Horizontal and Vertical Rotary Table

VERTEX HV-4

Condition: good (used), Year of construction: 2002, functionality: fully functional, USED Soraluce Soramill Model SP 10000 Travelling Column, Table Type CNC Milling Centre, with Automatic Oil Mist Lubricated Orthogonal Milling Head with 1 X 1 Degree Indexing and HEIDENHAIN TNC 430 M Control System. Year 2002 SN 8647 Table Area - 10000 x 1100 mm Column Traverse (X) - 8500 mm Vertical Traverse (Y) - 1600 mm Ram Traverse (Z) - 1200 mm Spindle Motor - 28 kW Spindle Taper - Standard ISO 50 BT50 tooling Pullstud - DIN 6987 2-Form A. ISO 7388/2-Form A Independent Gearbox with 2 Ranges Speed Range - 20 to 4000 RPM Feed Range - 5 to 5000 mm/min Rapid traverse rate - (X, Y, Z) 15,000 mm/min Preloaded double nuts and recirculating ballscrews to each axis. Linear Guiding System with recirculating cylindrical rollers and steel guideway assemblies in X, Y and Z axes Independent A.C Drive motor to each axis. Linear Transducer in X, Y and Z-axes with air purge system. Automatic tool clamping. Automatic hydraulic tool releasing device. CNC Control HEIDENHAIN TNC-430-M. (Flat TFT screen with digital drives) 9 axes CNC and 1 spindle, 5 of them simultaneously interpolated. Working area lighting Electrical cabinet cooling system Electrical cabinet lighting Heidenhain HR410 portable electronic handwheel with 3m spiral cable Horizontally articulated pendant for CNC control Orthogonal head 28KW, 800Nm, 1deg x 1 deg, 4000rpm oil lubricated Price includes oil cooling unit for both head and gearbox. Option G2, Ram prepared for 4000rpm, is also included. Coolant through the spindle type AD. Coolant system with 500l capacity tank with two pumps providing low and high pressure of 3 and 8 bars and 50l/min flow. The system includes a combined paper and magnetic drum-filtering unit. Standard operators platform fixed to the column 40 tools capacity toolchanger magazine, BT50 Max. Tool length = 400 mm. Max. Tool diameter: - With full magazine = 120 mm. With adjacent position empty = 250 mm. Max. Tool weight = 20 kg. Dedjr Hr Aropfx Adujcr Mean tool weight with full magazine = 10 kg. Max. Permitted total weight = 20 kg. Swarf Conveyor Hinge type conveyor belt Machine preparation for the addition of a 4th axis electro-mechanical table. Splash Guarding against swarf at the table front and both sides. Consists of four sliding front doors with a height from the floor of 2.100mm and a length of 1.700mm each one. Manually operated opening and closing with mechanical interlock. The doors can be opened for the full longitudinal traverse. The rear of the table is open. Protection in the back and both lateral sides of the machine column.

Condition: good (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, rotational speed (max.): 5,000 rpm, table length: 4,000 mm, table width: 2,000 mm, Sachman PX 120 Travelling column milling and boring machine with: - X-axis travel 6000 mm - Y-axis travel 1200 mm - Z-axis travel 2000 mm - Heidenhain TNC 530 control unit - CNC rotary-translating table 2000 x 2000 mm Dcsdsv Acatjpfx Adujr - Stolle table 4000 x 2000 mm - KOSMO 3 automatic head 0.02° x 0.02° - 60-place tool magazine - chip conveyor - standard accessories Free extension in 12/24 months

Condition: used, Year of construction: 2025, faceplate diameter 2.500 mm swing diameter 3.000 mm turning height 2.000 mm Control Fanuc max. Torque 55.010 Nm cutting capacity max. 5.000 kgf max. workpiece weight 15.000 kg table: table diameter 2.500 mm table speeds 1,0 - 150 1/min power capacity - table 60/75 kW C - Axis: resolution 0,001 ° Working speed 0 - 900 °/min max. table speed 2,5 1/min turret slide: Shank diameter 50 mm spindle cone ISO 7/24 / No.50 Spindlespeed 15 - 1.500 min/-1 power capacity - Tool Spindle 22 / 26 kW max. Torque 280 Nm ram cross section 280 mm axis stroke: x-axis 1.700 mm Dsdpfx Aovp Sc Doduocr z-axis 1.600 mm cross rail adjustment 1.000 mm Tool-Presetter: tool taper MAS-BT 50 number of toolpositions 24 (12 + 12) pos. max. tool weight 70,0 kg draw bolt P50T-I feeds: rapid feed (X / Z) 10,0 m/min feed speeds max. 10.000 mm/min rapid traverse of the crossrail 300 mm/min total power requirement 200 kVA weight of the machine ca. 60,0 t dimensions of the machine ca. 11,00 x 9,00 x 8,50 m CNC - Vertical Turret Lathe HANKOOK - VTB 250 E - NEWMACHINE (related picture)

Condition: good (used), Year of construction: 2015, functionality: fully functional, workpiece weight (max.): 100,000 kg, turning diameter: 6,000 mm, rotational speed (max.): 25 rpm, spindle speed (min.): 25 rpm, travel distance Z-axis: 1,500 mm, Main Technical Features • Manufacturer: SCHIESS Model: 18’ VBM Chuck Diameter: 5,500 mm Maximum Turning Diameter: 6,000 mm (distance between columns) Maximum Workpiece Height: 4,400 mm Movable Crossrail: 3,000 mm travel RAM (Z-axis): 1,500 mm travel Maximum Weight on Chuck: 100 tons Rotation Speeds: Range I: 1-8 rpm; Range II: 5-25 rpm • CNC Control: FAGOR 8055 (2015) Machine Condition: In operation and dismantled SCHIESS 18’ VBM vertical lathe—a robust machine featuring the oversized capacities typical of its era. Manufactured in Germany and retrofitted in 2015, this lathe is ideal for machining large, heavy workpieces. It is suitable for a wide range of industries, including metallurgy, general machining workshops, mechanical component production, heavy structural fabrication, and energy generation. PRICE AND FURTHER INFORMATION ON REQUEST (CNC, SIEMENS, HAAS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORI SEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKES) Dsdpfx Adjxnyh Usuecr

Condition: new, Year of construction: 2025, turning height: 2,000 mm, workpiece weight (max.): 12,000 kg, faceplate diameter: 2,000 mm, CNC Vertical Turning Center Model: VTC-20/30 with Fanuc 31i-B Table diameter: Ø2,000 mm Maximum swing diameter: Ø3,000 mm Maximum turning height: 2,000 mm Table speed: max. 200 rpm Table load capacity: 12,000 kg Table indexing: 0.001° Z-Axis (vertical ram travel): 1,200 mm Main spindle speed: max. 15 ~ 2,000 rpm Ram size: 240 mm x 240 mm Milling spindle taper: ISO 50 Tool shank size: 40 mm x 40 mm Crossrail (vertical travel): 1,000 mm 250 x 4 stages (hydraulic) Rapid traverse X-axis: 10,000 mm/min Rapid traverse 7-axis: 10,000 mm/min Cutting feed rate: 1 ~ 3,000 mm/min Table drive motor: AC 45/55 kW (continuous / 30 min.) Milling spindle drive power ISO 50: 18.5/22 kW (continuous / 30 min.) Control: Fanuc 31i-B Display unit: 15-inch TFT-LCD Tape memory: 1 MB Automatic tool changer: 12 positions (for 5 turning tools + 1 cover + 6 milling tools) Standard tool holders: New 240 TCR-01 (2 pieces) Splash guard: Table version (R-type standard) External coolant system: 3 bar (80 liters/min.) Chip conveyor: hinge-type 4-jaw independent manual chuck Foundation anchor bolts / shims Maintenance tools and toolbox Hydraulic power unit Work area lighting Signal lamp: 3 colors (green, red, yellow) Operating manuals (English): NC 1 CD with Fanuc manuals and 2 books with mechanical/electrical instructions Power supply: 220 V, 60 Hz, 3 phase Machine color: manufacturer standard OPTIONAL ACCESSORIES (#1) Automatic tool changer ATC 24 positions - on request Automatic shutdown for N.C - on request Turning tool holder type 240TCR - on request Through-spindle coolant supply: 30 bar (pump pressure) - on request Transformer 415 V, 50 Hz, 3 phase - on request Linear scales X, Z-axis - on request Rigid tapping - on request Automatic tool changer ATC 24 positions - on request Other notes: INSTALLATION, COMMISSIONING, TRIAL OPERATION AND TRAINING - not included in the price INSURANCE AND FREIGHT - not included in the price Dodsxqb D Nopfx Aduecr Errors in the technical data excepted. The scope of accessories applies only as explicitly described in the article’s text. Any additionally pictured accessories, for example for illustration purposes, are not included in the offer. The general terms and conditions of JS-Werkzeugmaschinen GmbH apply.

Condition: ready for operation (used), Year of construction: 2008, CNC Tilting Rotary Table TSUDAKOMA TTNC-1500 YEAR2008 Djdpfx Adsv E Dchjuocr T:dia1,500mm Max work weight:2,500kg Tilt range:-5to+95degree Rotary axis:TRC3-SR30 Tilt axis:TRC3-SR30

Condition: good (used), Year 1998 Grinding machine for machining centric or eccentric bearing diameters (also cones) of crankshafts or shaft-like components Control Fanuc Panel i Dcsdpfxst Uufbo Adusr Version with 2 grinding spindles on one tool carrier Use of CBN grinding wheels (nominal Ø400 + Ø450mm - Junker standard bore ring Ø127) with machining with oil Clamping with one-sided chuck and tailstock as counterholder - Grinding range ~500mm Automatic loading hatch from above with loader interface The machine is currently still in series production and can be inspected under power Components can be retrofitted after consultation for an additional charge with documentation of change parts and tools Fuse for control system and drives included - free location Availability after consultation, warranty excluded Year of Production:1998 Grinding machine for producing of centrical or excentrical Journal diameters (as well as cones) on crankshaft and other shaft components Machine Control Fanuc Panel i Machine set-up with 2 spindles on 1 tool console Usage of CBN Grinding wheels (nomnial Ø400+Ø450mm - Junkernormbohrungsring Ø127) with Oil as coolant set-up with jaws on drive side and centers as tailstock - grinding length ~500mm automatic Gantry door for overhead loading and corresponding interface Machines are actually in serial production and can be inspected upon request front glass of Monitor damaged, screen itslef seems unharmed on first glance safeguarding of control and drives included - free location availability on agreement, no warranty possible
