Used veneer cutters for sale (29)

Condition: good (used), Code: 0193 Brand: CASATI MACCHINE Model: BIG 3200 - CE Standard Hydraulic two knives veneer pack guillotine shear - CE Standard Description: Sturdy steel made structure, cast iron knife beam. Self-lubrificating prismatic slide-ways The machine allows, with a single operation, to cut the veneer pack on both sides to be trimmed - The simultaneous trimming on two sides of the veneer pack is carried out thanks to the movement at the same time, of two knives, one fitted on a fixed structure and the other one on a moving part - The machine is equipped with an adjustable rear shoulder, as well as with a pressor to clamp the veneer pack during cutting operations. Possibility of working as a single guillotine shear Useful cutting length (as double guillotine shear) mm 3200 Useful cutting length (as single guillotine shear) mm 3550 Pressore stroke mm 100 Pressor width mm 550 Min width to be cut mm 18 Max width to be cut mm 530 Scrap adjustment field mm 0/50 Photoelectric cells Electronic programmer allowing to program the number of cuts to be effectuated and the relevant width Csdpfxoqzky Ee Agtshb Perimeter protections Total power installed Kw 13, 9 Operating pressure bar 6/7 Overall dimensions mm 5200 x 1700 x 1800 h Weight kg 9000

Condition: excellent (used), Year of construction: 1994, Josting Veneer Pack Cutting Machine Type: EFS 2300 L - Year 1994 Codpfjxgbwzjx Agtjhb Cutting length: 2,300 mm Maximum insertion height: 80 mm FIESSLER safety light curtain Alignment light for cutting position display Parallel fence motorized adjustment, fine adjustment via handwheel Connected load: 7.7 kW Weight: 2,700 kg Dimensions: 3,610 x 1,700 x 1,680 mm Ex-works: - available immediately -

Condition: used, Year of construction: 1967, Veneer shears Manufacturer: Hymmen Type: AS Year of manufacture: 1967 Chjdozuzqwjpfx Agtob Technical data - 1-blade veneer shears - Working width: 2800 mm - Package height: 80 mm - Depth: 800 mm Note: The technical data and descriptions are copies of the original order confirmation. The information provided is for informational purposes only and is not binding.

Condition: used, Year of construction: 2007, - Cutting length: 3,400 x 1,300 x 35 mm (depending on the wood type) - Incl. 3 spare blades - Incl. milling cutter - Incl. gluing station - New energy chains installed in 2020 Veneer shear Manufacturer: Fischer & Rückle / Monguzzi Year of manufacture: 2007 Veneer shear with milling unit and gluing unit for butt joint gluing - Cutting length: 3,400 x 1,300 x 35 mm (depending on the wood type) - Incl. 3 spare blades - Incl. milling cutter - Incl. gluing station Chsdezuzqqspfx Agtob - New energy chains installed in 2020 - Length: 7 m - Width: 3 m - Height: 2 m Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2006, - Max. cutting length: 2600 mm - Cutting widths: 45 - 350 mm - Opening of the pressure bar: 100 mm - Width of the pressure bar: 350 mm - Parallel stop with digital display: 25 - 1000 mm - Cutting angle approx.: 45 Veneer shears Manufacturer: Monguzzi, Carugate Type: AFD-35/2600 Year of manufacture: 2006 For clean, perfectly parallel and right-angled joining of veneer bundles in a single operation. Thanks to its high productivity, gentle handling of the raw material (no manual turning) and its precisely parallel cut, this guillotine is the perfect machine for preparing veneer strips for splicing. Production Up to 3 bundles/min Technical data Max. cutting length: 2600 mm Cutting widths: 45 - 350 mm Opening of the pressure bar: 100 mm Width of the pressure bar: 350 mm Parallel stop with digital display: 25 - 1000 mm Cutting angle approx.: 45 Features - Solid, robust construction with generously sized pressure bar and cutting table to accommodate the high clamping and shearing forces - Unique system with a fixed, solid cutting table and a movable pressure bar - Laser lights for precise visual identification of the cutting lines - High-quality hydraulic system with a large oil tank - Electrically driven parallel stop with quick adjustment - Industrial computer based on Windows, widescreen monitor and keyboard Cedpszuzpmsfx Agtshb - Various operating modes and storable program sequences - Extensive recording of production data - Central lubrication unit Movable laser lines For optimizing veneer yield. The manually operated laser line for the position of the front knife can be quickly adjusted. The veneer width is transmitted to the computer at the touch of a button. The cutting process then starts automatically. Note: The technical data and descriptions are a transcript of the order confirmation from that time. Data is for informational purposes only and is not binding.

Condition: excellent (used), functionality: fully functional, working width 3100 mm working height 47 mm manual fence adjustment to size main motor power 4 kW cast iron body safety light barriers power supply 380V Csdpfxozxp Rae Agtohb

Condition: good (used), Year of construction: 1995, overall weight: 4,500 kg, High-quality veneer shears with 2 blades for optimal joint cutting. Chedpezvvffsfx Agtjb Maximum processing length: 2600 mm. CE marked.

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 861953, cutting length (max.): 2,050 mm, cutting height (max.): 60 mm, overall weight: 1,600 kg, cutting width at rip fence: 800 mm, Casati TSA/0 2050 Machine Number : 861953 Year of Construction : 1986 Cutting Lenght 2050 Cutting hight 60 Csdpfx Ajztyfqsgtohb Max rear feed width 800mm Min rear feed width 25mm

Condition: used, Year of construction: 1995, functionality: fully functional, JOSTING EFS 2300 L is a heavy-duty single-knife veneer guillotine designed for accurate cutting of veneer sheets and veneer packs. The machine has been modernized and upgraded with an electronic positioning and control system, improving cutting accuracy, repeatability and ease of operation. Manufacturer: JOSTING Model: EFS 2300 L Csdpfx Aszu Au Dsgtjhb Machine type: Veneer Jointing Guillotine / Veneer Pack Cutting Machine Cutting length: 2,300 mm Maximum insertion height: 80 mm Parallel fence range: approx. 20–720 mm* Pressure bar: Hydraulic cylinder with two pressure stages Cutter bar drive: Brake motor, gearbox and crank drive Parallel fence: Motor-driven positioning system Connected load: approx. 7.7 kW Machine footprint with parallel fence: approx. 3,640 × 1,700 mm Machine height: approx. 1,700 mm Net weight: approx. 3,000 kg Modernization INCLUDES: Digital LCD display Electronic measurement display in millimetres Numeric keypad for direct entry of required cutting dimensions Automatic positioning of the parallel back fence Programmable cutting dimensions Cutting sequence / step programming functions Electronic adjustment and positioning controls Start/Stop control directly from the operator panel Manual fine-adjustment controls Centralized operator interface combining machine and positioning functions

Condition: excellent (used), Year of construction: 1987, I sell the double knife veneer guillotine OMPEC OA 3200/400. Year 1987. Cutting length 3200mm. Csdpfx Ajyc I Tvjgtjhb Cutting height 80mm. Cutting width 20-450mm. Very good condition. Available immediately.

Condition: excellent (used), Year of construction: 1992, I sell the double knife veneer guillotine Josting ZFS 2800. Year 1992 / fully reconditioned 2007. Cutting length 2810mm. Cutting height 80mm. Cutting width 20-470mm. Very good condition. Available immediately. Chedpfevxli Ajx Agtsb

Condition: excellent (used), Year of construction: 2002, I sell the double knife veneer guillotine Casati Macchine Twinset 3100. Year 2002 Cutting length 3110mm. Codpfeznfbmsx Agtohb Cutting height 75mm. Cutting width 15-340mm. Very good condition. Available immediately.

Condition: good (used), functionality: fully functional, The machine consists of: 1. Loading conveyor belt for the sheet to be joined - Dimensions: 3200 x 2000 - Power: 2 kW 2. Lifting table - Dimensions: 3200 x 2000 - Capacity: 5000 kg - Power: 4 kW 3. Conveyor belt for loading empty pallets - Dimensions: 3200 x 2000 - Power: 2 kW 4. Empty loader for the sheet to be optimized VTSA 3800 - Length: 3200 - Feeding speed: 55 m/min - Power: 5 kW 5. Roller feeder VTSM 3800 - Length: 3200 - Power: 1.5 kW 6. Angle transmission with rollers and belts KS4 - 5400 - Length: 3200 - Width: 2000 - Power: 2+2 kW 7. Conveyor belt for aligning sheets on the side edge PKP - Length: 3000 - Power: 4 kW 8. Conveyor belt with chains for pinching the sheet - Length: 2000 - Power: 5.5 kW 9. Camera for reading the material to be optimized OK P - Analyzes the sheet and sends the cutting commands (head cut, tail cut, hole cut, etc., according to the parameters set by the operator) - Sheet thickness control unit 10. Pasta cutting unit - Hydraulic control 11. Group for selecting waste material (it is inserted in a belt below) 12. Splicing group with thermo-fuse wire - Number of splicing wires: 6 13. Cutter for cutting the joined sheets to size - Hydraulic control 14. Stacker for unloading the joined sheets - Length: 3200 Chedpfx Agjvnri Isteb - Width: 2000 - Power: 3 kW 15. Lift table - Length: 3200 - Width: 2000 - Load: 5000 kg - Power: 4 kW 16. Conveyor belt for unloading pallets - Length: 3200 - Width: 2000 - Power: 2 kW 17. Conveyor belt for loading empty pallets - Length: 3200 - Width: 2000 - Power: 2 kW 18. Evacuation belt for cutting waste - Power: 4 kW 19. Mechanical cutter for shredding waste

Condition: good (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 00359, cutting length (max.): 2,300 mm, cutting height (max.): 30 mm, Monguzzi 2300 TRC MP - Veneer scissors Defect - oil i leaking a little from the hydraulics. Fully functional. Cjdpfx Agsumvvretjhb

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 10108, cutting length (max.): 2,900 mm, cutting width (max.): 530 mm, CASATI BIG 2600 - Double knife veneer scissors. Machine is 100% functional. Chedpjum Rpgofx Agtsb

Condition: good (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 209070, CASATI BIT 900/2000 veneer cross-cutting machine. Fully functional. Chjdpfxsuna E Hj Agtjb

Condition: used, 3 m mechanical cutting machine Cedpfxszhnm Se Agtehb

Condition: good (used), Year of construction: 1981, functionality: fully functional, JOSTING EFS 2600 Veneer Shear Year of manufacture: 1981 S/N 9443 Manufacturer: JOSTING Maschinenfabrik GmbH & Co. KG Model: EFS 2600 Good condition Purpose: Precise cutting and trimming of veneer sheets and veneer bundles Technical specifications: Cutting length: 2,600 mm (effective cutting width) Material thickness: up to approx. 3 mm (depending on veneer type and condition) Drive: Electric motor drive via belt and eccentric shaft Cutting principle: Upper blade moves vertically against a fixed lower blade (guillotine cut) Blades: High-quality high-speed steel (HSS), ground and replaceable Feed mechanism: Manual or optionally pneumatic/hydraulic, depending on the model Table height: approx. 850 mm (ergonomic for Operator) Backgauge: Manually adjustable with scale; Optionally available with digital display or motorized adjustment Operation: Two-hand safety control with emergency stop button Foot pedal for the clamp on certain models Clamp: Mechanical or pneumatic, ensures precise fixation of the veneer stack Safety features: Two-hand operation Emergency stop Protective covers Electrical connection: 400 V / 3 Ph / 50 Hz Power rating: approx. 4–5 kW Weight: approx. 1,800–2,000 kg Codpfx Agswmxmvotohb Dimensions (L x W x H): approx. 3,400 x 1,300 x 1,700 mm Special features: Solid, torsion-resistant welded construction High repeatability for serial cuts Suitable for all common veneer types (beech, oak, maple, exotic woods, etc.) Areas of application: Veneer processing in joineries and Furniture factories Veneer production and sorting Interior and vehicle fittings (e.g., for yachts)

Condition: ready for operation (used), functionality: fully functional, cutting length (max.): 3,550 mm, cutting width (max.): 530 mm, overall weight: 9,000 kg, stroke length: 100 mm, TECHNICAL DETAILS Usable cutting length (as double guillotine): 3,200 mm Usable cutting length (as single plate shear): 3,550 mm Press stroke: 100 mm Press width: 550 mm Min. cutting width: 18 mm Max. cutting width: 530 mm Scrap setting range: 0/50 mm Operating pressure: 6/7 bar MACHINE DETAILS Installed total power: 13.9 kW Dimensions & Weight Dimensions (L x W x H): 5,200 x 1,700 x 1,800 mm Weight: 9,000 kg EQUIPMENT Chsdpfx Aoyf Eucjgtjb Robust steel construction Blade beam made of cast iron Self-lubricating prismatic guides Adjustable rear support Press for holding the veneer package during cutting Photoelectric cells Electronic programming device Perimeter safety guards

Condition: excellent (used), Year of construction: 1987, Max Cutting length : 2250 mm Cjdpfx Asyurl Tegtshb Automatic backstop, max depth : 800 mm Manual handwheel for accurate measurement 2 hand operated 2 x laser fence Green light indicator on cutting point 2 x extra cutting knives included Ask for WHATSAPP video presentation

Condition: used, Year of construction: 2000, Used MONGUZZI model 3200 hydraulic veneer cutter Theoretical cutting width: 3200 mm 2 motors Installed power: 10 HP Motorized rear guide with mechanical cutting width indicator REER safety barrier (new) for finger detection – safety level type 4 Codpfx Ajy Th Rwjgtshb Machine length: 4400 mm Weight: 3800 kg Overhauled machine, in excellent condition Complies with CE standards Year of manufacture: 2000

Condition: good (used), Year of construction: 1994, functionality: fully functional, cutting length (max.): 3,100 mm, cutting height (max.): 45 mm, overall weight: 2,300 kg, Veneer shears with a maximum cutting length of 3100 mm Maximum thickness 45 mm Built in 1994 Chjdpfx Aev Nzpmegtsb With spare blade

Condition: excellent (used), functionality: fully functional, cutting length (max.): 2,600 mm, AUTOMATIC HYDRAULIC GUILLOTINE fo veneer model MONGUZZI TRA 2600 second hand machine volt. 380/50 Chodpfx Ajfftuwjgtjb working conditions : good technical details : max. useful cutting length mm. 2650 max. useful cutting heigth mm. 100 max. useful cutting width mm. 1000 min. useful cutting width mm. 40 hydraulic motor power Hp 5,5 net weigth kgs. 2600 CE mark : NO

Condition: excellent (used), Year of construction: 2010, Automatic four-side cutter (4 blades) Working area 2300x620 Chjdsxbhzcspfx Agtob

Condition: used, Savi shear, working width 700 mm Chjdpjq Tx R Njfx Agtsb
