Powder painting equipment

Wagner

Wagner Powder painting equipment for sale!
Powder coating device, year 2010 consisting of:
Booth: Prima Cube 16000
Powder supply: Powder Center
Powder recovery: Cyclon Filter 16000
Movement generator: KHG 350
Production process configurations INCLUDING:
I. Presumes
Maximum size of parts: LxWxH=2600x400x1850 mm
II. Equipment
Technological Conveyor automatic speed V=1.2 mtrs/min.
Speed regulation between 0.5-2.5 mtrs/min
1. Pretreatment Stand MNA-3-LPG, total size 16,7 mtrs
Enter size L=2,5 mtrs
a. Washing, degreasing and phosphating; L=3,6 mtrs
-number of spray frames – 10
-number of nozzles in frame – 18
-number of nozzles in total – 180
-delivery of the pump – 162 m3/h
-power of the pump – 15 kW
-vessel 4 m3 for active liquid
-inner heat exchanger with LPG burner – 160 kW
-temperature 500C
-mechanical oil separator
- solution filter
-the dosing system, membrane pump with regulator
-washing time – 3 min
b. Dripping zone L= 3,1 mtrs
-time of dripping – 2 min 30 sec
c. First rinsing; L= 1,2 mtrs
-number of spray frames – 4
-number of nozzles in frame – 18
-number of nozzles in total – 64
-delivery of pump – 38 m3/h
-power of the pump – 3 kW
-vessel 1,5 m3 for water
-first rinsing time – 1 min
c. Dripping zone L= 3,1 mtrs
-time of dripping – 2 min 30 sec
d. Fine rinsing; L= 1,28 mtrs
-number of spray frames – 3
-number of nozzles in frame – 18
-number of nozzles in total – 54
-delivery of pump – 33 m3/h
-vessel 1,5 m3 for water
-power of the pump – 3 kW
-one extra spray frame
-number of nozzles in frame – 18
-fine rinsing time – 1 min
e. Dripping zone L= 2 mtrs
Gusdpfx Ajww Adteqxjb
-time of dripping – 1 min 40 sec
Three openings to connect to exhaust system with three ventilators
Operating space made of stainless steel.
Pipes made of PVC or S/S.
1 unit
2. Automatic Dryer after water AST-1-KLPG:
- operating space dimensions LxWxH=7000x3000x2800
- air curtains each side to avoid heat losses
- one indirect heat exchanger heated with liquid petrol gas to produce 200 kW of rated power
- three blowers 6000 m3/h of air delivery
- two openings to connect to exhaust system
- temperature sensor and temperature regulator
- overheating sensor
- circulation sensor
- operating space made of zinc plated steel
- thermal insulation 200 mm thick
- drying time 10 min
1 unit

3. Automatic Curing Oven APT-2-KLPG for curing powder paints
- operating space dimensions LxWxH=10200x3600x2800
- air curtains on one side to avoid heat losses
- two indirect heat exchangers heated with liquid petrol gas to produce 300 kW of rated power, of each
- eight circulation blowers, capacity of each 6 000 m3/h
- two openings to connect to exhaust system
- temperature sensor and temperature regulator
- overheating sensor
- circulation sensor
- operating space made of zinc plated steel
- thermal insulation 200 mm thick
- curing time 25 min
1 unit
4. An overhead rail conveying system ATR-ADAX, for the paint shop including the following:
• straight track with hangers L=400 mm 146 mtrs
• drive station 2 pc
• tension station 1 pc
• chain lubrication station 1 pc
• drawing of the track supporting structure 1 set
