Injection moulding machine

Battenfeld

Condition: used, Wittmann Battenfeld 3 Vertical V 800/315 injection molding machines for thermoplastics Type: Vertical V 800/315 Design: Vertical Control system: Battenfeld UNILOG B4 Clamping force: 800 kN Injection unit: 315 Screw diameter: 40 mm Calculated displacement volume: 201 cm³ Maximum shot weight: approx. 183 g Specific injection pressure: 1,575 bar Clear tie bar distance: 370 x 420 mm Minimum mold height: 200 mm Maximum opening stroke: 300 mm Tjdpfx Aszpwrgobaed Machine weight: 3 x approx. 5,500 kg Machine dimensions: approx. 2,917 x 1,423 x 3,643 mm Documentation and technical documents available Condition: used Disassembly and collection must be carried out by the buyer. Scope of delivery: (See image) (Changes and errors in the technical data are subject to change!) We will gladly answer any further questions you may have over the phone.

Condition: used, Wittmann TR7B7D7D0X_09_00 Wittmann Temperature Control Unit DISCO 2 Singulus 3X415V 50/60Hz 16A 5 kW Condition: used Scope of delivery: (See picture) (Changes and errors in the technical data are subject to change!) We will be happy to answer any further questions you may have over the phone. Tsdpfx Aozd Ruwebajd

Condition: used, Wittmann Battenfeld Type: SmartPower 210 Wittmann Battenfeld injection molding machine with UNILOG B8 control For use with thermosets Current software version IO4.26 The machine was serviced / inspected by WITTMANN BATTENFELD Deutschland GmbH in 2026 and brought up to the most current possible standard. In addition to the pressure switches that are already normally present, the machine can be equipped with two additional mold internal pressure switches (Kistler module for mold internal pressure switching, range 1: 20,000 pC, range 2: 10,000 pC). The parts for the mold internal pressure switch upgrade are included in the scope of delivery. Injection molding machine: Series: SmartPower Machine type: 210/1330 Control type: UNILOG B8 Machine number: 137949-100 Machine weight, gross/net Main dimensions of the machine Noise level (DIN EN ISO 3744-46) 65 dB(A) Tedpezdywnefx Abaed Ambient temperature +15 - +40°C Year of manufacture: 2017 Operating hours: 1437 hrs. Hydraulic system: Hydraulic oil, tank capacity Oil temperature min / max. (HLP 32) min 30°C (86°F) / max. 40°C (104°F) Oil temperature min / max. (HLP 46) min 40°C (104°F) / max. 50°C (122°F) Switch-on temperature for oil cooling (HLP 32) 35°C (95°F) Switch-on temperature for oil cooling (HLP 46) 45°C (113°F) Electrical system: Drive power, hydraulic pump 37kW Motor voltage Frequency Water system: Oil cooler: Cooling water consumption approx. 0.5 - 1.5 m³ / h (0.65 - 1.96 cu yd) Cooling water inlet max. 35°C (95°F) NW ⅜" Cooling water battery: Cooling water inlet ∅ ¾", max. 10 bar (max. 145 psi) Cooling water outlet ∅ ¾" Number of heating zones incl. nozzle 5 Clamping unit SmartPower 210 Clamping force 2100kN Link to a short demonstration video on YouTube: ?v=DGLJ1uijosw Type: SmartPower 210 Condition: used Scope of delivery: (See picture) (Changes and errors in the technical data are subject to change!) We will be happy to answer any further questions you may have on the phone.

Condition: refurbished (used), Year of construction: 2009, ø 450-1200 mm PE/PP Central clamping Tedpfow H Iyfox Abajd

Condition: good (used), Year of construction: 1997, This Battenfeld cooling tank is in machine storage at Plastima Used Machinery. The vacuum tank is from 1994 and is in great condition. Todpexu E T Asfx Abaed Brand: Battenfeld Extrusionstechnik GmbH Model: V125VA Year of construction: 1997 Tube outer diameter max: 125 mm Cooling length: 6000 mm

Condition: excellent (used), Year of construction: 2003, operating hours: 67,092 h, BATTENFELD HM 10000-9200 Manufacturer: BATTENFELD Model: HM 10000-9200 Control system: UNILOG B4 Year of manufacture: 2003 Operating hours: 67,092 h Technical data – Clamping unit Clamping force: 10,000 kN Tie bar spacing (h x v): 1120 x 1400 mm Platen size (h x v): 1960 x 1690 mm Minimum mold height: 550 mm Maximum mold height: 1,020 mm Maximum daylight: 2,120 mm Opening stroke: 1,100 mm Ejector stroke: 300 mm Ejector force: 118 kN Movable platen centering diameter: 250 mm Fixed platen centering diameter: 315 mm Technical data – Injection unit Screw diameter: 120 mm Shot volume: 5,655 cm³ Injection pressure: 1,632 bar Screw length: 22 L/D Screw stroke: 500 mm Screw speed: 130 min⁻¹ Screw torque: 11,370 Nm Plasticizing rate: 144 g/s PS Free discharge plasticizing rate: 1,144 g/s PS Number of heating zones: 8 Nozzle stroke: 700 mm Dimensions & Weight Machine dimensions (L x W x H): 11.6 m x 2.9 m x 2.5 m Total weight: 76,500 kg Equipment Display language: German CompactFlash drive 4x hydraulic core pulls Leveling elements Tedjx Up Rhepfx Abaed EUROMAP 12 interface Interface for temperature control unit Enlarged oil cooler 16x mold heating circuits

Condition: excellent (used), Year of construction: 1999, Battenfeld TM 1000/350 Clamping force: 100 tons Screw diameter: 40 mm Year of manufacture: 1999 Injection volume: 204 g Tsdpfx Abor Nf Rgjajd Tie bar spacing: 42x42

Condition: excellent (used), Year of construction: 2008, Battenfeld HM 100/525 with Battenfeld R10S Robot / Operating Hours: approx. 19,000 in automatic mode Year of manufacture: 2008 Injection Unit: Screw diameter: 40 mm Shot weight: 228.4 g Injection pressure: 2,100 bar Dosage volume: 251 ccm Clamping Unit: Clamping force: 100 t Tie bar spacing: 470x420 mm Platen size: 680x663 mm Tjdpfxoz Ipi Ee Abaod Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG B6 - touchscreen Additional equipment: Machine in very good technical condition Operating hours: approx. 19,000 in automatic mode Total operating hours: 26,580 Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and corrosion-resistant Battenfeld R10S Robot Year of manufacture: 2015 5-axis robot: 3 axes powered by servomotors (electric); axis B - pneumatic, axis C Robot with adapter Purchase of robot at extra cost Dimensions: Weight: 4,600 kg Length/Width/Height: 4.23x1.41x2.05 m All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests for the selected machine or to participate in live technical tests at our premises in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2007, Battenfeld TM 100/525 Year of manufacture: 2007 injection unit: Screw diameter: 40 mm Injection weight: 228.4 g Injection pressure: 2100 bar Metering volume: 251 ccm Clamping unit: clamping force: 100 t tie bar distance: 420x420 mm size of clamping platens: 640x640 mm ejector: hydraulic Tsdpfx Abez Ipifjaod clamping unit: toggle lever Control system: UNILOG B2 Additional equipment: Euromap 67 Robot interface Hydraulic core pull x 1 Control with hot runners x 12 Injection unit is wear resistant and resistant to corrosion Central lubrication Automatic mold height adjustment Dimensions: Weight: 3900 kg Length/width/height: 4.46x1.33x1.78 m Drive: Pumps/motor: 18.5 kW Heating power: 12,1 kW Total power: 30.6 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2014, Wittmann Battenfeld HM 150/750 Servo Power / Hybrid Machine / Operating hours: approx. 29,000 in automatic mode Year of manufacture: 2014 Injection unit: Screw diameter: 50 mm Injection weight: 402.2 g Injection pressure: 1,714 bar Shot volume: 442 ccm Clamping unit: Clamping force: 150 t Tie bar distance: 520x470 mm Dimensions of platens: 760x755 mm Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG B6P - touchscreen Additional equipment: Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 29,000 in automatic mode Total operating hours: 36,714 Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and corrosion-resistant Main drive motor - servo motor driven by inverter - energy saving Dimensions: Weight: 6,600 kg Length/Width/Height: 4.82x1.42x2.20 m Tsdpfsz Iph Usx Abasd All machines offered are started up by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request
