Used Maho Mh500W Cnc for sale (467)

Condition: good (used), Year of construction: 2009, Machine will come with robot . Bjdpsxfu S Nefx Abceww 42.000 rpm

Condition: ready for operation (used), Year of construction: 1999, Travel X/Y/Z: 600mm/525mm/500mm, rapid traverse: 15m/min, feed rate: 10m/min, speed: 12000rpm, spindle power: 10kW/15kW, spindle taper: SK40, tool positions: 25, table dimensions X/Y: 1000mm/540mm, max. table load: 350kg. Machine dimensions X/Y/Z: approx. 3000mm/2100mm/2300mm, weight: approx. 4500kg, control: Heidenhain TNC 426M, operating hours: 34055h, spindle hours: 8787h. An on-site inspection is possible. Bsdoxl Up Iopfx Abceww

Condition: used, CNC Vertical Travelling Column Bed Milling Machine DECKEL MAHO Vertical Machining Center Type DMF 220 linear Serial No.: 15115223474 Year of manufacture: 2008 CNC 3-D contouring control Heidenhain iTNC 530 Travel X: 2200 mm, Y: 560 mm, Z: 720 mm Table size 2600 x 605 mm Table load capacity 2200 kg Table height above floor 870 mm Distance table to spindle nose max. 752 mm Spindle taper SK 40 (DIN 69871 A) - ISO40 with drawbar DIN 69872 Spindle speed max. 12,000 rpm Spindle drive 35 kW at 40% duty cycle / 25 kW at 100% duty cycle Feed rate 0–20,000 mm/min Rapid traverse X-axis 100 m/min Rapid traverse Y+Z-axis 50 m/min Power supply 400 Volt, 50 Hz, 73 kVA - 30-position tool changer - Internal coolant supply through the spindle, 40 bar (IKZ) - Air blast with minimum quantity lubrication for tool cooling - Air blast through spindle center via M-function - 2 rotating safety windows - Operating mode 4, process monitoring during production - Electronic handwheel at the handheld command station - Separate coolant treatment system, paper band filter with filtration sump - Chip conveyor for positioning under the work area - Centralised grease lubrication - Operating manual - Operating hours – control on = 75,188 h - Operating hours – program run or spindle on = 31,632 h - Controller with interfaces for data transfer, RS232C + USB Footprint L x W x H 650 x 400 x 280 cm Space requirement for main machine L x W x H 490 x 395 x 275 cm (with control panel) Space requirement for chip conveyor L x W x H 550 x 90 x 160 cm (approx. 500 kg) Space requirement for coolant unit L x W x H 180 x 115 x 190 cm (500 kg) Main machine transport dimensions L x W x H 500 x 248 x 275 cm Bwjdpfjw Iqt Aex Abcow Additional transport space required for further parts 550 x 240 x 250 cm Weight of main machine approx. 12.5 t Good condition

Condition: used, Technical data: Working range X axis: 500 mm Y axis: 400 mm Z axis: 300 mm Work spindle Tool holder: ISO 40 Automatic feeds: 0.2 - 0.6 - 0.12 mm/min Spindle speeds: 20 - 4000 1/min, directly programmable Feed range: X / Y / Z = 1 - 3000 mm/min Rigid table: 700 x 350 mm, 5 T-slots Fixed table: max. load capacity 250 kg Connection: 400 V Weight, approx.: 1900 kg Machine dimensions, approx.: 2400 x 1850 x 1850 mm Space requirement: 3200 x 4100 mm, height 1920 mm Features: - CNC control - Fixed table Bwedpfx Asqbq Ufsbcjw - Milling head swivels +/- 90 - Hydr. clamping device - Coolant device - Emergency stop button

Condition: good (used), Deckel Maho 4-Axis CNC Milling Machine DMC 64 V linear Working area: - X-axis: 640 mm - Y-axis: 600 mm - Z-axis: 500 mm - Equipped with Heidenhain 520 control - Equipped with coolant system and paper filter - Probing system prepared, but probe is missing - Low operating hours - Machine from original owner - Used for single-part production of precision components - All 4 axes are operational; however, the encoder for the main spindle is defective Good condition, fully functional. Can be viewed and tested under power on site. Shipping also available internationally. Inspection: Please note that, to avoid misunderstandings, the item can be inspected and tested under power prior to purchase. Please ask any questions before buying to avoid uncertainties. For general inquiries or to arrange a viewing appointment, I am available at the phone number provided above or below at any time. Subject to prior sale and possible errors in the description. VAT will be shown separately on my invoices. Bedpfxexivy Ns Abcsww Shipping by freight forwarding.

Year of construction: 1987, condition: used, machine/vehicle number: 63658, movement x: 600 mm movement y: 400 mm movement z: 400 mm spindle taper: ISO 40 spindle turning speed range: 80 - 4000 rpm carriages continuously adjustable: 0,1 - 1500 mm/min Bodpjbv Haajfx Abcjww rapid move: x u. y/z 4/2,5 m/min electrical connection: 380 V, 16 kVA kW space needed: 2450 x 2200 x 1900 mm weight: 2250 kg

Year of construction: 1987, condition: excellent (used), Manufacturer MAHO Type MH 800 T year of construction 1987 Bodolzkdljpfx Abceww control Heidenhain TNC 355 technical data Working range X way 800 mm Y path 450 mm Z path 500 mm Table rigid angular table 900x600 mm Workpiece weight max 800 kg working spindle 63-3150 u/min Machine dimensions length 3817 mm width 3937mm height 2047 mm Weight 4100 kg

Condition: ready for operation (used), Deckel Maho 27073757 / a Touch Panel for Deckel Maho CNC 432 control, serial number as per photo, used, normal signs of use, 100% functional, scope of delivery as per photos Bjdpji D Upcefx Abceww

Condition: good (used), Year of construction: 2003, travel distance X-axis: 3,900 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, rapid traverse X-axis: 100,000 m/min, rapid traverse Y-axis: 60,000 m/min, rapid traverse Z-axis: 60,000 m/min, workpiece weight (max.): 2,200 kg, table width: 900 mm, table length: 4,200 mm, 5-axis CNC machine (VMC) DECKEL MAHO - DMF 360 Linear HSK-A63 Spindle Pendel screen Production package IKZ 40 Bar Filter capacity 23 L/Min Coolant tank 900 L Last DMG Repair in 2023 for 11.000 EUR    X - Travel: 3900mm Y - Travel: 920mm Z - Travel: 820mm B - Axis: 108° Table Length: 4200mm Table Width: 900mm Table load: 2200 Feed rate X-Axis: 100000mm/min. Feed rate Y-Axis: 60000mm/min. Feed rate Z-Axis: 60000mm/min. Spindle Taper: 63ISO/Bt/Mk Power on spindle: 35kW Speeds / ranges: 18000Rpm ATC / revolver: 30 Coolant through spindle / Bar:40 Bjdpfx Aow Rdyhebcsww Number of controlled axis: 3+1 Chip conveyor: Yes Coolantsystem: Yes Length: 8500mm Width: 3450mm Height: 2910mm Weight: 30700kg

Condition: used, CNC tool milling machine MAHO type MH 400 E Machine No. 43072 Year of construction 1989 travel X: 400 mm Y: 250 mm Z: 375 mm table size 700 x 270 mm distance spindle nose / table max. 410 mm Bwodpfeh Ic Ufsx Abcsw tool holder ISO 40 with draw pin type B spindle speed 80 - 4000 rpm. 18 steps feed speed 1-1500 mm/min. infinitely variable Rapid traverse (X, Z and Y) 2,5 m/min. Pinol shift vertical 50 mm spindle drive 2,2 kW mains connection 400 Volt, 50 Hz, 19 kVA - swivelling control panel with CNC path control PHILIPS 432 - LCD monitor VISCOTECH - hydro-mechanical tool clamping - swiveling device for the vertical milling head - Splash guard cabin as table enclosure with 3 folding doors - Electrical control cabinet fixed to the machine - Interface V24 (RS 232) for data transmission - 52470 operating hours, main switch on - rigid angular table - coolant unit with coolant pump adjacent under the machine - central oil lubrication Vogel - operator's manual, electrical circuit diagram space requirement L x W x H 2250 x 1800 x 1850 mm weight approx. 1,5 ton. good condition

Condition: good (used), Year of construction: 1987, Travel X/Y/Z 400/250/375 mm, 18 speed 80 - 4000 U/min, motor 2,2 KW, spindle SK 40, control MAHO CNC 232, table size 700x270 mm, hydraulic tool clamping, coolant device, spash guard, 20 tool holders with tools, tool setter, machine vice GOODJ 125 N, clamping set, machine feet, several tools, manual Bwedpfolu Hpgex Abcsw

Year of construction: 1988, condition: used, machine/vehicle number: 82053, table mounting size: 600 x 1100 mm movement x: 800 mm movement y: 450 mm movement z: 500 mm tailstock stroke: von Hand ca. 50 mm spindle turning speed range: 63 - 3150 rpm carriages continuously adjustable: 0,1 - 1500 mm/min rapid move: x/y/z 4,5/2,6/3 m/min electrical connection: 380 V, 5,5 kW space needed: 3000 x 2500 x 2030 mm Bsdpfxsxnp De Abceww weight: ca. 4000 kg control 432 with graphic

Condition: repair required (used), Year of construction: 2001, operating hours: 86,000 h, functionality: limited functionality, machine/vehicle number: 01160011131, turning length: 600 mm, turning diameter: 200 mm, spindle bore: 66 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 600 mm, spindle motor power: 21,000 W, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 24 m/min, bar passage: 65 mm, mount diameter: 30 mm, Equipment: documentation/manual, rotational speed infinitely variable, 2-axis CNC lathe Year of manufacture: 2001. CNC control HEIDENHAIN IT Tailstock Partial hollow clamping device Chip conveyor AC main drive 21 kW; 240 Nm 12-station VDI 30 turret Hoc Rwewb Eqdor A Tyst Coin collection arm diameter 66, length 100 Power chuck ø 200 (Berg) 66 mm spindle bore 86,000 operating hours (see hour counter) Bwedpow T Sw Tefx Abcsw

Condition: ready for operation (used), Deckel Maho 5100027000 Touch Panel for Deckel Maho CNC 432 control, serial number as per photo, used, normal signs of use, 100% functional, scope of delivery as per photos Bwjdpfsi D Upgex Abcew

Condition: ready for operation (used), Year of construction: 1998, Spindle speed range: 9000rpm, travel X/Y/Z: 500mm/400mm/400mm, feed rate: 10000mm/min, rapid traverse: 12m/min. Table dimensions X/Y: 700mm/500mm, max. table load: 200kg, number of T-slots: 7, distance between T-slots: 63mm. Control: Heidenhain, tool changer: 16-fold, dimensions X/Y/Z: 4000mm/2200mm/2450mm, weight: approx. 3500kg. Bodpfjw Tc Nyex Abcoww

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Bwedpfxjvt D D Ue Abcow Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Year of construction: 1997, condition: ready for operation (used), Tool length: 250mm, max. tool weight: 6kg, control: Heidenhain CNC 234, connected load: 40kVA, machine dimensions (LxWxH): 4700mm/4100mm/2300mm, weight: approx. 2.8t, operating hours: 43,408h. The guide rail of the front door is broken. Documentation available. An on-site inspection is possible. Bwodpfx Ajulzlcobcjw

Year of construction: 2005, condition: ready for operation (used), Travel X/Y/Z: 2500mm/900mm/800mm, speed: 18000rpm, spindle power: 35kW, max. table load: 3000kg, tool places: 30, machine dimensions X/Y/Z: approx. 6500mm/3000mm/3000mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D, operating hours: 55730h, spindle hours: 18696h. Z-axis brake defective, roller shutter in machine room defective, screen cable defective. Including cooling lubrication system Knoll VRF 250/1250, documentation available. On-site inspection is possible. Bedpfxjvamqds Abceww

Year of construction: 2006, condition: ready for operation (used), Travel X/Y/Z: 1050mm/800mm/560mm, C-axis: 360°, spindle head swivel range: -10°/110°, speed: 18000rpm, spindle power: 25kW/35kW, table diameter: 950mm, table load capacity: 800kg, max. workpiece height: 500mm. Tool positions: 30, tool holder: HSK A 63, max. tool diameter: 80mm/130mm, max. tool length: 250mm, rapid traverse: 90m/min, feed: 20m/min. Control: Heidenhain iTNC 530, operating hours: 113894h, spindle hours: 13349h. Including chip conveyor, IKZ, distance measuring system, Blum laser and measuring probe. Documentation available. On-site inspection is possible. Bwsdpfx Asv H Dgcobcjw

Year of construction: 2006, condition: ready for operation (used), Travel X/Y/Z: 835mm/510mm/510mm, speed: 12000rpm, spindle power: 14kW, table dimensions X/Y: 1000mm/560mm, table load capacity: 800kg, max. workpiece height: 720mm. Tool positions: 20, tool holder: SK40, max. tool diameter: 80mm/130mm, max. tool length: 250mm, rapid traverse: 30m/min, feed: 20m/min. Machine dimensions X/Y/Z: approx. 3500mm/3500mm/2700mm, weight: approx. 4500kg, control: Heidenhain iTNC 530, operating hours: 112962h, spindle hours: 30702h. Including chip conveyor, IKZ, distance measuring system. Documentation available. On-site inspection is possible. Bwodjv H Dgpjpfx Abcow

Year of construction: 2006, condition: ready for operation (used), Travels X/Y/Z: 885mm/600mm/600mm, travels B/C: -10° - 110°/360°, rapid traverse X/Y/Z: 9000mm/min, speed: 28000rpm. Table dimensions X/Y: 950mm/650mm, operating hours: 90711h, spindle hours: 19457h. Including workpiece measuring probe, tool changer with 100 places. Bodpsta H S Ssfx Abcoww

Year of construction: 1991, condition: ready for operation (used), X-axis: 1600mm, Y-axis: 800mm, Z-axis: 800mm, tool holder: ISO 50, speed: 20-4000/min, feed rate: 1-4000mm/min, max. rapid traverse: 10m/min, number of tool positions: 36, max. tool diameter: 160/210mm, max. tool length: 315/400mm, max. tool weight: 15kg, control: Heidenhain iTNC 530, connected load: 40kVA, machine dimensions: 5080mm/36xWxH Tool length: 315/400mm, max. tool weight: 15kg, control: Heidenhain iTNC 530, connected load: 40kVA, machine dimensions (LxWxH): 5080mm/3650mm/2005mm, weight: approx. 16t, documentation available, complete retrofit 2015. Bwedpfsulzk Ssx Abcsw

Year of construction: 1986, condition: ready for operation (used), Travel X/Y/Z: 700mm/500mm/450mm, table dimensions X/Y: 900mm/500mm, max. table load: 500kg, spindle mount: SK40, speed: 3150rpm, quill stroke: 100mm, feed: 3m/min, rapid traverse: 6m/min, machine dimensions X/Y/Z: approx. 3550mm/3150mm/2100mm, weight: approx. 3600kg. On-site inspection is possible. Bwedjwkihxopfx Abcew

Condition: ready for operation (used), Year of construction: 1990, Travel X/Y/Z: 600mm/500mm/400mm, table dimensions X/Y: 900mm/600mm, spindle mount: SK40, speed: 6000rpm, tool positions: 24, feed: 6m/min, rapid traverse: 15m/min, machine dimensions X/Y/Z: approx. 4000mm/4000mm/2700mm, weight: approx. 5000kg. On-site inspection is possible. Bedjwmqxqspfx Abceww

Condition: ready for operation (used), Year of construction: 1989, Travel X/Y/Z: 700mm/500mm/600mm, speed: 6300rpm, power: approx. 10kW, feed X/Y/Z: 4m/min, rapid traverse X/Y/Z: 10m/8m/10m/min, machine dimensions X/Y/Z: approx. 4500mm/2300mm/2500mm, weight: approx. 6000kg, operating hours: 65425h. On-site inspection is possible. Bwsdewmqxkepfx Abcow
