Used Friulmac Double End Tenoner for sale (10)

Condition: used, Year of construction: 2003, functionality: limited functionality, machine/vehicle number: 3458 F, working width: 2,500 mm, Double tenoner FRIULMAC 2003, 3+3 heads Giodpfx Ajx Rdrfjqxjt

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 3928 A, working width: 250 mm, Equipment: documentation/manual, Motor Power: 30 kW Equipped with: Hnebni Iow A A E Is Rp Tot 1+1 saws 1+1 milling unit 1+1 drilling unit Max length: 1000 mm Max width: 250 mm Max thickness: 50 mm double end tenoner, double drilling, step by step Gisdpfx Aexix Tfsqxjt

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, FRIULMAC IDRAMAT TC/5WS+1/2 2.5 – Throughfeed CNC Machining Center for Furniture Components Year of manufacture: 2019 Condition: Very good Availability: By arrangement Inspection: By arrangement Double-sided throughfeed CNC machining center FRIULMAC IDRAMAT TC/5WS+1/2 2.5, ideal for finishing solid wood furniture components. The machine integrates several work processes in a single production line: • Crosscutting & trimming • End drilling • Vertical and horizontal drilling • CNC milling • Glue application & injection • Dowel insertion Production output: 14–16 parts/minute Technical data • Material: Solid wood • Workpiece length: 200–2500 mm • Workpiece width: 30–200 mm • Workpiece thickness: 14–48 mm • Working height: 945 mm (0/+20 mm) • Voltage: 400 V / 50 Hz • Control system: CNC CNI with touchscreen Machine configuration 1. Throughfeed machining center IDRAMAT TC • Heavy-duty steel construction • Automatic width adjustment (movable shoulder) • Vertical magazine with photoelectric sensor • Servo-driven feed shoes • Upper pressure unit with rubber belts • Pneumatic workpiece clamping Working stations Giodpfx Ajyk Empsqxot 1st station – Scoring/Trimming B 2/B 8 • 2× motor, 3 kW each • 7,600 rpm • Max. saw blade Ø 125 + 180 mm 2nd station – End drilling M • Motor 3 kW • 5,000 rpm • Drilling stroke 25–80 mm • Electric cylinder with brushless motor 3rd station – CNC vertical milling J 3D • Electric motor 8 kW • 9,000–12,000 rpm • X axis automatic, Y/Z manual • HSK63C tool mount 4th station – CNC vertical milling J 3D (second unit) • Identical to 3rd station 5A station – Glue injection R 4 • Electronically adjustable glue volume • 2+2 glue injectors • Tilt ±30° 5B station – Dowel unit R 5 • Vibratory feeder • Dowel lengths 30 and 60 mm • Minimum spacing 16 mm • Pneumatic stroke 80 mm Outfeed area – Drilling bridge PO 2/PN 2 • Combined vertical and horizontal drilling operations • 3× vertical drilling units • 3× horizontal drilling units • Swiveling table • Automatic workpiece transfer • Chip conveyor with auger Equipment • Soundproof enclosure • Safety guard • Workpiece return to operator • Vertical hopper feeder • Complete documentation: o Operating manual: Slovak o Touch panel/labels: Slovak o Electrical/pneumatic diagrams: English The photos show examples of products that can be manufactured with this machine. Price: €290,000 excl. VAT, shipping, and disassembly.

Condition: good (used), functionality: fully functional, double tenoner, double drill, step by step Gsdpfxew A A E Is Aqxeit Equipped with: 1+1 saws 1+1 milling group 1+1 drilling group Max length: 2500 mm

Year of construction: 2007, condition: excellent (used), I sell the double end cutting and tenoning machine FRIULMAC IDRAMAT, Year 2007. Gsdpfxoib A E As Aqxoit Working width up to 2500mm Configuration left side / fix: 1 + 1 pcs. cutting saw aggregates / 3,0 + 3,0 KW 1 + 1 pcs. grooving saw aggregates front + back Configuration right side / moving: 1 + 1 pcs. cutting saw aggregates / 3,0 + 3,0 KW 1 pc. special milling aggregate / 5,5 KW Material pressure feeding band from top Special construction, suitable also for sizing. Throughfeed machine. Siemens Simantic control panel. Very good condition. Available immediately.

Condition: new, Year of construction: 2022, functionality: fully functional, Brand New Friulmac EQ 004 2.5 with feeding belt and a feeding hopper Touch-Screen Operation and automatic adjustment Working length - min 190mm - max 2500mm width - min 30mm - max 250mm thickness - min 12mm - max 35mm Speed - 6 - 25m/min 2 x 2 Hoger - 3kW - 720 rpm Main Profiling Head - 4kW - 7200 rpm Gedpfx Aevupm Deqxjit For more information I can send you the original documentation

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 32664, collet bore: 40 mm, saw blade diameter: 220 mm, main saw diameter: 220 mm, overall weight: 1,200 kg, table length: 5,000 mm, positioning accuracy: 0.1 mm, table width: 250 mm, working range: 250 mm, pressure: 6 bar, type of input current: three-phase, total width: 250 mm, cutting width (max.): 250 mm, compressed air connection: 6 bar, cutting diameter: 220 mm, extraction nozzle diameter: 120 mm, working height: 30 mm, Friulmac Randomat E 001 Serial No: 32644 Year 2001 in excellent condition specially made for End Matching all types of wood flooring. Fitted with a Sound & Safety Enclosure with front sliding doors and an entrance door at each end. 2 x 4kw motors do the cutting of the tongue & groove. Will machine random or fixed lengths from 250m/m up to 6m. long. 6m. Long Infeed Belt Conveyor, and a 6m. Long Outfeed Belt Conveyor. Siemens Simatic OP7 Control System. Gjdpfx Aex Ec Hnsqxeit Complete with documentation for Operating and Programming.

Condition: used, machine/vehicle number: 1656, SECOND-HAND THROUGHFEED LOADER FRIULMAC MOD. FN3 - Min/max working length 250/1300 mm - Max working width 160 mm - Min/max working thickness 10/80 mm - Production capacity : 0-50 psc / min - Diam. Blades 400 mm - S/N 1656 Giodpfxsqmpnle Aqxot

Condition: good (used), units span 1350mm Gjdpfx Ajw Ad Htoqxeit two motors 5,5kW feeding from magazine hydraulic feeder manual regulation of top pressure

Condition: used, SECOND-HAND THROUGHFEED LOADER FRIULMAC MOD. DUALFEED - CE RULES - Min / max working length 260/1300 mm Godpfxowr Ugps Aqxoit - Min / max working width 40/110 mm - Min / max working thickness 10/80 mm - Productivity : 0-55 psc / min - Diam. Blades 400 mm
