Hydraulic plate shear

DURMA

Year of construction: 2013, condition: ready for operation (used), A guillotine shear Durma is available. Working width: 3100mm, max. sheet thickness: 13mm, stroke: 125mm, stroke rate: 13/min, oil capacity: 330l, machine dimensions X/Y/Z: approx. 4250mm/3850mm/2200mm, weight: approx. 11700kg. An on-site inspection is possible. Fjlhcexph R Tecqlopc

Year of construction: 1993, condition: ready for operation (used), A Durmazlar press brake distributed by Knuth is available. Pressing force: 35t, bending length: 1350mm, motor power: 5.5kW, stroke: 100mm, stroke rate: 17/min, max. operating pressure: 240bar, oil capacity: 150l. Machine dimensions X/Y/Z: approx. 1400mm/1400mm/2100mm, weight: approx. 1750kg, operating hours: 1258h. An on-site inspection is possible. Fpslhccqexguc Rolec

Condition: excellent (used), Working width 1010 mm Max. sheet thickness 370 N/mm² 1.5 mm Upper beam opening 80 mm Small bending width 10 x s mm Small Inner radius 1.5-2 x s mm Bending beam adjustment approx. 40 mm Max. bending angle 130° Dimensions L x W x H 1650 x 500 x 1400 mm Weight 380 kg Accessories / Special Features: • Upper tool, 45° bending rail • Flat rail on the bending beam • Graduation with stop Fpslhcswg Ru Ejcqlec • Compensating counterweight • Heavy-duty cast iron construction • Easy adjustment of the upper beam via spindle • Versatile • The bending tools are suitable for narrow and wide sheet metal for fine bending • Angle adjustment with graduation • Easy bending thanks to counterweight Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2007, Technical details: pressure: 160 t chamfer lenght: 3050 mm distance between columns: 2550 mm throat: 350 mm Fpelhcceyfua Ioqlec Stroke: 175 mm dayligth: 86 mm range of back stop: 620 mm total power requirement: 15 kW dimensions of the machine ca.: 4250 x 2170 x 2800 mm weight of the machine ca.: 10 t

Condition: used, Year of construction: 2019, gebraucht 2019 080173 prompt, Zwischenverkauf v Türkei 39800 € 1 120 to 3050 mm 3 180 mm 2550 mm 250 mm 375 mm hydraulisch 100 mm/s 9 mm/s 77 mm/s 620 mm 250 mm/s 878 mm 104 mm 150 l 11 kW 3750 mm 1250 mm 2400 mm 5900 kg Excellent condition Only approximately 600 operating hours and 2000 strokes 3 axes (Y1, Y2 and X axes) CNC control DT-10 - intuitive touch-screen control (simple drawing of the bending outline with your finger) - user friendly programming in dialogue form - automatic calculation of bending sequence - automatic calculation of the blank sheet size - graphic product and tool memory - correction possibility - USB interfaces for backup and programm transportation - PC software, generating programms on the PC and transfer to the machine by USB CNC controlled back gauge with linear guide and ball screw spindles Manual, centralized adjustable crowning table intermediate clamps for upper tool upper tool1010/A/75°/0,8, sectioned,bending radius hardened and ground die holder for 60 mm dies die type2009/85°(V 16, 22, 35, 50 mm)sectioned, geteilt, bending radiihardened and ground Fpslhccoyfh N Aoqljc laser safety device Fiessler AKASmounted on the upper beam 2 sheet support arms protection covers on the sides andback side according to CE rules oilfilling users manual in GERMAN with EC declaration of conformity

Condition: new, Year of construction: 2025, neu 2025 080109 prompt, Zwischenverkauf v Türkei 68282 € Felowiq Sijhccqlopc 1135.89 € 1 1 60100 € 120 to 3050 mm Y1 / Y2 / X und R Achse 180 mm 2550 mm 250 mm 375 mm hydraulisch 100 mm/s 9 mm/s 77 mm/s 620 (mit optionaler R-Ach mm 250 mm/s 878 mm 104 mm 150 l 11 kW 3750 mm 1230 mm 2400 mm 5900 kg 4 axes (Y1, Y2, X and R axes) CNC control DT-10 - intuitive touch-screen control (simple drawing of the bending outline with your finger) - user friendly programming in dialogue form - automatic calculation of bending sequence - automatic calculation of the blank sheet size - graphic product and tool memory - correction possibility - USB interfaces for backup and programm transportation - PC software, generating programms on the PC and transfer to the machine by USB CNC controlled back gauge with linear guide and ball screw spindles CNC controlled crowning table intermediate clamps for upper tool upper tool1010/A/75°/0,8, sectioned,bending radius hardened and ground die holder for 60 mm dies die type2009/85°(V 16, 22, 35, 50 mm)sectioned, geteilt, bending radiihardened and ground laser safety device Fiessler AKASmounted on the upper beam sheet support arms protection covers on the sides andback side according to CE rules oilfilling users manual in GERMAN and ENGLISH ADVANTGES OF PBF SERIES: - compact structure - low cost due to serial production of standardised models without restrictions in quality and accuracy OPTION: DBend, 3D CAD/CAM importing- and simulation program (step, iges and dxf file import) WE HAVE MORE THAN 600 REFERENCES!

Year of construction: 2023, condition: new, Standard version: - Y1, Y2, X, R (4-axis) X=650 mm X,R - Control system - CNC CYBELEC ModEva 19T - CNC controlled motorised crowning - European clamping system - throat - Sliding front support arms with T-slot and tilt stop - Rear stop: Siemens DC servo with linear guide & ball screw - Protective covers Special accessories: (Available depending on bending length and pressing force): Bending aid: - Bending aid -motor. Height adjustment - max. load 125 kg - Bending aid -motor. Height adjustment - max. load 250 kg Backgauge axes: - X=650 mm X,R,Z1,Z2 (AL) - X=650 mm X,R,Z1,Z2,Delta X +/- 125mm CNC controlled - X=650 X1,X2,R - X=650 X1,X2,R,Z1,Z2 - X=750 X1,X2,R1,R2,Z1,Z2 - X=1000 mm X,R (AL ) - X=1000 mm X,R,Z1,Z2 (AL) Control: - DELEM DA 69T - DELEM DA 66T Safety system: - CE with manual F.AKAS II M -FPSC-B-C (SAFETY PLC) - CE with FIESSLER AKAS-3P motorised + FPSC (SAFETY PLC) - CE for tandem machines FIESSLER AKAS light barrier - tandem - - preparation + safety cover with switch - AKAS 3P tools: - Various tool clamping systems as well as tools to choose from. Further options: - DAM (Durma Laser Angle Measuring System) - Air conditioning for control cabinet - additional support arms movable - Central lubrication manual Fjlhen Tnn Eoccqlopc - Central lubrication motorised - Control panel on the other side - additional stop fingers - oil cooler - Parking area for bending aid (1 metre) - second foot pedal - die rail (groove 12.7 mm width, 15.8 mm height) - special painting - Tandem preparation - oil heating - laser bending line - lateral sliding doors Are you interested in exactly this machine model or do you have specific questions? Please use the contact field to send us a message. We will answer you immediately!

Condition: new, Standard equipment: - D-Touch 7 touch screen CNC control unit - CNC-controlled motorized cutting gap adjustment via upper knife (up to VS 4013) - CNC-controlled motorized cutting gap adjustment via lower knife (patented) (from VS 4016) - Plastic inserts for downholder (material protection) - variable cutting length adjustment via CNC - Cutting reel adjustment via CNC - Table plates with ball rollers - backgauge on ball screws 1000 mm - folding up finger guard to 1000 mm - 1 side stop L= 1500 mm, with scale, T-slot & tilt stop - 2 support arms L=1000 mm, with T-slot & tilt stop (up to VS 3020) - 3 support arms L=1000 mm, with T-slot & tilt stop (from VS 4006 to VS 4020) - 5 support arms L=1000 mm, with T-slot & tilt stop (from VS 6006 to VS 6016) - Cutting line illumination - Upper and lower knife can be rotated four times (4 sides can be used) Special accessories: - Light curtain for finger protection - throat 500 mm - Pneumatic sheet holding device "Durma I - Pneumatic sheet holding device without sheet return "Durma IV - Sheet metal holding device with conveyor belt and scrap container - CNC material feeding system - rear sheet metal chute Fpolhcen Ut Stocqlec - backgauge 1250 mm - Hydraulically liftable backgauge - X1, X2 axis control - adjustable angular stop 0-180 - additional supporting arm L= 2 m with vertical support - additional support arm L= 3 m with vertical support - extension arm L= 2 m with vertical support - extension arm L= 3 m with vertical support - side stop extension L= 2 m with vertical support - Side stop extension L= 3 m with vertical support - Side stop right L= 1500 mm, with scale, T-slot and vertical support - Ball in side stop or support arms - CNC front feed system for 3 meters - Laser cutting line - Spare knife (standard upper and lower knife) - Spare knife (upper and lower knife especially for stainless steel) - Oil cooler - Hydr. twist minimization for narrow sections - Central lubrication manual - Central lubrication motorized - Special painting - Control panel on the other side - Oil heating - Control panel air conditioning control system: - DURMA D-Touch 7 - 7 inch color touch screen - USB interface - Ethernet: RJ-45 10/100M - Stored database for automatic adjustment of cutting gap and cutting angle depending on material and sheet thickness - Creation of programs - Cut counter - User friendly - Fast data input Are you interested in exactly this machine model or do you have specific questions? Please feel free to send us a message via the contact field. We will answer you immediately!

Condition: new, Standard equipment: - D-Touch 7 touch screen CNC control unit - throat 50 mm - Backgauge with ball screw 1000 mm - Plastic inserts for hold down (material protection) - 1 side stop L= 1500 mm, with scale & T-slot & tilt stop - 2 support arms L=1000 mm, with T-slot & tilt stop - Table plates with ball rollers - Infinitely adjustable cutting length - manual cutting gap adjustment - automatically tiltable backgauge - cutting line illumination - upper knife can be rotated twice and lower knife four times special accessories: - Light curtain for finger protection - throat 350 mm - Throat 500 mm - Pneumatic sheet holding device "Durma I - Pneumatic sheet holding device without sheet return "Durma IV - Rear sheet guide - Back gauge 1250 mm Folhccqon Urhvjlopc - Hydraulic anti-rotation device for SBT 3016 and SBT 4013 - additional supporting arm L= 2 m with vertical support - additional supporting arm L= 3 m with vertical support - extension arm L= 2 m with vertical support - extension arm L= 3 m with vertical support - side stop extension L= 2 m with vertical support - Side stop extension L= 3 m with vertical support - Side stop right L= 1500 mm, with scale, T-slot with vertical support - ball in side stop or in support arms - adjustable angle stop 0-180 - CNC controlled motorized cutting gap adjustment - laser cutting line - spare knives - 1 set of upper and lower knives - oil cooler - special painting - Control panel on the other side - oil heating - control panel air conditioning DURMA D-Touch 7 7 inch color touch screen USB interface Ethernet: RJ-45 10/100M Stored database for automatic adjustment of cutting gap and cutting angle depending on material and sheet thickness Creation of programs Cut counter User friendly Fast data input DURMA D-Touch 7 7 inch color touch screen USB interface Ethernet: RJ-45 10/100M Stored database for automatic adjustment of cutting gap and cutting angle depending on material and sheet thickness Creation of programs Cut counter User friendly Fast data input Control system: - DURMA D-Touch 7 - 7 inch color touch screen - USB interface - Ethernet: RJ-45 10/100M - Stored database for automatic adjustment of cutting gap and cutting angle depending on material and sheet thickness - Creation of programs - Cut counter - User friendly - Fast data input Are you interested in exactly this machine model or do you have specific questions? Please feel free to send us a message via the contact field. We will answer you immediately!

Condition: new, Standard equipment - EZM9910 control unit (standard on MS 2004, 2504, 3004) Fpelhccqsn Tpifslec - 550 mm manual backgauge (standard on 1303, 2003, 2525) - 750 mm motorized backgauge programmable via control unit (standard on 2004, 2504, 3004) - plastic inserts for hold-downs (material protection) - 1 side stop and 2 sheet support arms - finger protection - portable foot switch with emergency stop - spring-loaded stop in T-slot of support arms (standard on MS 2004, 2504, 3004) - ball screw (standard on MS 2004, 2504, 3004) - Table plates with ball rollers (standard on MS 2004, 2504, 3004) - Upper and lower knife can be rotated twice (MS 1303, 2003, 2525) - Upper knife can be rotated twice and lower knife four times (MS 2004, 2504, 3004) Optional accessories: - D-Touch 7 touch screen CNC control unit - 750 mm motorized backgauge programmable via control unit (option on MS 1303, 2003, 2525) - 1000 mm motorized backgauge programmable via control unit - pneumatic sheet holding device - adjustable angle stop 0-180 - additional support arm L= 2 m with vertical support - additional supporting arm L= 3 m with vertical support - extension arm L= 2 m with vertical support - extension arm L= 3 m with vertical support - side stop extension L= 2 m with vertical support - Side stop extension L= 3 m with vertical support - Cutting line light (for MS 2004, 2504, 3004) - Spare blades 1 set of upper and lower blades - special painting control unit: EZM9910 control unit (standard on MS 2004, 2504, 3004) DURMA D-Touch 7 (option) - 7 inch color touch screen - USB interface - Ethernet: RJ-45 10/100M - User friendly - Fast data input - Easy connection - Unlimited material types Are you interested in this machine model or do you have specific questions? Please feel free to send us a message via the contact field. We will answer you immediately!
