Used Panel saws with a cutting length over 5000mm for sale (21)

Condition: used, Year of construction: 2023, Longitudinal traversing range: 33 m Crosswise traversing range: 13,5 m Number of rows max: 3 Bwjb Hn Ujwhfc Tj S Sel Places per row max: 10 Stack height max: 2.000 mm Workpiece width max: 2.100 mm Workpiece width min: 700 mm Workpiece length max: 4.200 mm Workpiece length min: 1.600 mm Load capacity: 150 kg Feedrate max: 180 m/min Infeed roller conveyor: Yes Raised storage level: Doppelstocklager Vacuum lifter: Yes Turning device: Yes Management of residual parts: Yes Adjustment to panel size: Yes Labelling: Yes Control: PC control Control cabinet cooling: Yes Total connection: 18 kW

Condition: good (used), Cutting area approx. 5200 x 2100 mm Manual feed Bwsb Hn Uewduame S Sjl Automatic deflection grate Cutting depth 70/80 mm Further technical data available upon request

Condition: reconditioned (used), Year of construction: 2007, Functionality: fully functional, cutting length (max.): 5,750 mm, cutting height (max.): 120 mm, cutting width (max.): 2,600 mm, main saw diameter: 460 mm, power: 27 kW (36.71 HP), Machine type: fh6 580 HT260 ERB-L / MCS-Evolution / Win 10 Cutting length: 5.750 mm Cutting width: 2.600 mm Year of construction: 2007 Saw blade projection max .: 135 mm Saw blade diameter max .: 460 mm Main saw motor: 27 kW Scorer aggregate Scorer saw blade diameter max .: 200 mm Package height max .: 120 mm Package height min .: 3 mm Saw aggregate forward: 6 up to 150 m / min Bwjb Hn U Ssvx Ru Do Sol Saw aggregate backward: up to 150 m / min Feeder: up to 80 m / min (Europe: forward 25 m/min acc. EN 1870-13) Number of clamps: 8 pcs grip push clamp Clamp opening: 125 mm Lifting / lowering device for clamps Strip aligner before and after the pressure beam Air cushion tables: 1 pcs. (2100 x 700 mm) Turn table: 1 pcs. (5800 x 2200 mm) 90° turnable Machine table: heavy-duty steel construction „Closed Frame Construction“ machine table surface is precision machined Machine table lips Automatic cutting length adjustment Lift table, max. panel width: 2600 mm Feeding roller conveyor: 7100 x 2600 mm Recesses for forklift trucks: 2 pcs Frequency converter for feeding roller conveyor Positioning stop: 2 pcs Push-off trolley Push-off device: 3 pcs Book aligning device for longitudinal board edges: 3 pcs Retaining device: 3 pcs Roller table Cross alignment stop at the roller table This machine is in very good conditions and works very well. The machine is reconditioned, checked and tested in our company. Errors and alterations in the technical datas and informations excepted! (displayed photos are symbol photos)

Condition: excellent (used), Year of construction: 1996, Striebig Standard TRK 6206 Year 1996 max. cutting width : 5300 mm max. cutting height : 2060 mm saw blade diameter : 300 mm max. machining thickness : 80 mm saw blade bore : 30 mm tilting saw head : manual saw feed : manual saw blade speed : 4750 min-1 slatted frame : can be moved out of the way mounting : free standing suction : external suction locking saw bar : manual weight approx. : 1200 kg dimension 6250x1500x2900 mm engine power : 4.3 kW Bwjb Hnopwf U As U S Sjl Location : Ex stock 54634 Bitburg - immediately available -

Condition: used, Year of construction: 2007, HOLZ-HER 6310 CUT 110 580 Computer controlled panel sizing saw Watch the video about the machine: Year of manufacture: 2007 Machine number: 136 Machine has been overhauled in all essential mechanical elements new PC, new label printer etc. in 2023. Technical data and description: Basic machine pressure beam saw execution: fence on the right side sawing cycle: from the fence cutting length: 5850 mm cutting width: 5850 mm Saw blades Main saw blade Ø 400 X 4,4 X 30 mm, Z72, FZ/TZ (not included!) HM scoring circular saw blade Ø 180 x 4,4/5,4 x 30 mm conical (not included!) Cutting height cutting height: 110 mm blade protrusion: 120 mm pressure bar pneumatic, pressure bar pressure adjustable Suction Central, moving dust channel at the aggregate Suction connection basic machine: 1x Ø 160 mm, placement right machine side Dust channel in pressure beam 2x Ø 120 mm - 1x top left, 1x top right for SL 5850 mm: 3x Ø 120 mm - 1x top left, 1x top center, 1x top right Air speed suction: 30 m/s Air volume: 4000 m3/h at 30 m/s Compressed air Compressed air requirement approx. 32 l/min at 6 bar per cutting cycle Switchable collet pressure Switchable from control panel For sensitive panel materials Automatic cutting length limitation The sawing unit detects the end of the workpiece by means of a guideless optical system and optimizes the sawing cycle. Residual cutting device For cuttings without residual dimension Collets retract into recessed pressure beam Bwjbenbiphj Hn U S Ssl Width stop Precision-guided, freely programmable width stop with collets Rack and pinion drive for precise positioning With surface-guided linear guides Return speed of the knife gate: 80 m/min Feed speed knife gate valve: 80 m/min (EU - feed speed max. permissible 25 m/min) Opening dimension for collets max. 120 mm for length and cross cutting clamp, floating design compensates tensions within the panel packs upwards - 6 pcs. at 3250 mm cutting length - 7 pcs. at 4250 mm cutting length - 8 pcs. at 5850 mm cutting length Control CUTCONTROL 2 with 15" TFT display Operating system Windows 2000 RJ45 network connection 10/100 Base-T Fast Ethernet Intel Celeron processor Midi Tower US keyboard Optical mouse CD ROM drive Control panel Control on the touch side Clearly arranged operator interface on graphical basis for easy operation and management of orders and material on Windows basis Real time display Large and clearly arranged buttons All functions are accessible from one level No limits in the input fields and unlimited input of orders are possible Control functions Direct cut: Cutting by direct input of cutting dimensions. Processing of absolute, serial or format cuts, with integrated grooves, recesses or position cuts. Infinite number of jobs programmable. Priority assignment of individual jobs (priority assignment is possible at any time). Job programming, parallel to cutting. NC cutting: Processing of optimized orders. Graphical overview of the machine with machine sequence function, as well as

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Weight 850 kg Bwsb Hn U Ssvz E D Es Sel Total power requirement 3 kw

Condition: repair required (used), Year of construction: 1998, Functionality: limited functionality, machine/vehicle number: 13189, VERTICAL PANEL SAW WITH ELECTRIC MOVEMENTS & DIGITAL CUTTING DISPLAYS Brand: GMC MACCHINE SRL Type (Model): KGS 660S Serial no.: 13189 Year: 1998 (Photos taken before any overhaul, machine offered as is) MACHINING CAPABILITIES : - Max. horizontal cutting length: 5300 mm - Max. horizontal cutting height: 2100 mm - Max. vertical cutting height: 2200 mm - Max. depth of cut: 80 mm OTHER FEATURES : - Power supply: 380v Three-phase+T - Installed power: 7.5 kW - Main motor power: 4.4 kW (6 hp) - Blade rotation speed: 5200 rpm pneumatic blade output - Carbide saw blade: Ø 300 mm bore Ø 30 mm - Welded chassis, PVC slatted frame automatic retraction by pneumatic cylinders - Full-length pneumatically retractable intermediate support with 2 adjustable, retractable stops - Retractable rollers for panel movement - Pneumatic locking of saw carriage - 8-bar pneumatic supply - Digital display for cuts - DPS total suction system Bjb Hnju R Ulhe U S Sswl Bottom covering the entire rear of the machine Lower longitudinal channel for sawdust recovery Several catchments in lower section Suction mouth: Ø100 mm - Bracket for stand mounting - CE marking Total footprint, mounted on supports: 6300 x 1600 x 3040 mm (includes operator and maintenance area) Dimensions for transport, 2 packages : . 1 frame 6300 x 860 x h.2620 mm . 1 pallet 3150 x 1000 x 1000 mm Overall weight: 1250 kg Please consult us for the supply of consumables, accessories and/or vacuum systems. Batch offered without overhaul, without warranty. Prices ex-store. Transport and services on request.

Condition: used, Cutting length 4300 mm Cutting height 2150 mm automatic , ELCON precision panel saw type D 215 ----- Cutting height: vertical 2,150mm, horizontal 2,100mm Cutting length: 4,300mm ----- Technical description: Cutting depth: max. 60mm Saw blade outlet behind the plate: max. 25mm Saw blade: diameter 250mm, bore 30mm, Z=48 hollow roof tooth Saw blade rotation: 5,100 rpm. Motor: 4 kW (S 6) Measurement reading for: horizontal saw cuts: via scale and strip cutting stop vertical saw cuts: above scale Extraction nozzle: 100 & 80mm Required air pressure: 6 bar Features: -Material support with 1 roll per meter of cutting length, switched on and off by foot pedal suspendable -1 infeed and outfeed roller -pneumatically yielding slatted frame -Central support, 1 support element per meter of cutting length, individually manually fold out -Scoring system: double cut of the main saw blade - Torsion-free, free-standing machine frame -Two folding stops for vertical saw cuts (above and below the middle support) Bjb Hji Hc S Djn U S Sewl ----- Special price "Partnership Edition" ex works in this version: on request! ----- plus pre-freight, freight, installation and instruction (if the machine does not have to be dismantled) Applies only within Germany. Unloading and cross transport to Installation location is determined by the customer. Price: EUR 1,900.00 plus statutory VAT ----- Options with extra charge: Cutting length 5,300mm instead of 4,300mm Order number: ELCO0075/O049 Surcharge: EUR 2,590.00 plus statutory VAT ----- Technical information according to the manufacturer - without guarantee!

Condition: repair required (used), Year of construction: 1993, Panel saw Bwob Hn U Sjvzbq Ie Ssl Manufacturer: Striebig Type: AUTOMAT TRK 6220 AV Year of manufacture: 1993 Control does not respond and display does not turn on. Cutting length: 5,300 mm Cutting height: 2,200 mm Cutting depth: 80 mm

Condition: excellent (used), Numerical Control Power Control + Software Cadmatic 4 Professional No. 1 Infeed roller tracks (ca.) 32,000 mm Lifting table (mm) 5600 x 2200 VAC loader (sliding bridge) with fan suction for loading special or delicate panels Bsb Hn Uovnq H Es S Sewl 1° Rear-pusher, with No. 6 clamps/grippers Turning device (rotating unit) at 90° 1° Panel Saw - Max cutting width mm 5600 (cutting line with air cushion) Max blade projection (mm) 190 Scoring Unit (max. diameter saw / power) mm 200 (Kw 2,2) Main Sawing Unit (max. diameter saw / power) mm 600 ( Kw 36) Adjustable speed of the saw carriage (QS) (m/min) 1 - 130 m/min 2° Rear-pusher, with No. 14 clamps/grippers 2° Panel Saw - Max cutting width mm 2200 (cutting line with air cushion) Max blade projection (mm) 190 Scoring Unit (max. diameter saw / power) mm 200 (Kw 2,2) Main Sawing Unit (max. diameter saw / power) mm 600 (Kw 36) Adjustable speed of the saw carriage (QS) (m/min) 1 - 130 m/min Waste evacuation system with grinder (Kw 19.5) No. 2 Front supporting tables with Air blowing system (mm 800 x 2160) Plastic wheels coated with special material to avoid scratching delicate panels Automatic unloading System of the cut panels: N° 2 x Liftomat HAU-A 25/12 Automatic Stacking System with 8 stations

Condition: used, Year of construction: 2023, Cutting length ca. 5300 mm Cutting height ca. 2150 mm Bweb Hnevwfcaj U S Sjl

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Bwjb Hn U Ssvz Euke Sel Weight 800 kg Total power requirement 3 kw

Condition: good (used), Year of construction: 2005, Panel saw Schelling FMH580 Year 2005 Without lifting table Saw blade diameter 450 mm Scoring saw blade diameter 200 mm Saw blade over table max 125 mm Clamping opening max 113 mm max package height 110 mm min package height 15 mm Motor power main saw 50 Hz, 19 kW Working height 970 mm Overall height 2070 mm Panel lengths / widths: Fiber cement board max 2500 / max 1250 mm Beb Hn Uoq Apigj S Sewl Plywood/ chipboard/ OS boards 2400- 5600 / 1200 - 2600 mm

Condition: used, Numerical control based on PC with Windows operating system and OSI software Computer, keyboard and mouse Video 15” OPTIPLANNING Optimizer Cutting blade projection mm 127 Cutting length mm 5900 Cutting width mm 2200 Bwob Hjuxhdgjn U S Ssl Front and manual loading and unloading of panels Automatic panel loading via rear lifting table Rear motorized preload rollers Rotating system of the panels via pneumatic table inside the machine body Automatic double aligner placed inside the presser with pneumatic cylinders N. 1 fixed front table in bakelite with air curtain system No. 4 mobile front tables in bakelite with air curtain system Main blade group KW 18.5 Engraving blade group KW 2.2 Blade carriage speed: forward 185 m/min. backward 185 m/min. – BRUSHLESS motors Pusher carriage speed: 90 \ 130 m/min. Pusher wagon with 11 clamps Cutting system for thin panels (3 mm) consisting of 3 special clamps mounted on the push carriage Barcode label printer Label Printing Software Hanging and orientable control panel for machine control Total installed power KW 53.5 TECHNICAL DETAILS TO BE CHECKED

Condition: used, Year of construction: 1984, used Make Holz-Her Type 1215 Year of manufacture 1984 Motor 4.0 kW Cutting length approx. 5300 mm Cutting height approx. 2200 mm Center support Saw blade diameter approx. 300 mm, cutting depth 80 mm Free-standing Slatted frame moves away Bwjb Hn Usvwgi Ij S Sol Storage location 97447 Gerolzhofen, free loading, unpacked Handed over in the current condition as viewed, without guarantee or warranty

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Bjb Hn U Sjvz Eudj Sswl Weight 665 kg Total power requirement 3 kw

Condition: used, Year of construction: 1985, used, good conditionmake Striebigtype 6220 Ayear of manufacture approx. 1985motor 4.4 kWcutting length approx. 5300 mmcutting height approx. 2100 / 2200 mmcenter supportcutting depth 80 cmsaw blade diameter approx. 303 mmwall mountingslatted frame moving awaysupport rails woodsuction connection D 120 mmspace requirement approx. 6300 mm x 1250 mm x 2720 mmWeight approx. 1200 kgTotal connected load approx. 4.4 kWStorage location 97447 Gerolzhofen, free loaded, unpackedHandover as seenwithout guarantee and warranty Bob Hn Ujvwfgxs S Sewl

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Weight 800 kg Bob Hovz Et Tjn U S Sjwl Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Weight 665 kg Bsb Hovz Ervsn U S Sswl Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Bjb Hn U Sevz Eihs Sewl Weight 665 kg Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6530x1150x2980 mm Weight 900 kg Bweb Hnovz Eg Hj U S Sol Total power requirement 3 kw
