SPECIAL ACTION Pressbrake

DURMA AD-S 30175

Condition: new, Year of construction: 2025, neu 2025 080112 prompt, Zwischenverkauf v Türkei 86376 € 1438.29 € 1 76100 € 175 to 3050 mm Y1 / Y2 / X und R-Achse 265 mm 2600 mm 450 mm 530 mm hydraulisch 160 mm/s 10 mm/s 100 mm/s 500 mm/s 350 mm/s 250 mm 900 mm 104 mm 250 l 18.5 kW 4250 mm 1700 mm 2850 mm 10900 kg 4axes (Y1, Y2,X and R) CNC control DT-15 - 2D grafic display 15" - intuitive touch-screen control (simple drawing of the bending outline with your finger) - user friendly programming in dialogue form - automatic calculation of the bending sequence - automatic calculation of the blank sheet size - graphic product and tool memory - correction possibility - USB interfaces for backup and programm transportation - PC software, generating programms on the PC and transfer to the machine by USB servo motorized back gauge on linear guides and ball screws back gauge finger blocks on double linear guides CNC crowning table upper tool 1010 / A / 75 °, devidedand cranked 4-V die block 60x60 2009 (V = 16,22,35 and 50 mm) laser safety device Fiessler AKASmounted on the upper beam linear guided sheet support arms according to CE rules oilfilling users manual in English or German ADVANTAGES OF AD-S COMPAIRED TO PBF: - more stroke, installation height and throat - higher approach and retraction speed of the top beam - higher backgauge speed - backgauge finger on double instead of single linear guide - more options available such as: additional backgauge axes (e.g. Z1/Z2, Delta X, up to 6 axes), bending aids, laser angle measuring system, tandem design, other CNC controls ... OPTIONAL EQUIPMENT (TIME OF DELIVERY WITH THESE OPTIONS 10WEEKS): Z1/Z2-Axis Fgodpfx Abswiransroh DBend, 3D CAD/CAM importing- and simulation program (step, iges and dxf file import) CNC Control SKY22 CNC Control Delem DA66 S CNC Control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import option Quick Release Clamping

Year of construction: 2024, condition: new, The DA-69T controller offers both 2D and 3D programming, which includes automatic calculation of the bending sequence and collision detection. The entire 3D machine setup includes multiple tool stations and provides immediate feedback on the feasibility and handling of the product. Delem-69T properties: - 3D and 2D graphic touch screen programming mode - 3D representation in simulation and production - 17-inch TFT colour display with high resolution - Complete Windows Application Suite - Compatible with Delem Modusys (module scalability and adaptivity) - USB, peripheral interface - Open system architecture - Bending and correction interface sensor - Profile-T3D offline software - great contribution to environmental protection, climate change and the greenhouse effect will thank us, the next generation will thank us too! AD-S 30175 with Y1, Y2, X and R axis Bending force: 175 tons bending length: 3050mm Passage between stands: 2600mm Rapid speed: 120 mm / sec working speed: 10mm / sec Speed of the return: 100 mm / sec Installation height of tool passage and the penetration depth of your press brake: 30mm table width: 104mm table height: 900mm stroke: 265 mm Projection: 410 mm Support arms: 2 pcs. Stop finger: 2 pcs. Fgedpfx Abjd Tpadjrsh Press force and speed of the press brake. X - axis: 500 mm / sec x-axis travel direction 650mm Speed R axis max.: 350 mm / sec R axis travel direction 250 mm Engine power: 18.5 kW Oil tank capacity: 250 litres length 42

Year of construction: 2024, operating hours: 32 h, condition: new, Make: DURMA Type: AD-S 30175 Year of construction: 2020* bending length: 3050 mm Press force: 1750 kN Control: DELEM DA-66T Operating hours: 32 h Controlled axes Backgauge: X,R,Z1,Z2,+Delta X +/- 125 mm CNC controlled passage between the uprights: 2600 mm stroke length: 265 mm Installation height: 530 mm table width: 104 mm table height: 900 mm Stands projection: 410 mm travel range X-axis: 650 mm traverse speed X-axis: 500 mm/s travel range R-axis: 250 mm infeed speed: 160 mm/s folding speed: 10 mm/s Retraction speed: 100 mm/s Dimensions L/W/H: approx. 4250x1700x2750 mm Weight: approx. 11500 kg Standard equipment Y1,Y2,X,R - X=650 mm Control: CNC Cybelec ModEva 19T - PC 1200 3D SW D-BEND 3D CAD/CAM import & simulation program CNC controlled motor-driven crowning European tool clamping system 60 mm die holder (only for European die system) Throat 410 mm 2 support arms movable from the front with T-slot and tilt stop Backgauge system: Siemens DC Servo motorized with linear guide and ball screw Protective covers CE Marking Fjdpfx Ajdx Nluebrogh Extended equipment Safety system CE standard for EU: FIESSLER AKAS-3P motorised+FPSC (SAFETY PLC) Controlled axes Backgauge: X,R,Z1,Z2,+Delta X +/- 125 mm CNC controlled Control: DELEM DA-66T Hydraulic top tool clamping Wila NSCL-II-HC/UPB - PREMIUM - 250 t/m Hydraulic bottom tool clamping Wila NSCR-II-HC-CNC/UPB - PREMIUM - 300 t/m Powerpack for hydraulic clamping AP3-AP4 Bending aid -

Condition: new, Year of construction: 2024, Discover the powerful Durma press brake at our demonstration center in Saerbeck. As a manufacturer, we offer you maximum precision and efficiency with a capacity of 3050 mm in length and 175 tons. Benefit from our comprehensive all-in-one service: We take care of transportation, installation, commissioning and offer you a one-year warranty as well as fast and reliable service. Visit us and see the quality and versatility of this first-class machine for yourself. Standard equipment Capacity (length X ton) 3050mm x 175t Installation height 530mm Outreach 450mm Stroke 265mm Fgjdpfxettatbe Abrsh Y1, Y2, X - 3 axes Control unit - DT 15 Manuel F. AKAS FPSC safety system CE F.AKAS BVLT light barrier and safety cages (for tandem press brakes) Servo motor backgauge & linear guide & Ball screw system (X) Manual crowning European style tool clamping system Sliding front arms Hydraulic block and valves in special design according to worldwide standard -Electrical equipment according to worldwide standard Selected options -Control unit - Delem 66S - NEW -Motorized crowning - X=650mm X,R, Z1, Z2 (6 axes controlled press brake) press brake) -Lower tool European M.460R.85 -European upper tool P135.75.R08

Condition: new, Year of construction: 2024, Make: DURMA Type: AD-S 30175 Year of construction: 2020 Folding length: 3050 mm Pressing force: 1750 kN Control: CNC DT-15 Operating hours: 33 h Bcq29blmc8 Controlled axes back gauge: X,R Clearance between the uprights: 2600 mm Stroke length: 265 mm Installation height: 530 mm Table width: 104 mm Table height: 900 mm Stand projection: 410 mm X-axis travel range: 650 mm Traversing speed X-axis: 250 mm/s Infeed speed: 160 mm/s Folding speed: 10 mm/s Retraction speed: 100 mm/s Dimensions L/W/H: approx. 4250x1700x2750 mm Fgjdpfx Aod Srk Ssbreh Weight: approx. 11500 kg Standard equipment Y1,Y2, X=650 mm Control: CNC DT-15 European die clamping system 60 mm die holder (only for European die system) 2 support arms movable from the front with linear guide along the entire length Servo motor backgauge Safety covers on the side CE marking Extended equipment Safety system CE with manual FIESSLER AKAS II M-FPSC- Controlled axes X,R-axis, Z-axes manually adjustable CNC controlled motorized crowning European upper tool/lower tool from Rolleri The machine can be viewed and demonstrated at any time by appointment at our demonstration center in Staufenberg. Further machines are available for demonstration in Staufenberg. We will be happy to send you further information on request.

Condition: new, Year of construction: 2024, working width: 3,050 mm, pressing force: 175 t, A high-performance DURMA press brake type AD-S 30175 is for sale. With its extensive standard equipment and selected options, it is ideally equipped for the demanding tasks involved in metal processing. Standard equipment: Fgjdpfsrx Rkuex Abrjh Capacity and size: 3050mm x 175 tons Installation height: 530mm Projection: 450mm Stroke: 265mm Axis control: Precise control with 4 axes. Safety systems: Manuel F. AKAS FPSC safety system, CE F.AKAS BVLT light barriers and safety cages provide maximum protection. Backgauge: Servo motor backgauge & linear guide & ball screw system for maximum precision. Tool clamping system: European standard for fast and safe tool changes. Front arms: Movable, supports the handling of different workpiece sizes. Selected options: Control unit upgrade: SKY 22 - 3D, for even more detailed bending operations and 3D visualization. Crowning: Motorized adjustment, for even more precise bending results. Backgauge: Extended with motorized X, R-axis backgauge (X=650mm), increases flexibility and precision. Quick clamping: Manual quick clamping for more efficient tool changes. This DURMA press brake is ready to support your production with its advanced technology and reliable performance. It is the ideal choice for companies that value precision, efficiency and safety. For more information or if you are interested, please contact us. Don't miss the chance to expand your production capacity with this high-quality machine.
