Chop saw

STROMAB CT800

Condition: good (used), Code: 0239 Brand: STROMAB Model: CT 800 - CE Standard Cutting centre for beams, wood carpentry, wooden roofs, sawmill, balconies, and various - CE Standard Technical data Blade diameter mm 800 Motor power Hp 20 N° 5 axis controlled by programmer : Saw table rotation ( 0-340°) - Speed of the saw table rotation 9 sec. each 180° - Blade beveling from 90° to 45° (speed of the blade beveling 20 sec.) - Height of the blade above the table ( speed 15 sec. each 10 cm) - Beam positioning and measuring ( speed 17 mt/min) - Motorized positioning of the saw table compared to the saw fence mm 600 Fedpfx Ahsxv Su Ae Sopp Photocell for the automatic reading of workpiece beginning Pair of vertical cylinders for cutting optimisation management Cutting capacity at 90° with single stroke: mm 280 x 290 / 250 x 390 / 200 x 450 At 90° with saw table sliding and repeted cut mm 280 x 770 / 250 x 840 At 45° with single stroke mm 200 x 210 At 45° with saw table sliding and repeted cut mm 200 x 760 Maximum ripping height mm 300 Cutting precision : +/- 2 mm on 10 mt beam (straight beam ) - +/-0,2° on rotation edge of the table - +/-0,2° on inclination angle of the blade Control by industry-standard PC Touch- Screen - Windows Operating System - USB ports - Ethernet Rollers: : n° 3 idle rollers benches mt. 2 with rollers diameter 133 mm Widia blade diameter 800 mm Compressed air 6/7 bar Machine weight kg 2900 Total weight kg 3250 (Machine + roller benches)

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 260105, saw blade diameter: 800 mm, overall weight: 2,960 kg, table length: 700 mm, Equipment: CE marking, TECHNICAL DETAILS Min. saw blade diameter: 790 mm Max. saw blade diameter: 800 mm Spindle saw blade diameter: 40 mm Infeed table length: 700 mm Outfeed table length: 700 mm MACHINE DETAILS Main motor power: 15.0 kW Fpjdpfx Asxq Au Ash Sop Dimensions & Weight Dimensions (L x W x H): 3,600 x 2,550 x 2,100 mm Weight: 2,960 kg EQUIPMENT CE marking

Condition: like new (used), electronic adjustment of blade tilt 90° – 45° maximum cutting width: 650 mm electronic adjustment of saw height automatic material feed touch control panel laser rotating work table 0° – 345° maximum blade diameter: 800 mm motor power: 16.6 kW Fedpfx Asxfr Etsh Sopp year of manufacture: 2016 CE marked 400 V

Condition: good (used), Code: 0254 Brand: STROMAB Model: CT 800 - CE Standard Cutting centre for beams, wood carpentry, wooden roofs, sawmill, balconies, and various - CE Standard CE Standard Technical data Blade diameter mm 800 Motor power Hp 20 Fpjdorzqy Nepfx Ah Sop N° 5 axis controlled by programmer : Saw table rotation ( 0-340°) - Speed of the saw table rotation 9 sec. each 180° - Blade beveling from 90° to 45° (speed of the blade beveling 20 sec.) - Height of the blade above the table ( speed 15 sec. each 10 cm) - Beam positioning and measuring ( speed 17 mt/min) - Motorized positioning of the saw table compared to the saw fence mm 600 Photocell for the automatic reading of workpiece beginning Cutting capacity at 90° with single stroke: mm 280 x 290 / 250 x 390 / 200 x 450 At 90° with saw table sliding and repeted cut mm 280 x 770 / 250 x 840 At 45° with single stroke mm 200 x 210 At 45° with saw table sliding and repeted cut mm 200 x 760 Maximum ripping height mm 300 Cutting precision : +/- 2 mm on 10 mt beam (straight beam ) - +/-0,2° on rotation edge of the table - +/-0,2° on inclination angle of the blade Control by industry-standard PC Touch- Screen - Windows Operating System - USB ports - Ethernet Rollers: : n° 4 idle rollers benches mt. 2 with rollers diameter 133 mm Widia blade diameter 800 mm Compressed air 6/7 bar Overall dimensions of mounted machine with roller conveyors: mm 7000 x 2600 x 2200 h Machine weight kg 2900 Total weight kg 3400 (Machine + roller benches)
