USED 5-AXIS MACHINING CENTER MANUF. HAAS, MODEL UMC 500

HAAS UMC 500

Condition: like new (used), Year of construction: 2022, functionality: fully functional, travel distance X-axis: 610 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 406 mm, workpiece weight (max.): 200 kg, table width: 500 mm, spindle speed (min.): 10,000 rpm, Equipment: chip conveyor, For sale: HAAS UMC-500 5-Axis Universal Machining Center Condition: Absolutely brand new machine. Only one part was produced for test machining. The equipment has been unused and stored for 2 years. Main technical specifications Travel: X-axis: 610 mm Y-axis: 406 mm Z-axis: 406 mm Table: Diameter: 500 mm Maximum workpiece weight: 200 kg 5-axis rotary/trunnion table (trunnion type) Fgsdpfxoxg Nd No Ac Hei Spindle: Inline direct-drive 10,000 rpm 30 HP (22.4 kW) CAT 40 taper (40T) Through-spindle coolant: 300 psi (21 bar) Tool changer: 30 tool positions Side-mount, high speed Precision and compensation: Temperature compensation DWO/TCPC – Dynamic Work Offset and Tool Center Point Control Rigid Tapping Equipment and features: Haas NGC CNC control (FANUC compatible) 1 GB memory Ethernet connection, WiFi connectivity USB port, color 15” LCD display Early power-failure detection module Memory lock (keyswitch) Spindle coolant system Protective enclosure with doors Internal lighting Centralized lubrication system Top cover Measurement and calibration equipment: Renishaw WIPS wireless intuitive probing system (Haas Visual Programming System, macros, spindle orientation, coordinate rotation and scaling) Rotary-Axis calibration tool RJH remote jog handle with color display Chip and coolant systems: Coolant tank – 95 gallons (360 L) Initial fill with Blaser coolant emulsion Chip conveyor (belt type – CONVEYOR-H) High-pressure air system Documentation: Original machine documentation (in English) Application Haas UMC-500 is a compact yet powerful universal 5-axis machining center designed for the production of complex, multi-sided, and free-form surface parts. Suitable for simultaneous 5-axis machining as well as 3+2 machining, significantly reducing setup operations and ensuring high accuracy. If you have further questions, we are happy to assist.

Condition: used, Year of construction: 1995, turning diameter 300 mm turning length 710 mm control SIEMENS SINUMERIC 840 total power requirement 40 kW weight of the machine ca. 6000 kg dimensions of the machine ca. m I N D E X (Germany) CNC Controlled Slant-Bed Chuck Lathe with Turret and Tailstock and INDEX CNC Control C 200 – 4 (SIEMENS) Model G 300 Year 1995 S/N 5000 65 _____ Turning - Ø, with chuck, max. 300 mm Spindle bore 90 mm Max. Workpiece Swing dia. 400 / 590 mm Turning length / travel of turning slide, (X-Achse) max. 710 mm Turret head slide cross movement (Z-Axis) max. 140 mm Turret with 12 tool holder positions DIN 30 mm Fodpst Hw Suefx Ac Hegi Feed range of turret slide / Quickfeed 0,1 - 20 m/Min. Feed Force of X/Z-Axis 8 – 13 kN Steplessly adjustable Spindle speeds up to 5.000 rpm Torque Forceon main spindle approx. 275 Nm Spindle drive 28 kW Total electrical load appr. 40 kW - 400 V - 50 Hz Weight 6,000 kg Accessories / Special Features: * INDEX CNC Control Model C 200-4 resp. SIEMENS 840 C for 3 Axes X/Z Axis and Main spindle as C-Axis (Spindle Orientation) Control Panel mounted swivable on front left side of machine. * Spindle orientation in 2,5° degree steps and Spindle indexing device * Mounted hydraulic 3 Jaws Chuck make FORKHARDT Model HS 250 with many Sets of jaws. Speed up to 5.000 rpm * INDEX- Turret with 12 positions for DIN 30 tool holders, prepared for driven tools and motorized by the indexing motor, Choice of approx. 40 pieces toolholders * Hydraulic Tailstock with stroke of 50 mm and with concentricity correction device * KNOLL – Swarf Conveyor with Coolant Device and High Pressure Pump, Sliding door, Oilskimmer, etc. Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2021, X Axis 24.0 in (610 mm) Y Axis 16.0 in (406 mm) Z Axis 16.0 in (406 mm) 10+1 pallet pool, UMC Max Speed 15,000 rpm Taper BT40 Magazine Capacity 50+1 Programmable coolant nozzle Air through spindle Coolant through spindle Renishaw probe WIFI camera Extra coolant filter B Axis – Tilt (S.A.E / Metric) Travel 120° to -35° Max Torque 1854 ft-lbf (2514 Nm) Brake Torque 900 ft-lbf (1220 Nm) C Axis – Rotation (S.A.E / Metric) Travel 360° / 360° Fsdjxl D Erepfx Ac Hsgi Max Torque 1854 ft-lbf (2514 Nm) Max Part Swing 18.0 in (457 mm) Brake Torque 900 ft-lbf (1220 Nm) Platter Diameter 15.70 in (400 mm) Max Weight on Platter 500 lb (226.8 kg) Max Weight on Platter w/Pallet Pool 200 lb (90.7 kg) T-Slot Width 0.626 in to 0.630 in (15.90 mm to 16.00 mm) Number of Std T-Slots 5 T-Slot Center Distance 2.48 in (63 mm) Max Tool Diameter (full) 2.5 in (64 mm) Max Tool Diameter (adjacent empty) 5.0 in (127 mm) Max Tool Length (from gauge line) 12 in (305 mm) Max Tool Weight 12 lb (5.4 kg) Coolant Capacity 55 gal (208 L)

Condition: ready for operation (used), Year of construction: 2023, Control Unit Brand HAAS Main Drive Spindle speed range 15000 RPM Spindle motor power 22.4 kW Tool taper ISO40 taper Media Chip conveyor Yes Fedpexdpa Esfx Ac Hegi Additional Equipment Chip Conveyor: Positioned above coolant tank with auto-reverse function This 5-axis HAAS UMC-500SS universal machining centre was manufactured in 2023. It offers advanced capabilities for complex and precise machining tasks. Consider the opportunity to buy this HAAS UMC-500SS universal machining centre. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2007, turning length: 1,065 mm, turning diameter: 470 mm, Chip conveyor SMW 315 3 chuck 2 x Radial live tooling holders 2 x Axial live tooling holders Spindle bore 80 mm BMT-Tooling system Fgjdpfx Acswq Rpws Hei Tool measuring probe Spindle hours 6960 / 6270 Running hours Max. turning Ø: 470mm X-Axis: 260mm Z-Axis: 1065mm Spindle bore: 80mm Speedrange: 4200Rpm Spindle power: 30kW ATC / revolver: 12 BMT Tool system Speed live tools:6000Rpm Power live tools:7,1kW Length: 3310mm Width: 1900mm Height: 1970mm Weight: 6100kg

Condition: like new (used), Year of construction: 2022, Controller HAAS (LCD screen, 1 Gb memory, touch screen, WIFI) Table size D400 mm Table load 227 kg No of T slots 5 X travel 610 mm Y travel 406 mm Z travel 406 mm B axis tilting +120 / - 35 degree C axis rotation 0 - 360 degree Distance between the spindle and table surface 102 - 508 mm Spindle speed 15000 rpm Spindle power 22,4 kW ATC magazin 50+1-fold Toolholder HSK-A63 Rapid speed X/Y/Z 30,5 m/min Feedrate 16,5 m/min Weight 5400 kgs Machine dimensionen LxWxH 2900 x 2280 x 2520 mm Features, accessories - CTS 69 bar - Coolant unit - Extra filter system on coolant unit Fgjdpfelaxu Djx Ac Hoi - Dinamical zero point shift / toolpoint programming - Intelligent over voltage protection - Ethernet interface - HAAS Connect, remote control - HAAS Drop (Wifi Data transfer) - High Speed machining - Media show during working by M130 - Rigid tapping - Protection from over voltage - Chip conveyor - Programmable coolant nozzles - Air through the spindle Two idencital machines are for sale. Ready to buy immediately.

Condition: ready for operation (used), Year of construction: 2021, Main Drive Spindle speed range 10000 Spindle motor power 22.4 kW Tool taper ISO40 Number of axis 5 Movement X-Axis Movement 610 mm Y-Axis Movement 406 mm Z-Axis Movement 406 mm Fgjdpfx Aowvb Diec Hji Additional Equipment Set of tool holders Renishaw probe set Chip conveyor High speed machining TSC-ready Programmable cooling nozzle Additional air conditioning unit for cooling the electrical cabinet This 5-axis HAAS UMC 500 was manufactured in 2021, featuring a 610x406x406 mm working travel and a ø400 mm table that can handle up to 226 kg. It includes a B-axis tilting at -35°/+120° and a full 360° C-axis rotation. The spindle reaches speeds up to 10,000 rpm with a power of 22.4 kW. Extras include a Renishaw probe set, chip conveyor, and additional cooling unit. If you are looking to get high-quality milling capabilities consider the HAAS UMC 500 machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2018, swing dia. 600 mm turning diameter 310 mm turning diameter over slide 355 mm spindle bore 53 mm bar capacity 45 mm Fgsdpfx Aowgi Hyoc Hoi turning speed range 6000 U/min turning length 388 mm travel -z axis 400 mm travel -x axis 220 mm turret (x-stations) 12 control SIEMENS 828D (Touch) c-axis 0,001° 0 total power requirement 20 kVA weight of the machine ca. 4,5 t dimensions of the machine ca. LTH 3,7 x 2,0 x 2,0 m Includes preparation for automation (loading robot) Year of manufacture: 11/2017, delivery: 2018 - Automatic door - 12-station tool turret, driven at 5,000 rpm - Workpiece catcher - RENISHAW touch probe, automatically retractable - Tailstock - Chip conveyor - Coolant pump Accessories: Including collet chuck Including 2 x driven tool holders (radial + axial) Including 9 x fixed tool holders Including USB & LAN interface Including manuals

Condition: as good as new (ex-display), Year of construction: 2019, functionality: fully functional, turning diameter over cross slide: 415 mm, turning length: 850 mm, turning diameter: 390 mm, spindle bore: 105 mm, spindle speed (max.): 2,000 rpm, travel distance X-axis: 225 mm, travel distance Z-axis: 950 mm, rapid traverse X-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, total height: 1,980 mm, total length: 4,600 mm, total width: 1,900 mm, quill diameter: 100 mm, quill stroke: 120 mm, overall weight: 7,000 kg, bar passage: 90 mm, chuck outer diameter: 300 mm, controller manufacturer: Siemens, controller model: 828D + Shopturn, Equipment: documentation/manual, max. turning diameter 390 mm Z-axis travel: 950 mm max. spindle speed: 2000 rpm AC spindle motor SIEMENS (cont./15min) 25/33 kW bar capacity: 90 mm spindle nose: A2-11 Fedpfsfk Et Aex Ac Hjgi Including accessories a. o: SAUTER 12-station turret VDI-40 Trifix holder for driven tools C-axis with spindle clamping and stabilization Wide and stable flat guides 45° inclined bed for optimum chip fall Hinged belt chip conveyor with chip bucket 3-jaw Kitagawa power chuck ø 300 mm Tool measurement can be swiveled in manually Hydraulic tailstock manually adjustable with programmable tailstock quill Coolant unit with powerful pump (4 bar) Rittal filter fan on the control cabinet

Condition: used, Year of construction: 2017, turning diameter 550 mm turning length 800 mm control FANUC Series 31i Model B spindle passage 76 mm turning speed range - drive spindle 3500 U/min drive capacity - spindle motor 40/25 kW max. torque on the spindle 864 Nm Number of tools 16 St. tool adaptor BMT rapid traverse 30 m/min dimensions 2,9 x 2,1 x 2,25 m weight of the machine ca. 6,5 t Used CNC- lathe with boxway system in very good condition Only 9.100 h power on. - 3- jaw chuck Ø 315 mm - chip conveyor - some tool holders - tailstock programmable - oil dust collector -"Build In" motor Fedpfxsw U U Ido Ac Hegi
