Victory 330/80tech

ENGEL

Condition: good (used), Year of construction: 2000, clamping force: 4,000 kN, _TECHNICAL DATA – ENGEL ES 1800H/500W/400 HL-2F_ _INJECTION UNIT_ | AG1800H | AG500W Screw diameter: 70 mm | 40 mm Screw length: L/D 20 | 20 Metering stroke: 270 mm | 200 mm Screw speed: 226 rpm | 400 rpm Shot rate: 81 g/s | 32 g/s Injection rate: 386 cm³/s | 198 cm³/s Max. shot volume: 1039 cm³ | 251 cm³ Spec. injection pressure: 1441 bar | 1300 bar Spec. inj. pressure (increased): 1735 bar | 2020 bar Nozzle stroke: 750 mm | +5/-100 mm Nozzle contact force: 144 kN | 63 kN Heating capacity: 30.2 kW | 11.4 kW Heating zones (incl. nozzle): 5 | 7 _CLAMPING UNIT_ Clamping force: 4000 kN Itjdpfozvf H Eox Af Usk Opening stroke: 950 mm Ejector force: 82 kN Ejector stroke: 250 mm Max. platen distance: 1550 mm Min. mold height: 600 mm Platen BAP: 1400×1080 mm Platen FAP: 1400×1200 mm _DRIVE_ Pump power: 55 kW Oil (main tank): 540 l Oil (suction tank): 400 l _WEIGHT (without oil)_ Clamping unit: 27 850 kg Inj. unit AG1800H: 5 600 kg Inj. unit AG500W: 1 000 kg

Condition: like new (used), Year of construction: 2024, clamping force: 27,000 kN, ENGEL DUO 36060/2700 TECH Manufacturer: ENGEL Model: DUO 36060/2700 TECH Clamping Force: 2,700 t (27,000 kN) CLAMPING UNIT Clamping force: 27,000 kN Opening stroke: 3,300 mm Max. daylight: 4,100 mm Min. mould height: 800 mm Max. mould height: 2,200 mm Tie bar spacing (H × V): 2,180 × 1,750 mm Platen dimensions (H × V): 2,970 × 2,640 mm Opening force: 770 kN Opening force with pressure pad: 1,600 kN Itodpfxszvc N Rs Af Usk Dry cycle time (Euromap 6): 5.6 s INJECTION UNIT Screw diameter: 190 mm L/D ratio: 25:1 Screw stroke: 850 mm Shot volume: 24,100 cm³ Theoretical shot weight PS: approx. 21.9 kg Injection rate: 2,620 cm³/s Injection pressure (regenerative): 1,300 bar Maximum injection pressure: 1,600 bar Screw speed: 85 rpm Maximum screw speed: 100 rpm Screw torque: 24,000 Nm Reduced torque at max. speed: 20,400 Nm Plasticizing rate (3-zone screw): 238 g/s Plasticizing rate (barrier screw): 296 g/s NOZZLE Nozzle stroke: 1,300 mm Nozzle contact force: 210 kN EJECTOR Ejector stroke: 400 mm Ejector force forward: 420 kN Ejector force return: 420 kN HEATING SYSTEM Heating zones incl. nozzle: 12 Installed heating power: 160.9 kW DRIVE UNIT Installed motor power: 355 kW Reload pump motor: 3 kW Hydraulic oil tank capacity: 3,500 l COOLING REQUIREMENTS Cooling capacity: 66.9 kW Water consumption (32°C inlet): 5.88 m³/h Options: Engel VIPER 90 robot Rectable tie bar (movable) Hotrunners: 160 cores: 3+3 Cascades: 72

Condition: excellent (used), Year of construction: 2015, clamping force: 9,000 kN, _ENGEL DUO 1800H/1800M/900 WP 2FCLS – Full Technical Parameters_ Year of manufacture: 2015 Control system: CC300 Clamping force: 9,000 kN (900 t) QMC system: Bolt Hole _— Clamp Unit —_ Min. mould height: 1,300 mm Max. mould height: 2,100 mm Platen size (H × V): 1,850 × 1,810 mm Tie-bar spacing (H × V): 1,420 × 1,170 mm Opening stroke: 1,800 mm Location ring – fixed platen: Ø 250 mm Location ring – moving platen: Ø 250 mm Max. total tool weight: 21,000 kg _— Injection Unit 1 —_ L/D ratio: 20 Screw diameter: Ø 60 mm Iedpfszu Snajx Af Uotk Barrel volume: 763 cm³ Injection rate: 317 cm³/s Max. hydraulic pressure: 180 bar Max. specific pressure: 1,960 bar Screw stroke: 270 mm Max. screw rotation: 253 RPM _— Injection Unit 2 —_ L/D ratio: 20 Screw diameter: Ø 60 mm Barrel volume: 763 cm³ Injection rate: 317 cm³/s Max. hydraulic pressure: 184 bar Max. specific pressure: 1,960 bar Screw stroke: 270 mm Max. screw rotation: 253 RPM _— Mould / Peripherals —_ Fixed platen cores: 1 Moving platen cores: 1 + 4 on rotary table Hot runner zones: 16 Sequential control zones: 48

Condition: excellent (used), Year of construction: 2006, clamping force: 2,600 kN, Controll : CC200 Clamping force: 260 t Screw dia: 40 mm Type: Multicomponent Drive: Hydraulic Itsdezu Smijpfx Af Ujk Rotary table Machine is including robot and conveyor belt Robot: ERC 23/1-F

Condition: good (used), Year of construction: 2003, Engel VCe 740/150 HL (2003) Itsdpezu R Nisfx Af Usk

Condition: excellent (used), Year of construction: 2006, _M 46_ _Engel VC 1050/220 HL_ Clamping force: 220 t Year of manufacture: 2006 Control system: CC 200 Iodpfszu R H Usx Af Ujtk Screw diameter: 55 mm Screw type: POM Min. mold height: 300 mm Max. opening stroke: 750 mm Max. platen distance: 1,050 mm Ejector stroke: 180 mm Tie-bar spacing (H × V): 860 × 830 mm Platen size: 560 × 600 mm Quick clamp: Yes Core pull: 2× Needle shut-off: 2×

Condition: used, Year of construction: 1993, Engel ES 80/50 HL (1993) Iodpfx Afezu R Hze Uotk

Condition: ready for operation (used), Year of construction: 2010, operating hours: 23,905 h, functionality: fully functional, clamping force: 600 kN, screw diameter: 35 mm, displacement volume: 135 cm³, injection pressure: 2,221 bar, opening stroke: 335 mm, total length: 2,420 mm, total width: 1,700 mm, total height: 3,100 mm, overall weight: 6,700 kg, Equipment: documentation/manual, For sale: Well-maintained injection moulding machine ENGEL INSERT 200V/60 with only 23,905 operating hours. The machine was used exclusively for sampling purposes. Inspection under power possible at any time! Itjdpey Iwlasfx Af Ujk Technical specifications as per the pictures! Machine is immediately available!

Condition: good (used), Year of construction: 1998, Screw diameter: 25 mm Clamping force: 25 tons Opening stroke: 350 mm Itedsvxh Iuspfx Af Uok Weight: 2,900 kg Immediately available from stock

Condition: good (used), Year of construction: 1992, Clamping force: 500 kN Iedpevygh Nefx Af Ustk Screw diameter: 30 mm Weight: 3,200 kg Available immediately from stock
