Used Dowel inserters / doweling machines for sale (8)

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. Dimensions (L/W/H) 6100x1500x2300 mm Weight 950 kg 1 NEW drilling and milling center Götzinger Power Drill 300 With the Götzinger PowerDrill you can, depending on the type and design: - Drill on the front and on the long side - Dowels of front doors, pegs, fighters - The drilling patterns are freely programmable - You can drill: handle slides and corner bearings, with quick-change multiple spindle - You can: Milling lock case, pusher and PZ as well as 3D belts and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, save and call again Base frame in sturdy design, covered with sheet metal Table top 1800 x 200 mm Processing unit: X-axis - 500 mm working travel Y-axis - 0-120 mm Z-axis - 0-105 mm (above table) Horizontal aggregates: 1 horizontal drilling unit (dowel drilling unit left) ----- Drilling motor 220 V, 1.1 kW Collet holder ER 25 4,000 - 11,000 rpm adjustable 1 milling unit horizontal for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 horizontal drilling unit (dowel drilling unit right) ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 Vertical aggregates: 1 drilling unit vertical ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 1 boring unit vertical - with quick-change boring head ----- Drilling motor 1,1 KW, 3,000 rpm Included: 1 boring head BKF 2/3, for corner bearing incl. Drill set, quick-change ----- On loose item, drill assembly to customer fitting 1 boring head BKF 3, for olive incl. Drill set, quick-change ----- On loose item, drill 1 cubo d = 25, 2 x dowel d = 10 1 milling unit vertical for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 piece length stop right and left, usable length 2.7 m, NC controlled Control: electro-pneumatic with three-axis NC positioning controller and integrated machine function Input via TFT display, 10 "color Machine complete, CE-compliant, with 1 set of drilling tools, DÜBO each 1 x d = 6,8,10,12 + 2 roughing cutters d = 16, ready for connection Loading dimensions: Bws Ia Unjif Az Uoxisl Machine L x W x H = 2.50 x 1.50 x 2.30 m, weight 850 kg Length stop L x W x H = 6.00 x 0.30 x 0.30 m, weight 100 kg ----- Total price in above mentioned version, ex works: on request Plus freight and installation / instruction (Technical information according to the manufacturer - without guarantee!)

Condition: excellent (used), Year of construction: 2007, Dowel machine Koch Bo Isn Nwq Usa Unxiewl

Condition: used, Year of construction: 2013, Bore diameter , mm Number of heads horizontal , St. Number of heads vertical , St. Bwj Ia Uov N N Spenxisl 2 pcs. Götzinger drilling and milling centers ----- For sale on behalf of a customer! 2 identical machines: One machine for "left" parts and one for "right" parts. The machines can also be used individually. The machines were controlled via window manufacturing software, but can also be operated via the machine software. Both machines are equipped identically: - Left and right drilling units for front-end drilling. - 3 units for drilling and milling for longitudinal machining. - Parts are loaded once, and the unit carrier then moves for the various machining operations. Installation length per machine approx. 6 m. Individual sale possible: Price per machine 10,000 Euro See the enclosed PDFs for more information.

Condition: used, Pitch 32 mm Working width 672 mm Boring depth max. 90 mm Machines from window manufacturing companies are no longer needed. Can be purchased cheaply directly from the customer Machines still in use and can be viewed ----- Item 1 Jago hole rows & dowel drilling machine Pivoting drilling beam 21 drills 23 mm pitch max drilling depth 90mm Price ex location: 1.800,00 Euro Bwe Ijv Dmqloa Unxiel ----- Item 2 Höfer belt sander Size of sanding table: 2500 x 1200 Price ex location: 1,500.00 Euro ----- Item 3 Stegherr FD window dowel drilling machine Drilling lengthways & frontally 1 drilling head for automatic setting of various drilling patterns Price ex location: 1.800,00 Euro ----- Item 4 Ayen olive drilling machine 1 olive drilling head Price ex location: 500.00 Euro ----- (technical data according to manufacturer - no guarantee!)

Condition: used, Year of construction: 2020, Bore diameter , mm Number of heads horizontal , St. Number of heads vertical , St. Weinig Unipin 200 with parapet gluing ----- Dowel driving machine with automatic gluing ! Sold on behalf of a customer: Only around 40 operating hours, no longer required due to product changeover! Manufacturer description: ----- Bws Iou Uvbisa Unxiol Weinig UniPin 200 for driving in dowels on the front after automatic glue application Workpiece clamping pneumatically via hand switch after manual presetting (handwheel). Room conditions ----- Temperature: In operation: from 15 to 30°C Out of operation: from 15 to 30°C During storage and before installation: from 5 to 40°C - +/- 5% Relative humidity (without condensation): In operation: from 10 to 70% - +/- 10% Out of operation: from 10 to 70% - +/- 10% During storage and before installation: from 0 to 90% - +/- 5% Altitude In operation: from 0 - 1500 m above sea level Technical data ----- Total connected load approx. 1.5 KW (2.0 HP) Full load current: approx. 3 A Pre-fuse: max. 10 A Air consumption/standard: 80 l/min /Blow-out device: 150 l/min Operating pressure: supply 8 bar Operating pressure: UniPin 6 bar Permissible workpiece dimensions: Width: 260 mm Height: 150 mm Dimensions Base area: 1050 x 2150 mm Working height: approx. 1000 mm Permissible dowel dimensions according to DIN 68150 Diameter 8 mm +/- 0.2 mm Length 60 mm +/- 1 mm Dowel feed via vibration conveyor Dowel diameter: 8 mm Filling quantity: 500 pieces Pressing force: max. 1000 N Glue system ----- Standard container: 30 liters Glue pressure: up to max. 50 bar For processing B4/D4 glue, one-component according to DIN 68602 / EN 204 suitable. Pump control system made entirely of V4A steel Viscosity at 25°C < 5000 m Pascal Viscosity at 20°C < 4000 m Pascal Standard equipment ----- Electronic dowel driving depth monitoring The driving depth of the dowel is indirectly monitored electronically via the end position of the driving cylinder. If the end position of the driving bolt is not reached during driving, the machine is stopped and a message is displayed on the operating terminal. Prerequisites: - Part must lie cleanly on the zero edge. - Dowel must correspond to the preset length Electronic glue monitoring consisting of monitoring the nozzle needle and pressure difference at the glue nozzle. Advantage: Ensures the gluing function The machine is stopped if there is a malfunction in the gluing function and a message is displayed on the operating terminal. The customer is responsible for maintaining the quality of the corner strength of the corner connection. Weinig accepts no liability for compliance with the quality standards of the corner connection Parapet gluing ----- Contactless application of glue dots to the front of the workpiece with a pulse valve. The dot size can be set by the nozzle opening time and or by means of the glue pressure. The rows of dots must be transferred from the customer’s computer program. The first and last dots in the respective horizontal line are described. The distances between the glue dots are calculated automatically by the control system. Optionally, a maximum dot distance can be transferred in the data set. ...

Condition: new, Bore diameter variabel mm Number of heads horizontal 1 St. Number of heads vertical 0 St. 1 Götzinger dowel gluing and insertion machine BLE Bwj Ia Unxou Uu Uzoisl With the BLE, the workpieces are glued and dowelled on the front. Optional the BLE can be upgraded with a drilling unit, counter milling unit and longitudinal stop will. A 10" touch panel allows easy operation for manual or online operation. Base frame: in a compact design, covered with sheet metal Table support approx. 800 x 200 mm position 1 ----- 1 glue station full jet valve Glue quantity precisely adjustable Glue gun for counter hole gluing position 2 ----- 1 stainless steel glue pump, high-pressure pump and glue hose item 3 ----- 1 press-in station with dowel separation and press-in cylinder item 4 ----- 1 oscillating conveyor for dowels d 8 x 50 mm with feed hose into the injection unit item 5 ----- 1 processing unit with cross table, linear guide and 3NC axis motors X = 200 mm processing width Y = 120 mm processing height Z = 50 mm offset item 6 ----- 1 positioning controller Touch panel 10" color 500 drilling patterns can be created and saved, which can be easily accessed when needed (1 drilling pattern can have up to 16 dowel positions) Software prepared for ONLINE connection With online control, the data for the control must be provided by the software be prepared. Our machine can then read and process this data. ----- Total price in this version Pos. 1 to Pos. 6: on request! Options with additional prices: ----- item 7 ----- 1 horizontal drilling unit, 1,000 W drilling motor Speed ??4,000 - 8,000 rpm, collet holder Pneumatic drill feed Surcharge: EUR 4,305.00 Additional accessories such as a larger touch screen, additional dowel station for additional dowel sizes or scanner for Program selection on request! Prices net plus statutory VAT, without packaging/shipping and without Installation. (technical data according to the manufacturer - without guarantee!)

Condition: new, Bore diameter variabel mm Bs Ia Uod Ih Hqjnxiowl Number of heads horizontal 3 St. Number of heads vertical 4 St. weight 1500 kg Dimensions (L/W/H) 4800x1600x2400 mm Width mit Auflage 2300 mm Götzinger Power Drill Type BF 297 With the Götzinger PowerDrill you can, depending on the type and design: Griffoliven drill on the loose frame part or for finished wings, with multi-spindle drilling head, quick-change, also for milling of the lock case for WK 2 or intermediate gear Ecklager drill on loose frame part, with Mehrspindelbohrkopf, quick-change, corner-oriented over stop or custom made (tilt window) Drill vertically from above for fitting, pre-drill for clip on loose frame part Milling vertically from above for pushers, profile cylinders, 3-D hinges Horizontal drilling with 2 drilling units, different drilling diameters, Dowel drill front and long side, plywood / fighter, sprouts, Corner connection, front door etc. Milling horizontally for lock case / fitting etc. machine description Base frame in stable welded construction, linear guide for the X-axis Table top 3,000 x 200 mm 6 clamping cylinder pneumatic with auto. Ausweichhub 2 side stops for machining on the front side, manually swiveling in and out 2 longitudinal stops can be manually swiveled in and out Travel: X-axis - 3,000 mm working length Y-axis - 120 mm Z-axis - 105 mm Aggregate: 1 drilling unit (unit 1) vertically from above, drill motor 1,1 KW Speed ??1,500 - 12,000 rpm, 1 spindle, collet holder ER 20 1 Bohraggreagt (unit 2) vertically from above, drill motor 1,1 KW Speed ??3,000 rpm, with drill head quick change device 1 boring head BKF 3, olives, quick-change 1 boring head BKF 3/2 corner bearing, quick-change 1 milling unit (Agg.3) vertically from above, milling motor 2 KW, 1,500 - 16,000 rpm, collet holder ER 25 2 horizontal drilling units (Agg.4 and 5) 1.0 KW, 1.500 - 12.000 U / min, Collet holder ER 20 1 milling unit horizontal (Agg.3) 2.0 KW, 1.500 - 16.000U / min, Collet holder ER 20 Electro-pneumatic control with 3-axis control X, Y, Z NC positioning controller make B + R input via TFT display 10 " Machine complete with 1 set of drilling tools dm 6, 8, 10 and 12, 2 roughing carbide cutters HM dm 16, CE compliant, ready for connection Suction connection: 1 x dm 120 Power connection: 1 x 400 V, 16 amps Air connection: 1 x LW 9 mm OPTION: Longitudinal stops right / left with NC axis high / low programmatically, thus dimension input by folding / light measure possible, Dimension: LxWxH = 4.80 x 1.60 x 2.40 m - weight machine 1,500 kg (technical data according to manufacturer - without guarantee!)

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. Götzinger Power Drill in special version with dübelleim and press-in station With the Götzinger PowerDrill, you can choose: - Drill the front and long sides - Doweling of doors, seatings, fighters - The drilling patterns are freely programmable - You can: Grip handle and corner bearing, with quick-change Multi-spindle drilling heads - You can: lock casings, pusher and PZ as well as 3D tapes and drill - The machine has a horizontal and a vertical milling unit Bj Ia Unxed Ih Hyeijwl - A simple control lets you create drilling and milling programs, Save and recall POWER DRILL - drilling and milling machine Universal drilling machine for drilling olives, corner bearings, dowel work On the front and the front, milling, lock boxes, tapes, etc. Base in stable design, covered with sheet metal Table top 1800 x 200 mm Processing unit: X-axis - 500 mm working travel Y-axis - 100 mm Z axis - 105 mm 1 drilling unit horizontal (dowel drilling unit left) Drilling motor 380 V, 1,100 W Clamping chuck d = 8/10 4,000 - 11,000 rpm can be adjusted 1 drilling unit vertically from above - fixed Drilling motor 1.1 KW, 3,000 rpm Quick change of the drill head 1 drill head BKF 2/3, quick-changeable, (corner bearing) On the loose part, hardware according to customer requirements including drill replacement Control: electro-pneumatic with three axes NC positioning controller and integrated machine function Input via TFT display, 10 "color Machine complete, CE compliant, with 1 set of drilling tools Dübo je 1xd = 6,8,10,14 + 2 Roughing cutter d = 16, 1 milling cutter d = 20, ready for connection 1 drill head BKF 3, fast exchangeable for olives including drill bit Fitting according to customer requirements 2 drilling units 1 x horizontal for drilling from above (for tapes) 1 x vertical for dowel work, right Drilling motor 1.100 Watt, infinitely variable 4,000 - 11,000 rpm with collet chuck ER 20 2 Milling units for lock boxes 1 x horizontal for tapes, lock boxes 1 x vertically from above for PZ, pushers, tapes Milling motor 2.2 KW Speed ??adjustable 3,000 - 16,000 rpm Clamping tool holder ER 25 1 length stop right and left, working length 2.8 m NC-controlled When the length stop is used, the fixed stops are removed. Dimension: LxBxH = 2.50 x 1.50 x 2.20 m - Weight machine 850 kg PowerDrill LxBxH = 0,30 x 0,30 x 6,00 m - Weight length stop 100 kg 1 Dübelleim- and press-in station consisting of: - Swing conveyor for dowels with feed -Dübeleinpressstation -High pressure glue pump made of stainless steel with glue container - Full jet valve for precise glue application Exhaust nozzle Price for 1 dowel diameter The basic machine will be about 300 mm longer (Technical data according to manufacturer - without guarantee!)
