Victory 33500/400 Tech

ENGEL

Condition: used, Year of construction: 2024, MACHINE PROFILE: 3,800 kN (420 US tons) IMM ===== Machine ID: • Injection Unit: 265 • Clamping Unit: 380 • Weight: 21,300 kg Clamping Unit Specifications: • Force: 3800 kN (388 tons / 420 US tons) • Tie-bar Spacing: 830x830 mm • Platen Size: 1190x1190 mm • Stroke (Open/Eject): 700 / 210 mm • Ejector Force: 90 kN • Mold Height (Min/Max): 300 / 750 mm (+800 option) • Max Mold Weight: 3.8 tons • Dry Cycle: 2.3s / 500mm Injection Unit Specifications (By Screw: 25 / 30 / 35 mm): • L/D Ratio: 24 / 24 / 20 • Capacity: 74 / 106 / 144 cm³ Gsdpozzv Tgsfx Aglskd • Rate: 98 / 141 / 192 cm³/s • Recovery Rate: 10 / 15 / 22 g/s • Pressure: 2700 / 2700 / 2000 bar • Stroke / Speed: 150 mm / 420 rpm • Nozzle (Stroke/Force): 305 mm / 40 kN • Heating Capacity: 9.2 kW

Condition: excellent (used), Year of construction: 2006, operating hours: 69,000 h, functionality: fully functional, machine/vehicle number: 163769, Here we offer a permanent maintained injection molding machine. from the following machine we have other machines of the same type and same year in stock also with Geiger Robot Manufacturer Engel Type Victory 200/80 Tech year of construction: 2006 Control system: CC 200 Extras -installed Languages: German Englisch -25 mm (wear and corrosion protected) - control CC200 - enlarged clamping plates (B plates) - minimum installation height 250 mm - maximum platen distance 700 mm - quality switch / PD protocol + graphics - 5 x CEE 400 V / 3 x Schuko 230 V Gkjdpfx Aom Nclvsgljd - 4 freely programmable inputs and outputs - handling interface Euromap 12 - Host computer interface Engel EMS - Geiger EA Mini 2001 SLI (#156686 0504 4417 / year 2005) - without material hopper or conveyor Clamping unit clamping force: 80 to./ 800 kN tie bar dimension: tie bar-less clamping platens: 730 x 600 (hxv) platen distance: 700 mm max installation height: 250 mm min. opening stroke: 450 mm Injection unit screw diameter 25 mm stroke volume: 69 ccm injection pressure: 2090 bar / 2400 increased Weight: 5,200 kg. dimensions: 4,00 mtr. x 1,40 mtr. x 2,00 mtr LxWxH from our warehouse Hannover /Germany free loading on truck of the buyer or free delivery against freight reimbursement Viewing under electric power possible functional guarantee

Condition: good (used), Year of construction: 2004, Ref. no.: 18255 Manufacturer: ENGEL Type: Victory 750 / 180 tech Year of construction: 2004 Clamping unit Clamping force: 180 ton Opening stroke: 750 mm Distance between tie bars: 960 x830 mm Mould height min.: 500 mm Opening width: 1250 mm Injection unit Screw diameter: 45 mm Injection volume: 318 cm³ Shot weight: 302 g Injection pressure: 1769/2360 bar Measurements and weight Machine weight: 13500 kg Gedewm Iz Nopfx Agljkd Robot Producer: Wittman Type: W743 Year: 2009 Further information: ENGEL Victory 750/180 Tech – Power, Flexibility and Reliability with Tie-Bar-Less Technology The ENGEL Victory series was specially developed for technical plastic processing and is known as a professional injection moulding machine series offering high energy efficiency and maximum mould flexibility. Unlike conventional tie-bar machines, this series provides a much more flexible working area thanks to its tie-bar-less clamping system. ⸻ 🔍 Advantages of the ENGEL Victory Series ✔ Tie-Bar-Less Design The biggest advantage of the world-renowned ENGEL Victory series is its tie-bar-less construction. This system offers several important advantages: • Larger moulds can be installed easily • Easier access for complex mould geometries • Reduced mould changeover times • Easier robot integration • More efficient use of production space This technology is especially advantageous for automotive, technical plastic parts, packaging and industrial applications. ⸻ ✔ Wittmann Robot Integration The machine has been operated together with a Wittmann robot. Robot specifications: • Wittmann W743-0424 • Year of manufacture: 2009 • Payload capacity: 25 kg • X-axis: 1200 mm • Y-axis: 1600 mm • Z-axis: 4000 mm This configuration provides major advantages for automated production processes. ⸻ 🔍 Machine Operating System The ENGEL Victory Tech series operates with a servo-hydraulic system. ✔ Hydraulic System: • Clamping unit • Injection movements • Ejector system • Mould movements are driven by a high-performance hydraulic system. ✔ Thanks to the servo-controlled hydraulic system: • Only the required amount of energy is consumed • Power consumption is significantly reduced • Quieter operation is achieved • Production stability is improved Unlike older conventional hydraulic machines, the machine does not run continuously at full power. The servo pump system operates only when needed, providing the following advantages: • Lower energy costs • Reduced heat generation • Longer component lifetime • More stable processing conditions

Condition: good (used), Year of construction: 2001, Ref. no.: 18092 Manufacturer: ENGEL Type: ES 1350H 200W / 300HL-2F Year of construction: 2001 Clamping unit Clamping force: 300 ton Opening stroke: 855 mm Platen size (h x v): 1050 x 650 mm Gkedpfx Aowm Iy Eeglod Injection unit Screw diameter: 60 +35 mm Injection volume: 735 +135 cm³ Shot weight: 662 + 122 g Injection pressure: 1834 +1620 bar Measurements and weight Dimensions: 7,75 x 2,35 x 2,6 m Machine weight: 24780 kg Further information: ENGEL ES 1350H200W/300HL-2F — 2K Injection Moulding Machine This machine from the prestigious Austrian manufacturer ENGEL, built in 2001, features a clamping force of 300 tonnes and a true 2K L-configuration in horizontal layout. Motor and Hydraulic System The machine is equipped with a powerful electric motor coupled to a high-pressure hydraulic pump group. The electric motor continuously drives the hydraulic pump, providing pressurised oil flow throughout the entire system. This pressurised oil feeds the clamping cylinder, the injection pistons of both units, and the ejector system. The thick red hydraulic hoses visible behind Unit B carry this high-pressure oil flow — both units are supplied via independent hydraulic circuits, allowing Unit A and Unit B to operate simultaneously without influencing each other. Operating Principle The two independent injection units are positioned at 90° to each other — in an L-shape. The mould is locked with 300 tonnes of clamping force. Unit A injects the primary material into the mould at 1834 bar. Immediately afterwards, Unit B injects the second material or colour from a 90° angle into the same mould at 1620 bar. The two materials bond at a molecular level inside the mould, cooling is completed and the ejectors push out the finished 2K part as a single piece. No gluing, screwing or assembly is required — two materials emerge as one single part in a single cycle. Applications Automotive interior and exterior trim parts, large technical plastic components, parts combining a rigid body with a soft grip surface, two-colour large-surface parts.

Condition: good (used), Year of construction: 2014, clamping force: 7,000 kN, *ENGEL DUO 2550/700* *Clamping unit* • Clamping force: 7000 kN • Opening stroke: 1700 mm • Mold height: 450–1300 mm • Max. daylight: 2150 mm • Platen size: 1510 × 1440 mm • Distance between tie bars: 1100 × 960 mm • Max. mold weight: 11,000 kg • Ejector: 250 mm / 95 kN *Injection unit 2550* • Screw diameter: 80 mm • Screw stroke: 310 mm • Max. injection capacity: 1558 cm³ • Recommended shot size (1D–3D): approx. 402–1206 cm³ • Max. screw speed: 163 rpm • Injection rate: 441 cm³/s • Max. injection pressure: 1640 bar • Plasticizing capacity: 80 g/s (3-zone screw), 101 g/s (barrier screw) • Nozzle: 600 mm / 110 kN • Heating: 34 kW, 5 zones *Other* • Pump drive power: 55 kW • Oil capacity: 690 l • Weight: 21.5 t + 7 t Godpfx Ao Ah R Rnsglskd Injection unit data per ENGEL catalogue for 80 mm screw and unit 2550.

Condition: excellent (used), Year of construction: 2011, Engel Victory 1350/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Machine Year of Manufacture: 2011 Injection Unit: Screw diameter: 55 mm Shot weight: approx. 590 g Injection pressure: 2183 bar Dosage volume: 618 ccm Clamping Unit: Clamping force: 260 t Tie-bar spacing: 0x0 mm Platen size: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Gedpez Iptkofx Aglokd Control system: CC 200 - Touchscreen Additional Equipment: Production line with Engel Viper 20 Robot Machine in very good technical condition Tie-barless hybrid machine: energy-saving and very quiet 8x air valve on the fixed platen side 2x hydraulic core pull on the fixed platen side 2x hydraulic core pull on the moving platen side 18 hot runner control zones Injection unit is wear-resistant and corrosion-proof Main drive motor – servo motor with inverter – energy-saving Proportional valve on injection unit – precise injection Engel Viper 20 Robot Year of Manufacture: 2011 6-axis robot: 4 axes (X, Y, Z, B - rotation) driven electrically by servo motors; axes A and C – pneumatic Robot safety package Robot with adapter, conveyor belt, and Engel brand safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 19,400 kg Length/Width/Height: 7.06x2.03x2.30 m All offered machines are started and tested by our service technicians before sale. A video of the technical tests of the selected machine can be provided, or you can attend live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2007, Engel Insert 80V/80V/100 2F / 2-K tie-bar-less machine, vertical / Perfect technical condition Year of manufacture: 2007 Injection unit: Screw diameter: 2 x 25 mm Injection weight: approx. 49 g Injection pressure: 1214 bar Metering volume: 54 ccm Clamping unit: Clamping force: 100 t tie bar distance: 0x0 mm Ejector: hydraulic Gjdpfx Ajz Ipn Ijgljkd Clamping unit: hydraulic Control unit: CC 200 Additional equipment: Tie-bar-less machine with two vertical injection units, with turntable. Air valve x 6 Hydraulic core puller x 2 Control system with hot runners x 12 Infrared protection curtains Thermoplastic and rubber injection units are available for this machine Turntable diameter: 1200 mm The machine has been regularly serviced by the authorized service Engel in Germany Dimensions: Weight: 9400 kg Length/width/height: 4.85x1.47x2.30 m Propulsion: Pumps/motor: 30 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2017, Engel Victory 330H/200V/140 combi Ecodrive / Production line with the Sepro Multi Inject 20 robot / Operating hours: approx. 18,000 h in automatic mode Year of construction: 2017 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Injection pressure: 2400 bar Dosing volume: 113 ccm Clamping unit: Clamping force: 140 t Godpfoz Ipqpox Agljkd Distance between tie bars: 0x0 mm Size of the clamping platens: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 300 - touch screen Additional equipment: 2K injection molding machine with rotary table and robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition Operating hours: approx. 18,000 in automatic mode Total number of operating hours: 25,369 h Euromap 67 Robot interface Air valve x 8 Hydraulic core pull x 5 Control unit with hot runners x 16 Reinforced injection units - bimetal Main motors - 2 x servo motor controlled with inverter Proportional valves on injection units - precise spraying Parallel movements Built-in pressure quality control system from Sensor Kistler - mold pressure measurement Screw diameter in the vertical injection unit: ⌀25 mm - approx. 58 g/hp It is possible to purchase the original Foboha turntable for an additional charge Turntable diameter: 740 mm Sepro Multi Inject 20 robot Year of construction: 2017 3-axis robot: 3 axes are driven by servo motors (electric): X, Y, Z (telescopic) Travel distances in axes approx.: X-4000, Y-1200, Z-1500 Automatic axis lubrication Touch control panel The safety package for robots Robot with adapter and protective housing Purchase of the robot for an additional charge Dimensions Weight: 10300 kg Length/width/height: 5.56x1.76x3.46 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2016, Engel Victory 2050/260 Tech Ecodrive with Engel Viper 20 robot / hybrid machine / operating hours: approx. 20,000 hours in automatic operation Year of manufacture: 2016 Injection unit: Screw diameter: 70 mm Shot weight: approx. 1020 g Injection pressure: 1780 bar Dosing volume: 1155 ccm Gksdoz Ipr Tjpfx Agljd Clamping unit: Clamping force: 260 t Tie bar spacing: 0x0 mm Platen size: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 300 - touchscreen Additional equipment: Production line with Engel Viper 20 robot Tie-barless, hybrid machine: energy-saving and very quiet Operating hours: approx. 20,000 in automatic operation Robot interface Air valve x 4 Hydraulic core pull x 2 on the side of the moving platen Hydraulic core pull x 6 on the side of the fixed platen Injection unit is wear-resistant and corrosion-resistant Main motor of the machine - servo motor driven by an inverter - energy saving Proportional valve on the injection unit – precise injection Kistler sensor - tool pressure control Automatic, hydraulically operated tool mounting system, controlled via the machine control panel Integrated automatic coolant regulator e-flomo with heating function Robot Engel Viper 20 Year of manufacture: 2016 6-axis robot: 6 axes are driven by servo motors (electric): X, Y, Z, B, C, A Payload: 11 kg Touch control panel Safety package for robots Robot with adapter, conveyor belt and protective housing Purchase of the robot and conveyor belt at an additional cost Dimensions: Weight: 21000 kg Length/Width/Height: 7.36x2.06x2.37 m All machines offered are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in technical live tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2012, Engel Victory 1350/300 Tech Ecodrive with Sepro Industrial Robot SDR 22S / Hybrid Machine / Operating Hours: approx. 18,000 hours in automatic operation Year of Construction: 2012 Injection Unit: Screw Diameter: 60 mm Shot Weight: approx. 670 g Injection Pressure: 1835 bar Dosing Volume: 735 ccm Clamping Unit: Clamping Force: 300 t Tie Bar Spacing: 0x0 mm Platen Size: 1200x1000 mm Ejector: hydraulic Clamping Unit: hydraulic Control System: CC 200 - Touchscreen Additional Equipment: Production line with Sepro Industrial Robot SDR 22S Machine in very good technical condition Operating Hours: approx. 18,000 hours in automatic operation Tie-barless, hybrid machine: energy-saving and very quiet Hydraulic core pull x 2 Control system with hot runner system x 12 Injection unit is wear-resistant and corrosion-resistant Main motor of the machine - driven by a servomotor with inverter - energy saving Proportional valve on the injection unit – precise injection Option to purchase spacer plates (movable and fixed), water-cooled plates, screw hole diameter M20 Material supply system Motan (dosing and conveying unit) available at an extra charge Robot Sepro Industrial Robot SDR 22S Year of Construction: 2016 4-axis robot: 3 axes are driven by servomotors (electric); Axis C - pneumatic Travel distances in axes: X-1500, Y-2200, Z-800 Vacuum x 2 Gripper x 2 Touch control panel Safety package for robot Robot with adapter, conveyor belt, and protective housing from Engel Purchase of the robot and conveyor belt available at an extra charge Dimensions: Weight: 19900 kg Length/Width/Height: 7.06x2.13x2.30 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Godpfx Agez Ipu Ujlokd Price: On request
