6060 mm
plate thickness:2 mm
total power requirement:7,5 kW
weight of the machine ca.:6,75 t
Lr9bxqun
dimensions of the machine ca.:7,0x2,0x2,5(LxBxH) m
3
8020x3.0 mm, 4.0 mm aluminum, with hydraulic roller shear CNC controlled backgauge, foot switch, 11 stands
color: grey/blue
space requirement: 9500 x 2200 x 1900
insertion depth: 1165 mm
machine weight: 9200 kg
engine power: 15 kW
with roller shear
number of stands: 11 pieces
opening width: 150 mm
Cbvhtmsiwv
bending angle: 145 degrees
Note:
Machine is still under revision at present, the pictures were made before revision.
Machine will be repaired, checked, cleaned and then fully functional b...
6
The bending machine taken to the next level. The Biegemaster BendTron is the first generation to be driven completely by electric motors. The BendTron enables you to bend all common profiles with a bending length ranging from 4 to 15 metres with material thicknesses of up to 1.5mm (steel) with the accustomed reliability and precision.
BIEGEMASTER long folding machine – BENDTRON 4.1,50
Working length : 4010 mm
Bending capacity
steel 400 N/mm² : 1,50 mm
stainless steel 600 N/mm² : 1,25 m...
4
hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl.
hydraulically dynamic camber, touchscreen,
pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam
Djmfszj
-images similar-
5
Hydr. swing bending machine make JORNS Norma-Line-125-SH-OP/2-8
Machine. # 9778-01 Year of construction 1997
Technical data:
Bending length 8000 mm
Fcmhz302
insertion depth 1000 mm
max. sheet thickness steel 1,25 mm
max. sheet thickness aluminum 2 mm
max. sheet thickness VA 0,80 mm
max. operating pressure 140 bar
stroke of the upper beam 200 mm
number of bending cylinders 4
drive power 4,0 kW
dimensions 8500 x 1300 x 1800 mm
weight approx. 4,9 t
with
- OP 2100-axis control (9 memory locations)
-...
9
Jorns super-Line 2001 CNC pressbrake.
Machine software updated to CBC 50 with new screen, encoders etc by Jorns in 2018.
Folding length 8m long
Max sheet thickness 2mm
Electric backgauge, range 1000mm
CNC Foot control,
Engine power 7.5kW
Electric connection 400V
Manual available
B2pwfxgudp
Dimensions 9m long x 1.9m wide x 1.9m high
Weight 6500kg
Equipped with slitting shears, capacity 3mm.
1
bending length 6.000 mm
max. sheet thickness steel 1,00 mm
max. thickness ALU 1,5 mm
B8b7t3xcfe
incl. cutting device
4
8020x1,5 mm , 2,0 mm Alu, with electric roller shear, with running cable box,
bending angle to adjust, sheet thickness adjustment manual
Machine has been checked by expert and is functional. Machine in age-related
condition. The machine is sold in existing condition.
Qk97x
without backgauge
throat: 1000 mm
color: green
total power requirement: 16 A
space requirement approx.: 1800 x 9500 mm
machine weight: 4500 kg
upper beam stroke: 200 mm
roller shear: yes/electric
number of uprights: 7 pieces
b...
5
BIEGEMASTER Up- and Down- Bending machine – model XBend 6.2,00
Working length : 6400 mm
Bending capacity
steel 400 N/mm² : 2,00 mm
stainless steel 600 N/mm² : 1,50 mm
alu 190 N/mm² : 3,00 mm
Stands + Tension Arms : 7 pcs.
Driven linkage joints upper beam : 7 pcs.
Driven linkage joints down beam : 7 pcs.
Incl. Cranked bending beam for making small Z-, U- and hat-profiles
Incl. BMS Multi-Touch-Steuerung and automatic back-gauge
Incl. electric cutter
Incl. taper back-gauge
Ytnld0
In...
4
hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl.
hydraulically dynamic camber, touchscreen,
pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam
-images similar-
Bwmzmokoei
Hydraulic swivel bending machine
Fab. Premel Typ. Bima 6000 x 2,00
Very good condition, year 2009
Technical details
Make: Premel
Type: Bima 6000 x 2,00mm
Year of manufacture: 2009
Useful length: 6020 mm
Power: 2 mm
stroke upper beam: 180 mm
engine power: 5,5 kW
Weight: approx. 6 t
Equipment:
- Touch screen control Premel/Sigmatek
- CNC controlled backgauge
- Upper beam adjustment
- Electro-hydraulic cutting device up to 2,0 mm
- Sheet thickness adjustment
All data without guarantee.
The machine ...
Computer control of sheet metal bending
Length: 8000mm
Width: 1300mm
Memory: over 1000 set angles
Space requirements: (1900 x 1650 x 8800)
Metal sheet bending thickness: 0.7mm
Bending angle: 136°
Iwhdy37
Machine weight: 3t
Power requirements: 3kw/16A
Motor power: 2,2 kW
Opening width: 105mm
Insertion depth: 1250mm
Motor-driven scissors
Designed for fast work with tasters & angle device. Security system by e-stop & cable. Footswitch for 2 operators.
If you have any more questions, please contac...
3
Long folding hydraulic machine (HKS 4m Easy) with manual cutting system.
Working length: 4.000 mm
Machine length: 4.900 mm
Sheet metal thickness: 1,25mm (Al), 1,00 mm (Steel)
B8jdje0sxy
Stand number: 4
Machine weight: 2.000 kg
2
6020x1.0 mm, 1.5 mm ALu, 0.6 mm VA, with hand roller shear, foot switch, one-angle control,
Cacrwusu3p
Machine will be repaired, inspected, cleaned by a specialist and will be fully functional. Test run will be performed.
without backgauge
throat: 1000 mm
color: blue
total power requirement: 16 A
space requirement: 6800 x 1600 x 1700 mm
insertion depth: 1000 mm
machine weight: 2600 kg
with hand roll shear
number of stands: 4 pieces
opening width: 200 mm
bending angle: 145 degrees
4
Working length : 6200 mm
Bending capacity
steel 400 N/mm² : 1,50 mm
stainless steel 600 N/mm² : 1,25 mm
alu 190 N/mm² : 2,00 mm
Stands + Tension Arms : 7 pcs.
Driven linkage joints : 7 pcs.
Insertion depth : 1130 mm
incl. BMS-Multi-Touch Control
incl. electric cutter
O8dpf
Directly from the manufacturer.
Made in Germay
9
The revolutionary and patented bending system enables unprecedented freedom of bending. Bends of up to 300 ° (150 ° “up and down”) are standard for the EVOBEND, which is a problem with other long folding machines.
= OUR PATENTED BENDING PRINCIPLE =
Almost scratch-free bending of the EVOBEND provides the aesthetic added value. So far, the bending beams have folded the sheets by means of pivoting movements. However, this movement caused permanent damage to the sheet metal profiles. The “rubbing” ...
9
Motorized swivel bending machine
Fab. HERA Typ. UM 3
year 1983
Technical Data
Make: HERA
Type: UM 3
year of construction: 1983
sheet width: 4000 mm
sheet thickness: 3 mm
stroke upper beam: 350 mm
Opening lower beam: 125 mm
dimensions: approx. L 5,00 x W 1,50 x H 1,70
Weight: approx. 5 t
Equipment
Bzxyojrwse
- Bending angle adjustment via POTI
- Divided cutting foot, height 80 mm
- Bending rail 20 mm
- 2 rear support arms with T-slots, laterally adjustable
All data without guarantee.
The machine ...
Type: CNC
Length: 8000mm
Width: 1300mm
Space requirements: (1900 x 1650 x 8800)
Metal sheet bending thickness: 0.7mm
Bending angle: 136°
Machine weight: 3t
Dxykda
Power requirements: 3kw/16A
Motor power: 2,2 kW
Opening width: 105mm
Insertion depth: 1250mm
If you want to see more pictures of the machine, please contact us.
The machine can be manufactured by your requirements, from 3 to 8 meters.
Long folding machine (HKS-E 6m Easy) with automatic cutting system, 5 inch Touch screen and easy programming software with 90 programms stoarage capacity.
Working length: 6.100 mm
Machine length: 7.000 mm
Sheet metal thickness: 1,0mm (Al), 0,80 mm (Stahl)
Stand number: 5
Machine weight: 2.500 kg
Jvcitm
1
Single program control, emergency off rail, motorized roller shear, single angle adjustment,
Machine will be repaired, checked, cleaned by specialist and then fully functional. Test run will be carried out.
Sheet width: 6020 mm
sheet thickness steel: 1,25 mm
sheet thickness aluminum: 2,00 mm
sheet thickness VA: 0,80 mm
without backgauge
throat: 1000 mm
Qcmyd
color: green
total power requirement: 16 A
space requirement: 7500 x 1800 x 1800 mm
machine weight: 2500 kg
with roller shear
number of sta...
12
NO ENGINE NOISE AT IDLE SPEED
bending length 8200 mm
bending depth 1500 mm
Ns7b9
bending capacity 2 mm
autom. depth stop: 8 - 1500 mm
max. opening width of the upper beam: 200 mm
adjustment range of the upper beam: 6 mm
bending angle 0-140
weight: approx.7000 kg
Control: Duscher Controlling
machine outside dimensions: 9350 x 2300 x 1950 mm
11
The revolutionary and patented bending system enables bending freedom never seen before. Bends up to 300° (150° “up and down”), which are a problem with other long-folding machines, are considered standard on the EVOBEND.
= OUR PATENTED BENDING PRINCIPLE =
Almost scratch-free bending of EVOBEND provides the aesthetic surplus value. Until now, the bending beams have bent the sheets by means of swivel movements. However, this movement has permanently damaged the sheet metal profiles. The “rubbing...
Long folding machine (HKS-CNC 6m Profi) with automatic cutting system, back-gauge system, graphical Programing system (Pathfinder).
Working length: 6.100 mm
Machine length: 7.000 mm
Sheet metal thickness: 1,5mm (Al), 1,25 mm (Stahl)
Stand number: 6
Machine weight: 4.000 kg
Gvu7o8
2
6200x1.5 mm, 2.0 mm aluminium, 1.0 mm VA, with manual stop and 6-fold angle preselection, with foot pedal, emergency stop rail, 7234 operating hours
Machine is repaired, checked and cleaned by a specialist and is then fully functional. Test run is carried out.
backgauge: 1000 mm
Throat: 1000 mm
Colour: blue
Total power consumption: 32 A
Billbqvxre
Machine weight: 4000 kg
with roller shears
Number of stands: 4
Bending angle: 145 degrees
11
The revolutionary and patented bending system enables bending freedom never seen before. Bends up to 300° (150° “up and down”), which are a problem with other long-folding machines, are considered standard on the EVOBEND.
Gmrdwwlry
= OUR PATENTED BENDING PRINCIPLE =
Almost scratch-free bending of EVOBEND provides the aesthetic surplus value. Until now, the bending beams have bent the sheets by means of swivel movements. However, this movement has permanently damaged the sheet metal profiles. Th...
4
6200x1,5 mm, 2,0 mm Alu, 1,0 mm VA, with roller shear, with controlled backgauge, even closing by control shaft, upper cheek rail exchangeable, upper cheek rail rotatable, with large and small radius
Cu0leo3
Machine will be repaired, checked and cleaned by a specialist and is then fully functional. Test run will be carried out.
back gauge: 1000 mm
throat: 1000 mm
Colour: green
Total power requirement: 32 A
space requirement: 7400 x 1800 mm
machine weight: 4000 kg
upper cheek stroke approx: 200 m...
3
6200x2,00, 3,00 mm alu, 1,25 mm VA, solid and stable construction, with motorized roller shear, 5 wide upright units, with foot switch, emergency/off rail, backgauge motorized
throat: 1000 mm
color: blue
total power requirement: 400 V
upper beam stroke approx.: 200 mm
roller shear: hydr. motor roller shear
number of stands: 5 pieces
bending angle: 145 degree
weight: 5000 kg
Fwst297is
Machine is currently still in the process of overhaul, the pictures were taken before the overhaul. Machine will ...
- 8020x3.0 mm, 4.0 mm aluminum, 1.5 mm VA
- with motor stop
- crowning device
- NC control
- without roller shear
- backgauge: motorized
- throat: 1000 mm
- color: blue/yellow
- total power requirement: 12,5 kW
- space requirement: 9000 x 1500 mm
- insertion depth: 1000 mm
Dwq9wi
- machine weight approx.: 12 t
- number of stands: 10 pieces
- solid stable construction
The machine has been regularly maintained. The bearings of the bending arms were renewed
The machine is still being repaired, chec...
1
6400x1,5 mm, Alu 2,5 mm, VA 1,0 mm, with the following equipment:
- sheet metal cassettes horizontally and vertically adjustable
- upper beam with large freedom and water fold groove
- safety according to BG, with emergency stop/foot switch
- Touch screen with graphic control (CNC 800) mounted on swivel arm
- Motor stop system type 11
- 4 stop fingers (tilt-turn fingers)
- Hydro shear SL (1,5mm steel)
- RH hydr. radius adjustment
Machine will be repaired, checked and cleaned by a specialist and ...
2
with hand lever control and hand roller shear, 5-fold control
Machine will be repaired, checked, cleaned by specialist and then it will be fully functional. Test run will be done
sheet width: 6020 mm
sheet thickness steel: 1,2 mm
sheet thickness aluminum: 1,5 mm
B7pv8y88gw
Color: green
total power requirement: 1,5 kW
space requirement: 6600 x 1700 mm
insertion depth: 1000 mm
machine weight: 2000 kg
roller shear: manual
opening width: 200 mm
bending angle: 140 degrees
Delivery time: about 6 weeks
