Vertical machining center

HAAS VF-4 BHE 40 ATC

Condition: excellent (used), Year of construction: 2012, - 3-axis CNC center SCM Pratix S - model PRATIX 12B from 2012. - Range X, Y, Z axes: 2500x1250x150+ mm - Number of tool spaces in the magazine: 8 - Machine table: Raster aluminum table, 2 sections. - Control: PC control - Software: SCM NESTING, SCM XILOG MAESTRO - Serial no.: AH/115920 Number of milling axes: 1 Drilling unit: 1 - practically unused Maximum spindle speed: 24,000 rpm Tool holder: HSK-F63 Main engine: 6.6 kW Table measurements: 130 cm x 260 cm Fedpfx Afsuu Ntgofepg Portal construction: Machine with movable portal Vacuum pumps: 2 pcs. BECKER from 2012 - one placed outside, the other installed in the machine. Vacuum pump capacity m³/h: 240/280 m³/h. Interface for reading CAD format (.dxf) Security: Rejects Weight approx. 2,500 kg Length: 5,900 mm Width: 2,790 mm Height: 2,190 mm Automatic tool length measurement

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 13-13, The BLOMAX 4 Blowmoulding machine is of the model 13-13. The machine has no defects and operates in excellent condition with full functionality. Power : 400V/150A/60000W Year of construction : 2000 Fpjdpfx Afot Akgwofeg

Condition: used, Year of construction: 2011, MACHINE SPECIFICATION MAZAK VARIAXIS 500-5X II Robot is not included. - X travel (spindle longitudinal travel): 510 mm - Y travel (table transverse travel): 510 mm - Z travel (spindle vertical travel): 460 mm - A-axis (table tilt): -120° to +30° - C-axis (table rotation): ±360° Spindle: - Spindle motor AC: 22.0 kW / 15 min rating - Rapid traverse X, Y, Z: 52 m/min - Tool magazine: 40 stations - Spindle taper: ISO 40 - Spindle motor AC: 22.0 kW / 15 min - Spindle bearing bore / outer diameter: Ø 80 / 110 mm - Speed range: 35 – 12,000 rpm - Max torque: 143 Nm @ 15% ED Axes details: X-axis (spindle longitudinal travel) - Travel: 510 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min - Guides: Linear ball guides Y-axis (table transverse travel) - Travel: 510 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min - Guides: Linear ball guides Z-axis (spindle vertical travel) - Travel: 460 mm - Spindle nose to table top distance: 190 – 650 mm - Spindle nose to table center distance: 140 – 600 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min A-axis (table tilt) - Range: -120° to +30° - Minimum positioning increment: 0.0001° - Locking torque: 2,156 Nm - Positioning time for 90°: 1.9 s C-axis (table rotation) - Range: ±360° - Minimum positioning increment: 0.0001° - Locking torque: 2,156 Nm - Positioning time for 90°: 1.5 s Accuracy: - Positioning accuracy X, Y, Z: 0.012 mm - Positioning accuracy A, C: 21 / 14 arc sec - Repeatability X, Y, Z: 0.007 mm - Repeatability A, C: 12 / 8 arc sec Tool changer: - Type: Chain with double arm - Number of tool positions: 40 stations - Tool selection: shortest path search - Max tool diameter: Ø 80 mm - Max tool diameter when adjacent pocket is empty: Ø 125 mm - Max tool weight: 8 kg - Max tool length: 300 mm - Tool taper: CAT 40 - Pull stud: ANSI 40 type Mazak - Tool change time (chip-to-chip): approx. 4.5 s Table: - Table size: Ø 500 mm x 400 mm - Max uniformly distributed load: 300 kg - Table equipped with T-slots: 5 slots, 80 mm pitch Fpjdpeygimljfx Affjg - Center hole: Ø 50 H6 - Table height above floor: approx. 800 mm Coolant: - Through-spindle coolant: 15 bar - Tank capacity: approx. 250 L - Coolant filtration: filter - Flush nozzle: at spindle nose Miscellaneous: - Floor space (standard machine): approx. 2805 x 2950 mm - Machine height (standard): approx. 2838 mm - Weight: approx. 7,500 kg - Total fuse / power supply requirement: 50 kVA Included / options and features: - 40 tool stations - Tool identification system including pull stud with ID chip - Tool length measurement - Through-spindle coolant 15 bar + Through-Air - Spindle cooling - Machine lighting - Cooling through the ball screws on X, Y, and Z axes - HSM function for 2-D machining - Mazak “Tornado” for threading and milling - Synchronized feed/speed during threading - ISO/EIA programming - CE marking in accordance with European regulations VARIAXIS500II – Quantity: 1 unit MAZAK VARIAXIS 500-II 5X Vertical 5-axis multi-operation machine equipped with Mazatrol Matrix control system for simultaneous (ISO‑programmed) 4- and 5‑axis machining. Options / items listed: - MAZ85330 – 1 pcs – Through-spindle coolant, 15 bar - MAZ80551 – 1 pcs – Chip conveyor to side - MAZ71190X – 1 pcs – High-speed function type 1, only for ISO/EIA - High-speed function MAZACC-3D G05 P2 - Smooth transitions G61.1 - Contour compensation via parameter settings

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of turrets : 1 - Number of axes : 6 MAIN SPINDLE - Spindle nose : A2-8 - Max. bar diameter : 80 [mm] - Spindle power : 18,5 [kW] - Spindle speeds : 4.000 [rpm] - Max. turning diameter : 460 [mm] - C axis indexing precision : 0,001 [°] TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 260 x 795 [mm] - Y stroke : +/- 50 [mm] - Live tools speed : 6.000 [rpm] - Live tools power : 5,5 [kW] COUNTER-SPINDLE - Spindle nose : A2-5 - Max. bar diameter : 51 [mm] - Max. turning diameter : 190 [mm] - Spindle power : 11 [kW] - Spindle speeds : 6.000 [rpm] - C axis indexing precision : 0,001 [°] - Travel : 760 [mm] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 42 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 4.414 x 2.370 [mm] - Machine height : 2.115 [mm] - Machine weight : 6.200 [kg] MACHINE HOURS - Number of hours under power : 15525 [h] - Number of working hours : 12865 [h] EQUIPMENT - CNC : Mitsubishi MSX-850II - Interactive programming : MAPPS III Fodpfjx Tvkrex Affspg - Interface : USB / PCMCIA / RJ45 - Tool probe : Renishaw - 3 colors status lamp - Tailstock function - Coolant tank - Chips conveyor : Droite - Spindle cooling unit - Parts catcher - Bar loader : LNS Quick LoadSERVO 80 - Parts conveying strip - Number of turning tool holders : 2 - Number of fixed tool holders : 10 - Chuck 3 jaws

Year of construction: 2006, condition: good (used), 5-axis vertical machining center fully equipped with direct-drive technology. Fpsdpfxjpkyn Re Affsg Machine equipped with 30,000 rpm spindle, 60-place tool magazine and Heidenhain TNC 530 CNC

Condition: excellent (used), Year of construction: 2025, functionality: fully functional, Options: Chip conveyor, Z travel 1000 mm, 16-position powered turret, productivity package, bar feeder interface, robot interface, memory extension, overload detection, high-pressure coolant, 3-color signal lamp, tooling Fjdpoymlkasfx Affspg

Condition: excellent (used), Year of construction: 2011, CNC Control: FANUC Series 31i-A5 X axis travel mm: 730 Y axis travel mm: 510 Z axis travel mm: 510 B axis (degrees): +160 / -180 C axis (degrees): 360 Number of pallets: 1 Table size mm: Ø500 Table load capacity kg: 300 Cutting feedrate mm/min (X, Y, Z): 50,000, 50,000, 40,000 Maximum rapid traverse m/min (X, Y, Z): 50, 50, 40 Spindle speed rpm: 12,000 Spindle power kW: 18.5 / 15 Taper type: BT-40 Torque Nm: - Tool changer type: Chain Tool magazine capacity: 61 Max. tool diameter mm: 90 Max. tool diameter with adjacent positions empty: 125 Max. tool length mm: 300 Max. tool weight kg: 8 Coolant tank capacity l: 750 Through-spindle coolant (bar): Yes EQUIPMENT Rotary table with digital readouts: Included Work light: Included Through-spindle coolant Electronic handwheel integrated in CNC panel Coolant oil skimmer Tool life management 3D tool compensation Cylindrical interpolation MORI-APM programming software MACHINE DIMENSIONS Length mm: 2,771 Width mm: 3,948 Height mm: 3,264 Fodpfx Afjydh Hlefspg Weight kg: 12,400

Condition: used, Swing Diameter Over Bed: 400 mm Swing Diameter Over Longitudinal Slide: 350 mm Distance Between Centers: 610 mm Travel Limit: 240 mm Suggested Workpiece Diameter: 200 mm Max Longitudinal Travel: 560 mm Machining Length: 550 mm Max Cross Travel: 40 mm + 120 mm Height of Spindle Axis from Floor: 1135 mm Fpsdpfx Afoxg Nd Aofeg Programmable Spindle Speed Range: 40 to 4000 rpm Spindle Bore Diameter: 52 mm Spindle Interior Cone: MK 6 Slide/Bed Slope: 45/45° Turret Positions: 12 Tools Main Motor: 15 kW Control: Fanuc 6T Equipped with: See photos

Condition: used, Year of construction: 2010, Mazak INTEGREX 300-IV – Technical Data Year of manufacture: 10/2010 Model according to nameplate: INTEGREX 300-IV Serial number / Ass. No.: 221788 Power on time: approx. 50 000 hours General Machine Data Machine type: Turn-mill center Control: Mazatrol Matrix Fjdpfjyxm S Rsx Affjpg Chuck: Kitagawa B-212 (12”) Max. turning diameter: approx. 762 mm Max. machining length: approx. 1524 mm Bar capacity: approx. 76 mm Main spindle speed: 4,000 rpm Second spindle speed: 4,000 rpm Milling spindle speed: up to 12,000 rpm Tool magazine: 40 stations C-axis: 0.001° B-axis: 0.001° indexing X-axis travel: approx. 630 mm Y-axis travel: approx. 230 mm Z-axis travel: approx. 1585 mm Main power supply: 3 AC, 400 V, 50/60 Hz Control circuit: AC 100 V / DC 24 V Max. current: 80 A

Condition: excellent (used), functionality: fully functional, machine/vehicle number: G01747, Turning diameter over bed : 500 mm Turning diameter over slide : 280 mm Workpiece length : 2000 mm X-axis travel range : 280 mm Z axis travel range : 1935 mm Rotation speed : 3000 rpm/min Spindle tip : A2-8 Spindle flight : 82mm X / Z accelerated feed : 4/6 m/min Tailstock sleeve diameter : 75 mm Fjdevfdiuopfx Affjpg Tailstock taper : MT5 Main spindle motor : 11/15 kW Tool shank size : 25x25 mm Tailstock step : 150 mm Positioning accuracy of the X/Z axis (C, Y) : 0,018/0,021 mm Repeatability accuracy of the X/Z axis (C, Y) : 0,014 mm Weight : 2800 kg
