Used blow molding machines for sale (36)

Condition: used, Year of construction: 2017, Rotary stretch blow molding machine for blowing PET bottles from preforms. Preforms are poured from a container into the feed hopper via a tilting device. From there, the preforms are fed out via an ascending belt with electronically controlled speed and are transported to the blow molding machine in a uniform orientation via a chute and loading star wheel. The shape and size of the preforms are checked and defective preforms are ejected before they are fed to the heating boxes via a mechanical star wheel. In the heating boxes, the preforms are preheated with infrared lamps. They are continuously rotated to ensure symmetrical heat distribution. Fans prevent overheating on the outside. Finally, the preform temperatures are checked using an optical pyrometer. Grippers feed the preforms to the blow wheel and remove them from it. The blow molding unit works with “crocodile molds,” in which expansion along the longitudinal axis is supported by a stretching rod. The preforms are then blown into PET bottles. The stretch-blown bottles are removed from the cavities by grippers and conveyed to the ejector. Additional title: rotational molding machine Capacity: 18000 bo/h Number of cavities: 8 pcs. Number of bottles to be ejected per stop: 202 pcs. Blow pressure: 30 bar Power: 58 kW Voltage: 400 V Frequency: 50 Hz Water: 4 bar Compressed air: 360 Nm3/h at 7 bar Weight: 16700 kg Formats: 0.5 l; 1.0 l; 1.5 l PET bottles Gslhcdwoxyktljyjbl Features: Preform feed hopper with tilting device for containers, inclined belt conveyor for preforms, preform inspection, heating boxes, blow wheel; bottle ejector; visualization on screen

Condition: used, Year of construction: 2000, machine/vehicle number: SO126, Used HDPE Extrusion Blow Molding Machine for 10 L – 300 bph – Overview Second-hand Uniloy Milacron HSM10/D extrusion blow molding machine designed for producing up to 10 L HDPE containers. With a single-parison head and robust clamp, this EBM unit is ideal for industrial packaging and beverage production auxiliaries (e.g., water canisters, edible oils) and can be integrated within a used bottling line. Documentation and manuals are available. Reference number: SO126. Technical Specifications & Performance Data Main data Make/Model: Uniloy Milacron HSM10/D Year: 2000 Technology: Extrusion Blow Molding (EBM), single parison Material: HDPE Number of cavities: 1 Max container volume: 10 L Indicative output: up to about 300 bph on 10 L (application-dependent) Manuals: included Ref. no.: SO126 Extruder Screw diameter: 100 mm; L/D 24 HDPE screw speed: 0–70 rpm Plasticizing capacity (HDPE): approx. 300 kg/h Main extruder motor: 89 kW Heating zones: 6; barrel heating power: 31.4 kW Motor cooling power: 0.58 kW; barrel cooling power: 1 kW Parison head Type: PE 1/200, single parison Max die diameter: 200 mm Head heating power: 14.2 kW Parison thickness control: hydraulic (wall-thickness programming) Clamp & blow unit Clamp force: 200 kN Max mould size: 650 × 500 mm (H) Mould thickness: 2 × 150 mm Mould opening stroke: 300 mm Horizontal carriage stroke: 660 mm Blow pin stroke: 240 ± 5 mm Gbelhcdsyhbt Howyjl Blow pin thrust at 50 bar: 320 kg Electrical Installed power: 156 kW (average consumption ~104 kW) Supply: 400 V, 50 Hz, 318 A, 3 + N Hydraulic system Reservoir capacity: 400 l Pump flow (1470 rpm): 123 l/min Max pressure (main circuit): 190 bar Main hydraulic motor: 37 kW; oil cooling motor: 1.5 kW Pneumatics Operating pressure (general): 6–8 bar; air use: 2000–2500 Nl/min Post-cooling pressure: 6–8 bar; air use: 1000–1500 Nl/min Cooling water Mould circuit: 8–12 °C; flow 15 m³/h Extruder & hydraulic oil: 10–24 °C; flow 4 m³/h Dimensions & weights Approx. machine size (L × W × H): 7600 × 7700 × 3900 mm Blow unit weight: 7600 kg; Extrusion group weight: 6400 kg Noise level at operator: < 85 dB(A) Advanced Automation & Control Systems Hydraulic wall-thickness programming for precise parison control, improving weight distribution and top-load performance on 10 L containers. Dedicated Uniloy command and control software (version code available in manuals) with operator interface for setpoint management and diagnostics. Integrated temperature control across six extruder zones and heated head for stable processing at up to 300 °C transformation temperature. Interlocked guarding and emergency stops for safe operation. Production Line Integration Capabilities This second-hand extrusion blow molder is integration-ready for downstream equipment typical of a used bottling line and industrial packaging systems: Conveyor...

Condition: good (used), Production capacity of up to 4000 b/h (depending on the format) For formats between 0,25lts up to 3lts Composed by: • Oven for heating the preforms composed of 6 heating modules with 8 infrared lamps each • Preform transfer Wheel • Two-stage compressed air blowing body, low pressure pre-blowing and subsequent high pressure blowing. Golhcswcggvedwyobl • Bottle transfer Wheel • Delivered with pallet turner. DOCUMENTATION AVAILABLE

Condition: used, Year of construction: 2004, machine/vehicle number: SO127, Blow Molding Machine Contiform – Overview This used Krones Contiform S8 blow molding machine is engineered for high-efficiency production of PET bottles in modern beverage and industrial packaging operations. With a rotary configuration and robust mechanical design, it reaches up to 13,000 bottles per hour, supporting scalable output for medium to high-speed lines. The machine is optimized for PET containers and is suitable for diverse beverage production environments, including water, beer, wine, spirits, milk, oil, and carbonated soft drinks. Krones engineering ensures excellent reliability, consistent bottle quality, and streamlined changeovers. Designed as a versatile component for a used bottling line or as a standalone blow molder, this second hand system delivers precise preform handling and stable heating, coupled with efficient blowing performance. It features an Alaska thread finish, an 8-cavity configuration, and a clockwise work direction, making it a proven choice for beverage production and industrial packaging where uptime and repeatability are critical. Technical Specifications & Performance Data Gbolhcdwsx H Tf Toysl Manufacturer: Krones Model: Contiform S8 Manufacturing year: 2004 Configuration: Rotary Maximum speed: 13,000 bph Container material: PET Current bottle format: 0.5L No. of cavities: 8 Thread/neck finish: Alaska Max container height: 350 mm No. of grippers (inlet–outlet): 6 No. of mandrels: 180 Work direction: Clockwise Working plane height: 1470 mm Electrical supply: 400 V, 3-phase, 50 Hz Operating current: 331 A Operating pressure: 40 bar PLC: Siemens HMI: Krones Advanced Automation & Control Systems The Contiform S8 integrates a Siemens PLC for robust automation and process control, complemented by a Krones HMI for intuitive operation and fast diagnostics. The control architecture supports stable preform heating profiles, accurate blowing cycles, and reliable handling of PET preforms and bottles. Safety interlocks and operator protections are integrated into the guarding and access points to support consistent production with minimized downtime. Production Line Integration Capabilities This blow molding machine can operate as a standalone unit or integrate seamlessly into a complete used bottling line. It interfaces effectively with upstream preform feeding systems and downstream air conveyors, rinsers, fillers, and labelers. Format changeovers are streamlined around the 8-cavity rotary platform, and the Alaska neck finish provides compatibility for a wide range of closures and filling monoblocks across beverage production. Machine Condition & Maintenance History The machine is available in multiple supply configurations: as-is, refurbished and guaranteed, or ready for operation with compatible spare parts. When supplied refurbished, a 6-month warranty is available, offering confidence in performance and longevity for second hand indus...

Condition: used, Year of construction: 2009, machine/vehicle number: SO128, Used Blow Molding Machine Contiform This used Krones Contiform S14 blow molding machine is engineered for high-output PET bottle production in modern beverage manufacturing. With a maximum speed of up to 25,000 bottles per hour, it is an excellent choice for businesses looking to expand capacity or upgrade a used bottling line with reliable second hand industrial packaging equipment. The machine is equipped with a Siemens PLC and a Krones HMI for robust automation and operator-friendly control. Neck-handling transfer ensures stable bottle handling across formats, while the rotary architecture delivers consistent performance for beverage production. Manufactured by Krones, a global leader in beverage production technology, this model supports PET containers and is suitable for a wide range of products including still and sparkling water, soft drinks, milk, oil, beer, wine, and spirits. The current setup is optimized for 1.5L format and a maximum container height of 320 mm, making it a versatile asset for PET bottle processing in integrated bottling equipment lines. Technical Specifications & Performance Data Manufacturer: Krones Golhcex H Tgdodwysbl Model series: Contiform Model code: S14 Year of manufacture: 2009 Maximum speed: 25,000 bottles/hour Container material: PET Current format: 1.5L Maximum container height: 320 mm Worktable height: 1470 mm Type: Rotary Transfer type: Neck-handling Neck finish: Alaska Number of cavities (molds): 14 Number of spindles: 7 Number of grippers (inlet/outlet): 7 Work direction: Counterclockwise Electrical supply: 400 V, 3 PH + N, 50 Hz Rated current: 313 A Advanced Automation & Control Systems The machine features a Siemens PLC for reliable process control and a Krones HMI for intuitive operation, recipe management, and diagnostics. The electrical configuration at 400 V and 50 Hz with 3 PH + N supports stable, industrial-grade performance. Safety guarding and interlocked access points facilitate secure operation during production and changeovers. Neck-handling design contributes to smoother format adjustments and reduced container scuffing. Production Line Integration Capabilities This Krones Contiform S14 can operate as a standalone blow molder or be integrated into a complete beverage production line. It interfaces smoothly with preform handling systems, high- and low-pressure air utilities, and downstream conveyors leading to filling, labeling, and packaging machinery. The rotary platform and neck-handling transfer provide compatibility across typical PET bottle sizes, including 1.5L and other common formats used in water and soft drink applications. Machine Condition & Maintenance History The unit is available in multiple supply options: as-is (seen and liked), refurbished and guaranteed, or ready for operation with compatible spare parts. A 6-month warranty is available when supplied refurbished. These options provide flexibility to match project timelines ...

Condition: ready for operation (used), Year of construction: 1988, functionality: fully functional, Industrial blow molding machine BATTENFELD FISCHER model VK1-1, year 1988, currently operational. Single-station machine used for industrial packaging production via blow molding process. Functional equipment available for inspection at the plant in Albacete (Spain). Gbelheyn Ityecdwysl Net price EXW Albacete. Negotiable.

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, Industrial blower VOITH FISCHER model VK1-07, year 1979, currently operational. Gbolsyn Iuwohcdwyol Compact machine suitable for the production of small containers using blow molding process. Equipment has been used in an industrial environment and is available for inspection at the plant in Albacete (Spain). Net price EXW Albacete. Negotiable.

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 2.065.0, clamping force: 200 kN, New digital control from BBM. Two sets of extruder heads (see attached pictures). Gelhsw Dcybecdwyjbl

Condition: ready for operation (used), Year of construction: 1988, A Bekum injection blow molding machine without molds is available. Industry: pharmaceutical, product: plastic bottles, operating bottle volume: 10ml, production capacity: 10ml: approx. 4800pieces/h, materials: PE/PP, machine dimensions X/Y/Z: approx. 6250mm/2200mm/2200mm, weight: approx. 12000kg. The rotary drive of the rotary table appears to be worn out. The injection cylinder of the unit is leaking and further leakages are present. An on-site inspection is possible. Expected to be available from July 2026. Gjlhjyz Ap Decdwyebl

Condition: used, Year of construction: 2010, operating hours: 39,000 h, machine/vehicle number: SO134, Used Nissei blow molding machine ASB 50MB 2010Technical Specifications & Performance DataThis Nissei ASB ASB-50MB is a one-stage biaxial orientation stretch blow molding machine designed for precision PET bottle production. As a compact rotary indexing platform, it integrates injection and blow molding in a single cycle, ensuring excellent neck finish accuracy and consistent wall distribution. This second hand machine offers reliable output for beverage production and industrial packaging projects seeking a proven, cost-effective solution.Manufacturer: Nissei ASB engineeringModel: ASB-50MBManufacturing year: 2010Process: One-stage ISBM (injection-stretch-blow)Production speed: approx. 1000 bph with 4 cavitiesCavities: current setup 4 (machine supports 1–6 cavities depending on article)Bottle formats: 40 ml to 750 mlContainer type: PET bottlesElectrical data (plate): 400 V AC heater, 6.1 kW; motor 380 V AC 18.5 kW and 200 V AC 0.75 kW; 50 HzInstalled power (approx.): 25.35 kWAdvanced Automation & Control SystemsThe ASB-50MB platform offers stable, repeatable operation with synchronized control of injection, conditioning, stretching, and blowing stations. Its rotary indexing table ensures precise timing between stages, supporting high-quality bottle formation in a compact footprint. Operator interfaces facilitate routine adjustments and process monitoring, while integrated heating controls deliver accurate temperature profiles for consistent preform conditioning.Rotary indexing one-stage machine with coordinated station controlDedicated heater power section for precise thermal managementStructured electrical supply at 50 Hz for stable operationDesigned for quick mold and format changeovers within the compatible size rangeIntegrated protections and interlocks for safe machine accessProduction Line Integration CapabilitiesThis blow molding machine integrates seamlessly within a used bottling line or as a standalone PET container production unit. Its output can feed conveyors to downstream rinsing, filling, capping, and labeling equipment in beverage production and other industrial packaging applications.Standalone or inline configuration with downstream bottling equipmentCompatible with standard conveyor interfacesFormat flexibility for 0.04L to 0.75L PET bottlesSuitable for water, juice, CSD, and other PET applications when paired with appropriate downstream systemsMachine Condition & Maintenance HistoryThis second hand ASB-50MB is in good working condition and ready for operation. The machine shows approximately 39,000 operating hours, consistent with typical industrial usage while retaining solid performance potential for new production environments.Operational status: ready for operationOperating hours: approx. 39,000Well-maintained example from a proven ISBM seriesOperational Perfo... Gbolhcdjyhbf Ajwyel

Condition: used, Year of construction: 2006, operating hours: 33,000 h, machine/vehicle number: SO135, Used Nissei blow molding machine ASB 50MB 2006Technical Specifications & Performance DataThis one-stage biaxial orientation stretch blow molding machine delivers consistent PET bottle production with reliable throughput and compact footprint. Manufactured by ASB INTERNATIONAL PVT. LTD. (Nissei ASB engineering), the ASB-50 MB combines injection, conditioning, and blow molding in a single machine, reducing handling and improving quality control for a second hand or used bottling line seeking dependable PET bottle supply.Manufacturer: ASB INTERNATIONAL PVT. LTD. (Nissei ASB)Model: ASB-50 MBMachine type: One-stage biaxial orientation stretch blow molding machineYear: 2006Production speed: ~1,000 bottles/hour with 4-cavity moldCavities: Configurable 1–6; supplied in 4-cavity configurationFormats: 40 ml to 750 ml (typical PET bottle sizes within this range)Containers: PET bottlesElectrical supply: 400 VAC, 50 HzInstalled power (observed): approx. 20.1 kWMotor circuits: 380 VAC — 13.5 kW; 200 VAC — 0.5 kWHeater circuits: 400 VAC — 6.1 kWAdvanced Automation & Control SystemsThe ASB-50 MB architecture enables precise control of heating and stretch-blow parameters for stable bottle quality across different formats. Typical one-stage controls coordinate injection, conditioning, and blowing stations for repeatable results, with safety interlocks and guarding to protect operators. Quick-change mold capability supports efficient format changes, minimizing downtime during product transitions common in industrial packaging and beverage production environments.Production Line Integration CapabilitiesDesigned for PET bottle manufacturing upstream of filling, capping, and labeling systems, this machine integrates effectively with conveyors, accumulation tables, and downstream bottling equipment. Its one-stage process eliminates the need for separate preform handling equipment (such as preform unscramblers, tippers, and elevators), simplifying line layouts in a used bottling line. Bottle format flexibility from 40 ml to 750 ml supports water, juice, CSD, and other beverage applications when equipped with appropriate molds.Machine Condition & Maintenance HistoryThis second hand machine is presented in ready-for-operation condition, suitable for immediate integration into an existing beverage production or industrial packaging setup. As with any pre-owned blow molding machine, commissioning checks and routine maintenance are recommended to align the installation with site utilities and product specifications.Operational Performance & VersatilityThe ASB-50 MB delivers stable output around 1,000 bph in a 4-cavity configuration, with potential to reconfigure up to 6 cavities depending on molds and process settings. Its one-stage design promotes excellent neck dimensional control and clarity, supporting a wide range of bottle shapes within the 40–750 ml range. When paired with suitable molds and process recipes, it can produce PET containers for ... Gjlhcdwsyhbfieyobl

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, overall weight: 8,700 kg, workpiece length (max.): 165 mm, workpiece diameter (max.): 35 mm, production capacity: 7,200 unit/h, TECHNICAL DETAILS Number of cavities: 6 Max. output: 7,200 bottles/h Product dimensions Max. preform length: 165 mm Preform diameter: 18–35 mm Ring diameter: 27–42 mm Max. neck finish diameter: 38 mm Neck height: 9–27 mm Max. bottle height: 350 mm Max. bottle diameter: 105 mm Max. bottle volume: 2 l MACHINE DETAILS Dimensions & Weight Blow module (L × W × H): 3,293 × 2,325 × 3,196 mm Control cabinet (L × W × H): 1,998 × 602 × 2,410 mm Blow module: 6,300 kg Control cabinet: 1,200 kg Preforms feeder: 1,200 kg Total weight: 8,700 kg Noise level: 83 dB(A) Installed power Installed power: max. 160 kW Reference consumption (1,500 ml bottle): 88 kW Golhcdwoyrfvgeyjbl Reference consumption (1,000 ml bottle): 62 kW Reference consumption (500 ml bottle): 45 kW Infrared heating (9 zones): 132 kW Operation and feed system: 28 kW Power supply Supply voltage: 230/400 V ±10 % Frequency: 50 Hz ±1 % Cooling water Cooling capacity: 20,000 kcal/h Water temperature: 8–12 °C Flow rate: max. 5 m³/h Pressure: 3–5 bar Compressed air Air consumption at 40 bar (0.25–2 l bottle): 180–700 Nm³/h Air consumption at 7 bar (operating air): 35 Nm³/h

Condition: used, Year of construction: 2017, machine/vehicle number: SO133, Used SIPA blow molding machine 2017 - 18.000 bphTechnical Specifications & Performance DataThis SIPA SFR EVO3 is a rotary stretch blow molding machine designed for high-efficiency PET bottle production in modern beverage operations. As a robust second hand asset for industrial packaging, it delivers reliable output for beverage production lines seeking consistent quality and throughput. The machine features an 8-cavity configuration and supports a broad range of bottle sizes commonly used across water and soft drink applications.Manufacturer: SIPAModel: SFR EVO3Year of manufacture: 2017Production speed: up to 18,000 bottles per hourNo. of cavities: 8Neck finish: PCO 28-1810Bottle formats: Compatible with 0.5L, 1.0L, 1.5L bottle formatsContainer type: Designed for PET bottle handlingBottle diameter (min–max, diagonal): 50–125 mmBottle height (min–max, without neck): 80–349 mmAdvanced Automation & Control SystemsEngineered for consistent performance, the SFR EVO3 integrates advanced automation with precise preform heating and controlled blowing sequences. Operator-friendly HMI and PLC-based control help streamline recipe management, process monitoring, and format changes. The machine architecture prioritizes repeatability of pre-blow and blow phases, promoting stable bottle quality across high-speed runs.Automated process control with user-oriented HMIEfficient preform heating for uniform material distributionQuick-change features to support format adjustmentsSafety-interlocked guards and emergency stop circuitry for operator protectionProduction Line Integration CapabilitiesThis blow molder integrates seamlessly into used bottling line configurations for PET, whether operated as a standalone unit upstream of a filler or synchronized within a complete beverage production line. The included preform feeding and preform cooling systems facilitate smooth infeed and stable production conditions, enhancing overall line efficiency.Inline or standalone operation with standard conveyor interfacesCompatible with downstream filling, capping, and labeling equipmentFlexible handling across 0.5L, 1.0L, and 1.5L bottle formatsSuitable for modernization or capacity upgrades in second hand packaging machinery setupsMachine Condition & Maintenance HistoryThe machine is currently working, indicating operational readiness within an active environment. Built in 2017, it offers a modern platform for operators seeking dependable performance and repeatable quality in PET bottle production. Its status as a functional, second hand unit makes it a strong candidate for rapid deployment in industrial packaging lines.Operational Performance & VersatilityWith 8 cavities and up to 18,000 bph output, the SFR EVO3 balances speed and quality for high-demand beverage production. The PCO 28-1810 neck standard supports widespread closure compatibility, simplifying cap sourcing and ... Gslhcjyhbihsdwyebl

Condition: excellent (used), Year of construction: 1999, operating hours: 48,400 h, 1.0 used blow molding machine Gbjlhcjynutmedwyjl Manufacturer: Fischer - W. Müller Model: FMB 3-120 Year: 1999 Clamping force: 120 tons Extruder type: 120/24 WT Accumulator head: BFKS25 (approx. 17.75 kg) This machine is capable of producing barrels up to 200 liters in size. Video available!

Condition: used, Year of construction: 1998, Automatic PET bottle blowing machine Manufacturer: SIDEL Gbolhcoutni Rjdwyjl Type: SBO 16/16 S1 Year of manufacture 1998 Capacity: 16,000 for 1.5 L bottles and up to 19,000 bph for 0.5 L bottles Installed power: 347 kW Includes 1.5 L moulds Preform feeder Chiller cooling unit Technical condition: used machine, functional until dismantled. The machine is currently dismantled, assembled in elements and prepared for transport. Full and original technical documentation.

Condition: used, Year of construction: 1992, Automatic PET bottle blowing machine Manufacturer: SIDEL Type: SBO 4 S1 Year of prod. 1992 Capacity: 4,000 for 1.5 L / 2 L bottles Installed power: 150 kW Gjlhcdwswa Rhrsyjbl Includes 1.5 L molds Preform feeder Technical condition: used machine, starts up, program is functional

Condition: like new (used), Year of construction: 2022, operating hours: 200 h, functionality: fully functional, screw diameter: 70 mm, overall weight: 600 kg, clamping force: 80 kN, total width: 2,800 mm, total length: 4,000 mm, total height: 2,260 mm, Main Features: 1. Computer Control System (PLC) – Japanese Mitsubishi PLC 2. Electrical Cabinet – All electrical components are sourced from globally renowned brands, ensuring quality and stability. 3. Touch Screen – Innovation computer control system 4. Advanced Hydraulic Cylinder from Germany 5. Linear Guideway 6. ABB Inverter from Switzerland & Rexroth from Germany 7. Large Diameter Galvanized Steel Pipes 8. Electric Lifting Platform 9. Ceramic Heater 10. Hydraulic System & Valve Connections – From Yuken Industry Technical Specifications: • Suitable Material: PE, PP, and others • Max Volume: 6 L • Production Capacity: 170-260 pcs/h • Dimensions: 4.0 × 2.26 × 2.8 m • Weight: 6T Plasticization System: • Reducer: Hard finishing, high strength, low noise • Screw: Ø 70 mm, L/D ratio 24, 38CrMoALA, cooling system available • Plasticization Capacity: 100 kg/h (HDPE) Gbjlhev Iflpscdwyjl • Heating Zones: 3-4 aluminum heaters, automatic heating • Heating Power: 12 kW/h • Extruder Motor: Three-phase asynchronous motor (380V, 50HZ) • Cooling Fan: 4 zones, automatic cooling Extrusion System: • Material: High-grade alloy steel, central feeding • Number of Die Heads: 1 • Max Die Mouth Diameter: Ø 160 mm • Heating Zones: 4, stainless steel heating cycle • Heating Power: 5-7 kW Clamping System: • Features: High strength, rigidity, central mold locking, stable mold opening & closing • Clamping Force: 80KN • Template Distance Adjustment: 170-520 mm • Max Mold Size: 380 × 420 mm Electric System: • Automatic Monitoring, Fault Alarms, Auto Counting, Auxiliary Functions • Control Interface: Touchscreen with self-diagnosis alarm system • Temperature Control: Automatic temperature control module • Motion Control: Inovance (Chinese/English version) Hydraulic System: • Features: Multi-functional integrated hydraulic block, proportional control, high efficiency • Oil Pump Motor: Three-phase asynchronous motor (380V/220V, 50/60HZ) • Oil Pump: Imported double pump • Valves: Imported oil pump valves and connections • Oil Pipes: Double-layer wear-resistant • System Pressure: 60 kg/cm² • Cooling System: Separate water cooling cycle, oil cooler Pneumatic System: • Brand: Taiwan AIRTAC pneumatic system • Air Pressure: 0.6 MPa • Air Displacement: 0.8 m³/min • Electromagnetic Valve: Taiwan AIRTAC Main Components: Electronic Parts: • PLC Control System: MITSUBISHI from Japan • Touch Screen: INOVANCE • Temperature Controller: HUICHUAN • Auxiliary Relay: OMRON • Contactor: Schneider from France • Electric Motor: Three-phase 380V • Power Source: TAIWAN MEANWELL • Transducer: ABB from SWITZERLAND Hydraulic Parts: • Oil Pump: TAIWAN HIGH-TECH • Valve: YUKEN • Oil Pump and Connection: YUKEN • Sealed Part: HALLITE Air Control System: • Cylinder: AIRTAC • Air Valve: AIRTAC This blow molding injection machine was purchased directly from a factory in China for a specific project that was never realized. The machine was used for only one month. Location: Siemianowice Slaskie, Poland We also have peripheral equipment available for sale, such as: • 5 HP AIR COOLING SYSTEM • Auto Loading • 150 kg Color Mixer • Scraps Crusher

Condition: used, Year of construction: 2022, functionality: fully functional, machine/vehicle number: HY-43, screw diameter: 110 mm, total width: 2,500 mm, total length: 8,500 mm, total height: 9,500 mm, power: 350 kW (475.87 HP), Equipment: documentation/manual, The two-layer blow molding machine is a new generation of plastic extrusion blow molding equipment. It is mainly used for molding kayaks, canoes, surfboards, and other large hollow plastic products. The machine uses a motor designed to deliver high torque and sufficient power for material cutting. The molten plastic is extruded into a storage die head. When the material reaches the preset volume, the wall-thickness control system continuously adjusts the opening ratio. Gbjlhox R R Igscdwysl The extruded material is formed into a parison, which is then molded into the final product.

Condition: like new (used), functionality: fully functional, machine/vehicle number: SBO 6/10, Sidel Stretch Blow Moulding Machine Max. output: 6.000 bottles/hour. Max. bottle size: 3.000 cc. Blow stations: 6. Machine is in very good conditioning and well maintained. GENERAL INFORMATION The SBO 6/10 has 6 molds and 10 heating modules. Will work with a wide range of bottle sizes and styles from 0.25 to 3 liters. Sidel 2-step ^PET stretch-blow molders require previously manufactured preforms be supplied to the machine. Separating the bottle manufacturing and preform manufacturing processes allow production to be optimized, provide greater flexibility of operation and use, and provide higher production output rates and yield. MAXIMUM PREFORM DIMENSIONS Neck height 9 – 41 mm (measured from bottom of support ring) Minimum inside diameter of neck 19 mm Maximum outside diameter of neck 34 mm Preform support ring diameter 29 – 51 mm Maximum preform length 210 mm MAXIMUM BOTTLE DIMENSIONS Maximum bottle diameter 130 mm Maximum bottle height 380 mm Bottle capacity 0.25 – 3 liters Gbolhcog Ailcedwyel AVERAGE PREFORM WEIGHTS (non carbonated and carbonated liquids) 0.25 liter bottle 14-20 grams 0.50 liter bottle 20-33 grams 1.00 liter bottle 26-40 grams 1.50 liter bottle 35-51 grams 2.00 liter bottle 44-58 grams 3.00 liter bottle 68-84 grams BLOW WHEEL Height 3.5 meters Number of molds 6 Closing force 10 tons Item height (under neck) at outfeed 1.4 meters approximately Machine DC drive motor power 4 KW HEAT CONDITIONING Height 2 meters Number of oven heating units 10 Number of heating zones per unit 8 Maximum power 170 KW ELECTRICAL USAGE Maximum supplied power 200 KW Average consumption 100-150 KW/hr (varies per bottle being produced) COMPRESSED AIR Supplied power from 7-35 bar Pressure 7 bar Flow rate 50-100 Nm3/hr (varies per bottle being produced) Blow pressure – champagne base up to 25 bar Blow flow rate – champagne base 110-550 Nm3/hr Blow pressure – petaloid base up to 35 bar Blow flow rate – petaloid base 155-770 Nm3/hr CHILLED WATER Temperature 10-12 degrees Centigrade Pressure 5-6 bar Flow rate up to 6 cubic meters/hour Kcal to be removed up to 16,000 Kcal/hour WEIGHT Blow wheel with molds 8 tons Heat conditioning unit 2.2 tons Preform feeder 0.65 tons Electrical cabinet 0.85 tons PREFORM HEAT CONDITONING The preforms are transferred neck up to the heat conditioning device. This unit continuously insures the preforms are inverted before passing, neck down, in front of the heating units and then inverts them again. During the heating phase, the preforms are rotated and their necks protected from the heat in order to optimize the distribution of heat without deforming the neck. Heating is insured by 10 heat modules. Each unit can accommodate up to 8 infrared lamps stacked horizontally whose ends are air cooled. The heating power of 8 zones, corresponding to the 8 rows of lamps, can be controlled in order to optimize the heat profile. These zones are regulated on all SBO Models. After heating, a control by infra-red camera of preform temperature enables regulation of the zones under control, thus insuring maintenance of the required temperature.

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, product height (max.): 380 mm, workpiece diameter (max.): 130 mm, production capacity: 7,200 unit/h, TECHNICAL DETAILS Number of cavities: 6 Capacity with standard bottles: up to 7,200 bph Product formats Bottle volume: 0.25 – 3.0 L Max. bottle height: 380 mm Max. bottle diameter: 130 mm Preform dimensions Max. preform length: 210 mm Neck inner diameter: 34 mm MACHINE DETAILS Dimensions & Weight Blow module dimensions: 2,000 x 2,200 x 2,200 mm Blow module weight: 8,000 kg Oven dimensions: 3,000 x 1,100 x 2,100 mm Oven weight: 2,000 kg Control cabinet dimensions: 1,500 x 1,000 x 2,100 mm Control cabinet weight: 1,000 kg Transformer 415V / 380V dimensions: 1,000 x 500 x 2,000 mm Transformer weight: 500 kg Preform hopper and conveyor dimensions: 3,000 x 1,500 x 3,500 mm Preform hopper and conveyor weight: 600 kg Preform feeder dimensions: 2,000 x 2,500 mm Preform feeder weight: 250 kg Infeed guide rail length: 2,000 mm Power supply Total power: 142 kW Mains connection: 380/420 V +/- 10%, 50 Hz +/- 1% Cooling water Cooling capacity: 16,000 kcal/h Water temperature: 10 – 12°C Gjlhcdox A Uu Eowyobl Flow rate: up to 6.0 m³/h Water pressure: 5 – 6 bar Compressed air Service air pressure: 7 bar Service air flow: 50 – 100 Nm³/h Blowing air pressure: up to 35 bar Blowing air flow for 0.25 – 3.0 L: 155 – 770 Nm³/h EQUIPMENT Transformer 415V / 380V Preform hopper and conveyor Preform feeder Infeed guides Adaptation to other voltages possible

Condition: ready for operation (used), Year of construction: 2008, A SIG Corpoplast blow molding machine is available. Output: 21600 bottles/h, bottle formats: 500ml/750ml/1000ml/1500ml, max. blowing air pressure: 40bar, dimensions X/Y/Z: approx. 7000mm/4300mm/3100mm, weight: approx. 20000kg. Including preform feeder Transver AG, year of construction: 2008, silo, elevator, sorting and chute. Documentation available. On-site inspection is possible. Gbolhcdwjt Eu Azeysl

Condition: ready for operation (used), Year of construction: 2001, A complete 5-layer coextrusion blown film line with 5 extruders and all peripheral equipment is available. Total line dimensions X/Y/Z: 14m/22m/11m, blow head: Kiefel Worms FSBK 500 with IBC, die diameter: 500mm, film width range: 700mm-2000mm, haul-off width: 2000mm, winding width: 2000mm, line speed: 120m/min, melting capacity: 500kg/h, total power requirement: approx. 300kW. 1) Double winder Wintech, winding width: 2000mm, film thickness range: 35µm-150µm, max. roll diameter: 1000mm, max. roll weight: 1900kg, core inner diameter: 152mm/6inch. 2) Extruder Kiefel Worms 70.29D, power: 89kW, screw: 5-zone barrier screw, speed: 125rpm, renewed: 2010. 3) Adhesive extruder Kiefel Worms 50.25D, power: 34kW, screw: 3-zone barrier screw, speed: 200rpm. 4) Center extruder Kiefel Worms 50.25D, power: 34kW, screw: 3-zone core progressive screw, speed: 175rpm. 5) Adhesion promoting extruder Kiefel Worms 50.25D for the outer layer, power: 34kW, screw: 3-zone barrier screw, speed: 200rpm. 6) Kiefel Worms 80.25D outer layer extruder, power: 125kW, screw: 5-zone barrier screw, speed: 150rpm. 7) Reinhold SRK 200/9.6 film calibrating device. The entire line is controlled by a Plast Control system. Further components: integrated width measurement, C-scan for profile measurement, web center control, corona pre-treatment, film pre-draw. Including a replacement FSBK 5-layer blow head with IBC, replacement rollers, annular gap blower with filter, suction units, crane and external system terminal. Documentation available. On-site inspection is possible. Gbolhev T An Socdwyol

Condition: ready for operation (used), A 13-layer blown film line Kuhne for the production of biaxially oriented high-barrier films is available. Film thickness range: 20µm-80µm, max. film width: 1400mm, max. output capacity: 400kg/h, extruders: 13 units, max. die head pressure: 500bar, flex ring die: 250mm/300mm, calibration tools: 200mm/225mm/250mm/280mm/300mm, yield: 80%-90%. Laminating films: sealing layer thickness: 25µm-35µm, printing layer thickness: 25µm-45µm. Monofilms: shrink lid thickness: 23µm-28µm, AF lid film thickness: 25µm-45µm, top and bottom film thickness: 75µm, balloon film thickness: 25µm-31µm. Documentation available. An on-site inspection is possible. Gbslhcsw R Dh Eodwyol

Condition: excellent (used), Year of construction: 2003, PET bottle blowing machine Gbolhjvddkvscdwyol Manufacturer: KRONES Model: CONTIFORM K781 Efficiency: 12,000 bph Includes 1.5 L and 0.5 L bottle molds Power: 150 kW Air requirement: 10 bar - 1500 m3/h, 30 bar - 1000 m3/h Set dimensions (blow mold + preform feeder): 1100 x 340 cm, h: 450 cm Blow mold dimensions: 500 x 340 cm, h: 250 cm Feeder dimensions: 600 x 250 cm, h: 450 cm Air requirement: 10 bar - 1500 m3/h, 30 bar - 1000 m3/h Year of production: 2003 Technical documentation of machine operation Very good condition

Condition: used, Semi-automatic PET bottle blow molding machine Geljugu E Rehcdwyebl Manufacturer: FERENC Model: F-1400 Year of manufacture: 2006 Output: approx. 800 pcs/h Number of molds in the machine: 2 x 5 L (48 mm cap) Oven dimensions: - Length: 900 mm - Width: 900 mm - Height: 1200 mm Blow molder dimensions: - Length: 1800 mm - Width: 750 mm - Height: 2000 mm Set weight: 1200 kg Technical condition: used machine
