Condition: used, bore 40 mm Dodpfx Aijzc Rx Ietekp circle diameter 112-320,4 mm knife system WP material Stahl A set of window-making tools from Leitz for manufacturing IV 68/78 windows, in very good condition. The set is designed for manual feed (BG test) on table routers or similar machines. Ideal for woodworking shops without window manufacturing equipment.

Condition: used, 0 ja_yes Dodpfjyn R Iyox Aitokp Striffler sash Fitting Table ----- - with automatic screwdriver and screw feeder - Fitting rack - Punch for Roto fittings (Technical specifications according to the manufacturer, without guarantee!)

Condition: used, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm 1 used Weinig Unicontrol 6 window system ----- Manufacturer's description: For the production of individual parts, elements, and small series. Spindle arrangement: One cross-cutting saw, one single-sided tenoning and slotting spindle, one right-hand profiling spindle, one tenoning and slotting spindle, and profiling spindle suitable for holding multiple tools stacked on top of each other, with pneumatic spindle movement. Slotting table with motorized table movement and automatic transfer to the continuous, chainless rubber roller feed of the profiling unit. Feed height adjustment manually. Workpiece clamping via 2 pneumatic clamping cylinders. Length stop with scale and magnifying glass for frame or sash external dimensions. Tool positions (longitudinal and transverse machining) controlled via selector switch on the control panel. Technical Specifications ----- Crosscut Saw ----- Number of Tools: 1 Spindle Speed: 2,800 rpm Spindle Diameter: 40 mm Max. Tool Diameter: 350 mm Motor: 3 kW Mortise and Slot Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Dkedpfx Aox Tu N Heitjp Spindle Speed: 3,500 rpm Spindle Diameter: 50 mm Tool Clamping Length: 320 mm Max. Tool Diameter: 320 mm Motor: 11 kW Profile Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Spindle Speed: 6,000 rpm Spindle Diameter: 50 mm Tool clamping length 320 mm Max. tool diameter 232 mm Motor 11 kW Special equipment: Synchronous spindle ----- Pneumatically timed forward/backward for tear-free rerouting of window sashes, frames, and doors. Spindle diameter 50 mm, 4 kW Tool clamping length 120 mm, zero tool diameter 112-140 mm Max. tool diameter 232 mm, spindle speed 6000 rpm Motor boost for synchronous spindle from 4 kW to 7.5 kW Screen control for 99 window types. One type can contain up to 8 different parts, each with 2 end profiles and 2 longitudinal profiles. Production options: single parts, double parts, frame-by-frame, series, rerouting. Data entry via keyboard with integrated operator guidance and error diagnostics. 1 Grooving spindle from above ----- Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm, with 10 x 4 mm key Clamping length: 13 mm Clamping length: 40 mm Axial stroke, 2 positions Radial stroke, 2 positions Max. tool diameter: 130 mm Grooving spindle motor boost from 2.2 to 3 kW 1 Fitting milling unit, right: ----- For milling fitting grooves in the circumferential milling pass or for grooving in the longitudinal profile. Pneumatic horizontal movement with selector switch on the control panel. Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm Clamping height: 125 mm Tool cutting radius: min. 140 mm, max. 180 mm Home position below table level: 10 mm Special design of the fittings milling machine: Clamping length 150 mm Axial stroke 80 mm, 3 positions 3 tools Radial cycle, 2 positions Motor booster for the hinge milling spindle from 2.2 to 3 kW Hinge milling spindle for 230 mm tool diameters in and above the table Electric height adjustment of the feed with selector switch on the co...

Year of construction: 2014, condition: used, Number of sanding units 6 St. sanding width 180 mm Sanding height max. 150 mm STAEHLE Grinding Machine Type Gloria/Saturn E 180 RF ----- Stähle Hess Finish Grinding Machine Type Saturn E 180 RF (formerly Gloria) with 2 grinding units, plus top and bottom Roto Finish grinding attachments. 1 upper grinding belt 1 lower grinding belt 2 upper Roto Finish grinding attachments 2 lower Roto Finish grinding attachments For a detailed description, please see the accompanying PDF from the manufacturer. Djdpsx Dng Dsfx Aitekp Sold on behalf of a customer. The images are from our archive and were taken before the machine was delivered to the customer. (Technical specifications according to the manufacturer - without guarantee!)

Year of construction: 2022, condition: used, Number of sanding units 6 st. sanding width 45-165 mm Sanding height max. 45-92 mm weight 2200 kg Ecoline Q-SAND 6 For sale on behalf of a customer ----- Full text as PDF attachment! Short description: Machine with infeed conveyor and automatic height detection. Dsdpoxyafksfx Aitokp It has two grinding discs on top and two grinding discs on the bottom, each connected to a brush unit. Technical manufacturer's description: Ecoline Q-Sand: the ideal grinder for squared timber and more. Designed to work on both sides of the workpiece with three-dimensional adjustment, the Q-Sand guarantees maximum precision and uniformity. It is equipped with grinding discs, flap brushes, and a double disc for more effective material removal, thus improving adhesion for subsequent treatments. The Q-Sand can be installed in a production line or, due to its complete operational autonomy, can also be used independently. It is also ideal for window frames, beams, and custom-made products, and optimizes processing times with automated systems and advanced production control. ----- Price of the above-mentioned machine available upon request! ----- (Technical specifications according to the manufacturer - without guarantee!) All prices quoted are net prices, excluding VAT. The video is from the manufacturer Ecoline and shows a new machine.

Condition: used, Year of construction: 2018, 0 ja Working width 3000 mm 0 nein Eder + Mueller fitting centre for windows ----- Sale on behalf of the customer from the customer's location. The machine was in use until closing and is now at the customer's warehouse. Previous hardware: Maco Multi Matic (other hardware is also possible) Technical manufacturer's description: ----- Table height and working angle mechanically adjustable with permanently mounted hardware bearing Sash stop table, length 3,000 mm, with fixed hardware bearing Felt-bonded support 12 pivoting counterholders for hanging the sashes Hardware detection for centered and constant gear position 1 storage unit with 4-way air connection with automatic special screwdriver with pneumatic depth stop Dkodpfx Aiexmamuotep 6-way turret stop for different screw depths Pneumatic height adjustment for 6 screw levels Automatic screw feed Manual insertion for a second screw length Dimensions: Length approx. 3,500 mm, depth approx. 2,200 mm, height approx. 2,100 mm ----- Price of the above-mentioned machine upon request! ----- (Technical specifications according to the manufacturer - without guarantee!) All prices quoted are net, plus VAT.

Condition: new, Finiture Paint Line for Windows and Doors ----- Short description: Item 1: 1x Double-rail overhead conveyor Item 2: 1x Traverse rotation unit with one coupling Item 3: 1x "Superjet" flood coating system Item 4: 1x High-pressure humidifier Item 5: 1x Wastewater separation system Dsdsy D A Hhjpfx Aitjkp Optional: Flood channel or dipping tank (5–6 basins) For detailed technical description and layout, please see the PDF attachment! ----- Price of the above-mentioned paint line on request! ----- (Technical specifications according to manufacturer – no guarantee!) All prices are net plus statutory VAT.

Condition: new, max. tool diameter 400 mm 0 180 mm operating pressure 2 bar ROTATHERM chamber washing systems are used in all areas of industry and Craftsmanship for cost-effective cleaning of a wide variety of items to be cleaned and materials used. The parts are cleaned like in a dishwasher. Inserted into one Wire mesh basket they are in the closed device with a hot Lye shower washed from all sides. The machine will be selected after the Temperature and washing time set in operation. A centrifugal pump promotes the Washing water circulates to the nozzle system, which at the same time moves the basket in offset rotation. (Optional electric basket drive) After the cleaning process is complete, the device switches off automatically. the Parts can also be removed beforehand. In this case, when lifting the the pump is automatically put out of operation. ROTATHERM chamber washing systems are available in various sizes and at short notice Designs are available and can be requested on special claims be modified. As a rule, water-based cleaners are used deployed. But solvents are also used in ours cleaning machines. If necessary, the systems can be ex-protected version are delivered. Technical details EMSA ROTATHERM Mini: ----- Basket diameter: 400 mm Usable height: 180 mm Load capacity: 50kg Spray pressure without / with filter: 1.5 / 2.3 bar Circulation volume: 2.5 m³/h Tank capacity: 35 l Heating power: 2 kW Connected load: 2.5 kW Voltage: 220/230V Frequency: 50Hz Dimensions ----- Dkodpfx Ajyrtytjitop Depth: 530mm Width: 650mm Height: 630mm Weight: 48kg ----- Price of the basic machine in the above design: On request! ----- Accesories: ----- Order No.: 1.521 Raised lid/max. Tool length 310 mm Order No.: 1.522 HSK 63 F tool holder for changing with basket Order No.: 1.523 HSK 63 E tool holder for changing with basket Order No.: 1.524 Tool holder for Weinig Powermat to change with basket Order number: 2.006 small parts basket, Order number: 1.504 filter system (0.08m²), Order number: 1.510 pressure gauge, Order No.: 1.511 Electromotive basket drive, Order number: 1.512 mobile frame, Order number: 1,513 rolls, Order number: 1.514 suction device, Order number: 1.516 oil separator / belt skimmer, Order number: 1.518 system completely in stainless steel, Order number: 1.519 nozzles in stainless steel, ----- Price on request The ROTAHTERM tool washing machine is also available in larger versions Standard, Maxi and XL available. All devices are also available in special voltages. Surcharge on request. When ordering accessories, the specified technical data and possibly the delivery time! The values ??given are guide values. Construction changes reserved. Delivery time: short term and after Agreement. All prices ex works plus packaging, transport, insurance and legal VAT. (technical information according to the manufacturer - without guarantee!)

Condition: as good as new (ex-display), Year of construction: 2026, Number of motors 2 Stück 0 3000 mm Control ja/CNC loading dimensions L x W x H 4000 x 1500 x 1500 mm Weight 800 kg HECHT Double Miter Saw Exenso DS350E - 3000 mm ----- For wooden glazing beads, mullions, profile strips, aluminum strips, etc. Item 1.1 Article number 942.5103 1 pc. HECHT Exenso DS350E - Working length 3000 mm - Swivel range 22.5° (inside) to 135° (outside) - Right head movable - Saw blade holder Ø 350 mm - Includes 1 pc. center support. - Pneumatic clamping of the components. - Exenso DS3 positioning control with 15" touch panel display in a dustproof monitor housing. - 3-axis control, 1 longitudinal axis and 2 swivel axes. - Manual input of cutting data - Processing of data from a cutting list (data set according to specifications) - Processing of measuring rod data (GMF wireless caliper) - Ethernet connection 10/100 (TCP/IP) - USB interface - Includes control cabinet, motor, and software licenses. Item 1.2 Part number 942.5203 DS hydropneumatic feed unit Item 1.3 Part number 723.0121 2 pcs. DS saw blade for wood Bevel/Angle/Flat tooth - Positive Item 1.4 Part number 942.5236 2 sets of DS combined workpiece clamping Combined workpiece clamping consisting of: Pneumatic swivel clamp - for clamping the Materials from above. (Free access to the worktable) Pneumatic horizontal clamp - Anti-rotation clamping cylinder with pressure piece. The clamps can be individually selected via the saw's control system. The clamping sequence can also be set via the control system. Includes safety pre-tensioning pressure. Scope of delivery for 2 sets: - 2 pieces (left/right) vertical swivel clamps. - 2 pieces (left/right) horizontal clamps. Item 1.5 Part number 942.5241 DS350 table support grooved (standard groove, special grooves according to customer specifications available on request!) Item 3.1 Part number 945.2007 Packaging DS350 (transport frame) ----- Dksdpfxjyy A Ike Aitop Total price in this configuration ex works - on request! ----- ALTERNATIVE options, prices on request! ----- For horizontal clamping of the Offcuts for butt-jointed glazing beads instead of the 2nd set Item 1.3 943.5236 DS workpiece clamping combined! Item 2.1 Item number 942.5201 ES / DS workpiece clamping from the front - 2 clamping cylinders, rotationally secured - 2 cylinder holders with clamping levers ----- OPTIONAL accessories, at extra cost upon request: ----- Item 4.3 Item number 942.5237 DS software "Extra Length" (subsequent steps must be confirmed) Sequence control incl. hardware. After entering a cutting dimension > max. cutting length of the system, the cutting is carried out in a timed sequence. (Left unit cuts, right unit moves the material and cuts to size.) ----- Item 2.1 Item number 944.1023 GMF 3000mm caliper complete set (1500 mm plus 1500 mm extension) Includes charger and receiver. A robust aluminum measuring rail with a measuring range of 3,000 mm is ideal for measuring glazing beads. Functionality For use on doors and large window sashes, the GMF caliper can be mechanically extended safely and quickly to a measuring length of 3,000 mm. Base length: 1,500 mm Extension: 1,500 mm, automatic detection Accuracy of ±0.1 mm Resolutio...

Condition: as good as new (ex-display), Year of construction: 2026, Working width 4500 mm Working height 3000 mm Number of cylinders 6 St. Dimensions (L/W/H) 5500x1400x3550 mm Weight 3000 kg S&S frame press Bavaria 2000 L, built 2026 ----- SHORT TIMED availabe exw warehouse Engelfried, 73447 Oberkochen NEW for the Holz-Handwerk 2026 trade fair in Nuremberg: Now also with semi-automatic positioning of the vertical press cylinders 1, 2, and 3 via enabling switch, including ON/OFF selector switch for beam 2 With automatic pressing cycle + manual control for corner connections tenon+slots and dowel connection/mortised tenon, can be switched using a selector switch on the control cabinet. With basic equipment for optional use of counter profiles if the sash is rebated on the loose part. CE version Basic machine in the strongest frame welded construction, with thick-walled special hollow profiles. Guideways of the pressure beams for the press corners in a low-abrasion machined version. Fast, smooth, manual width adjustment using ball-bearing carriage, fixing in 50 mm hole grid, optional motorized width adjustment with hydraulic clamping (at an additional cost). Height adjustment and pressing using long-stroke cylinders in one work cycle. Right-hand press corners with integrated horizontal cylinders, therefore no vertical positioning of the horizontal pressure cylinders is necessary, which avoids cylinder collisions. Lower support can be adjusted in several positions to the most suitable insertion height. 3 KW compact hydraulic system with integrated control block, variable pressure control from 20 - 120 bar, pressure gauge Control via touch button with separate control circuits for the vertical and horizontal press cylinders, mounted on a freely movable control panel. 2 vertical press cylinders, double-acting, stroke adapted to working height, piston diameter 60 mm Pressure force per cylinder max. 2100 kg 2 horizontal press cylinders, double-acting, 80 mm stroke, piston diameter 40 mm Pressure force per cylinder max. 1250 kg Abutment and pressure plate depth 100 mm Control cabinet on the machine base on the left, 400 volts, 50 Hz Machine with ready-to-connect plug 16 A Paint: RAL 7035 light gray with RAL 7016 anthracite gray Working size: length x height = 4,500 mm x 2,750 mm Note: Actual working size: 4,500 x 3,000 mm (length x height) Space required: 5,500 mm x 1,400 mm x 3,550 mm (LengthxWidthxHeight) Article medium pressure bar complete with pressure cylinder, pressure hose and shut-off valve up to 2,750 mm high Note: actual working height: 3,000 mm Article Individual pressure control for medium pressure bar, pressure control range up to max. 100 bar (For pressing cross-bar windows) Dsdpfx Aieyyqnfstokp Article infinitely height-adjustable cross pressure device, complete with pressure cylinder and abutment, throttle and shut-off valve Article Individual pressure control for cross pressure device pressure control range up to max. 100 bar (For pressing cross-bar window) Article Shut-off valve on the 3rd vertical cylinder Article Shut-off valve on the upper horizontal cylinder Article Shut-off valve on the lower horizontal cylinder ...

Condition: not inspected (used), Year of construction: 2004, Tenoning spindle 2 St. Number of milling agregates 7 St. Spindle diameter 50 mm control Weinig PC-Nexus Weinig Uncontrol 12 with radial and axial CNC spindles and VARIO table ..... The machine has already been professionally dismantled and stored in 73447 Oberkochen Specifications summary (please inquire about any additional accessories included) ..... crosscut saw ..... > Crosscut saw electronically, horizontally infinitely adjustable > Number of tools: 1 pc. > Spindle speed: 3000-6000 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser guide light for detecting the sawing section > Axial adjustment path 150 mm NC axis, electronically stepless > Adjustment path, radial, pneumatic, 8 positions, e.g. for edge rounding from above rounding aggregate ..... > Position: horizontally below > Axial adjustment path together with the crosscut saw. electronic length stop ..... > Length 4500mm 1. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered 2. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered transfer tape ..... Included for transferring the parts to longitudinal processing Separation of double parts before entering longitudinal processing. 1. Profiling spindle (synchronous and counter-rotating) ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 2. Profiling spindle ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 3. Profile milling unit (grooving device from above) ..... > Position: horizontally above > Motor power: 3.0 kW Dkedpfx Aoyrtzkeitjp > Spindle diameter: 40 mm > Tool clamping length: 40 mm > Axial adjustment range 30 mm NC axis, stepless > Radial adjustment range 125 mm NC axis, stepless > Spindle speed: 9000 rpm > Tool flight circle max.: 130 mm ...

Condition: not inspected (used), Tenoning spindle 2 St. Number of milling agregates 7 St. Spindle diameter 50 mm control Weinig, PC-Nexus Weinig Unicontrol 12 with radial and axial CNC spindles as well as VARIO table and milling carriage ..... Machine dismantled professionally and in our warehouse in 73447 Oberkochen. Video and pictures were taken before dismantling. Technical data summary (please inquire about any additional accessories included) ..... crosscut saw ..... > Electronic crosscut saw, horizontally infinitely adjustable > Number of tools: 1 piece. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser directional light to detect the saw section > Axial adjustment path 150 mm NC axis, electronically infinitely variable > Radial pneumatic adjustment path 8 positions for e.g. edge rounding from above Rounding aggregate ..... > Position: horizontally below > Motor power: 1.5 kW > Spindle diameter: 20 mm > Tool clamping length: 25 mm > Spindle speed: 9,000 rpm > Tool diameter: max. 130 mm > Axial adjustment path mechanically coupled with crosscut saw. > Radial adjustment pneumatically controlled on/off electronic length stop ..... > Length 4500 mm 1. Tap and slot spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment path: 580 mm NC axis, continuously variable > Spindle speed: 2,800 rpm > Tool diameter: max. 400 mm Dkjdpfex H Al Njx Aitop > Overtravel counter, complete clamping length is countered 2. Tap and slot spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment path: 580 mm NC axis, continuously variable > Spindle speed: 2,800rpm > Tool diameter: max. 400 mm > Overtravel counter, complete clamping length is countered Transfer tape ..... Included for transferring the parts to longitudinal machining Separation of double parts before the start of longitudinal processing. 1. Profiling spindle (synchronous and counter-rotation) ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment path 350 mm NC axis, infinitely variable > Radial adjustment path 80 mm NC axis, infinitely variable > Spindle speed: 6000 rpm > Tool flight circle min.: 140 mm > Tool flight circle max.: 232 mm > 2 feed rollers axially pneumatically controlled opposite the spindle, 8 positions > Table top pneumatically controlled to the tool diameter 2. Profiling spindle ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment path 350 mm NC axis, infinitely variable > Radial adjustment path 80 mm NC axis, infinitely variable > Spindle speed: 6000 rpm > Tool fli...

Condition: new, 0 4000,5000 mm Djdpoxmk Amjfx Aitjkp Working height 120 mm 0 ja

Condition: reconditioned (used), Working width 230 mm Working height 15-120 mm Number of spindles 2 St. Weinig Hydro Planer Type Uniplan 23 ----- Machine was factory overhauled by Weinig in 2024. Description: For two-sided horizontal woodworking with two working spindles. Spindle arrangement: horizontal, bottom and top. The two horizontal spindles are equipped with hydraulically tensioned counterbearings without axial adjustment. Built-in straight jointers on both spindles with automatic stone feed, remotely controlled with the hood closed. Machine with continuous, chainless feed, equipped with rubber rollers. Electric up/down adjustment of the spindles according to a mechanical digital display (SIKO). On/off switch for limiting the up/down adjustment. Feed roller pressure pneumatic. Stops and table tops are not adjustable. Machine with steel table tops. Dksdpexpn Tzofx Aitjp Machine with full enclosure and integrated sound and dust protection including interior lighting. Electrical design according to DIN VDE 0113, electrical equipment of industrial machines EN 60204, IEC - 204 - 1. Other electrical regulations are not taken into account. Machine includes operating tools, but does not include machining tools. The Weinig Uniplan spindles operate at a speed of 7200 revolutions per minute. Before using existing tools, please check that they are suitable for the speed. Please also consider this when ordering new tools. Technical specifications Max. working width: 230 mm Min. working height: 15 mm, max.: 120 mm Feed: 3 kW (4 HP) Horizontal spindles each: 7.5 kW (7.5 HP) Infinitely variable feed speed: 6 - 36 m/min. Spindle speed: 7,200 rpm Spindle diameter: 50 mm Tool clamping length: 240 mm Maximum tool radius: 163 mm Fixed clamping clearance at bottom: 0.5 mm (Technical data according to the manufacturer - no guarantee!)

Condition: reconditioned (used), Tenoning spindle 1 St Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled ----- The machine was factory overhauled by Weinig in 2024. The control system was also upgraded to a Siemens S 7 677 C, with a new membrane panel "Touch". With the following machining units: Crosscut saw ----- with laser alignment light, motor power 3 kW, spindle diameter 40 mm, spindle speed 3,000 Axially adjustable via NC axis Radial pneumatic adjustment to 8 positions for edge rounding from above Unit from below for edge rounding ----- Axially adjustable with crosscut saw Tenon and slotting spindle Dkedjxpi Duspfx Aitep ----- Motor power 15 kW Spindle diameter 50 mm Spindle speed 2,925 rpm Tool travel radius min. 380, max. 400 mm Tool clamping length 640 mm Axially adjustable CNC axis Axially adjustable travel 580 mm Adjustment speed 100 mm/sec. 1. Profile spindle (up- and down-rotation) ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis 2. Profile spindle ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis Profile milling unit horizontally mounted on top ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 9,000 rpm Pneumatically adjustable to 8 axial and radial positions Profile milling unit vertically mounted on the right side Machine end ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 5,850 rpm Pneumatic adjustment to 8 axial and radial positions Additional accessories ----- CNC-controlled length stop, mounted on the slotting table for lengths up to 3,500 mm, including a positioned cross-cutting saw integrated into the control system. Studio window device, pivots 60° on both sides Double-part package with automatic separation and transfer Synchronization device with automatic window rebating Rebating carriage for rebating small sash widths Air conditioning unit in the control cabinet PC control NEXUS Automatic turning system Slat conveyor, including conveyor belt for returning the workpieces to the operator (Technical specifications according to the manufacturer - without guarantee).

Condition: reconditioned (used), Working width 3500 mm Working height 2550 mm Number of cylinders 6 St. loading dimensions L x W x H 4500x950x2900 mm Hess Speedy frame press ----- will be checked Insertion dimension / pressing length max. 3,500 mm Insertion dimension / pressing height max. 2,550 mm Sliding carriage for width adjustment locking in 50 mm Double hole grid system Electric height adjustment of the long-stroke cylinders (hydraulic) Insertion height of the abutment plates can be preselected in 4 positions 3 vertical printing cylinders stroke 1000 mm Pressure force per cylinder 2000 kN / 20000 N 3 horizontal printing cylinders stroke 80 mm Pressure force per cylinder 1250 kN / 12500 N Dkodpfx Aijxnqw Tstep Printing plate depth 100 mm width 140 mm Grid for cylinder fixation/rear bearing 50 mm Medium pressure beam with shut-off valve Final pressure switch-off and pressure control Control and pressing process in touch button operation Adjustable pressing pressure min. 25 – max. 160 bar Electrical connection 2.2 kW / 400V 3 pendulum pressure plates for studio windows 1 pendulum pressure plate for pointed windows 1 extension for pendulum pressure plate 1 small parts allowance Image and video not original, show identical model ----- (technical data according to the manufacturer - no guarantee!)

Condition: ready for operation (used), Tenoning spindle 1 St. Number of milling agregates 1 St. Spindle diameter 40 mm Small-scale window manufacturing consisting of: ----- 1) Haberkorn FZS1 slotting machine. Price: €12,500 2) Okoma SF3F table milling machine with glazing bead saw. Price: €4 Oertli tooling for the Haberkorn and Okoma machines. Price: €7,500 1 set of wooden windows IV 68/78/88 and 1 set of wood-aluminum windows IV 68/78, manufactured in 2011 4) Götzinger OBM Plus corner hinge and olive drilling machine, Maco MultiMatic hardware. Price: €7 (Hardware can be converted for an additional charge upon request!) ----- Technical Manufacturer's Description: - Haberkorn FZS1 slotting machine with automatic feed, - Stepless height adjustment D 40 mm Crosscut saw: - Spindle arrangement: top - Three-phase motor: 3 kW - Spindle diameter: 30 mm - Speed: 2800 rpm - Saw blade diameter: 400 mm - Automatic brake with speed monitoring - Pneumatic horizontal positioning, manually adjustable - Guard and dust extraction hood with extraction port diameter: 100 mm Slotting spindle D 40 mm: - Power: 7.5 kW - Speed: 4200 rpm - Working length: 252 mm - Maximum tool diameter: 340 mm - 220 mm stroke, stepless height adjustment via Precision ball screws Dodpfx Aoxa Hi Neitokp - Guard and dust extraction hood with extraction port diameter: 180 mm - Automatic brake with speed monitoring Studio table: - Swivel range +/- 65 degrees - Automatically changing counterweight (programmable) - Pneumatic clamp - High-precision electric degree indicator - Automatic length compensation - Counterweight at every angle setting in the cutting plane Optional equipment: - Laser for workpiece positioning - Pneumatic saw position - Length stop LA 2500 mm + 1850 extension ----- 2) Okoma SF3F table milling machine with lifting spindle, 3 tools - Dust extraction ports 2 x 120 mm - Spindle length 270 mm - Counter gauge with fine adjustment and turret - Triple stroke, maximum stroke height 90 mm - Glass strip cutting saw with protective and extraction hood, 80 mm diameter - 8-roller feed unit with stand and hold-down arm, required for the glass strip cutting saw attachment - Pneumatically controlled dispensing unit for edge drive, speed 6000 rpm - 2 x 3 kW motors - Mounting diameter 30 mm ----- 3) Oertli tools for Haberkorn and Okoma machines - 1 set of wood window IV 68/78/88 - 1 set of wood-aluminum window IV 68/78 Tools are sold in the condition, scope, and with accessories as currently available in our stock. Note regarding window cuts, tool drawings, and tool system listings: Engelfried GmbH does not guarantee that the tools actually available correspond to the systems mentioned and drawn. [Note regarding window cuts, tool drawings, and tool system listings:] ----- 4) Götzinger OBM Plus Corner Hinge and Olive Drilling Machine -Corner and scissor hinges + handle olive drilling -Vertical drilling unit with: -Quick-change drill head device -Pneumatic feed via foot valve -1x Olive drill head 24 mm -1x Double-head corner hinge -Maco MultiMatic fitting -1x Adjustable flip stop, left, with 6 stops -1x Adjustable flip stop, right, with 6 stops -1x Machine stand complete with storage tray -220/400 V, 60 Hz, 1.3 kW -1x Roller conveyor appr...

Condition: reconditioned (used), Working width 3600 mm Working height 2600 mm Number of cylinders 5 St. loading dimensions L x W x H 4400 x 1150 x 2970 mm weight 3000 kg Schafberger + Sproedhuber Bavaria Frame Press ----- Machine is overhauled by us before delivery. With automatic pressing cycle + manual control for tenon + slot corner joints. Dkodjw T Un Ujpfx Aitop CE-certified version Basic machine in the strongest welded frame construction, with thick-walled special hollow profiles. Guideways for the pressure beams for the press corners in a low-wear machined design. Fast, smooth, manual width adjustment via ball-bearing carriages, fixed in a hole pattern. Height adjustment and pressing via long-stroke cylinders in a single work cycle. Right-side press corners with integrated horizontal cylinders, therefore no vertical positioning of the horizontal pressure cylinders necessary, thus avoiding cylinder collisions. Lower abutment adjustable in several positions for the most favorable insertion height. 3 vertical press cylinders, double-acting, stroke adjusted to working height 2 horizontal press cylinders, double-acting Abutment and pressure plate depth 80 mm Working size: Length x Height = approx. 3,600 mm x 2,600 mm Space requirement/loading dimensions: approx. 4,400 mm x 1,150 mm x 2,970 mm (Length x Width x Height) Option: ALWA pressing supports for sloped windows (Technical specifications according to the manufacturer – no guarantee! Images may differ from the original. Prices are net, plus VAT (domestic))

Condition: ready for operation (used), Working width 3450 mm Working height 2000 mm Number of cylinders 5 St. loading dimensions L x W x H 3600 x 1200 x 2720 mm Hess "Multipress" Perforated Plate Press For all sloped, segmental, and round-arch windows and doors. Also for interior work or frame construction. For gluing staircase block joints and much more. Largest working area approx. 3450 x 2000 mm External dimensions approx. 3600 x 1200 x 2720 mm The vertical perforated plate press is constructed of heavy-duty, torsion-free steel. Thanks to its simple, robust, and economical design, it has a long service life. The perforated plate is made of 10 mm sheet steel with a 50 mm hole pattern. The pressure cylinders and abutments are self-locking. 5 plug-in hand hydraulic cylinders on a perforated plate with a built-in pump, 2000 kp pressure relief valve, 140 Dkodpewqr R Aofx Aitjp mm pressure plate width, 80 mm pressure plate depth, 60 mm cylinder stroke 4 fixed individual abutments (Technical specifications according to the manufacturer - no guarantee!)

Condition: new, Dimensions (L,W) , mm Weight ca. 90 kg adjustable height (yes/no) ja stroke 300 - 800 mm surface of working table 1.700 x 1.500 mm table width max. 3.800 mm 0 ca. 130 kg Ruchser RU-4-SSP rotary-tilt table ----- Support surface 1700 x 1500 mm, maximum Table width swung out 3800 mm, pneumatically tiltable, weatherproof recess, with 6 storage boxes, each with 2 compartments, pull-outs below for widening, with 2 support feet and 2 flat clamping cylinders, Lifting device from 300 - 800 mm, Roller conveyor as a surface, foldable. Payload capacity 130kg. Driving device with 4 swivel castors Stop device (RU-4SSP) 2 stops for final inspection and To seal Wing assembly device with tool tray and adjustable stop for Inclination for RU-4-SSP Holder for drill, screwdriver gun etc. with screwdriver quiver Driving device with flanged rollers Dkodpfx Aisvu Hfdotsp RU-DKFA and RU-4SSP 3 double meter rail for Driving device 25 x 10 mm ----- Price of the above machine on request! plus packaging and shipping ----- (technical data according to manufacturer - no guarantee!)

Condition: not inspected (used), Year of construction: 2013, Bore diameter , mm Number of heads horizontal , St. Number of heads vertical , St. 2 pcs. Götzinger drilling and milling centers ----- For sale on behalf of a customer! 2 identical machines: One machine for "left" parts and one for "right" parts. The machines can also be used individually. The machines were controlled via window manufacturing software, but can also be operated via the machine software. Both machines are equipped identically: - Left and right drilling units for front-end drilling. - 3 units for drilling and milling for longitudinal machining. - Parts are loaded once, and the unit carrier then moves for the various machining operations. Installation length per machine approx. 6 m. Individual sale possible: Djdpfx Aiov N N Spstskp Price per machine 10,000 Euro See the enclosed PDFs for more information.

Condition: ready for operation (used), Number of sanding units 2 st. Dkjdpfx Aiov D Rg Dotjp sanding width 190 mm Sanding height max. 4-180 mm HESS - GLORIA 2 BELT SINGLE WOOD SANDING MACHINE ----- Manufacturer's description: ----- Compact design designed according to modern principles. Quiet and vibration-free operation thanks to rigid, stable machine housing and special insulation. Work safety device in accordance with the EC Machinery Directive with the "dust-tested" certificate. Offset grinding units with large-dimensioned tension rollers for good heat dissipation and stable sanding belt guidance. Sanding units with forced sanding belt oscillation. 2-point sanding dust extraction directly on the sanding roller. Airborne dust extraction on the large tension rollers. Integrated sanding belt blower for longer service life of the sanding belts. Integrated brushing and finishing device, adjustable via threaded spindle, with large dust extraction. Motorized grinding thickness adjustment of the entire upper unit via precision threaded spindles and linear ball sets on hardened and ground precision shafts with dust and dirt protection. Electronic digital display for workpiece thickness (resolution 0.1 mm). Contact roller and grinding shoe in a balanced ratio to the grinding belt grain load. Hardened and ground grinding rollers. Maintenance-free and wear-free oxide ceramic grinding shoes (DBGM) with excellent sliding properties, good heat dissipation and high dimensional accuracy. Grinding belt tension via pneumatic cylinder. Grinding belt change via pneumatically controlled belt relaxation. Ability to adjust the grinding belt run when changing the belt. Electro-pneumatic pressure monitoring of the compressed air supply with visual fault display. Automatic machine stop triggered when sanding belt breaks and by run-in protection with integrated wood thickness control. Optical display on the control panel. Feed device and proven, calibrated non-slip and non-adhesive transport belts on precisely ground tables and spring-loaded pressure rollers. Cardan shaft drive for even wood transport. Feed speed continuously adjustable. Chip removal adjustment bottom via precision threaded spindle with dimension display via scale ring (resolution 0.1 mm) Ergonomic arrangement of the operating and setting elements on the machine front: sanding unit and brush device at the top, sanding unit and brush device at the bottom, workpiece transport device, sanding thickness setting, operating display, fault display. Control and operating unit with lockable main switch built into the machine housing. All motors electrically protected against overload. Technical data: ----- Grinding belt speed: 24 m/sec. Grinding width: 190 mm Grinding thickness: 4 - 180 mm Shortest workpiece length: 300 mm Feed speed: Continuously adjustable 5 - 25 m/min. Sanding belt dimensions: 200 mm wide 1600 mm long Electrical connection: 400 V, 3/N PE, 50 HZ Grinding units: 2 x 4 kW Feed: 0.75 kW Height adjustment: 0.18 kW Pneumatic connection: R 3/8", 80 NL, 8 bar Extraction air volume: 2 x 2000 - 2500 m3/h 20 - 25 m/sec. Extraction connection nozzle: 2 x 160 mm diameter at the top of the machine housing External dimensions: Length: 1600 mm Width: 1030 mm Height: 1820 mm Height with extraction nozzle: 1930 mm Working...

Condition: ready for operation (used), Number of boring motors 1 St. boring of corner bearing 1=yes, 0=no 1 ja_yes boring of olive 1=yes, 0=no 1 ja_yes 1 HESS fitting drilling station for corner bearings and olives This Hess drilling station for tradesmen offers a lot of drilling technology for little money. A complete station for drilling corner bearings and olives with all the important features, such as 2 clamping cylinders, drilling depth sensing, effective suction, stop systems for corner bearing and olive drilling, drilling head with interchangeable chuck, adjustable drilling feed speed, automatic program sequence. This means technology for perfect work: just one machine with just one drilling unit and just one drilling head for 2 work steps. The system: - Base frame as a support wall for frames and sashes up to 100 mm - Drilling unit positioned in the middle, height manually adjustable via threaded spindle - Drill hole position and depth set to the specified fitting type, can be adjusted via a stop system when changing types - Drilling feed speed can be variably regulated via throttle valve - Direct extraction - Electro-pneumatic control system with automatic Program sequence for - Fixing workpieces - Drill motor on - Drilling unit forwards - Drilling - Drilling unit backwards - Drill motor off - Releasing workpiece fixation - Fixed stop systems Basic equipment / Technical data: Sturdy base frame as a support wall, precise support made of abrasion-resistant and dimensionally stable plastic, for frames and sashes up to 100 mm thick, Corner bearing and olive drilling in one machine and in one drilling unit, simple and convenient, vertical work, easy handling, no templates, minimal time required for the safe workpiece positioning, guarantee for exact and precise drilling, 2 clamping cylinders for immovable fixation of sash or frame, adjustable to different wood thicknesses, side stop in the rebate for the corner bearings, ergonomically arranged stop system for olive drilling with 14 swiveling stops and additional color markings, fixed stop system for drill hole height determination when changing from corner bearing to olive, automatic drilling depth sensing for corner bearing and olive, drill unit with quick-change chuck for the various tools for corner bearing and olive, tool change in "no time", automatic program sequence, clean work thanks to effective suction, Dsdsvu Hgzepfx Aitskp small space requirement and mobile thanks to steering/brake rollers. Electrical equipment in accordance with VDE. Electrical connection: 0.55 KW, 400 V, 50 Hz. Pneumatic connection: R 3/8", 4 - 8 bar Extraction connection nozzle: 1 x 100 mm diameter Extraction speed: 25 m/sec. Space required: Width: 2600 mm Height: 1250 mm Depth: 800 mm Support height: 300 mm Paint finish: RAL 7030 stone grey with RAL 1018 zinc yellow 1 drill set with 1 drill 25 mm and 2 drills 10 mm plus 1 drill 34 mm diameter (technical data according to manufacturer - no guarantee!)

Condition: excellent (used), Number of sanding units 4 St. sanding width 190 mm Sanding height max. 180 mm Control ja weight 3300 kg Dimensions (L/W/H) 2600x920x1890 mm Dust suction hood 2x180, 2x120 mm Löwer DSM 2004 Double-Sided Sanding Machine ----- 4-Belt Sander + Disc Unit (Top/Bottom) Manufacturer's Description: ----- Double-sided, four-belt, single-wood sander for sanding solid wood such as window frames, etc. Highly stable, top-quality design with innovative details. Suitable for high continuous loads, even with high material removal rates. - Sequentially arranged grinding units for roughing, fine grinding, and finishing, each from above and below 1. Belt grinding unit with heavy steel roller 2. Belt grinding unit with rubberized roller and shoe 3. Finishing unit with fiber brush (see optional equipment below) - Direct-drive grinding rollers for slip-free power transmission Djdpfsvu Hgbsx Aitekp - Maintenance-free and wear-free CERMET-coated grinding shoes with very good thermal conductivity and absolute dimensional accuracy - External cooling of the grinding zones for cooler grinding and longer belt life - Forced pneumatically controlled grinding belt oscillation - Effective grinding dust extraction directly at the grinding rollers - Airborne dust extraction at the tension rollers - Integrated brushing and finishing unit with large grinding dust extraction - Motorized grinding thickness adjustment via precision threaded spindles and large linear ball bearing sets on hardened and ground precision shafts with dust and Dirt protection - Chip removal adjustment at the bottom via precision threaded spindle with dimension display via scale ring (0.1 mm resolution) - Sanding belt tension via pneumatic cylinder with constant tension pressure - Sanding belt change with pneumatic belt release in seconds - Sanding belt tracking adjustment during belt change - Electropneumatic compressed air monitoring - Infeed protection via contact roller for workpieces that are too thick - Workpiece transport via calibrated, non-slip and adhesive conveyor belts over heavy-duty cast iron tables with a finely planed surface and spring-loaded pressure rollers with fine adjustment - Cardan shaft drive for smooth and consistent workpiece transport - Geared feed motor with infinitely variable speed 4-20 m/min - All motors electrically protected - Ergonomically arranged operating elements - Digital thickness display (0.1 mm resolution) with modern magnetic tape system Technical data: ----- - Sanding belt speed 22 m/s - Sanding belt length 1800 mm - Sanding belt width 200 mm - Working width 190 mm - Sanding thickness 2-180 mm - Four brake motors for drive 5.5 kW - Feed motor 1.5 kW - Feed speed 4-20 m/min - Automatic height adjustment 0.37 kW - Two brush units with fiber brushes D 120 x 200 mm at 0.37 kW each - Extraction ports 2 x 180 mm, 2 x 120 mm - Extraction air velocity 20 m/s - Pneumatic connection 6 bar - Working height 870 mm - Length (with soft disc 2740 mm) 2600 mm - Length with control unit (with soft disc 3035 mm) 2985 mm - Width 880 mm - Height 1910 mm - Weight approx. 3300 kg - Operating voltage 400 volts, 50 Hz, 3P - CE compliant Equipped with the following special options: -----...

Condition: reconditioned (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Djdpfx Aijvu Hfqetokp Spindle diameter 50 mm control Weinig, PC-Nexus # 2764 Weinig Unicontrol 6 with NC spindles ----- Machine will be cleaned and completely checked before delivery Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, infinitely adjustable horizontally > Number of tools: 1 piece > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser aiming light for detecting the saw section > NC length stop, mounted on slot table included Positioning of the cross-cut saw integrated in the control system. > Length 3500 mm Item 2: tenoning spindle ----- > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (synchronous spindle and counter-rotation) > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool flight circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 11 kW 2 feed rollers opposite the spindle, axially pneumatically controlled, 2 positions Rung guide consisting of: Guide ruler in the stop (area of ??synchronous spindle), Rung support bar from above in the area of ??profile milling unit vertical right and profiling spindle. Pos. 5: Profile milling unit horizontal top ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed ??5,850 rpm > Tool flight circle max. 130 mm > Axial adjustment range 30 mm, 8 positions using pneumatic turret > Radial adjustment range 125 mm, 8 positions using pneumatic turret Pos. 6: 3rd profiling spindle (fitting spindle) ----- > Position: vertical right > Tool clamping length: 160 mm > Axial adjustment range 115 mm, 8 positions using pneumatic turret > Radial adjustment range 100 mm, 8 positions using pneumatic turret > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool flight circle: 210 mm > Motor power: 3.0 kW Other features ----- > online-capable > rebating device for tear-free rebating > double parts package > return conveyor for 1-man operation: tilting belt > screen control > inclined window device > electronic angle display for inclined windows > industrial PC, PC control/NEXUS > Weinig type production program > without processing tools No original images available yet. Images show identical machines from our archive. ----- Price of the above-mentioned machine upon request! ----- Optional with additional charge: EUR 6.500,00 Note on used tools: We currently ha...
