Hydraulic table press

Norton

Year of construction: 2004, condition: reconditioned (used), Stock-No. 2054 1used, partly overhauled and functionally tested Single-screw extruder AlphaTec A-ES 75.28 Screw –Ø 75 mm- 28 LD main drive 75 kW- AC Screw speed up to 80 r.p.m. - adjustable 1x venting port with vacuum-pump cylinder barrel heating apporx. 30 kW installed 3x addituional temperature controller for down-stream equipment Iaodoiyx Uzopfx Ad Nsl Control board overhauled You´re welcome for inspection visit in our stock Wuppertal-Germany More extruders available

Year of construction: 2018, condition: good (used), functionality: fully functional, machine/vehicle number: H3000TM, Universal testing machine H3000TM Made in Germany Crosshead stroke: 520 mm Working area depth: 66 mm Iedet Rg H Ajpfx Ad Neal Total height: 1010 mm Weight: 45 kg Test speed: 1 to 500 mm / min Return speed: 500 mm / min Travel resolution: 0.01 mm We have a very large selection of clamping fixtures - screw clamping fixtures - wedge clamping fixtures - pneumatic and hydraulic clamping fixtures. Pressure plates-bending fixtures-friction fixtures and much more. Strain gauges-extensometers-long displacement transducers-clamp-on transducers-clamping chambers. Force transducers optionally 50N-100N- 200N- 500N- 1000N- 2000N- or 3000N incl. Hess software Windows 8-9-10 or 11 for universal test sequences, simple tests even without a PC and a 5KN SP 56g screw clamp with pyramid or rubber jaws 30x50 mm Factory calibration certificate with DAkkS calibrated measuring equipment. In tension and compression direction in 10 steps. The universal testing machine of the H3000TM series is a single-spindle machine, a robust construction made of aluminum and V2a with ball screws, ball bushing guides and toothed belt drive. The bellows cover protects the spindle and guides. The testing machine is microprocessor-controlled and has a membrane keypad. The force and travel are shown on the 2-line LCD display. The testing machine can be used as a standalone unit or with a PC via a USB interface. The displacement is measured using an encoder with 0.01 mm visible resolution on the LCD (internal 0.0001mm). The machine is manufactured with a standard load cell: 0.03% linearity and the corresponding calibration. Optionally it is possible to add a second channel for a second load cell or a displacement transducer. The universal testing machine is manufactured with two different travel ranges, 500 mm or 1200 mm (with load cell without test tool). Additional scope of delivery: A load cell of your choice 50N-100N-200N-500N-1000N-2000N or 3000N, certificate 220 volt cable, USB cable, description, CE declaration of conformity. Load cell 3000N Measuring range:1-3000N tension and compression, with nom. 2mV/V Output signal, overload protection: +/- 100%, linearity: +/- 0.05%, hysteresis: +/- 0.03%, reproducibility: +/- 0.02%, with, incl. 1.5m connection cable incl. calibration certificate

Year of construction: 2004, condition: reconditioned (used), Stock-No. 2054 1used, partly overhauled and functionally tested Single-screw extruder AlphaTec A-ES 75.28 Screw –Ø 75 mm- 28 LD main drive 75 kW- AC Screw speed up to 80 r.p.m. - adjustable 1x venting port with vacuum-pump cylinder barrel heating apporx. 30 kW installed 3x additional temperature controller for down-stream equipment Iaodpfx Adeiyya Ao Nol Control board overhauled You´re welcome for inspection visit in our stock Wuppertal-Germany More extruders available

Condition: good (used), Year of construction: 1998, Press Force 315.00 t Stroke 500 mm Throat 425 mm Installation Height (Upward Stroke) 1,000 mm Iedpfx Aev Rwu Uod Neal Table Surface 1,200 x 815 mm Table Height above Floor 800 mm Ram Surface 1,100 x 700 mm Speed Down 48 mm/s Speed Up 330 mm/s Working Speed 19 mm/s Oil Volume 1,600 l Power Requirement 82.0 kW Weight 23.00 t Dimensions (WxDxH) 2.4 x 2.8 x 4.0 m For Permitted for manual loading according to the CE standard with oil-hydraulic drive, controllable depending on pressure/time and travel, light-guard at the front (Sick), two-hand operation permitted for manual loading according to the CE standard with oil-hydraulic drive, controllable depending on pressure/time and travel, light-guard at the front (Sick), two-hand operation

Condition: good (used), Year of construction: 1989, Power: 1.000 kN Size of bolster: 800 x 750 mm Distance betw. columns: 900mm Size of ram: 800 x 600mm Daylight: max. 800 mm Stroke: 480 mm Speed: Fast down: 300 mm/s Working: 30 mm/s Fast up: 300 mm/s Electric power total: app. 31 kW Weight: app. 13.000 kg Size of footprint: app. 1,6 x 2,90 x 3,8m (T x B x H) • die cushion, activ, 400kN, stroke 200mm • allowed for 2-hand working • equipped by oil - air chiller Iodjd E U Nnjpfx Ad Neal • ram guiding by 4 pc. hard chromed Guiding columns

Condition: used, Year of construction: 1971, pressure 200 t passage width NA mm stroke 180 mm table length 690 mm table width 530 mm distance between columns 420 mm total power requirement 18 kW weight of the machine ca. t dimensions of the machine ca. m Iaodpfst Hw Dwex Ad Nol Hydr. 4-Pillar Press for Embossing/Calibration

Condition: refurbished (used), Year of construction: 2024, machine/vehicle number: 2260, installation height: 280 mm, pressing force: 25 t, table width: 580 mm, table length: 320 mm, stroke length: 100 mm, Schoen hydraulic double column press Year of manufacture 1978/2024 Machine is/will be generally overhauled - new control - New light barrier - Revision of the hydraulics Pressing force: 250 kN Isdpst Dzy Rsfx Ad Neal Installation height: 280 mm stroke: 100 mm Table width: 580 mm Table depth: 320 mm

Year of construction: 1997, condition: used, Technical details: pressure: 250 t stroke: ca. 400 mm pass through width: 640 mm table above floor: 900 mm ram stroke speed: regulierbar/adjustable passage between the side columns: 470 mm Isdpsu Nfn Rjfx Ad Neal table clamping surface LxW: 570x550 mm clamping area of ram: 570x550 mm total power requirement: 56 kW weight of the machine ca.: ca. 9,0 t dimension machine xH: 2,5x1,8x3,8 m transport dimensions LxWxH: 2,6x1,8x3,1 m - control manual and via automatic via SPS Allen Bradley - one hand and two hand control - ram guidance column, zero backlash - set up mode and automatic mode via SPS controlled - light curtain type "Sick" and safety curtains installed - no CE certification available i.D. *

Condition: used, Year of construction: 1982, Technical details: pressure: 16 t stroke: 250 mm throat: 270 mm dayligth: ca. 400 mm table surface area: 800 x 500 mm boring diameter: Ø 50 mm Iajdpfxou Nfmys Ad Njl ram surface area: 220 x 360 mm mortise hole in ram: Ø 40 mm table height over floor: 970 mm voltage: 380 / 50 Hz V control voltage: 220 V / 50 Hz total power requirement: 3,0 kW weight of the machine ca.: 2,3 t dimension machine xH: 1,8 x 1,5 x 2,72 m Press frame in robust welded construction. Adjustment of the operating mode via switch: inching, two-hand, foot or continuous operation with feed Press has a piece counter on the side with overload protection (pressure relief valve) with cutting shock damping Light curtain SICK optical electronics (can be repaired optionally) *

Condition: refurbished (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4290, total height: 2,750 mm, installation height: 500 mm, pressing force: 30 t, table width: 440 mm, table length: 320 mm, stroke length: 300 mm, overhauled Schoen double column press year 1997/2024 Pressing force 300 kN Installation height 500 mm stroke: 300 mm Isdpfx Aou Hyx Sod Nsal Table: W x D 440 x 320 mm Machine will be overhauled: - new control - new light barrier - revision of the hydraulics
