Used powder equipment for sale (76)

Year of construction: 2022, condition: new, Model KPO-3 Booth Type Open Worksize dimensions 2800 width x 2200 height x 1000 depth Gcjdpfx Asbuyr Tsd Asa Overall dimensions 2800 width x 2300 height x 1700 depth Weight 550kg Power supply Electric Nominal power 0,69kW x2 Voltage 380V Frequency 50-60Hz Filters Polyester Filters count 3 Filters hang type Bagnet type, easy on/off Filter area 22,5m2 Filter cleaning system Pneumatic - Jet Venturi Ventilator type Aluminium ray rotor 2pcs. Loudness 74dBa Air consumption 10,200m3/h Warranty 12 months

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 700 kg, workpiece height (max.): 2,300 mm, workpiece length (max.): 6,000 mm, insulation material: Mineralwolle, insulation thickness: 150 mm, workpiece width (max.): 2,000 mm, Complete Plant with Chemical Pretreatment (7 Stages) for GSB Certification (QUALICOAT) (Suitable for Multimetal) All dimensions and further modifications can be taken into account during design and planning. The offer includes the following components: - Pretreatment cabin incl. reverse osmosis unit - Walk-in coating booth - Powder spray gun - Powder curing oven - Dryer - Manual conveyor system - Lifting-lowering station - Electrical control system Details: 1. Walk-in cleaning cabin, pretreatment for steel and aluminum The cleaning cabin is designed for automatic cleaning. Medium pressure spraying can be applied. The cabin contains 7 different spray tanks. Maximum part size: L = 6000 mm, W = 2000 mm, H = 2300 mm. 1. Cabin dimensions - Length: 6,500 mm - Width: 3,000 mm - Height: 3,600 mm 2. Total pretreatment dimensions - Length: 6,600 mm - Width: 4,640 mm - Height: 4,300 mm Process Stages: 1st Stage: Degreasing/Neutral Pickle - Heated tank, 50-55°C, time = 3-6 minutes, drip-off time = 80 seconds 2nd Stage: Acidic Mineral Pickle - Heated tank, 50-55°C, time = 3-6 minutes, drip-off time = 80 seconds 3rd Stage: Rinse 1 - Rinsing with ambient temperature, time = 0.75-1.5 minutes, drip-off time = 1 minute 4th Stage: Rinse 2 - Rinsing with ambient temperature, time = 0.75-1.5 minutes, drip-off time = 45 seconds 5th Stage: Rinse 3 Gcjdpfx Ajffv Tped Aja - Rinsing with ambient temperature, time = 0.75-1.5 minutes, drip-off time = 45 seconds 6th Stage: Nano-Ceramic - Processed at ambient temperature, time = 0.75-1.5 minutes, drip-off time = 60 seconds 7th Stage: Overhead spray ring for post-rinsing after Stage 6 - Rinsing with ambient temperature, time = 1 minute, drip-off time = 60 seconds 8th Stage: Passivation, no-rinse for aluminum - Rinsing with ambient temperature, time = 2-3 minutes, drip-off time = 1-2 minutes 1.1. Reverse Osmosis Unit - Reverse osmosis system, 250 liters/hour 1.2. Oil Skimmer - Tank no. 1 is equipped with an oil skimmer "UniSkim-21-100". Construction: The spraying system is two-part and movable, and can be shifted up to 500 mm via a pneumatic sliding system. Return to the tanks is also mobile via a pneumatic sliding system with 7 positions in order to serve the 7 tanks. 2. Walk-in coating booth 1. Booth dimensions - Length: 7,400 mm - Width: 4,000 mm - Height: 3,236 mm 2. Booth dimensions incl. extraction system - Length: 8,552 mm - Width: 6,232 mm - Height: 4,393 mm The booth features 2 single-side pneumatic doors for entry/exit of workpieces, and an additional side door for the coater. 3. Powder Coating Equipment Wagner, Manual System "Sprint 2 B" 4. Powder Curing Oven - Internal dimensions: - Length: 6,500 mm - Width: 2,200 mm - Height: 3,416 mm 5. Dryer - Internal dimensions: - Length: 6,500 mm - Width: 1,200 mm - Height: 3,416 mm 6. Manual Conveyor System The conveyor system consists of: The conveyor system is designed for a crossbar weight of 700 kg. The carriage can carry a maximum of 2,000 kg on 3 rails.

Condition: good (used), Year of construction: 1990, functionality: fully functional, For sale is a complete, fully operational powder coating system, year of manufacture 1990. Over the past few years, numerous system components have been modernized or completely replaced and upgraded. The system was decommissioned in Q1-2025, but can be reactivated and operated at any time if required. All components remain on standby and can be started up and demonstrated on site. The system features one manual and two automatic spray booths (which can be operated simultaneously). The maximum workpiece dimensions that can be coated across all booths are 7000x2300x800 mm. The entire conveyor system is supplied by CSF. Gcjdpfx Asw Ek Ntod Aja All system controls, including a visualization system, all control cabinets, all frequency inverters, as well as many other components have been completely renewed within the last 5–7 years. There is no maintenance backlog; the system has been regularly and meticulously serviced by our own maintenance department and the respective manufacturers. A detailed description can be provided upon request. Price on request!

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 250 kg, Manual powder coating system, suitable for gas cylinder coating Gedewhbvpepfx Ad Ajca

Condition: new, Year of construction: 2025, functionality: fully functional, As a leading manufacturer of systems for surface technology, we offer you an almost limitless portfolio for powder coating applications. At our site in 47669 Wachtendonk, we turn your individual requirements into reality and produce your desired concept. Thanks to our in-house production for almost all components, we are flexible and can respond specifically to your requirements. We not only provide you with your ideal powder coating system - we are also on hand with comprehensive user expertise to support you in all matters relating to surface technology. Every item offered here is manufactured especially for you. Whether large or small projects - we supply complete systems from a single source, tailored to your requirements. We look forward to hearing from you and implementing your ideas together! Example: KM Pro KM Pro electric chamber oven Heating type electric Air circulation Heating capacity 30kW Circulating air motor 3kW Insulated up to 250°C Connected load 380-400V, 34kW Floor insulation 100mm Insulation walls 150mm (highly compressed) External dimensions : 3400mm (L) x 1800mm (W) x 2550 (H) without fan motor on top and switch cabinet on the side Working dimension (inside) Gcjdjtxcpwopfx Ad Aoa 3100mm (L) x 1200mm (W) x 1880m (H) Height due to the low-lying rails ≠ 2000mm Equipment - Double-wing door, incl. door bolt and handle - Adjustable air slats (optimum air circulation regulation) - 2 pcs. Heating coil - 2 PT 100 temperature sensors (top and bottom) - Exhaust air throttle flap, manual adjustment (exhaust air regulation) - 2 rails on the oven ceiling - Walls made of galvanized sheet steel Control system : - Rittal control cabinet - Hitachi panel 7 inch (touch operation) - Control via Hitachi PLC - Speed control of the air circulation motor via frequency converter, with braking resistor - Emergency off - Adjustable control power of the heating coil (if current peaks are reached, you can regulate the oven down) - GELLING function for stoving different colors in one oven (air circulation motor is throttled over a period of time) - OPEN-DOOR function regulates the air circulation downwards when the door is opened. So you have less heat loss - Traffic light to indicate the respective status. - STAY-HOME-WARM-UP is a time-controlled switch-on of the oven. This allows you to start the oven before starting work. - SEE-TEMP shows the temperature curve of the oven. This allows you to check the temperature. - GO-HOME-LEAN-BACK switches the oven off via a time control.

Condition: good (used), Year of construction: 2019, functionality: fully functional, inner dimension length: 7,400 mm, inner dimension width: 1,600 mm, inner dimension height: 2,200 mm, Powder Coating – Complete System for Large Parts – including Curing Oven 7,400 mm, year 2018–2021 Complete powder coating system for large parts, including: • OVEN (1): Vismont KWP-440/114 – Internal: 7,400 mm length – year 2018 • OVEN (2): Libra SLET40-25-20 – year 2020 • POWDER BOOTH: Vismont KNP-1500/06 – year 2018 • WASHING SYSTEM: Libra MR35-21-17 – year 2021 Gedpfx Adexrd A Dj Aoca • MANUAL WASHING UNIT: Libra MR42 – year 2020 • AIR FILTRATION SYSTEM: Kemper 390600 – year 2016 • MANUAL POWDER COATING SYSTEM: Nordson Encore HD MPS – year 2021 • SCREW COMPRESSOR: Kaeser SM 15 – year 2013 • OVERHEAD CONVEYOR SYSTEM • FORKLIFT: Hyundai 30L-7A – year 2012 All equipment is in operation and fully functional. Price: Depending on partial or complete purchase.

Year of construction: 2019, condition: new, Powder coating machine Mini - for beginners The Spark / ROMER® powder coating plant Mini - consists of: Powder oven SLS-9 small (inside: 1200x1400x1200mm - without transport system) Powder booth KPZ-2 Delivery time: approx. 12 to 16 weeks after ordering Shipping costs will be calculated individually. ( also self collection ) Gedpfectx Irox Ad Ajca In order to offer you a detailed quotation for a system tailored to your application, further details regarding the application and the batch would be necessary. We will then immediately prepare an offer for a suitable plant in the dimensions according to your request. Payment terms: 30% deposit and the 70% balance upon notification of readiness for shipment.

Condition: new, Year of construction: 2025, functionality: fully functional, total length: 2,000 mm, total width: 2,100 mm, power: 3 kW (4.08 HP), compressed air connection: 6.5 bar, volume flow: 6 m³/h, Open spray stand 2x2.1x2.2 The overspray during powdering is collected via the suction unit. The powder spray stand is supplied on castors and is therefore mobile. - The suction unit is equipped with a 60 l powder container (rollbar). - There are 4 filters in the extraction unit as the 1st stage. - The absolute filter is located above the booth. Gcjdpfefhv Tqex Ad Asa 1 Dimensions of the powder stand Width 2,000 mm Depth 2,100 mm Height 2,200 mm 2 fans 1 pc. 6,000 m³/h Electric motor 3.0 kW 3 Filter Ø 325x600 4 pcs. type filter cartridges 4 Electromagnetic valves 2 pcs. 1" "Turbo" Italy 5 Absolute filter 1 pc. type pocket filter

Condition: new, Year of construction: 2025, Powder coating booths, sizes defined by customer, Gedpfxjizw Hyo Ad Asca Additional equippment possible.

Condition: new, functionality: fully functional, Pretreatment system for wet chemical cleaning of workpieces to be coated - NEW - As a leading manufacturer of systems for surface technology, we offer you an almost limitless portfolio for powder coating applications. At our location in 47669 Wachtendonk, we put your individual needs into practice and produce your desired concept. Thanks to our own production for almost all components, we are flexible and can respond specifically to your requirements. With us, you not only get your ideal powder coating system - we also have comprehensive user expertise at your side to support you with all questions about surface technology. Every item offered here is manufactured especially for you. Regardless of whether it is a large or small project - we supply complete systems from a single source, according to your ideas. We look forward to hearing from you and implementing your ideas together! Gedpfxotxcyis Ad Asca Here we offer you our newly manufactured VBH KM Pro pretreatment system for part dimensions of up to 4,000x1,400x2,000mm. System description: Pretreatment system for wet-chemical cleaning of workpieces before coating using the 3-zone process + nozzle line for loss. Equipment: -Washing stations for up to 2 traverses in one cleaning cycle -3 rails (1 middle, 2 side washing stations) -Washing ring with removable middle nozzle line (Info: The middle nozzle line is used when 2 rails with flat workpieces are to be cleaned at the same time; without the middle nozzle line, wider workpieces can be moved in and cleaned on the middle guide rail.) -4 washing zones (degreasing circuit, 1st rinse (pre-rinse) circuit, 2nd rinse (final rinse) demineralized water cascading to degreasing basin 1 -final spray ring (zone 4) for passivation in the no-rinse process when pulling out the goods carriers (duration of fogging adjustable) Passivation is injected into demineralized water. Inlet in basin 1. -2 storage containers made of stainless steel including level monitoring (sink 1 + demineralized sink) -1 stainless steel container insulated, as electrically heated, including level monitoring (degreasing) -Drain taps on the basins for disposal, cleaning and new preparation -Supply of the VE water requirement via mixed bed cartridges -Exhaust fan to remove the water vapor to the outside including exhaust pipe -Cabin made of stainless steel -Loading via double-wing door -Operating terminal (PLC controlled) outside the washing cabin -Control via PLC and touch display including remote maintenance module -Intuitive, illustrated operation for quick and easy handling Suitability: -particularly for flat workpieces, as the use of the central line means 2 product carriers can be cleaned at the same time -Frames and uncomplicated, open geometries up to a maximum of 1,000 mm wide can also be cleaned well Advantages: -Personnel-free, automatic cleaning, within approx. 20 minutes. -optimal adhesion properties especially for the subsequent coating -fully parameterizable process program from KM Industrieservice, thus completely flexible for changed chemical systems -lifetime support and spare parts availability from KM Industrieservice -cost-effective pretreatment solution with service life-optimized tank quality, thus also cost-effective wastewater disposal We can send you a video link to this system on request.

Year of construction: 2019, condition: new, Booth KPZ-4P • Booth Type Closed drive-thru • Worksize dimensions 3500 width x 1800 height x 1000 depth • Overall dimensions 3300width x 2300 height x 1800 depth • Power supply Electric • Nominal power 0,69kW x4 • Voltage 380V Gcodpfx Adobxmfns Aea • Frequency 50-60Hz • Filters 100% Polyester • Filters count 4 • Filters hang type Bagnet type, easy on/off • Filter area 30m2 • Filter cleaning system Pneumatic - Jet Venturi • Ventilator type Aluminium ray rotor . • Air consumption 20,400m3/h • Loudness 74dBa • Doors Double, both side • Inside drive diameter 800mm

Condition: new, Year of construction: 2025, functionality: fully functional, total length: 3,636 mm, total width: 2,300 mm, workpiece weight (max.): 200 kg, power: 2.2 kW (2.99 HP), temperature: 220 °C, heating capacity: 39 kW (53.03 HP), inner dimension length: 3,225 mm, inner dimension width: 1,400 mm, inner dimension height: 2,000 mm, workpiece height (max.): 1,600 mm, workpiece length (max.): 3,000 mm, volume flow: 4.5 m³/h, fuel: electricity, insulation material: Steinwolle 75 kg/m³, insulation thickness: 150 mm, workpiece width (max.): 1,200 mm, Powder coating booth open spray booth Dimensions of the powder booth Width 2,000 mm Depth 2,100 mm Height 2,200 mm Fan 1 fan 6000 m³/h Power 3 kW (electric motor) Filter 4 pcs. type filter cartridges (à ⌀325 x 600 [mm]) Electromagnetic valves 2 pcs. 1" "Turbo" Italy Absolute filter 1 pcs. pocket filter type Wagner "Prima Sprint" powder gun Mains standard 230 VAC Frequency 50 - 60 Hz Inlet compressed air 6-8 bar Outlet compressed air 0.05 - 5.5 Nm³/hour Powder combustion furnace Internal dimensions length 3,225 mm Internal width 1,400 mm Internal height 2,000 mm Insulation Rock wool 150 mm [75 kg/m³] Temperature Max. 220°C Fans 1 unit 4,500 m³/h Gsdeb Dxnwspfx Ad Aeca Electric motors 1 pc. 1.5 kW, 1450 rpm, 3 F, 50 Hz Thermal output 39 kW Doors on both sides 2 manual, insulated with rock wool 150mm 70Kg/m³ Indirect heating via thermoblock, Heating chamber Tubular heat exchanger Burner* 1 electric heater Steel support for fastening conveyor technology IPE 80 *Choice of gas, oil or hybrid for an extra charge Manual conveyor technology Substructure Steel profiles IPE and SQ Bends 9040C 90 degrees, radius 600 mm 4 pcs. Rail system no. 9040 27m Roller units 9842 GLRHT 16 pcs. Connectors 9041 M 12 pcs. Fixing clamps 9047/100 16 pcs. Manual tongue switch 45 degrees 9401 AIYM 2 pcs. Load carrier L = 1000 mm 8 pcs.

Condition: new, Year of construction: 2025, Some components can be choose: - chamber pretreatement with osmosis plant, - Water drier oven, - Powder curing oven, - manual transportsystem inkl. steel frame, - Controler siemens, Additionsal chooseable components possible. Gcjdpjizw Hnsfx Ad Aea

Condition: new, Year of construction: 2025, Starter Kit KM Pro for Powder Coating Consisting of Electric Curing Oven KM Pro + ASAP XS Eco In stock and available immediately Electric Curing Oven KM Pro ✅Heating medium: Electric ✅Heating type: Circulating air ✅Heating capacity: 30 kW (continuously adjustable) ✅Circulation air motor: 1.5 kW up to 250°C ✅Connected load: 380-400 V, 32 kW ✅Insulation: 150mm compressed ✅Working dimensions: 2200mm (L) x 1900mm (W) x 1700mm (H) ✅KM Pro control unit with crystal-clear touch display and intuitive operation ✅Remote maintenance KM Pro optional (additionally for only €2,200.00, controllable via smartphone or PC) ✅Loading via double-wing door ✅2x rack trolleys, half size for simultaneous curing ✅Automatic exhaust via actuator for smoke and temperature extraction ASAP XS Eco Powder Extraction ✅4,000 m³/h extraction capacity ✅2 polyester filter cartridges, each with 20 m² filter area ✅Working dimensions: 2300mm (H) x 1600mm (W) ✅Jet-pulse filter cleaning, manually switchable ✅Collection container with rollers ✅Powder baffle plate ✅Silencer for pleasant working noise levels Gcjdpextf Azefx Ad Aja ✅Mobile, can be rolled ✅Extraction fan 1.1 kW with IE3 motor ✅Sturdy construction made of galvanized sheet metal ✅Ready to connect via 16 A plug Now together for just €35,990.00 net, plus shipping For more information, feel free to contact us. LEASING / HIRE PURCHASE Together with our financing partner, we are happy to offer you leasing and hire purchase options (subject to good credit rating). Contact us for details. KM Industrieservice – The machine builder for your surface technology needs, specializing in powder coating. We manufacture: • Curing technology (electric, gas, oil, infrared, wood chips, hybrid) with certified curing results, available as KM Basic or KM Pro versions • Extraction and filter systems as standalone or cabin solutions in various designs • Pre-treatment systems for wet-chemical cleaning prior to coating, ensuring ideal adhesion conditions (manual, automatic, in all versions) • Blasting technology, manual or automatic, from small parts up to heavy-duty • Transport technology – for efficient parts transport (manual, automatic, lift-lower units, transverse shuttles, combination devices, and much more) • Remote maintenance – Fast and flexible service interventions Our Service Promise: ✅Highly individual consulting, manufacturing, and production tailored for even the most demanding requirements, all from a single source ✅Perfect fit and reliable delivery ✅In-house, German-speaking service technicians ✅Manufacturer expertise – As the OEM, we know your equipment inside out, and you can always count on immediate support. ✅Top-level and rapid spare parts availability ✅Long-term assistance for durable systems A video says more than a thousand words – Visit us on social media: ✅Instagram: km_industrieservice ✅Facebook: KM Industrieservice Would you like an in-depth consultation? We are happy to advise you personally: ✅02153-1377061. We look forward to your inquiry and to finding the right solutions for you!

Year of construction: 2022, condition: new, Model SLS-9 working dimensions 1000 width x 1400 height x 1200 depth External dimensions 1200 width x 1660 height x 1400 depth Electrical power supply Rated power 9 KW Voltage 380V Frequency 50-60Hz Door type One-sided, blind Homogeneity <± 4,0 ° C, at 180 ° C Temperature stability <± 5 ° C Temperature max. 230 ° C Transport: without Gravity Heaters Exchangeable heating modules Capacity 3456 L Warranty 12 months Delivery time: approx. 12 - 16 weeks after ordering Shipping costs will be calculated individually. GERMAN SPEAKING CONTACT PERSONS IN GERMANY JUST ASK Also plants according to your desire you simply ask Gedpfx Asb Al Akod Asca More information under Romer Germany Pintura en pols, pintura electrostàtica, Powder Coating, Jauhemaalaus, muovijauhetta , Peinture en poudre, thermoplastique, Verniciatura a polvere, Poederlakken, Порошковая окраска, Порошкове фарбування gemapulverbeschichtungskabine powder coating plant powder coating plant powder coating powder coating booth surface technology powder gun powder guns baking oven powder oven Industrial oven INDUSTRIEOFEN Air circulation stoving furnace Powder furnace

Condition: new, Year of construction: 2025, functionality: fully functional, insulation material: Mineralwolle 75 kg/m³, insulation thickness: 150 mm, 1. powder coating booth, open spray booth Gcedpfx Aoffwfxsd Aoa The overspray during powder coating is collected by the suction unit. The powder spray booth is supplied on castors and is therefore mobile. - The extraction unit is equipped with a 60 l powder container (rollbar). - There are 4 filters in the extraction unit as the 1st stage. - The absolute filter is located above the booth. 1 Dimensions of the powder level Width 2,450 mm Depth 2,350 mm Height 2,700 mm 2 fans 1 pc. 6,000 m³/h Electric motor 3.0 kW 3 Filter Ø 325x800 [mm] 4 pcs. type filter cartridges 4 Electromagnetic valves 2 pcs. 1" "Turbo" Italy 5 Absolute filter 1 pc. type pocket filter 2. powder combustion furnace 1 Internal dimension length 4,000 mm 2 Inner dimension width 1,500 mm 3 Internal height 2,200 mm 4 External dimension incl. thermoblock length 5,250 mm 5 External dimension incl. thermoblock width 2,050 mm 6 External dimension incl. thermoblock height 2,530/2,750 mm 3. switch cabinet 4 Manual conveyor system The "Mantion system" conveyor technology is designed for max. 250 kg per product carrier and 750 kg/ trolley.

Condition: new, Year of construction: 2025, Internal dimensions LxWxH 4300x1700x2200mm, Gcsdpeizw E Uofx Ad Aea Temperature max. 220°C, oil, gas or electrical heated possible, Tracks for hordes waggons possible, Manual or automatic transport usable, flap or sliding doors producable.

Condition: new, Year of construction: 2024, Povder sieve Model SV-200 Screen type stand Mesh 149 µ Gjdpfx Asbwh S Sjd Aeca External dimensions 700 x700 x1200mm 220-240V voltage Power Consumption 40W Performance ~ 20kg/5min Frequency of 50Hz Tank with fluidisation

Condition: new, Year of construction: 2025, Powder baking furnace 3,500 x 1,900 x 2,000 mm 1 Inner dimension length 3,500 mm 2 Inner dimension width 1,900 mm 3 Inner dimension height 2.000 mm 4 Substructure 1 set of steel profiles 5 Walls 1 set of double-sided galvanized sheets 1mm, outside RAL 6 Insulation walls, ceiling 1 set rock wool 150mm 75Kg/m² 7 Floor furnace receives 2 drive-in rails for trolleys 8 Temperature 220°C Gedjfhv Tcspfx Ad Aoca 9 Fans 1 pc. 7.500 m³/hour 10 Electric motors 1 pc. 3 kW , 1450 U/m, 3 F, 50 Hz 11 Thermal power 58 kW 12 Hinged doors one-sided 2 pcs. insulated with rock wool 150mm 75Kg/m² Heating indirectly by thermoblock 13 Thermoblock 1 set stainless steel INOX AISI 316 heating electric heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burner 1 pc. furnace is heated electrically 15 Exhaust air 1 pc. device for exhaust air pipe, manual flap guide

Condition: new, Year of construction: 2025, machine/vehicle number: A1481630, Complete finishing line max. product dim. lenth = 2000mm, width = 750mm, hight = 1000mm max. weight 50kg (higher weight possible) Godpfxebqh R Tj Ad Aeca speed up tp max. 1m/min. (higher speed possible) Please contact us for more information.

Condition: new, Year of construction: 2025, functionality: fully functional, temperature: 220 °C, insulation material: Mineralwolle 75 kg/m³, insulation thickness: 150 mm, Powder ovens in various sizes 1 Internal dimensions length 1500 - 6,500 [mm] 2 Internal dimensions width 1700 - 1,900 [mm] Gedpfx Aofhv Tljd Ajca 3 Internal dimension height 2,000 [mm] 4 Substructure Steel profile 5 Walls 1 mm galvanized sheet metal on both sides, RAL on the outside 6 Insulation walls, ceiling rock wool 150mm 75Kg/m² 7 Oven floor receives 2 entry rails for rack trolleys (optionally with conveyor technology) 8 Temperature 220°C 9 Fans 1 - 2 pcs. 2600 - 15,000 [m³/h] 10 Electric motors 1 - 2 pcs. 1.1 - 6 [kW] , 1450 [rpm], 3 F, 50 [Hz] 11 Thermal output 14 - 99 [kW] 12 Sash or sliding doors on one or both sides 2 - 4 insulated with rock wool 150mm 75Kg/m² Indirect heating via thermoblock 13 Thermoblock stainless steel INOX AISI 316 Heating electric or gas heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection

Condition: new, Year of construction: 2025, Powder coating system for large parts All dimensions and other changes can be taken into account in the design and planning The offer includes the following components: Cabin for chemical pretreatment (3 zones) with spray ring Walk-in coating cabin Powder gun Powder firing oven Manual conveyor system Electrical control Example: (all sizes can be changed individually) Space requirement: 30 x 15 meters Part size: L= 6,200mm W= 2,300mm H= 2,000mm Walk-in cleaning cabin including automatic spray ring 1 Dimensions of the cabin Length 9,000 mm Width 4,500 mm Height 3,400 mm 2 Dimensions of the tanks Length 1,200 mm Width 850 mm Height 1,000 mm 2 Dimensions of the cabin complete Length 9,140 mm including tanks width 5,580 mm height 4,200 mm Walk-in coating booth, manual coating 1 Dimensions of booth length 9,000 mm width 4,500 mm height 3,400 mm 2 Dimensions of booth including extraction length 10,125 mm width 4,500 mm height 3,400 mm powder firing oven 1 Internal dimensions length 6,500 mm 2 Internal dimensions width 2,500 mm 3 Internal dimensions height 2,950 mm 4 External dimensions including thermoblock length 7,600 mm 5 External dimensions including thermoblock width 2,800 mm 6 External dimensions including thermoblock height 3,100 mm Manual conveyor system The conveyor system consists of made of: 1. Support structure, consisting of steel elements, 120x120m/ IPE 160 2. Rollers - No. 9862 GL 4 pieces 3. Pneumatic accessories for locking - unlocking during transfer 4. Rail system - No. 9060 - 234 meters 5. Rollers - No. 9862 GLHT 24 pieces 6. Connecting pieces - No. 9061M 34 pieces 7. Fastening clamps - No. 9067/180 234 pieces 8. Stoppers - No. 9169 21 pieces 9. Movable locking - No. 9601 VM 6 pieces 10. Rigid locking - No. 9601 VF 17 pieces Electrical control The electrical control unit is divided into electrical and automatic control. With it we can control all the units mentioned above and consists of: - PLC - Touch screen 5" color -easy view- - Modem Godpfx Adobhh Awe Ajca - Thermo-magnetic switch. Fuse (Telemechanique, Siemens, ABB). - Cables, supports, pipes, etc.

Condition: new, Year of construction: 2025, functionality: fully functional, power: 88 kW (119.65 HP), temperature: 220 °C, heating capacity: 30 kW (40.79 HP), workpiece height (max.): 1,500 mm, workpiece length (max.): 500 mm, insulation material: Steinwolle, insulation thickness: 150 mm, workpiece width (max.): 500 mm, Scope of delivery: 1. chemical pre-treatment by spraying (in cycle process) 2. dryer 3. powder coating system 4. single powder oven 5. conveyor technology, semi-automatic 6. electrical control system Hall/ floor space Floor area of the system max. 12,000 x 6,500 mm Hall floor Industrial floor Workpiece sizes Max. Part dimensions L= 500mm, H= 1,500mm, W= 500mm Range of steel parts Conveyor technology P&F chain conveyor in cycle mode, semi-automatic Pre-treatment Gsdpfx Aeulwg Ned Aeca Chemical Power supply Electricity On-site power (max. 88 kW) Gas On-site power Compressed air On-site power Water On-site power Calculation Type of system Cycle system Conveying speed 3.2 meters / min Length per cycle L = 1,600 mm Time for cycle movement: Tm = 1.6 meters : 3.2 meters/min = 0.5 minute Time for cycle standstill: Ts = 8.5-12 minutes Total time for cycle Tt = Tm + Ts = 9-12.5 min Electrical energy: Total power 88 kW min. Average consumption 60 kWh max. average consumption 70 kWh

Condition: new, Year of construction: 2025, functionality: fully functional, total length: 30,000 mm, total height: 4,300 mm, total width: 6,500 mm, workpiece weight (max.): 100 kg, temperature: 220 °C, heating capacity: 80 kW (108.77 HP), workpiece height (max.): 1,200 mm, workpiece length (max.): 2,500 mm, insulation material: Mineralwolle 75 kg/m³, insulation thickness: 150 mm, workpiece width (max.): 800 mm, The continuous system consists of the following components: Chemical pre-treatment by spraying Dryer Gjdpfx Adsum Ufls Asca Powder coating system Powder curing oven Conveying technology (cycle process) Electrical control system

Condition: new, Year of construction: 2025, Starter Packages Powder Coating Starter sets or individually designed packages for starting your own business in surface technology, e.g. for coating alloy wheels: The package includes two sample configurations for entering powder coating or expanding an existing business. Our focus is on customized consulting tailored to the customer’s budget and requirements. Modifications and special requests are standard with us. Proven, robust and low-maintenance technology is at the center of our offer. Gedpobqk Nbefx Ad Ajca Set 1: - Powder curing oven, internal dimensions 2,000 x 1,900 x 2,000 mm - 150 mm thick mineral wool wall insulation for energy-efficient and cost-saving operation - 36 kW thermal output for rapid heat-up time - Oil, gas, or electric heating options - 6,000 m³/h recirculating air (2.2 kW) for efficient heat transfer to workpieces - Up to 220°C - Powder coating booth (open spray booth) Powder booth dimensions: - Width: 2,100 mm - Depth: 2,000 mm - Height: 2,200 mm - Fan: 6,000 m³/h, electric motor 3.0 kW for a clean working environment - Filters: 4 units, ø 325x600, cartridge type with interval-controlled self-cleaning - Secondary filtration via pocket filters - Powder coating system Wagner, manual system “Sprint 2 B” - Latest model from premium manufacturer Wagner for optimal coating results (other brands available upon request) - Corona manual gun - PEM-C4 Ergo - EPG-Sprint control unit - Powder feed system with Fluid Crown ST 550/10 - Powder injector PI-F1 - Equipment trolley with vibrating table Set 2: - Powder curing oven, internal dimensions 1,500 x 1,200 x 1,750 mm - 150 mm thick mineral wool wall insulation for energy-efficient and cost-saving operation - 14 kW thermal output for rapid heat-up time - Electric heating - 2,600 m³/h recirculating air (1.1 kW) for efficient heat transfer to workpieces - Up to 220°C - Powder coating booth (open spray booth) Powder booth dimensions: - Width: 1,200 mm - Depth: 1,100 mm - Height: 2,380 mm - Fan: 2,500 m³/h, electric motor 1.1 kW for a clean working environment - Filters: 2 units, ø 325x600, cartridge type with interval-controlled self-cleaning - Secondary filtration via pocket filters - Powder coating system Wagner, manual system “Sprint 2 B” - Latest model from premium manufacturer Wagner for optimal coating results (other brands available upon request) - Corona manual gun - PEM-C4 Ergo - EPG-Sprint control unit - Powder feed system with Fluid Crown ST 550/10 - Powder injector PI-F1 - Equipment trolley with vibrating table
