Pull stud/ tool holder

SHW

Condition: used, Year of construction: 2007, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, position of the milling head: 360 x 1° en 180 x 1°, spindle speed (max.): 6,000 rpm, type of input current: three-phase, total width: 9,000 mm, total height: 4,900 mm, total length: 16,200 mm, table length: 5,500 mm, table width: 2,600 mm, table load: 10,000 kg, coolant supply: 16 bar, workpiece weight (max.): 10,000 kg, grinding spindle motor power: 30,000 W, feed length W-axis: 1,000 mm, SHW Powerspeed 5 with Heidenhain iTNC530, including: • X-8,000 mm, Y-2,100 mm, Z-1,300 mm • W-1,000 mm with C-axis, with 1600 x 1600 mm (suitable for a 10T table load) • Fixed clamping table with T-slots 22 mm, 5,500 x 2,600 mm • Orthogonal machining head SK50, max. 6,000 rpm, 360 x 1° and 180 x 1° • Power P = 30 kW at 100% ED / 41 kW at 40% ED. • Tool holder SK50 according to DIN 69871/72-AD Fpodpfjzz Hkpsx Amtjl • Heidenhain measuring scales in X, Y and Z axes • Chip conveyor in articulated belt design for X-8,000 mm • External and internal coolant supply with paper band filter and 1,000L clean water tank. High-pressure pump 16 bar • Air cooling along and through the spindle • Tool magazine with 48 positions SK50 (max. Ø125 mm, max 400 mm length, max. 25 kg) • Shuttle machining capability with a fixed position for the removable partition • Dimensions L x W x H = 16.2 m x 9 m x 4.9 m (from the normal floor) • Electrical connection 400V / 50 Hz / 3Ph, 65 kVA and 3 x 95A slow-blow fuse

Year of construction: 2008, operating hours: 12,897 h, condition: ready for operation (used), travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,600 mm, overall weight: 34,000 kg, total width: 11,000 mm, total height: 6,450 mm, product length (max.): 12,500 mm, spindle speed (max.): 2,500 rpm, tool weight: 25,000 g, number of axes: 5, This 5-axis SHW UFZ 6L Bed Type Milling Machine was manufactured in 2008. It features an impressive X-axis travel of 6000 mm, Y-axis travel of 2100 mm, and Z-axis travel of 1600 mm. The machine includes an automatic tool changer with a capacity for 150 tools and a robust clamping plate surface of 3600 x 3750 mm. If you are looking to get high-quality milling capabilities, consider the SHW UFZ 6L machine we have for sale. Contact us for further details. Spindle operating time: 12,897 hoursHydraulic operating time: 43,912 hours • W-axis travel: 1500 mm • Digital feed drives • X-axis: 2–20000 mm/min • Y-axis: 2–24000 mm/min • Z-axis: 2–24000 mm/min • Rapid traverse • X-axis: 20000 mm/min • Y-axis: 24000 mm/min • Z-axis: 24000 mm/min • Spindle • Head: Automatic universal milling head • Main spindle motor: Siemens 1PH7 167 • Gearbox: ZF 2K300 / SEW FF37 / FA47 B / KA Z37 • Repeatability: ±0.002 mm • Spindle Speed (60 min Max): 3200 rpm • Spindle Speed (15 min Max): 4000 rpm • Tool changer • Type: Automatic • Capacity: 150 tools • Max tool length: 400 mm • Max tool weight: 25 kg • Tool taper: SK50 DIN 69871 • Station: Pickup-station • Table/plates • Clamping plate surface: 3600 x 3750 mm • Electronics and control • Control panel: Integrated CNC in work platform • Servo motors: Siemens 1FT6 series • Drives/regulators: Indramat ECOdrive 3 • Measuring systems: Heidenhain LS 186C / LB 382C / ROD 480 / ROQ 425 • Electronic pressure switch: ifm PN 5, PN 7 • Power supply • Voltage: 400 V, 3-phase, 50 Hz • Power connection: approx. 80 kVA • Main fuse: 160 A (slow-blow) Fpsdjy Nzdcspfx Amtsl • Conductor cross-section: 70 mm² • Pneumatics and hydraulics • Pressure: 4–6 bar • Connection: G1/4 • Air consumption: approx. 320–400 l • Valve terminal: Festo CP10+ • Hydraulic system: Bosch with 1 x 50 l accumulator Additional equipment • CNC rotary table unit: Demmeler DRTN • Table surface: 2000 x 1800 mm • Max rotation speed: 4 min^-1 • Collision monitoring: Brankamp Typ CMS (1-channel) • Safety brake: Mayr Typ 891... • Cooling unit: Schimpke DK 38 V / BKW SK 250D • Coolant filter: Knoll KF110/1100 • Oil filter: ARGO D 062-156 • Chip conveyor: Richter SP 250/63 (x2) • Measurement system: m&h 20.10 Set Multi SK50 / m&h 35.10 TS plug • Lubrication: Automatic • Machine enclosure: 3-sided Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2000, x-travel 6000 mm y-travel 1600 mm z-travel 1300 mm control FIDIA C20 /4H-SB tool taper SK50 spindle turning speed range 22 - 4000 U/min SHW – UFZ5 Year of manufacture: 2000 Specifications X-axis 6000 mm Y-axis 1600 mm (stroke with vertical head rotated 1900 mm) Z-axis 1300 mm Orthogonal head 2 axes, indexed 1° Automatically swivelling milling head holder (rear) 360x1 degree Automatically swivelling milling head holder (front) 180x1 degree Control: Fidia - C20 / 4H-SB SK 50 - DIN 69871 Infinitely variable feed range; X-axis: 2–12,000 mm/min. Fpsdpfx Amoxmaqystol Y-axis: 2–18,000 mm/min. Z-axis: 2–18,000 mm/min. Rapid traverse; X-axis: 12,000 mm/min. Y-axis: 18,000 mm/min. Z-axis: 18,000 mm/min. Spindle/auto. Milling head: Speed 22 - 4,000 rpm Torque max. 1180 Nm Total current load: approx. 50 kVA/80 A. Without clamping plate Without chip conveyor

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, table length: 4,000 mm, table width: 1,500 mm, tank capacity: 500 l, SHW PowerSpeed 5 Travel Ranges • X-axis (bed): 4,000 mm • Y-axis (vertical): 2,100 mm Fpjdpfx Amsw I Rz Hjtol • Z-axis (spindle horizontal): 1,300 mm Control System • CNC control: Heidenhain iTNC 530 Feed Speed • X, Y, and Z axes: 2 - 30,000 mm/min • Acceleration: 3.5 m/s² Universal Milling Head in Orthogonal Design • Milling head swivel range (mounting): 360 x 1 degree • Milling head swivel range: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 – 4,000 rpm o Short-term: 36 – 6,000 rpm Automatic Tool Changer • Tool magazine for 48 tools Clamping Plate • Clamping surface: 4,000 x 1,500 mm Chip Conveyor • Fork length: 4,000 mm Coolant System • Tank capacity: 500 l Splash and Chip Protection • One-sided, with 2 manually sliding doors About the Company MBM MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include, among others, spare parts delivery, on-site customer service, machine overhauls, and control system modernization. Services: - Used machines - Spare parts - Customer service - Machine servicing - Machine overhauls - CNC control modernization ----- _____ Used machine – used milling machine – used traveling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used cnc milling machine – used boring and milling machine – used metal milling machine – used metal mill – used metal machining center – used cnc mill – cnc milling machines – milling machinery – large part machining – cnc large part machining – milling – shw – PS5 – PS 5 – Powerspeed – SHW PSZ 5 – SHW Powerspeed – SHW Powerspeed 5 – PSZ 5 – Heidenhain – MBM milling machine – MBM machine – column-type milling machine

Condition: refurbished (used), Year of construction: 2005, operating hours: 80,000 h, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,600 mm, position of the milling head: Orthogonal, spindle speed (max.): 2,200 rpm, spindle speed (min.): 22 rpm, rotational speed (max.): 2,200 rpm, rotational speed (min.): 22 rpm, year of last overhaul: 2026, spindle motor power: 40 W, Equipment: documentation/manual, rotational speed infinitely variable, Used SHW UF 6L – Universal Milling and Drilling Center Year of manufacture: 2005 Machine no.: XXXX Partially overhauled in 2026 High-performance SHW universal milling center with a large working area, automatic universal milling head, Heidenhain iTNC 530, and extensive equipment. Technical main data Travel ranges X-axis: 8,000 mm Y-axis: 2,600 mm Z-axis: 1,600 mm Automatic universal milling head CNC-controlled, swivels in two planes Milling head mount: 360 × 1° Milling head: 180 × 1° A total of 64,800 programmable head positions Tool mount: SK 50 / DIN 69871 Hydromechanical tool clamping Oriented spindle holder 360 × 1° Main spindle Drive power: 40 kW at 100% ED Max. power: 56 kW at 40% ED 2-stage gearbox Speed range: 22–3,200 min⁻¹ Feeds X-axis: up to 20,000 mm/min Y/Z-axis: up to 24,000 mm/min Digital AC feed drives Direct linear measuring systems CNC control HEIDENHAIN iTNC 530 External electronic handwheel HR 420 Second control panel in front of the machine Equipment Electro-mechanical leveling system for the spindle stock Traveling work platform with CNC control panel Pick-up tool station for 10 tools Max. tool weight: 25 kg Max. tool length: 400 mm Wireless measuring probe, 3-dimensional 1-channel collision monitoring Internal and external coolant supply Coolant pressure up to 16 bar / approx. 32 l/min Fjdoztqylspfx Amtspl Coolant/air switching Paper band filter system Coolant tank approx. 800 l Oil cooler for the spindle stock Hinged belt chip conveyor Impulse central lubrication system Traveling control cabinet Fixtures incl. foundation anchor bolts Connection data 400 V / 3 phases / 50 Hz Connection power approx. 80 kVA Fuses 160 A Compressed air 4–6 bar Robust SHW universal milling center with an 8,000 mm X-axis travel, a powerful 40 kW main drive, and an automatic universal milling head – suitable for the flexible machining of large and complex workpieces. Accessories such as a dividing head table and rotary table available upon request. Automatic tool changer (ATC) available upon request. Images are sample images.

Year of construction: 1990, condition: ready for operation (used), A CNC universal milling and drilling center SHW is available. Travel X/Y/Z: 6000mm/2100mm/1500mm, milling head swivel: 180°, rapid traverse X/Y/Z: 8m/min, speed: 4500rpm, spindle power: 31.5kW, machine dimensions X/Y/Z: approx. 11000mm/9000mm/6000mm, weight: approx. 44000kg. Documentation available. On-site inspection is possible. Fpedpfxjuh Azie Amtol

Condition: used, Year of construction: 1970, x-travel 3000 mm y-travel 1350 mm z-travel 1400 mm spindle taper ISO 50 turning speeds 22-1400 U/min Rotary table 800x600 mm Table dimensions 2500x1200 mm Fedoyqu Rqopfx Amtepl Feed 5-3000 mm/min ball screw The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 4501, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,300 mm, rotational speed (min.): 6,000 rpm, Equipment: chip conveyor, rotational speed infinitely variable, Machine configuration: • UniSpeed3500 • Central chip conveyor • Control panel for side and front operation • Platform • Padded seat • Rotoclear side viewing window • 3-color signal lamp • Main drive up to 6,000 rpm • Tool holder SK 50 BigPlus • Orthogonal milling head (C-axis 0.01°, A-axis 0.01°) • Siemens Sinumerik One • HT2 handheld operating device • Rotary table Ø 1,600 mm, 8 t • Side milling table segments • ToolRunner for 90 tools • Coolant system 950 l • Coolant pump 40 bar / 32 l/min • Coolant-to-air switching • Wash gun in working area • m&h wireless probe • 1-channel collision monitoring system Fpodpfxjygtqbj Amtjl • Operating mode 3 • Air purification system 4,000 m³/h

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 9101, travel distance Y-axis: 4,600 mm, travel distance Z-axis: 1,600 mm, rotational speed (max.): 6,000 rpm, Equipment: rotational speed infinitely variable, Machine configuration: • PowerPortal4000 • 45° diagonal milling head (C 0.01° / A 0.01°) • Camera system integrated in SHW diagonal milling head • 4-point Hirth-type milling head interface • Heidenhain TNC 7 • HR 550 FS handwheel • Heidenhain optimization for 5-axis machining • X = freely selectable, Y = 4,600 mm, Z = 1,600 mm Fodpfx Aoygtnajmtspl • ToolCenter with 90 tools • Coolant system 2,500 l • Coolant pump 70 bar / 30 l/min • Coolant/air switching • Wash gun in the working area • Main drive 75 kW up to 6,000 rpm • Tool holder SK 50 BIG-PLUS • Panelling and grating • Double chip conveyor • SHW-UniScan • Sealing air • Operating mode 3 • Hexagon wireless probe • LED workspace lighting • Second camera in the working area

Condition: reconditioned (used), travel distance X-axis: 10,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 2,100 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, rotational speed (max.): 6,000 rpm, tank capacity: 1,200 l, SHW Powerspeed 5 Travel paths • X-axis (bed): 10,000 mm • Y-axis (headstock): 1,300 mm • Z-axis (vertical): 2,100 mm Control • CNC control: Heidenhain iTNC 530 Feed rate • X, Y and Z axes: 30,000 mm/min • Acceleration: 3.5 m/s² Universal milling head in orthogonal design • Milling head holder swivel range: 360 x 1 degree • Milling head swivel range: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 - 6,000 rpm Chip conveyor • Feed length: 10,000 mm Coolant system • Container capacity: 1,200 Liter ATTENTION the images are comparison images Fpedpfjv Dhw Tsx Amtel About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include spare parts deliveries, on-site customer service, machine overhauls and control system modernizations. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control system modernization _____ Used machine - used milling machine - used traveling column milling machine - orthogonal milling head - metalworking - tool milling machine - milling head - SHW machine - SHW spare parts - used milling machine - used milling machine - used CNC milling machine - used drilling and milling machine - used metal milling machine - used metal milling machine - used metal milling machine - used CNC milling machine - CNC milling machines - CNC milling machines - milling machine - large part machining - large part machining - large part machining - CNC large part machining - milling - shw - PS5 - PS 5 - Powerspeed - SHW PSZ 5 - SHW Powerspeed - SHW Powerspeed 5 - PSZ 5 - PSZ 5 - Heidenhain - MBM milling machine - MBM machine - column milling machine
