Used Finger jointing lines for sale (74)

Condition: new, Year of construction: 2019, operating hours: 10 h, Functionality: fully functional, MACHINE BRAND NEW - WORKED 10h Cgjb Esv A Tb Io Ilugot The machine has undercutters for gluing furniture boards - it is a universal machine, it can glue in a zigzag and on a line. FAMAD PDFE 2-tenoning line - with a magazine Year of production 2019 The PDFD line consists of two basic components: a DFC 60 milling-tenoning socket (where the ends of the strips are processed) and a PHSL press for joining to length, on which the elements are joined into a strip up to 6.6 m long with the possibility of programming up to eight intercuts dividing the strip into sections of a length programmed by the service. Between these basic devices there are transport devices that also perform the function of pre-tenoning. The presented line configuration allows for the achievement of an efficiency of approx. 8,000 m/shift. The microprocessor control system allows for flexible adjustment of operating parameters to the user's needs. The presented machine has the ability to process "calzing" type elements as well as elements for the production of countertops (connected "on a line"). The use of a receiving table with automatic feeding of strips to the PHSL press input conveyor allows the line to be operated by one employee feeding the elements. The receiving table is equipped with a buffering screen that increases efficiency and smoothness of work. The line operates in an automatic cycle with manual feeding of material. The components of the line can be assembled in various (agreed with the recipient) configurations enabling the machine to be adapted to the user's local conditions. Technical and operational data: Width of the milling-tenoning machine input package mm 650 Width of glued elements mm 30 ÷ 155 Length of glued elements mm 170 ÷ 900 Thickness of glued elements mm 20 ÷ 70 Working air pressure MPa 0.6 Compressed air demand m3/h approx. 25 Working efficiency cycles/min. up to 4 (6600 strip) Length of glued element mm 4500 ÷ 6600 Working voltage V AC 3/N/PE 400 V 50 Hz Control voltage V DC 24 Power demand kW max 100

Condition: excellent (used), Year of construction: 2011, Masina de inbinat a degetelor Ceb Eet D Nxzs Ilugsgt

Condition: excellent (used), Year of construction: 2001, The GreCon Ultra 2 vertical finger jointing line is a compact solution designed for the efficient utilization of short wood sections in medium-sized production facilities. Key Features: Workpiece Dimensions: Length: 150 – 1,000 mm Width: 40 – 150 mm Thickness: 20 – 80 mm Finished board length: 3,000 – 6,100 mm Csb E Iluov Rx Enegegt Performance: The Ultra 2 line is approximately 40% more efficient than the Ultra model, thanks to the implementation of an automatic rotary table.

Condition: good (used), The machine has been overhauled many new parts new cables new hydraulic station Ceb Ejv Ihdzo Ilugsgt The machine has been checked, is functional, We can send a video.

Condition: like new (used), Handling equipment for a finger jointing line. Roller conveyors, wide- and narrow belt conveyors, a trim saw conveyor, trim saws, etc. See pictures. With documentation. Good condition, made by Martek in Finland. Cjbjd Duz Ee E Ilugegt

Condition: repair required (used), Finger jointing machine dimter HK 400 wood input lengths 800-6000mm Cjb E Ilovi Hw Nsugjgt Color blue Needs repair in the condition it is

Condition: excellent (used), Year of construction: 2006, Functionality: fully functional, GRECON ULTRA TT wood joining line Year of production 2006 The machine is equipped with undercuts for gluing on the flat / on the line, which makes the machine universal - it can glue elements on the stile (on the zigzag) or on the flat (on the line). Technical data: Cgjb E Ilsuag Epeugjt Dimensions of the machine: - length - 15000 mm - width - 6000 mm - height - 2100 mm Sizes of glued material: - Width - min.40 mm - max. 205 mm - Thickness - min. 20 mm - max. 80 mm - Length - min. 150 mm - max. 1000 mm - Pressing length - min. 3000 mm - max. 6100 mm Power supply: - Rated voltage 400V - Power consumption 43.5KW - Connection fuse 100A The machine consists of the following components: 1.Loading belt 2.Automatic rotary table 3.Milling machine table 4.Milling machine 5.Insertion station 6.Press 7. exit from the press Machine fully operational working in good condition.

Condition: excellent (used), operating hours: 10 h, Functionality: fully functional, Grecon Dimter Ultra automatic wood joining line Machine after major renovation. Specification: Tenner: Sawheadstock: - Spindle speed: 3000 rpm - Saw motor power: 6 kW - Chip extraction: Ø100 mm Milling headstock: - Shank diameter: Ø50 mm - Usable shank length: 210 mm - Max. tool diameter: Ø250 mm-Ø150 mm Cgeb E Ijuddvasluget - Spindle speed: 6000 rpm - Milling motor: 15 kW / 3000 rpm - Chip extraction: Ø150 mm Feed table: - Minimum board length: 150 mm - Maximum board length: 700 mm - Working feed: Steplessly adjustable Dust extraction: Chipper exhaust port diameter: Ø100 mm Mill exhaust nozzle diameter: Ø150 mm Dust extraction capacity (flow rate): ~2400 m3/h Pneumatic system: Working pressure: 6 bar Air requirement: ~2.5 m3/h at 6 bar (15 Nm3/h) CONTI M 6/6000 longitudinal wood joining press: Press: - Loaded strip width: 25 – 160 mm - Finished strip length: approx. 6000+15-50 mm - Pressing force: 3 – 7.5 T (3 000 – 7500 daN) Circular saw: - Saw diameter: Ø400 mm - Spindle diameter: Ø30 mm - Motor: 4 kW / 3000 rpm Dust extraction: - Saw exhaust nozzle diameter: Ø100 mm - Dust extraction efficiency (flow rate): ~400 m3/h Pneumatic installation: - Working pressure: 6 bar - Air demand: ~2.5 m3/h at 6 bar (15 Nm3/h) Scope of renovation work: 1. Cleaning the machine bodies and applying new paint 2. Replacing with new bearings on: the main spindle of the tenoner; on the saw headstock of the press; linear bearings on the guide of the tenoner table carriage; bearings on the working belts. 3. Installing a new glue nozzle with a pitch of 3.8 mm on the tenoner body, installing a glue supply tank with a safety valve; 4. New conveyor belts 5. Replacement of wiring on machine bodies 6. Replacement of pneumatic hoses for actuators, solenoid valves and other pneumatic elements in machines with new ones; 7. Replacement of gear wheels and double-row chain on the belt-chain feeder of the press. 8. Regeneration of electromagnetic brakes on the tenoning machine 9. Replacement of seals and O-rings (repair kits) in pneumatic actuators Replacement of worn solenoid valves with new ones. 10. Replacement of graphic panels on the tenoning machine cabinet, on the press cabinet, on the small press panel with new ones. 11. Replacement of buttons, lamps and switches on panels and control boxes with new ones. Replacement of boxes with connectors with new ones. 12. Replacement of controllers supervising the operation of the tenoning machine and press with new ones. Adjustment of the machine control program to the user's needs 13. Installation of a new inverter on the press rollers and on the pusher of the receiving table projector; 14. Maintenance of electrical installations in control cabinets, modernization and preparation of electrical diagrams. 15. Installation of covers, grids and necessary descriptions, stickers and health and safety signs as well as manufacturer's logos and nameplates. 16. Replacement of V-belts with new ones, checking pulleys; gear motors and engines; 17. Replacement of limit switches, inductive and optical sensors (photocells) with new ones. We specialize in wood joining machines. Installation, start-up and training of employees in the scope of machine operation in Poland included in the price, in other countries for an additional fee. We provide service and access to spare parts.

Year of construction: 2000, Condition: excellent (used), The line is fully operational, modernized in 2019. Among others, : Hydraulic installations and control. minimum material thickness - 20mm max material thickness - 130mm minimum material width - 30mm Cgoboim Ez Do E Ilugjt max material width - 130mm minimum input length of the material - 250mm max input length of the material - 1600mm minimum output length of the material - 250mm max output length of the material - 300mm

Condition: ready for operation (used), Year of construction: 1993, Functionality: fully functional, Machine can be inspected while in operation. Available from mid-August 2025. Cgjbevy Ergj E Iluget Renewed control system. Negotiable €100,000, dismantled, ex-works. If you have any questions or are interested, please feel free to contact us.

Condition: excellent (used), Year of construction: 2007, Functionality: fully functional, GOMA Industrial Double-Screw Wood Splicing Line for Microcrane. Type/Model: FC-10KZ6 + FC10PZ6/2 Technical Condition: Very Good Year of Production: 2007 (General overhaul 2022) JUWAL Hydraulic Press 2022 r 6.6m Roller Glue Applicator Press like new - glued material on it for literally several loads The line after renovation worked for 2 months, then was occasionally turned on, also processed only a few hundred m3 - like new There is an opportunity to see the machine how it works. For questions and more detailed information, please contact me by phone Csb E Iluetq E Rfegegt The price is net price for the set VAT invoice

Condition: reconditioned (used), Year of construction: 1998, Fully automatic package jointing line 500 mm Packaging width - Consisting of: - Finger jointing Central Milling Machine - 2 fixed transport tables - 1 Wheeled processing unit - 2 milling spindles - 2 flakers - Glue - Separating station with tilt-back - Threading section 2 transport chains - Feed with double rollers Cgsb E Ilslatv Asuget - Extrusion press 12 ton - crosscut - Packaging width 500 mm - wood in max. 1950 mm - wood in min. 200 mm - Workpiece 50-215 mm - Workpiece thickness of 25 to 100 mm - Performance 2,5- 3 tables / min - Press force max. 12000 kp - Length of the threading section 3900 mm - Lenght of the press bed 5000 mm - wood with fingerjoint endless - Engine performance milling spindle 2x18,5 kW - Engine chipper 2x 7.5 kW

Year of construction: 2012, Condition: excellent (used), Set for finger jointing in medium and mass production. The machine is technically efficient and in good condition. Several sets of tools are included. Characteristic: – industrial set with one tenoning machine. Loading the package under the supervision of the operator enables the processing of inferior raw material, – sensitivity controlled by microprocessors /automatic control/, – turning the package after 1 treatment on the turntable (sharp connection) or turning the package on the back (furniture joint with a line; unique GOMA solution), – the set includes an automatic station for loading the press, – the possibility of using cuts on the press, Tenoner with feed table Data Values Milling spindle fi 50x210 mm Spindle speed 6000 rpm 18.5 kW motor Tool dimensions fi 250x160 mm Cgob Eelu D Tfs Ilugst The saw spindle aligns the face Special chipper fi 300x8 mm 6 kW / 3000 rpm motor Stepless feed table Working width x working height 600 x 30-160 mm Glue nozzle outline by tool PRESS FC-10 PZ6/2 Data Values Board width 30-160 mm Jufefe Board thickness 20-70 mm The length of the finished board is 6000 mm Pressing force 3 - 7.5 - 10 T Hydraulic power pack 3 kW / 140 bar

Condition: excellent (used), Year of construction: 2021, Functionality: fully functional, machine/vehicle number: V001420, Profi-Joint Shaper 6000mm Four stage press Includes PUR glue pump and applicator Csb E Iov Rzw Tslugsgt Additional consideration: - Sawdust extraction (AUD$20,000)

Condition: new, Year of construction: 2025, pressing force: 25 t, Equipment: double-sided, The Marinus Powermax Finger Jointer Line profiles horizontally, applies adhesive, cuts out defects, presses and cuts to length. The unique process creates a clean joint that does not require post-processing. About the Finger Jointer When feeding wood into the machine, it is possible to mark defects, such as knots or cracks, with a luminescent crayon. The machine will cut out these defects, including the crayon lines. For instance, to get cladding or paneling without knots or holes. Before the profiling and also before the pressing, the wood is brought to a stationary position, fixed sideways and clamped to an accurate reference surface above. This results in a highly accurate connection of the finger joint, with a flat surface at the joint and a straight end-product. Because of this precision (for most purposes) the wood does not need to be planed or sanded afterwards. The adhesive applicator is mounted to the carriage with the profile cutters. In the returning stroke of the profiling carriage the adhesive is applied. The use of PU adhesive ensures a very strong bond, suitable for outdoor use and in wet environments. While most other finger jointers move the wood transversely (right-angled) past the profiling heads, the Marinus Finger Jointer moves the wood longitudinally (lengthwise) through the machine. This enables feeding in long lengths of 6 meters or even longer. As a result, the machine can process all the wood, including longer lengths, and use it all (except for the defects) for the jointed end-product. This way, there is no good wood turned into short pieces of scrap. Where other finger jointers focus on re-using short pieces of scrap wood, the Marinus eliminates the production of scrap wood. The Marinus Finger Jointer contributes to an efficient and sustainable production process. Specifications: Infeed Lenghts: 450 - 6000+ mm Infeed Widths: 50 - 300 mm Infeed Thicknesses: 8 - 50 mm Length modes: Variable / Fixed Cgsb Ejp R Iwhs Ilugot Capacity: Up to 8 joints/min This machinery is engineered and built in our company in The Netherlands and will be delivered new from our factory. This machinery is equipped with an online remote support system. We provide customer support worldwide. This listing on Machineseeker is also made by us: Marinus Machinery.

Condition: excellent (used), Year of construction: 2005, Functionality: fully functional, AUTOMATIC HIGH PRODUCTION FINGER-JOINT LINE, WITH DOUBLE HEAD AND 6,000 mm PRESS. Brand YONGQIANG, model FJL150/8 Transfer with smooth conveyor belts, for the introduction of the pieces in the first finger-joint machine. 1st finger-jointing machine MHB3515B-A, complete with hydraulically driven sliding carriage and vertical and front pressers, belt for parts introduction, scoring unit, disc-crusher unit and shaper unit. Ceb Eet Ivpnj Ilugsgt 2nd finger-jointing machine MHB3515B-B, complete with sliding carriage with hydraulic movement and vertical and frontal clamps, belt for parts introduction, scoring unit, disc-shredder unit, shaper unit and gluing unit. Transfer with motorized rollers and piece-to-piece separation system RC 2x800, consisting of pneumatic transversal piston and motorized belt in vertical position. Transfer SC300, with drive system by means of two lateral chains, one of them adjustable in width and central presser along the whole length of the transfer, with vertical idle wheels. The function of this transfer is the guided instruction of the pieces one by one in the press. Hydraulic finger press MHB15608-C, composed of grooved and motorized roller for the introduction of the pieces, cutting group, pre-pressing system and system of pressing and ejection of the pieces and support arms for the unloading of the strips. Used machine, year of manufacture 2005. Very good condition In the link it is possible to see a video of a line in operation exactly like the one offered.

Year of construction: 2022, Condition: as good as new (ex-display), I sell the semi-automatic finger joint line LESSPOJ. Year 2022. Input length 180-1.000mm Input width 20-160mm / 610mm in 1 step Input thickness 20-80mm Automatic finger joint unit with glue spraying 1 side Automatic turning of the material for the 2nd pass on turning table Automatic feeding to the press Press 3,00 - 6,10m with automatic cycle and end-cutting saw Total area covered 16.250 x 3.684mm Cgeb E Iluomig Tdjgjt Strong construction. Very good condition. Available immediately.

Condition: repair required (used), Year of construction: 1994, machine/vehicle number: 6305/7, pressing force: 15 t, working height: 905 mm, total length: 1,900 mm, pressing force 15 t line consisting of : feed rollers with servo drive press 15 t inclusive hydraulic unit feed rollers with servo drive Cobjg T Spae E Ilugsgt saw >>without electrical equipment

Condition: good (used), Year of construction: 2016, Functionality: fully functional, machine/vehicle number: V001257, Profi-Joint Shaper 6000mm two stage press Includes PUR glue pump and applicator Additional consideration: Cebev Ryb Ro E Ilugsgt Sawdust extraction (A$20,000)

Condition: repair required (used), Year of construction: 1976, pressing force: 10 t, working height: 805 mm, total length: 1,700 mm, Finger jointing press Finger jointing press Cycle press for finger joints Pressing force 10 t Hydraulic finger jointing cycle press Wood width 80 - 280 mm Csb Ejt Sc Sws Ilugsgt Wood thickness 18 - 80 mm Hydraulic unit 300 ltr and 5,5 kW motor, manufacturer GOD OPTIONAL with hydraulic unit

Condition: used, Mini tine cutter Mini tine cutter head Tine cutter Finger joint cutters Cgob E Ijrr Uphjluget mini tine cutter finger joint milling tool milling cutter finger joint

Condition: repair required (used), Year of construction: 1993, machine/vehicle number: 624/9, pressing force: 10 t, working height: 805 mm, total length: 1,900 mm, Indexing press for finger joints Finger jointing press Finger jointing press Pressing force 10 t Wood width 80-300 mm Cgjbjt Sc T Ij E Iluget Wood thickness 18 - 80 mm OPTIONAL with hydraulic unit

Condition: repair required (used), Year of construction: 1993, machine/vehicle number: 6272/6, pressing force: 10 t, working height: 805 mm, total length: 1,900 mm, Finger jointing press Finger jointing press Cycle press for finger joints Hydraulic finger jointing cycle press Pressing force 10 t Wood width 80-300 mm Cgebet Sc Uxe E Ilugjt Wood thickness 18 - 80 mm OPTIONAL with hydraulic unit

Condition: used, Milling spindle Milling spindles for tine cutters different lengths different models in stock at www jöma store Manufacturer GreCon + Sauter + DIMTER Ceb E Ilsqwgrpjugsgt

Condition: ready for operation (used), Glue application with profile rollers Csb E Iluolxx Dqogegt 10 - 15 - 20mm
