Bed Type Milling Machine - Vertical

WAGNER WBE1300R

Condition: used, Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, rapid traverse X-axis: 35,600 m/min, rapid traverse Y-axis: 35,600 m/min, rapid traverse Z-axis: 35,600 m/min, workpiece diameter (max.): 127 mm, number of slots in tool magazine: 31, tool length: 330 mm, Haas VF-4SSHE – Vertical Machining Center The Haas VF-4SSHE is a high-performance vertical machining center, manufactured in 2007, equipped with Haas CNC control. Ideal for fast and precise machining, it offers generous work capacity and a compact structure. Main technical features: Axis travel: X = 1,270 mm, Y = 508 mm, Z = 635 mm Spindle: ISO-40, 12,000 rpm, 22.4 kW Spindle – table distance: 107 ÷ 742 mm Rapid traverse: 35,600 mm/min Feed rate during machining: 21,200 mm/min Table: Dimensions: 1,321 x 495 mm Load capacity: 800 kg Tool changer: Fodpfx Ajwt Ripoduegk Tool type: BT-40 Magazine capacity: 24 positions Max tool diameter (adjacent/free): Ø64 / Ø127 mm Max tool length: 330 mm Max tool weight: 5.4 kg Additional equipment: 4th axis – Haas rotary table Ø 310 mm High-pressure coolant pump through the spindle Tank with wash pump Spindle cooler Screw-type chip conveyor Manuals, electrical diagrams, and CE declaration Machine dimensions: L 4,100 mm × W 2,600 mm × H 2,690 mm – Weight: 6,250 kg

Condition: used, Year of construction: 2010, functionality: limited functionality, travel distance X-axis: 1,626 mm, travel distance Y-axis: 813 mm, travel distance Z-axis: 762 mm, nominal power (apparent): 22 kVA, controller manufacturer: Haas, controller model: MOCON 17.28, table width: 1,626 mm, table length: 710 mm, overall weight: 12,000 kg, spindle speed (max.): 7,500 rpm, number of spindles: 1, number of slots in tool magazine: 30, type of input current: three-phase, Equipment: chip conveyor, Vertical 3-axis machining center Haas VF6 / 50 HE Linear guideway machine with up to 610 Nm torque (at 500 rpm) Travel paths: X 1626 mm Y 813 mm Z 762 mm Linear position measurement system 2-speed gear spindle SK50 with 7,500 RPM and 22.4 kW Automatic tool changer with 30 +1 positions Internal coolant supply with 1000 psi (approx. 70 bar) Coolant tank 360 liters Spiral chip conveyor Includes: Oil mist extraction unit Ethernet interface RENISHAW wireless tool measurement system Fgedpfsw Rbx Uex Aduek Additional loading fixture for inserting tools into the machine Macro programming enabled. The machine is only partially functional.

Condition: good (used), Year of construction: 2002, travel distance X-axis: 1,050 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, 3-Axis Machining Center Manufacturer: Bridgeport Fsdpfxjw Nyfde Adusgk Model: VMC-1000 XP Year of manufacture: 10-2002 Control type: Heidenhain iTNC-530 Operating hours: n/a S/N: 82XXXX Technical Data: ----- - Travel X-Y-Z: 1,050 x 610 x 600 mm - Spindle: max. 8,000 rpm - Tool holder: SK40 - Tool magazine: 22 positions - Coolant system - Through-spindle coolant (IKZ) - Glass scales on all axes X-Y-Z - Central lubrication - Weight: approx. 4.2 t - Dimensions LxWxH: 3,000 x 2,350 x 2,400 mm Accessories: ----- - Manuals - Tool holder package Special features: ----- - Through-spindle coolant (IKZ) deactivated due to defective flow tube in spindle - Spindle replaced in 2023, few hours of operation, precise concentricity

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, nominal power (apparent): 25 kVA, controller model: Ultimax 4, table width: 1,220 mm, table length: 510 mm, spindle speed (min.): 80 rpm, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 24, mount diameter: 40 mm, Equipment: rotational speed infinitely variable, Hurco BMC 4020 CNC Milling Machine Ultimax 4 Control Travel X 1,020 mm, Y 510 mm, Z 610 mm Clamping Area 1,220 x 510 mm Tool Positions 24 x SK40 Spindle Speed 80-8,000 rpm Fgodpfx Aswa T Inedujk Coolant System Please contact us if you are interested.

Condition: ready for operation (used), Haas VF-5B/40HE vertical machining center, year 2006. Fodpfx Adow H R H Ieujgk

Condition: excellent (used), Year of construction: 2004, VERTICAL MACHINING CENTER FAMUP TRAVELS 1600x650x650 SPINDLE ISO 40 12,000 RPM Fsdpfovq Rznex Aduegk RANDOM TOOL CHANGE 30 POSITIONS HIGH PRESSURE THROUGH SPINDLE CHIP CONVEYOR SPINDLE COOLING FRIDGE CNC FANUC 18iMB REMOTE HANDWHEEL MACHINE WEIGHT 12,000 KG

Condition: excellent (used), Year of construction: 1997, Ultimax 3-4 control system with two color screens (text and graphics) Travel X/Y/Z: 1020/510/610 mm Speed: 8000 rpm Tool magazine for 24 tools, SK 40 Fgsdpfx Adowzy N Ijuok DCF software

Condition: used, Year of construction: 2003, Used machine Fedpfew I Ulcox Adujgk Year of manufacture 2003 New HSD milling spindle 2023 not yet in use New drilling gearbox 2020 Technical specifications: X-axis working area 3400 mm Y-axis working area 1300 mm Z-axis working area 130 mm Max. workpiece size 3000 x 1300 x 100 mm X-axis speed 25 m/min Y-axis speed 25 m/min Z-axis speed 20 m/min Milling spindle motor speed 0-24000 rpm Drill spindle motor speed 3400 rpm Milling spindle motor power 7 kW Drill spindle motor power Tool changer Interface 2.2 kW 5-way ISO-30 Brushless motor power X-axis 5.39 N/m Brushless motor power Y-axis 5.39 N/m Power Brushless motor Z-axis 2.39 N/m Number of drill spindles 15 Grooving saw diameter 120 mm Vacuum pump 100 m³/h Max. installed electrical power 15 kW Extraction hose connection diameter 120 mm Machine dimensions (L/W/H) 4500 x 2000 x 2500 mm Machine weight 2400 kg Location: Röllbach Availability: Upon request
