Used planing & moulding machines for sale (525)

Condition: good (used), Year of construction: 1995, Planing width mm 220 Iasdpfx Acjhaxh Nohow Planing height mm 120 Number of spindles 5 Arrangement of spindles down / right / left / up / down Spindle speed max / min 6000 Electric height adjustment Max feed m / min 25

Condition: good (used), Year of construction: 1990, functionality: fully functional, working width: 250 mm, planing height: 125 mm, spindle diameter: 35 mm, GUILLIET four-sided planer with 250 mm table width, reinforced motors, long table Isdpfx Acsy Sk Ayohoaw

Condition: used, Year of construction: 2003, functionality: fully functional, Ledinek High speed double side calibrate planer 150 m/min Rotoles 300 2V-KS 150 Iaedpfszc H T Usx Achsw 214 KW

Condition: used, Weinig U22N Number of spindles: 8 Spindle diameter: 40 mm Spindle arrangement: Bottom Right Left Right Top Iasdpfezhk T Uex Achow Bottom Top Universal

Condition: used, Weinig U17N Spindle arrangement Ijdpozhkwtofx Acheaw Bottom Right Left Right Top Bottom

Condition: excellent (used), functionality: fully functional, Working dimensions: 230x160mm Spindle configuration: 1. Lower 15kW – Powerlock 2. Right 15kW – Powerlock 3. Left 15kW – Powerlock 4. Upper 22kW – Powerlock 5. Lower 15kW – Powerlock 6. Upper 30kW – Powerlock Isdpszi Tz Rofx Achjaw 7. Lower 15kW – Powerlock Feed drive - 7.5kW Spindle speed 12,000 rpm Pneumatic pressure rollers for the infeed Feed drive on cardan shafts Smooth feed speed adjustment 6/36 m/min Automatic lubrication of the table Table made with MaratonCoating technology Control system: PowerCOM with motor control in Polish Soundproof cabin VibroControl vibration sensor Year of manufacture: 2010 Highnech E1 feeder, 2010 Infeed rollers driven by a 7.5 kW hydraulic pump.

Condition: used, Year of construction: 2010, Number of spindles 6 St. Working width 230 mm Iedpfxjyq S Duo Acheaw Working height 120 mm Length of the planing table 2500 mm Feed motor 3 kW Feed speed 5-30 m/min. control Powercom Weinig Powermat 500, year of manufacture 2010, window version ----- technical details short summary: ----- - 6 spindles, 5 of which are PowerLock - 8,000 rpm - Large PowerCom control system - Spindles 2, 3, and 4 axially CNC-controlled - Spindles 2, 3, 4, and 5 radially CNC-controlled - Window package for glazing bead removal: Pneumatic indexing of right and top spindles for bead removal See attached PDF document for detailed description Options with additional costs: ----- - Existing planing and molding tools by Leitz (price on request!) (Technical specifications according to the manufacturer, without guarantee!)

Condition: used, Year of construction: 2011, Working width: 20–230 mm Working height: 8–120 mm Feed system • Variable-frequency controlled feed drive: 5–30 m/min, continuously adjustable, with 7 kW (9.5 HP) brake motor. • Pneumatically controlled up/down infeed roller before the 1st bottom spindle. • Axial adjustment range of the feed rollers relative to the left spindle: 35 mm. • Extended pendulum axis opposite the left spindles to 150 mm. • Reduced roller spacing in the area of the right-hand spindles. Machine frame, tables and fences • 2 m long jointing table (including jointing fence). • Grooved guide for short or difficult-to-feed workpieces, coated with Marathon PowerCoating. Table tops are non-removable. o Minimum working width: 25 mm o Maximum stock removal at the 1st bottom spindle: 7 mm • Manual lubrication pump. • One driven, hardened outfeed table roller, 210 mm wide. • One driven, hardened machine table roller, 210 mm wide. Pressure elements and guides • Spring-loaded top pressure rollers. • Anti-kickback device before the top spindle for short workpieces. Machine operation • Memory function for storing profile setup data. • EasyCom for quick and easy setup of the moulder and planer. • Storage for up to 1,000 profile programs, including tool data. • Reduced setup times. • Convenient and safe operation. • Basic equipment prepared for CNC-controlled adjustment and positioning. • 2 CNC-controlled radial adjustment and positioning axes for tool spindles No. 4 and No. 5, in conjunction with the Memory function or EasyCom. • CNC-controlled feed height adjustment (up/down) in conjunction with the Memory function. • Mobil- tool spindle (1 axis): automatic adjustment of the left spindle to different workpiece widths. Iedpfx Ajzkklpocheaw • Centralized lubrication points located at the front of the machine. • Electromagnetic locking of the safety hood. • One internal light inside the safety hood. Specifications are provided for information only. This machine is offered for sale on behalf of a customer. Viewing is available by prior arrangement. Please contact us through the platform's messaging system for further information and the relevant technical contact details.

Condition: used, Year of construction: 2002, functionality: fully functional, overall weight: 2,100 kg, power: 25 kW (33.99 HP), Industrial copy shaping machine P. BACCI FC2 1600. Manufactured in 2002, weight 2100 kg, power 25 kW. Designed for woodworking (solid wood, furniture components). The machine comes with an Ecosis Soundproof Enclosure (Model CSF) from 2002. Current condition: The machine is dismantled and located in our warehouse. Key Features: Weight: 2100 kg Power: 25 kW Pneumatic vertical clamps Control panel with adjustable feed rates Isdpfx Acjzi N Awshoaw Cutter head with interchangeable HM inserts included

Condition: excellent (used), Catalogue number 7988 TECHNICAL DATA - spindle width: 510mm - 4-knife planing shaft - max thickness of workpiece in thicknesser: 200mm - max thickness of workpiece on side heads, 3-sided: 100mm From above: - pawls - toothed infeed pulling roller - planing shaft - pressure beam - smooth outfeed pulling roller From below: - 2 adjustable rollers in lower table - guide rail From rear: - 2 side spindles + pressure beams - spindle height: 100mm - max spindle spacing: 510mm Ijdpfezc Nk Njx Acheaw - spindle diameter: 30mm - manual left/right spindle adjustment - motor approx. 2x3kW - main motor: 7.5kW - exhaust port: 2x120mm - overall dimensions (L/W/H): 1700x1200x1000mm - weight: 1060kg ADVANTAGES – made in Poland – 4-knife shaft – DTR documentation – very good condition – used planer Net price: 12,900 PLN Net price: 3,070 EUR at 4.2 EUR rate (Prices may change with larger fluctuations)

Condition: excellent (used), Year of construction: 2013, Weinig Powermat 600 automatic profiling planer, net price €68,800 Technical specifications: Year of manufacture: 2013 Working width (with a cutting circle of 93 - 125 mm): 20 - 230 mm Working height (with a cutting circle of 93 - 125 mm): 10 - 120 mm 7 spindles First lower horizontal spindle, 5.5 kW (7.5 HP) motor First right vertical spindle, shared motor with the left vertical spindle, 11 kW (15 HP) First left vertical spindle, shared motor with the 1st right vertical spindle Second right vertical spindle, 5.5 kW (7.5 HP) motor First upper horizontal spindle, 7.5 kW (10 HP) motor Second upper horizontal spindle, 7.5 kW (10 HP) motor Second lower horizontal spindle, 5.5 kW (7.5 HP) motor Electronic feed with brake, steplessly adjustable 5 - 30 m/min. 4 kW (5.5 HP) motor Operating voltage: 400 V (voltage range 380 - 420 V), 50 Hz All spindle motors are IE2 rated. All spindles have high rotational accuracy. Basic equipment for PowerLock. Surfacing table length 2 m (including a longitudinal guide) Marathon Coating for the machine table and fences Special coating for protecting table segments and fences against excessive wear. Recommended for processing abrasive materials (e.g. tropical wood, MDF, chipboard). Iasdpfx Aceytd S Nehsw OPTION TO PURCHASE THE FOLLOWING MACHINES AT SEPARATE PRICES: 1. Weinig Rondamat 960 Powerlock (automatic straight knife and profile grinder), net price €13,500 Specifications: Weinig Rondamat 960 Powerlock / HSK profile grinder. High-precision knife grinder for sharpening straight knives and profiling with a template. Sharpening straight knives in the cutting block. Manual grinder for profile and straight grinding. Grinding wheel diameter min./max.: 150 mm / 225 mm Grinding wheel width: ceramic 5 mm, borazon 10 mm Grinding wheel bore: 60 mm Tool circle min./max.: 100 mm / 300 mm Tool width max.: 240 mm Grinding wheel drive: 1.1 kW Spindle speed: 1700/2000/2400/3000 rpm Clearance angle: Radial: (rear) 10 - 30 degrees, Axial: 0 - 20 degrees For rotary heads up to 60 degrees Coolant tank approx. 50 liters Table feed 0 - 240 mm Electrical connection approx. 2 kW POWER LOCK SYSTEM option For grinding Powerlock tools. Tool holder with manual quick-change HSK system. Radial table mounting with precise adjustment, max. tool width 240 mm. 2. WEINIG OptiControl 970095 tool measuring station, net price €7,650 Specifications: Tool diameter min. 90 Tool diameter max. 300 mm Tool length 0 - 240 mm Radial measuring range (radius): 150 mm Non-contact measurement of tool dimensions, radius (R) and height (H) and display on electronic digital displays. Electronic digital displays indicating tool radius and height. HSK63 tool holder for PowerLock tools NEW PowerLock adapter HSK63, shank D=50 x 260 mm 3. Weinig Template maker Isel 3020 template milling machine, net price €1,700 Application: Profiling milling Creating templates for tools used for further processing on the machine, e.g. Weinig Rondamat 4. POWERLOCK MOUNTED CUTTING HEADS, price €7,500 Two cabinets full of cutting heads for various applications, approximately 45 pieces.

Condition: good (used), functionality: fully functional, Four-sided planer BMH Coroprofil 32 320x160mm Working width: 320 mm Working height: 160 mm Number of spindles: 6 Spindle configuration: Bottom: 9.2 kW Right: 7.5 kW Left: 7.5 kW Top: 11 kW Right: 7.5 kW Left: 7.5 kW Spindle diameter: 40 mm Side spindles adjustable in two planes Electronic machine positioning Feed speed: 4–24 m/min Ijdpjzd Eg Ijfx Achoaw

Condition: reconditioned (used), Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. Control Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ----- This machine is currently being refurbished at our facility! Pictures taken before dismantling and currently during the processing phase! Brief Summary: ----- - 5 spindles with 8,000 rpm - 4 x HSK/Powerlock - Axially and radial CNC adjustments of the spindles via control - CNC-controlled adjustment and positioning of the feed - Table tops with guide blades at spindles 2 and 3. - Includes Weinig/Neumann RF 15 return conveyor system Detailed Description: ----- Technical Data: Working width: 20-230 mm Working height: 8-120 mm 1st tool holder - bottom ----- Motor with brake: 5.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter: 93 - 145 mm Axially travel: 5 mm Folding device MarathonCoatin for table insert in front of 1st lower Tool Holder 2nd Tool Holder - PowerLock - Right ----- Motor with brake: 7.5 kW Shared motor with left tool holder Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. tool diameter behind stop plane: 180 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle: CNC controlled axially Table tops with guide blades 3rd Tool Holder - PowerLock - Left ----- Motor with brake: Shared motor with the 2nd spindle Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 180 mm Table surface: 93 - 200 mm Tool swing diameter 55 mm below table surface: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle axially and radially CNC controlled Table tops with guide blades 4. Tool holder - PowerLock - top ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Iaedjyy A Iqepfx Achew Tool swing diameter for straight cutter heads max.: 180 mm Max. groove depth: 35 mm Axially travel: 40 mm Split pressure shoe in front of upper tool holder, adjustable and pivoting away from the tool, spring-loaded. Pressure shoe in front of, and discharge after, the upper tool holder with electronic digital displays, integrated into memory functions CNC-controlled radial spindle 5. Tool holder - PowerLock - bottom ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Max. throat depth: 15 mm Axially travel: 35 mm Feed system ----- Frequency-controlled feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers (Weinig patent) wi...

Condition: reconditioned (used), Number of spindles 6 St. Working width 240 mm Working height 120 mm Dimensions (L/W/H) 4900 x 1700 x 1700 mm weight of the machine ca. 3500 kg Control Mobile 10 SCM SUPERSET NTE 31 PLUS automatic profile milling machine with 6 shafts 14 axis control with touch screen - WINDOW VERSION Machine with 6 spindles Spindle speed 8,300 rpm Working width 240 mm, working height 120 mm Electronic horizontal and vertical positioning of the spindles Iasdpfxsyhxmuj Achsw Glazing bead cutting Touchscreen controls Detailed technical description, see adjacent PDF documents. Suction nozzle diameter: 1. Spindle down: 120mm 2nd spindle right: 120 mm 3. Left spindle: 120 mm 4. Spindle top: 150mm 5. Spindle top: 150mm 6. Spindle below: 120mm Images are from our archive of a machine of the same model. (Technical information according to the manufacturer - without guarantee!)

Condition: reconditioned (used), Number of spindles 8 St. Working width 230 mm Working height 120 mm Weinig Planing and moulding line ----- Consisting of the following individual machines: Item 1: Weinig Profimat 23 E, four-side planer, stock number: 2803 5 spindles + glazing bead saw Item 2: Weinig Uniplan 23, stock number: 2804 Fine and hydroplaner with 2 horizontal spindles Item 3: Weinig RF 15, stock number: 2805 Longitudinal-cross-longitudinal conveyor with workpiece return to the operator Iaodpsxpn Tujfx Achjw Detailed descriptions of the machines can be found under the mentioned stock numbers. (Technical specifications according to the manufacturer, without guarantee!)

Condition: reconditioned (used), Year of construction: 2014, Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. Control Memory-Funktion Weinig Powermat 600 Compact ----- The machine has been cleaned and fully inspected. Brief Summary: ----- - 5 Spindles - Powerful Motors - Left and top spindles controlled for width and height Detailed Description: ----- Technical Data: Working Width: 20-230 mm Working Height: 10-120 mm Number of Spindles: 5 1st Spindle - Bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool Circle: 125-145 mm Tool Circle for Rebating Cutter: 130-160 mm Axially Travel: 5 mm Rebating Device MarathonCoatine for table insert in front of the 1st lower tool holder Electronic digital display for rotary adjustment 2nd Spindle - Right ----- Motor with brake: 11.0 kW Shared motor with left-hand tool holder Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. tool diameter behind fence: 180 mm Max. groove depth: 35 mm Axially travel: 55 mm 3rd Spindle - Left ----- Motor with brake: Shared motor with the 2nd spindle Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. groove depth: 35 mm Axially travel: 55 mm CNC-controlled radial spindle 4th spindle - top ----- Motor with brake: 11.0 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter: 93 - 200 mm Tool swing diameter for straight cutter heads max.: 180 mm Iaedpfx Aowzmu Rechjw Max. groove depth: 35 mm Axially travel: 40 mm CNC-controlled radial spindle Split pressure shoe in front of upper tool holder, adjustable to the tool swing diameter and pivoting away from the tool, spring-loaded. Pressure shoe in front of, and discharge after, the upper spindle with electronic digital displays, integrated into the memory function or the PowerCom 5. Spindle - bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool travel: 93 - 200 mm Max. throat depth: 15 mm Axially travel: 35 mm Feed system ----- Electronic feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers with depth limiter and self-cleaning. Adjustment travel of the feed rollers relative to the left tool holder, axial 35 mm Machine electrical system ----- Operating voltage 400 V (voltage range 380–420 V), 50 Hz. All spindles IE2 design. Electrical design according to DIN VDE 0113, electrical equipment of industrial machines EN 60204, IEC 204-1. Other electrical regulations are not considered. Machine stand, tables, and ...

Condition: reconditioned (used), Number of spindles 5 St. Working width 20 - 230 mm Working height 8 - 120 mm Length of the planing table 2000 mm Feed motor 1,1 kW Feed speed stufenlos regelbar 2 - 12 m/min. Control Memory Funktion 1 WEINIG VARIOMAT planer and moulder including multifunction / slotting table ----- Machine will be cleaned and functionally tested before delivery ! Technical manufacturer's description: ----- Working width: 20 - 230 mm Working height: 8 - 120 mm 1st spindle horizontal, bottom ----- Motor with brake: 5.5 kW Diameter 40 mm Speed ??6000 rpm Tool radius 125 - 145 mm Axis adjustment range 5 mm Folding device including rebate cutter MarathonCoating for table insert before and after the 1st lower spindle 2nd spindle vertical, right ----- Motor with brake: 11 kW Common motor with left vertical spindle Diameter 40 mm mm Speed ??electronically adjustable 3000 - 6000 rpm (for 11 kW/15 HP) Tool cutting radius for longitudinal machining 93-232 mm Minimum tool diameter at stop plane: 93 mm Maximum tool diameter behind stop plane: 180 mm Maximum throat depth 45 mm Axially adjustable travel 30 mm Insertion segment, including additional stop lip 125 mm Insertion segment, including additional stop lip 150 mm 3rd vertical spindle, left POWERLOCK/HSK ----- Shared motor with 1st right spindle PowerLock tool holder Shared speed with right vertical spindle Tool cutting radius for longitudinal machining 93-232 mm Maximum throat depth 45 mm Minimum throat depth with tool cutting radius 200 mm: 20 mm Axially adjustable travel under table 30 mm Insertion segment 125 mm Insertion segment 150 mm 4th spindle, horizontal, top ----- Motor with brake: 5.5 kW Iajdpfxjwugpbj Achow Diameter 40 mm Speed ??6000 rpm Tool cutting radius 125-200 mm Maximum chamfering depth 30 mm Minimum chamfering depth with a tool cutting radius of 200 mm: 20 mm Axially adjustable range 30 mm Glazing bead removal after the upper spindle 5th spindle, second, horizontal, bottom ----- Motor with brake: 4 kW Diameter 40 mm Speed ??6000 rpm Tool cutting radius 125-200 mm Maximum chamfering depth 15 mm Axially adjustable range 10 mm Machine operation ----- Both axes of all spindles - with the exception of the first lower spindle - are equipped with mechanical digital displays. Central radial adjustment with mechanical digital display of the feed rate along with the pressure in front of the upper spindle. The pressure after the upper spindle can be adjusted separately. Memory function ----- For saving the setting values ??of profiles Tool holder axes and pressure elements before and after the upper tool holder with electronic dual displays: Function: -Saving the setting values ??of the finished profile at the touch of a button under a profile number - When the profile number is selected again, the electronic dual displays show the setting values - By manually adjusting the tool holders and pressure elements, the displays are aligned - 99 memory locations 3 axial CNC-controlled adjustment and positioning of the spindles in conjunction with the memory fun...

Condition: not inspected (used), Year of construction: 2010, Number of spindles 6 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm feed 5-25 m/min Dimensions (L/W/H) 4700/1800/1100 mm weight ca. 4.000 kg CASOLIN MEGA 230/6 four-side planer ----- 6 spindles, with touchscreen control. Width and height controlled. Spindle arrangement: 1st spindle: bottom, 40 mm diameter, 6,000 rpm, 5.5 kW 2nd spindle: right, 40 mm diameter, 6,000 rpm, 11 kW together with 3rd spindle: left, 40 mm diameter, 6,000 rpm 4th spindle: top, 40 mm diameter, 6,000 rpm, 7.5 kW 5th spindle: bottom, 40 mm diameter, 8,000 rpm, 5.5 kW Ijdewmggkspfx Acheaw 6th spindle: top, 40 mm diameter, 8,000 rpm, 5.5 kW Machine without machining tools. The additional screen on the front of the machine is not included in the scope of delivery (is part of the window system). Machine already dismantled and stored. (technical information according to the manufacturer - no guarantee!)

Condition: as good as new (ex-display), Year of construction: 2021, Number of spindles 5 St. Working width 250 mm Working height 160 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 6-24 m/min. control K2 Basic 7"-Touch KUPER SWT XL-5 AUTOMATIC PLANER AND MOULDER ----- LIKE NEW, showroom machine ! - 5 spindles: bottom, right, left, top, bottom - Speed: frequency-controlled 4,000 - 6,000 rpm, spindle 4.5 to 8,000 rpm - Width and height motor-controlled: left spindle radial upper spindle axial - Feed carrier motor-controlled - Additional motor-controlled positioning: right spindle radial and axial left spindle axial - working width 250 mm TECHNICAL DATA ----- Working width (perimeter of tools 163 mm) 15 - 230 mm Working height(perimeter of tools 163 mm) 10 - 150 mm (perimeter of tools 123 mm) 10 - 160 mm Min. workpiece length: single piece: min. 800 mm piece by piece: min. 300 mm The processing of the work pieces is depending on the following operating parameters: material, wood moisture, tools, diameter of the chip removal and feed speed. If necessary adjustments to the operating parameter have to be done. SPINDLE CONFIGURATION ----- bottom, right, left, top, bottom 1st spindle: HORIZONTAL, BOTTOM ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 250 mm Usabale length for tools Spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 125 - 160 mm Reference cutter Diameter difference 20 - 25mm to the cutterhead Connecting piece D = 125 mm Quick action lock nut Pro-Lock 2nd spindle: VERTICAL, RIGHT ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 165 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Adjustment path axial 60 mm Adjustable table plate to tool radius Standard profile depth 20 mm Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock Isdpowgwmnofx Achoaw 3rd spindle: VERTICAL, LEFT ----- Siemens IE3 motor with inverter brake 7,5 kW (10 HP) Diameter 40 mm Spindle length 165 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Adjustment path axial 60 mm Standard profile depth 20 mm Adjustable table plate to tool radius Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock 4th spindle: HORIZONTAL, TOP ----- Siemens IE3 motor with inverter brake 7,5 kW (10 HP) Diameter 40 mm Spindle length 235 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Pressure shoe pneumatically, via linear guides dynamically adjustable Standard profile depth 20 mm Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock 5th spindle: HORIZONTAL, BOTTOM ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 235 mm Usable length for tools spindle lenght minus approx. 6 mm Drive, frequency-controlled...

Condition: as good as new (ex-display), Year of construction: 2021, Number of spindles 5 St. Working width 230 mm Working height 160 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 6-24 m/min. Control K2 Basic 7"-Touch KUPER SWT XL-5 AUTOMATIC PLANER AND MOULDER ----- LIKE NEW, showroom machine ! - 5 spindles: bottom, right, left, top, bottom - Speed: frequency-controlled 4,000 - 6,000 rpm - Width and height motor-controlled: left spindle radial upper spindle axial - Feed carriage motorized adjustment TECHNICAL DATA in Detail ----- Working width (for tool diameter 125-163 mm): 15-230 mm Working height (for tool diameter 125 mm): 10-160 mm (Tool diameter up to 163 mm): 10-160 mm Min. workpiece length: single piece: min. 800 mm piece by piece: min. 300 mm The processing of the work pieces is depending on the following operating parameters: material, wood moisture, tools, diameter of the chip removal and feed speed. If necessary adjustments to the operating parameter have to be done. SPINDLE CONFIGURATION ----- bottom, right, left, top, bottom 1st spindle: HORIZONTAL, BOTTOM ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 250 mm Usabale length for tools Spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 125 - 160 mm Reference cutter Diameter difference 20 - 25mm to the cutterhead Connecting piece D = 125 mm Quick action lock nut Pro-Lock 2nd spindle: VERTICAL, RIGHT ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 165 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Adjustment path axial 60 mm Adjustable table plate to tool radius Standard profile depth 20 mm Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock 3rd spindle: VERTICAL, LEFT ----- Siemens IE3 motor with inverter brake 7,5 kW (10 HP) Diameter 40 mm Spindle length 165 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Adjustment path axial 60 mm Standard profile depth 20 mm Adjustable table plate to tool radius Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock 4th spindle: HORIZONTAL, TOP ----- Siemens IE3 motor with inverter brake 7,5 kW (10 HP) Iaodpfxewgwmho Achsw Diameter 40 mm Spindle length 235 mm Usable length for tools spindle length minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Pressure shoe pneumatically, via linear guides dynamically adjustable Standard profile depth 20 mm Connecting piece D = 125 mm Aspiration individual adjustable shavings guiding plate Quick action lock nut Pro-Lock 5th spindle: HORIZONTAL, BOTTOM ----- Siemens IE3 motor with inverter brake 5,5 kW (7,5 HP) Diameter 40 mm Spindle length 235 mm Usable length for tools spindle lenght minus approx. 6 mm Drive, frequency-controlled 4000 - 6000 rpm Perimeter of tools 112 - 200 mm Adjustment range axial 20 mm Connecting piece D = 125 mm Aspiration individ...

Condition: reconditioned (used), Number of spindles 6 St. Working width 230 mm Working height 160 mm Length of the planing table 1050 mm Feed motor 7 kW Feed speed 6-40 m/min. control MemoryPlus Weinig Powermat 1200 ----- with infeed automation Weinig wheel magazine EM 100 and linked with outfeed automation Weinig High-Mech A 1 The machine will be completely overhauled at our warehouse before delivery ! Detailed description: ----- 1. Weinig planer and moulder Powermat 1200 ----- Technical data: ----- Working width 20 - 230 mm (with tool flight circle 93 - 163 mm) Working height 10 - 160 mm (with tool flight circle 93 - 163 mm) 1. Spindle ----- First lower horizontal spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 125 - 180 mm In conjunction with PowerLock 93 - 180 mm Tool flight circle rebate cutter 130-160 mm Axially adjustable range 17 mm Folding device MarathonCoating in front of 1st lower tool holder 2nd spindle ----- First right vertical spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 93 - 200 mm Maximum throat depth 35 mm Axial adjustment range 80 mm Radial adjustment range Min. tool diameter on stop plane 93 mm Max. tool diameter behind stop plane 200 mm 3rd spindle ----- First left vertical spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 93 - 200 mm Tool flight circle for straight cutter heads max. 163 mm Maximum throat depth 35 mm Axially adjustable travel 80 mm Iaedpfovnwbcjx Achow Pressure shoe in front of left tool holder, including 2 side pressure rollers, spring-loaded 4th spindle ----- First upper horizontal spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 93 - 200 mm Tool flight circle for straight cutter heads max. 163 mm Maximum throat depth 35 mm Axially adjustable travel 40 mm Split pressure shoe in front of upper tool holder on tool flight circle adjustable and swinging away from the tool, spring-loaded. Upper spindle prepared for later installation of the cassette system 5th spindle ----- Second upper horizontal spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 93 - 200 mm Tool flight circle for straight cutter heads max. 163 mm Maximum throat depth 35 mm Axially adjustable travel 40 mm Split pressure shoe in front of upper tool holder on tool flight circle adjustable and swinging away from the tool, spring-loaded. Upper spindle prepared for later installation of the cassette system 6th spindle ----- Second lower horizontal spindle Motor with brake 7.5 KW Spindle diameter 50 mm Speed ??8,000 rpm Tool flight circle 93 - 225 mm Maximum throat depth 15 mm Axially adjustable travel 40 mm Radial adjustable travel Min. tool diameter to table level 93 mm Max. tool diameter 6 mm below table level 225 mm All spindles with high concentricity. Lubrication points for the axial tool holder movement. Feed system ----- Electronic feed, infin...

Condition: reconditioned (used), Number of spindles 6 St. Iaodpsuzaa Sjfx Achjw Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. control Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ----- The machine renovated and functionally checked ! Short summary: ----- 6 spindles with 8,000 rpm 5 x HSK/Powerlock Axial and radial CNC adjustment of the spindles via control CNC - controlled adjustment and positioning of the feed Detailed description: ----- Technical specifications: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 6 1. Tool holder - below ----- Motor with brake: 5.5 kW Spindle diameter: 40mm Speed: 6,000 rpm Tool flight circle: 93 - 160 mm Axial adjustment range: 5 mm Rebating device MarathonCoatin for table insert in front of 1st lower tool holder 2. Tool holder - PowerLock - right ----- Motor with brake: 11.0 kW Common motor with left tool holder Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle 40 mm below table level: 93 - 200 mm Tool flight circle 55 mm below table level: 93 - 180 mm Tool cutting circle for straight cutter heads max. 163 mm Max. tool diameter behind stop level: 180 mm Max throat depth: 35 mm Axial adjustment range: 55 mm Spindle axially and radially CNC controlled 3. Tool holder - PowerLock - left ----- Motor with brake: Common motor with the 2nd spindle Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle 40 mm below table level: 93 - 200 mm Tool flight circle 55 mm below table level: 93 - 180 mm Tool cutting circle for straight cutter heads max. 163 mm Max throat depth: 35 mm Axial adjustment range: 55 mm Spindle axially and radially CNC controlled 4. Tool holder - PowerLock - above ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle: 93 - 200 mm Tool cutting circle for straight cutter heads max.: 180 mm Max throat depth: 35 mm Axial adjustment range: 40 mm Divided pressure shoe in front of the upper tool holder, on tool flight circle adjustable and pivoting away from the tool, spring-loaded. Radial CNC-controlled spindle 5. Tool holder - PowerLock - above ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle: 93 - 200 mm Tool cutting circle for straight cutter heads max. : 180 mm Max throat depth: 35 mm Axial adjustment range: 40 mm Divided pressure shoe in front of the upper tool holder, on tool flight circle adjustable and pivoting away from the tool, spring-loaded. Spindle axially and radially CNC controlled 6. Tool holder - PowerLock - below ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle: 93 - 200 mm Max throat depth: 15 mm Axial adjustment range: 35 mm Radial CNC-controlled spindle feed system -----...

Condition: ready for operation (used), Number of spindles 6 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 3 kW Feed speed 5-24 m/min. total power requirement 27 kw Dimensions (L/W/H) 3900 x 2200 x 2000 mm weight of the machine ca. 2500 kg Weinig four-side planer Profimat 23 window version with glazing bead removal, ATS control and program control ----- Machine will be renovated and functionally checked! Technical data summary (please inquire about any additional accessories included) ----- Generally ----- > Working width: 230 mm > Working height: 120 mm > Number of spindles: 6 pieces. > Dressing table length: 2500 mm > Feed speed: 5-24 m/min > Total power requirement: 27 kW > Dimensions: 3900 x 2200 x 2000 mm > Machine weight, approx.: 2500 kg Spindle arrangement ----- > Spindle 1: bottom > Spindle 2: right, pneumatically clocked up-down > Spindle 3: left > Spindle 4: top > Spindle 5: bottom > Spindle 6: Glass bead saw pneumatically up and down Spindle description ----- > Spindle 1: 4 kW, 6000 rpm, 40 mm diameter > Spindle 2: 7.5 kW, 6000 rpm, 40 mm diameter > Spindle 3: 6000 rpm, 40 mm diameter > Spindle 4: 5.5 kW, 6000 rpm, 40 mm diameter > Spindle 5: 4 kW, 6000 rpm, 40 mm diameter > Spindle 6: Glass bead saw 2.2 kW, 6000 rpm, 40 mm diameter Other features ----- > Glazing bead removal > ATS control, automatic 2-axis positioning for width and height (left and upper spindle) with program memory 99 programs > Machine operation: window package Joint control of the right spindle and the glazing bead removal via manual selector switch in the control panel > Spindles with mechanical digital display Option: used planer heads Iaodpfx Aeu Su Hujchjw (technical data according to the manufacturer - no guarantee!)

Condition: excellent (used), Catalogue No. 6747 TECHNICAL DATA - Maximum planing width: 170 mm - Maximum planing height: 130 mm 7 spindles: 1) Bottom horizontal spindle: 170 mm, 4 kW 2) Right vertical spindle: 130 mm, 5.5 kW 3) Left vertical spindle: 130 mm, 5.5 kW 4) Additional right vertical spindle: 130 mm, 5.5 kW 5) Top horizontal spindle: 170 mm, 4 kW - 5th spindle with electric height adjustment 6) Additional bottom horizontal spindle: 170 mm, 5.5 kW 7) Universal spindle: 170 mm, adjustable up to 180°, 7.5 kW - Spindle diameter: 35 mm (all spindles) - All spindles adjustable vertically and horizontally - Top: 6 powered feed rollers (toothed), including 2 double rollers - Top: 4 outfeed rubber rollers - Pneumatically pressed rollers - Side pressure roller included - 2 guide rails in the table - Electrically adjustable planing thickness: 0.37 kW - Infeed table length: 2,480 mm - Stepless feed speed adjustment - Feed motor: 2.2 kW - Extraction port diameters: 1 x 135 mm, 5 x 120 mm - Dimensions (LxWxH): 5,550 x 1,900 x 1,660 mm - Weight: approx. 3,500 kg Iaedpezcu Rzofx Achow FEATURES – Made in Germany – Equipped with 7 cutterheads – Universal spindle – Used planer, in very good condition Net price: 27,900 PLN Net price: 6,640 EUR Net price calculated at exchange rate 4.2 PLN/EUR (price may change with significant exchange rate fluctuations)

Condition: used, Number of boring spindles 7 St. Working width 160 mm Working height 120 mm Length of the planing table 2.000 mm Iajdpfx Acezb Rffshsw Feed motor 2,2 kW Weinig PFA 17 N (Unimat) automatic planing and chamfering machine for four-sided planing and profiling of wood, equipped with a universal spindle. Spindle 1: Bottom / 35 mm / 4 kW Spindle 2: Right / 35 mm / 3 kW Spindle 3: Left / 35 mm / 5.5 kW Spindle 4: Right / 35 mm / 7.5 kW Spindle 5: Top / 35 mm / 5.5 kW Spindle 6: Bottom / 35 mm / 4 kW Spindle 7: Universal / 35 mm / 4 kW
