Dividing head with tailstock, dividing device, indexing head

DECKEL

Condition: ready for operation (used), Year of construction: 2000, operating hours: 6,328 h, functionality: fully functional, machine/vehicle number: 11180000573, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, workpiece weight (max.): 1,000 kg, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,250 mm Travel range Y-axis: 880 mm Travel range Z-axis: 800 mm C-axis indexing: 360° (0.001°) Feed rate: 40 m/min Rapid traverse: 40 m/min Number of pallets: 1 Pallet dimensions, diameter: 1,000 mm Max. workpiece weight: 1,000 kg Max. torque: 7,900 Nm Max. spindle speed: 18,000 rpm Spindle drive power: 15 kW at 40% duty cycle Spindle drive power: 10 kW in continuous operation Tool interface: CAT 40 Number of tool positions in the magazine: 60 Tool changer: Double gripper MACHINE DETAILS CNC control: 3D contouring control MillPlus Total power consumption: 55 kVA Coolant tank capacity: 600 l Dimensions (L x W x H): 7,000 x 3,500 x 3,902 mm Operating hours Hours under power: 33,831 h Spindle operating time: 6,328 h EQUIPMENT Electronic handwheel Chip conveyor Internal coolant supply Rotating viewing windows Flushing gun Preparation for Renishaw probe Accuracy package Preparation for internal cooling with 40/80 bar Paper band filter Dwsdpszxf Inofx Acqeb

Condition: good (used), Clamping table, clamping angle, T-slot table, rotary table, milling machine table Dwsdpfx Aob A Iccjcqeb -Table surface: 210 x 570 mm -T slots: 3 - rotatable and swiveling -Fits Deckel Mikron WMW and other milling machines -Weight: 95 kg

Condition: ready for operation (used), Year of construction: 2001, operating hours: 29,173 h, functionality: fully functional, machine/vehicle number: 11045522744, travel distance X-axis: 500 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 380 mm, controller model: HEIDENHAIN MILLPLUS, spindle speed (max.): 18,000 rpm, No minimum price – guaranteed sale to the highest bidder! Submitting a bid commits you to collecting the item promptly between October 7, 2026, and October 14, 2026! TECHNICAL DETAILS Travel range X-axis: 500 mm Travel range Y-axis: 420 mm Travel range Z-axis: 380 mm Rapid traverse rate X-axis: 50 m/min Rapid traverse rate Y-axis: 50 m/min Rapid traverse rate Z-axis: 50 m/min Feed rate X-axis: 20 m/min Feed rate Y-axis: 20 m/min Feed rate Z-axis: 20 m/min Spindle speed: 18,000 rpm Torque: 1,100 Nm Tool holder: SK 40 Holder diameter: 40 mm Number of tool positions: 32 Max. tool length from spindle nose: 280 mm Max. tool weight with automatic tool changer: 6 kg Max. total weight of tools in magazine: 90 kg Table length: 500 mm Table width: 380 mm Dwsdpfx Aozu Ixnocqeb Max. workpiece weight: 330 kg Clamping area: 500 × 380 mm Distance between T-slots: 63 mm T-slot width: 4 H7 Centering bore diameter: 30 H6 Max. table rotation speed: 33 rpm Max. swivel torque: 1,400 Nm Swivel speed: 26 rpm Linear scale resolution X/Y/Z: 0.001 mm Positioning tolerance: 0.010 mm MACHINE DETAILS Control system: HEIDENHAIN MILLPLUS Rated apparent power: 40 kVA Input voltage: 400 V Input frequency: 50 Hz Input current: 80 A Dimensions and weight Dimensions (L x W x H): 3,500 x 2,400 x 2,500 mm Total weight: 7,000 kg Operating hours Counter 1: 80,842 h Counter 2: 29,173 h EQUIPMENT NC rotary table with swivel axis

Condition: good (used), Year of construction: 1974, functionality: fully functional, Technical details x-travel 500 mm y-travel 300 mm z-travel 380 mm table surface area 800 x 420 mm table load capacity 400 kg tool taper ISO 40 spindle turning speed range 40 - 2000 U/min feeds longditudinal/cross/vertical 10 - 500 mm/min rapid traverse 1500 mm/min main drive 3 kW weight of the machine ca. 1,3 t Additional information Djdpfx Aezzwzfocqjwb * 3-axis digital readout (Heidenhain) * Adjustable vertical milling head with quill adjustment * Additional horizontal spindle * REPAR 2 safety device * Machine light * Anti-vibration mounts Transport dimensions: The machine will be loaded onto a heavy-duty pallet; Dimensions: 1800 x 1100 x 2100 mm (length x width x height)

Condition: excellent (used), Year of construction: 2008, operating hours: 40,255 h, functionality: fully functional, For sale is a DMG DECKEL MAHO DMF 220 linear, a 5-axis universal travelling-column machining center. The machine was built in 2008 and was modernized / totally retrofitted in 2022 with Siemens Sinumerik 840D Solution Line control. Equipped with 5-axis simultaneous machining license, Siemens Sinamics drive technology, Siemens OP15 Black Operator Panel, MCP control panel and electronic handwheel. Technical data: Manufacturer: DMG DECKEL MAHO Type: DMF 220 linear Machine type: 5-axis universal machining center / travelling-column machining center Year of manufacture: 2008 Control: Siemens Sinumerik 840D Solution Line Modernization / Total Retrofit: Siemens CNC / drive modernization in 2022 5-axis simultaneous operation: License available Serial number: 15115223244 Machine number: 2499093 Travel X: 2,200 mm Travel Y: 560 mm Travel Z: 720 mm Tool taper: SK 40 Table load: 2,500 kg Main spindle speed range: 20 - 14,000 rpm Connected load: 80 kVA Max. rated current: 115 A Fuse protection: 125 A Supply voltage: 400 V Frequency: 50 Hz AC control voltage: 230 V DC control voltage: 24 V Power-on hours: approx. 40,255 h Spindle / working hours: approx. 13,082 h CNC / drive technology: X-axis: Siemens Sinamics 160 A, 2 x SMC20 encoder module Y-axis: Siemens Sinamics 50 A, 2 x SMC20 encoder module Z-axis: Siemens Sinamics 80 A, 2 x SMC20 encoder module B-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module A-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module Spindle axis: Siemens Sinamics 26 kW, 2 x SMC20 encoder module Operator panel: Siemens OP15 Black Operator Panel MCP control panel: Siemens Electronic handwheel: Siemens Magazine technology: Dwsdpjyuzg Hefx Acqjb Magazine A: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine B: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine C: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Software / licenses: 5-axis simultaneous machining license Axis licenses Operator software license Equipment: Integrated swivelling table / trunnion-type table setup Paper band filter unit Coolant / filter unit Electrical cabinet Full enclosure Working area lighting Siemens control panel Condition: Machine in well-maintained condition Modernized Siemens control and drive technology 5-axis simultaneous machining available

Condition: good (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 3,600 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 900 mm, spindle speed (max.): 18,000 rpm, The complete photo gallery is available only upon exclusive request from end-user customers. DMG / DECKEL MAHO DMF 360 linear Year of manufacture: 2013 Working area X: 3,600 mm Y: 1,100 mm Z: 900 mm Moving table design 2 working spaces for pendulum machining removable working space partition direct measuring systems Dynamics / Axes Linear drive X-axis Rapid traverse X/Y/Z: 80 / 60 / 60 m/min Acceleration X/Y/Z: 5 / 6 / 6 m/s² Active cooling for main spindle and linear motor Swivel head / Main spindle CNC swivel head B-axis Speed range: 20–18,000 rpm Tool holder: HSK-A63 According to DIN 69893 Power: 35 / 25 kW at 40 / 100 % duty cycle Tool magazine 60 tool positions Magazine version compatible with HSK-A63 / SK40 Chain magazine Double gripper Chip-to-chip time: 7.5 s Control system HEIDENHAIN iTNC 530 3D control smarT.NC ERGOline Control 19" screen Table / Rotary table Fixed table: 4,200 × 1,100 mm Integrated rotary table Rotary table Ø 1,050 mm Arranged on the left Max. load capacity: 1,200 kg Hydraulic clamping Hydraulic clamping 30–240 bar 2 circuits Coolant / Production Internal coolant through the spindle 40 bar Coolant system 980 liters Chip conveyor Spray gun Rotary through-spindle Purge air for linear measuring systems Blow-through air through the spindle center Blow-through air selectable via M-function Maintained compressed air with low oil content Measuring technology Dedpfx Acezznnvsqewb Infrared measuring probe HEIDENHAIN TS 649 DMG Laser tool breakage detection Further standard equipment Automatic working space doors 2 rotating viewing windows 4-color signal light Electronic handwheel Operating mode 4 / Process monitoring Safety package in case of power failure Overvoltage protection Undervoltage monitoring Fast brake control Torque support HSK-A63 / SK40 / CAT40 Tool package for aluminum machining DMG Messenger Web DMG Netservice Client

Condition: excellent (used), Manufacturer under license: Feinmechanik GmbH Dwsdpezzpmtsfx Acqeb including base with collet chucks (see image)

Condition: used, Year of construction: 2008, Deckel Maho DMC 55H duoBlock Horizontal Machining Center – Copy" Horizontal Machining Center Deckel Maho Type / Model: DMC 55 H DuoBlock Year of Construction: 2008 Condition: Used Program Runtime: approx. 61,600 h Spindle Runtime: approx. 44,700 h Technical Data Travel ranges X / Y / Z axes: 560 mm / 600 mm / 600 mm Rapid traverse rate (X/Y/Z): 40 m/min Work table & Pallet Changer (APC) Number of pallets: 2-position pallet changer Pallet size: 400 mm x 400 mm Max. workpiece weight: 500 kg Max. workpiece height: 850 mm B-axis (rotary table): 360° (designed as an NC rotary table, usually with 0.001° indexing) Main spindle: 12,000 1/min; HSK 63; approx. 38 kW Tool Changer (ATC) Tool magazine: 40 magazine positions Tool holder: HSK-A63 Max. tool diameter: 80 mm (up to 160 mm with free neighboring positions) Max. tool length: 330 mm Electrical Data Power connection: 400V 3/N, PE 50Hz Power consumption: 58 kVA Inrush current: 84 A Max. fuse rating: 100 A DC control voltage: 24 VDC Auxiliary voltage: 230 VAC Dwjdpfx Aozzc Evocqsb Dimensions, Weight & Control Machine weight: approx. 11,000 kg to 13,000 kg (depending on magazine size and chip conveyor) Footprint (L x W x H): approx. 5.0 x 3.0 x 2.8 m (pure space requirement without peripherals) Control system: Siemens Sinumerik 840D Equipment NC rotary table Tool measurement system BLUM Mist and fume extractor IIFE-2000 Hydraulic clamping system Proportional amplifier Handwheel BHG Signal light Coolant system 980l Coolant nozzle Rotoclear Chip conveyor Master probe OMP60 Operating mode 4 Quotation item: Transport costs in a separate offer.

Condition: ready for operation (used), Year of construction: 2003, operating hours: 14,085 h, travel distance X-axis: 650 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 426, spindle speed (max.): 18,000 rpm, number of slots in tool magazine: 30, number of axes: 3, This 3-axis DECKEL MAHO DMC 65 V was manufactured in 2003. It features a spindle speed of 18,000 rpm and a tool changer capacity of 30 positions, enhancing its operational efficiency. The machine is equipped with a Heidenhain TNC 426 control system and optional equipment such as tool measurement and an automatic 3D probe. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMC 65 V vertical machining centre we have for sale. Contact us for further details. Dwjdpfx Aszza Eaecqjb - Optional Equipment: Tool measurement, Automatic 3D probe, Chip conveyor, External cooling system- Operating Hours (Power-on / Program Run): 52,067 h / 14,085 h- Electrical Connection: 230V / 1A (Auxiliary)- Known Defects: Sensor for control cabinet ventilation does not always turn on; spindle collet seizes after ~3 weeks of inactivity (loosens after ~200 cycles of clamping/releasing, works flawlessly in continuous operation)

Condition: used, DECKEL MAHO DMU 60T HEIDENHAIN 426 Dwedpfxewg Df Do Acqeb – worktable dimensions (length x width): 900 x 500 mm – table load: 350 kg – maximum feeds in the X/Y/Z axes: 600/525/ 500 mm

Year of construction: 2001, operating hours: 26,266 h, condition: used, Colour: Grey Empty weight: 7.000 kg Dimensions (LxBxH): 350 x 220 x 240 cm Price: On request Milling machine, VMC Model: CNC Manufacturer: DMG / Deckel MAHO Type: DMU60T Year of manufacturing: 2001 Control: Heidenhain Working-hours: 26266 Travel: 630x560x560mm Spindle-speed: 10.000 rpm Table-dimensions: 1000x600mm Spindle-take: ISO40 Max. Workpiece-weight: 400kg Dwsdpfx Acsywt Nyoqjb Incl. Filter Interlit SK200-760 Incl. Automatic toolholder Incl. Documents Incl. Video available Machine-weight: 6700kg Machine-dimensions: 3500x2400x2200mm - Year: 2001 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Operating hours: 26266 - Drive system: CNC - Control system brand: Heidenhain - Number of axes [pcs]: 3 - X-axis travel [mm]: 630 - Y-axis travel [mm]: 560 - Z-axis travel [mm]: 560 - Table length [mm]: 1000 - Table width [mm]: 600 - Tool holder: SK40 - Max. spindle speed [rpm]: 10000 - Options: External cooling, Tool magazine - Transport dimensions: 3500mm x 2200mm x 2400mm (l x w x h) - Transport weight [kg]: 7000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum
