Internal threading machine

CHIRON

Condition: good (used), Year of construction: 2006, operating hours: 9,911 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 75 m/min, rapid traverse Z-axis: 75 m/min, nominal power (apparent): 17 kVA, total height: 2,300 mm, total length: 1,500 mm, total width: 2,600 mm, overall weight: 3,400 kg, spindle speed (max.): 30,000 rpm, spindle nose: HSK40, number of slots in tool magazine: 40, input voltage: 400 V, Equipment: documentation/manual, CNC machining center CHIRON FZ08 KS Magnum High Speed Plus (HSP) TECHNICAL CHARACTERISTICS: Year of manufacturing: 2006 CNC control : FANUC 18i-MB5 Number of axes : 7 Stroke X axis : 450 [mm] Stroke Y axis : 270 [mm] Stroke Z axis : 310 [mm] Traversing feeds X, Y and Z axes : 75000 [mm/min] Max. bar diameter in turning spindle : 32 [mm] Main spindle max. speed : 8000 [rpm] Main spindle max. power : 12 [kW] Angular A axis stroke : 360 [°] A axis indexing precision : 0.001 [°] B axis swivelling stroke : -20° / +115 [°] B axis indexing precision : 0.001 [°] Spindle type : HSK40 Max. spindle speed : 30000 [rpm] Tool changer magazin number of stations : 40 Part turnaround by robot (6th side machining) : Yes RS232 Interface : Yes Total power required : 17 [kVA] Supply voltage : 400 [V] Number of running hours : 9911 [h] Dimensions : 1500 x 2600 x 2300 [mm] Weight : 3400 [Kg] Dodex Iiw Ijpfx Apdjkn EQUIPMENT INCLUDED: x1 RENISHAW TS27R tool probe x1 spindle cooling unit x1 parts catcher x1 coolant tank x1 unit for 6th face machining (gripping system not included) x29 tool holders type HSK40 BIG KAISER x10 collets type F37 SCHAUBLIN x1 washing gun x1 3-color status light x1 maintenance manual x1 electrical diagrams manual x1 operator's manual x1 programming manual Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed Machine similar to brands such as Okamoto, ELB, GER, Tacchella, Karstens, Jones & Shipman, Jung, Favretto, Blohm. Internal and external grinding (ID/OD) also to be considered. Surface grinder, lathe, machining center, milling machine.

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 75 m/min, rapid traverse Z-axis: 75 m/min, nominal power (apparent): 17 kVA, total height: 2,300 mm, total length: 1,500 mm, total width: 2,600 mm, overall weight: 3,400 kg, spindle speed (max.): 30,000 rpm, spindle nose: HSK40, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, CNC Machining Centre CHIRON FZ 08K S Magnum High Speed Plus (HSP) TECHNICAL CHARACTERISTICS: Year of manufacturing: 2007 CNC control: FANUC 18i-MB5 Number of axes: 7 Stroke X axis: 450 [mm] Stroke Y axis: 270 [mm] Stroke Z axis: 310 [mm] Traversing feeds X, Y and Z axes: 75000 [mm/min] Max. bar diameter in turning spindle: 32 [mm] Angular A axis stroke: 360 [°] A axis indexing precision: 0.001 [°] B axis swivelling stroke: -20° / +115 [°] B axis indexing precision: 0.001 [°] Spindle type: HSK40 Max. spindle speed: 30000 [rpm] Tool changer magazin number of stations: 40 Dodpfx Aeyq Nyyepdskn Total power required: 17 [kVA] Supply voltage: 400 [V] Dimensions: 1500 x 2600 x 2300 [mm] Weight: 3400 [Kg] INCLUDED EQUIPMENT: x1 RENISHAW tool probe, type TS27R x1 spindle cooling unit x1 coolant tank x1 unit for 6th-face machining x1 SCHUNK clamping vice x84 tool holders - type HSK40 x14 collets - type F35 x1 electrical cabinet air conditioning unit x1 DONALDSON mist extraction unit - type Torit DCE x1 washing gun x1 three-color status light x1 MACHINING INSTRUCTIONS manual x1 operator manual x1 programming manual Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machines similar to Mikron, Hermle, DMG MORI, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas, and Alzmetall, as well as CNC milling, drilling, and tapping machines, and CNC grinding machines

Condition: good (used), Year of construction: 1997, The photo shows a Fanuc Series 0-M (a popular CNC controller used in the 1980s/90s). It supports X, Y, Z axis interpolation and a tool magazine. Features include a CRT screen and a classic push-button keyboard. 3. Electrical parameters (nameplate) Power supply: 3-phase, 380 V, 50 Hz Dodpfx Apjw Uab Asdokn Control voltage: (not specified, but typically Fanuc 110/220 V → transformer) Auxiliary voltage: 24 V Protection: 16 A (flink) Electrical diagram number: 711 792 01 01 4. Machine construction Vertical CNC machining center (milling machine) with a fully enclosed housing. Worktable with grid of holes for mounting workpieces. Carousel tool magazine (visible in the photo) – most often 12, 20, or 24 tools (depending on version). Automatic tool changer (ATC). Z-axis operates vertically (guideway assembly and telescopic way covers visible). 5. Typical technical data (for Chiron FZ 12/15 machines from this period) (values may differ depending on the model, but these are approximate parameters): Travels (X/Y/Z): approx. 500 – 700 / 400 / 400 mm Table surface: 800 × 400 mm (example) Table load: 200 – 300 kg Spindle speed: 20 – 6000 rpm (some versions up to 8000 rpm) Spindle taper: SK 40 (DIN 69871) Spindle drive: 7.5 – 15 kW (depending on version) Tool magazine: 12 – 24 tools Positioning accuracy: ±0.005 mm Rapid traverse: 30 m/min (X/Y/Z axes) 6. Application Metalworking (steel, aluminum, cast iron, light alloys). 📌 General information: • Manufacturer: CHIRON, Germany • Type: CNC machining center • Control: as seen in the photo (Fanuc Series 0-M) • Automatic tool changer • Heavy-duty worktable with workpiece clamping options • Solid industrial construction 📌 Machine condition: • Used machine, in good condition • Regularly serviced • Shows normal signs of use • Fully functional 📌 Application: • High-precision milling • Machining of metal components • Single-part and batch production

Condition: excellent (used), Year of construction: 2015, Control system 840 D SL, twin spindle HSK 40, 2 x 16 tool positions, 18,000 rpm, direct path measuring systems, internal coolant system 30 bar, Knoll coolant system, workpiece changer, laser control, measuring probe, central lubrication system, automatic loading doors. Dsdpfxszcapvj Apdskn

Condition: ready for operation (used), Year of construction: 2012, operating hours: 29,801 h, travel distance X-axis: 729 mm, travel distance Y-axis: 401 mm, travel distance Z-axis: 361 mm, controller manufacturer: FANUC, controller model: Series 31i, spindle speed (max.): 12,000 rpm, number of axes: 4, This 4-axis CHIRON FZ 15 KWM HS vertical machining center was manufactured in 2012. If you are looking to get high-quality milling capabilities, consider the CHIRON FZ 15 KWM HS machine we have for sale. Contact us for more information. Machine Benefits Technical Machine Benefits • Availability: available from 1/7/25 • Operating voltage: 400 v • Control voltage: 230/23 v • Material processed in the machine: aluminum • Cone type : hsk-63 • 48 tool stations • Tool holder: HSK63 Extra Information Dedpfxsx D Nmle Apdekn Machine still under power

Condition: used, Year of construction: 1990, Type/Designation: 307-153/714-750 Serial Number: 82/293 Country of Manufacture: Made in West Germany (before 1990) Dkedpew T U Ubjfx Apdon Technical Data (approximate, for this type of CHIRON machine from the 1970s/80s): Machine Type: Column drill / single-station drilling machine for metal Motor Power: typically from 1.5 kW to 3 kW (three-phase, 380 V) Spindle Speeds: 100 – 4000 rpm (mechanically or electrically switched) Max. Drilling Diameter in Steel: approx. 20–25 mm (depending on the version) Spindle Taper: usually MT2 or MT3 Feed: manual or mechanical (some models equipped with automatic feed) Weight: several hundred kilograms (approx. 300–600 kg) Intended Use: serial production in industry (precise hole drilling, light milling operations in metals, use in production lines) Machine Table: cast iron, capable of securing workpieces Full control panel – variable speed adjustment available 2. Key Working Head Parameters (important for riveting): Press Force (kN) – if specified on the cylinder label or in the electrical box (often 10–30 kN for this size) Spindle/Slide Stroke (mm) – measure from top to bottom position Daylight (working clearance: distance between tool tip and table at top position) Throat Depth – from spindle axis to column (working reach) Max. Rivet Diameter / Work Range – specify based on tests or prior use Voltage: usually 380/400 V, 50 Hz 3. Dimensions and Logistics: L×W×H (of base/overall, in cm) Electrical Supply: 3×400 V, protection e.g. C16–C20 (indicate according to power rating) Weight (weigh with pallet jack with scale or estimate)

Condition: excellent (used), Year of construction: 2016, Siemens 840 SL control, twin spindle, 20,000 rpm, HSK 63, 2 x 32 tool positions, internal coolant supply at 30 bar, X 550 mm, Y 400 mm, Z 400 mm, direct measuring system, workpiece changer, laser control, Knoll coolant system, fixture flushing system, central lubrication system, automatic loading doors, year of manufacture 2016. Dkodpfxezb D Rne Apdjn

Condition: used, MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1*) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindle ... Dedpfx Apsgqg Sgsdjkn

Condition: used, MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1*) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindle ... Dksdpfxogmi Une Apden

Condition: not inspected (used), Year of construction: 1994, travel distance X-axis: 550 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 426 mm, overall weight: 6,500 kg, number of slots in tool magazine: 20, Fanuc OM control unit BT40 spindle, maximum spindle speed 8,000 RPM 20-tool changer 2 tables Nikken rotary table Dodpfx Aszbal Ijpdskn
