Used decanter for sale (45)

Condition: used, Year of construction: 1991, Flottweg three-phase decanter, Z4D-3/441, last used in a fruit juice plant. Inner drum diameter: 420 mm Inner drum length: 1245 mm Drum wall thickness: 10 mm The medium to be separated is fed into the hollow center axis of the decanter. Centrifugal force causes the solids to collect on the drum shell. A cylindrical-conical screw conveyor transports the ring of solids to the discharge openings, where it is ejected into the solids housing. The two liquid components separate according to their specific density and form two hollow liquid cylinders. The diameter of the liquid rings can be adjusted using a peeling disc and overflow weir. One of the two phases is discharged without pressure and one is discharged under pressure via the paring disc. The moisture content of the solids and the purity of the liquids can be controlled by: - Varying the phase separation discs and paring diameter - Decanter speed - Screw speed Additional title: 3-phase decanter Max. bowl speed: 4000 r/min Max. sediment-density: 1 g/cm³ Max. ambient temperature: 100 °C Mass moment of inertia: 15.5 kgm2 with an empty drum Bljdpfx Abjyr Iccowef Weight: 2250 kg Material: housing from stainless steel 1.4301 (AISI 304); drum made of high-strength cast stainless steel 1.4463 Position: free standing Base construction: Horizontal decanter drum in steel frame, on square tube frame with dome feet Features: Base with rubber mountings, electric motor (Loher 180 M, 22 kW)

Condition: like new (used), Year of construction: 2020, operating hours: 50 h, machine/vehicle number: LW250*1000, Decanter centrifuge manufactured in 2020, but put into operation in May 2021! The machine is in like new condition (used in total approx. 50 operating hours)! The decanter is for sale due to a change in technology, it works flawlessly! Manufacturer: YIXING HEAD SEPARATOR MACHINERY CO. LTD., CHINA Year of manufacturing date: 2020 Serial Number: LW250*1000 Blsdpfx Abspu A D Aewof Machine signal: 02-001 Decanter indication number: 2647 Sludge formation capacity of decanter: 500 kg/h Main motor capacity: 7,5 KW Vice motor capacity: 3 KW Capacity: 1-5 m3/h Netto weight of decanter: 1000 kg Material of wetted parts:1.4404 Feed volume flow: 0,5t – 3t/h Stainless steel Reference number: 2590

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, overall weight: 2,000 kg, rotational speed (max.): 4,700 rpm, TECHNICAL DETAILS Drum diameter: 340 mm Maximum drum speed: 4,700 rpm g-factor: max. 4,198 g MACHINE DETAILS Main motor power: 22 kW Secondary motor power: 11 kW Motor operation: Frequency converter Drive system: Summation drive Blodpfeymx N Ajx Abwsf Inlet and outlet connections: DIN 11864-2 DN40 / DN25 Dimensions & Weight Dimensions (L x W x H): 3,300 x 870 x 1,500 mm Weight: 2,000 kg EQUIPMENT Temperature sensors on both drum bearings Level monitoring for gearbox oil and oil-air lubrication Pressure sensor for oil-air lubrication Vibration monitoring: continuous monitoring of drum bearings on both sides Speed monitoring via proximity sensors Further configuration details can be found in the attached document.

Condition: used, System: Sangerhausen Maschinenfabrik, Hortz screw centrifuge, used Manufacturer: Maschinenfabrik Sangerhausen Bljdpfxjvz Ic Ds Abwef Type: SKZSNh-S450L4 Manufacturer no.: 6952 Year of manufacture: 1992 Speed: 3000 min1 Engine power: 22 kW Drum inner diameter: 450 mm Empty weight: 3000 kg

Condition: used, Plant: Mobile sludge dewatering plant, decanter / centrifuge mobile Manufacturer: Hiller Model: Solid bowl screw centrifuge Type: DP45-422 Machine No.: H3480 Year of construction: 2006 Blodpfx Abeppddyewof Maximum permissible: Drum speed 3800 I/min Inner diameter: Drum 450 mm Drum material: H2/St52 Electric motor: yes Other: steel exchange case with reinforced bottom, accessories: pump for sludge inlet, flocculant suction pump, flocculant release pump Flocculant station 2 chamber system for liquid polymers with agitator , adjustable Double shaft paddle mixer galvanized steel Total mass : approx. 3200 kg Purchase and rent : possible.

Year of construction: 2002, condition: used, Machine No..3236 Speed: 3000/3200 rpm. Blodpfxjppdd Se Abwjf Drum diameter: 520 mm

Condition: used, Year of construction: 2001, inner diameter: 450 mm, wall thickness: 11 mm, overall weight: 3,200 kg, System: Decanter / centrifuge, used Manufacturer: Hiller Model: DP45-422 Mach. No.: 2818 Year of manufacture: 2001 Maximum drum speed: 3800 l/min Drum inner diameter: approx. 450 mm Bedpevz A Uzsfx Abwelf Drum wall thickness: 11.0 Drum material: H2/ST52 Weight: approx. 3200 kg Permissible density 1.50 kg/dm3

Condition: used, Year of construction: 2007, System: Mobile sludge dewatering system, mobile decanter/centrifuge Manufacturer: Hiller Model: Solid bowl screw centrifuge Type: DP51 Bsdpfjvz Dnpsx Abwslf Mach. no.: H3991 Year of manufacture: 2007 Maximum drum speed: 3400 l/min Drum inner diameter: approx. 505 mm Drum material: ST52.0 Drum wall thickness: 13.0 mm Other: Steel exchange case with reinforced base, Accessories: Pump for sludge inlet, flocculant suction pump, flocculant solution pump Flocculant station: 2 chamber system for liquid polymers with agitator, adjustable Double shaft paddle mixer: galvanized steel Total weight: approx. 4200 kg Purchase and rental possible.

Condition: used, System: Decanter Type: CP 4-1.1 Year of manufacture: 1991 Machine number: 5045 Blsdpfx Ajvz Rw Robwef Speed: 2200 1/min Drum wall thickness: 16 mm Drum material: 1.7382 Total weight: 9500 kg Separation technology: Sludge dewatering using decanting centrifuges (solid bowl screw centrifuges, decanters). The high centrifugal forces separate the fine solids from the suspension due to different densities.

Condition: like new (used), Year of construction: 2020, System: 2-phase centrifuge, dewatering system in a double-deck container Manufacturer: Hiller Type: DP45N.422 VA HY Mach. No.: H6138 Year of manufacture: 2020 System: in a double-deck container, conveyor technology with side swivel conveyor, separate pump technology. System: demonstration system - as good as NEW! Maximum permissible speed: 3500 l/min Permissible Density: 1.3 kg/m3 Inner diameter of drum: approx. 450 mm Material: All parts in contact with the media made of duplex steel Drum material: 1.4470 Drum wall thickness: 11 mm Max. operating pressure: 100 mbar Drum drive: size 200L Power: 30 kW Speed: 3000 rpm V/Hz: 400V, 50 Hz Hydraulic unit: PVRK07521L Power: 7.5 kW Control: FU Seepex pump: concentrate pump MD 006-12, see photos Macerator: Vogelsang, type RotaCut, RCQ-26G inline cyclone, BioCut and RCQ-33G inline cyclone see photos Spiral conveyor: Hiller see photos Bledjv D Rlyopfx Abwsf Polymer plant: GVU Technik Polymer Mix Station - technical data see photos Documentation: complete

Condition: used, Plant: Used decanter / centrifuge Manufacturer: Flottweg Model: Solid bowl centrifuge Type: Z73-4/454 Machine No.: 010.014.04 Year of construction: 1999 Drum: max. speed. 2800 min-1 Bledpoppa Tcefx Abwjf Perm. sediment density: 1,3 kg/dm3

Condition: used, Year of construction: 1994, System: Decanter / centrifuge, used Manufacturer: Alfa Laval Bledpfx Abovz Dddswsf Model: ALDEC 406 Mach. No. 512-0006.01 Year of manufacture 1994 Maximum drum speed 4000 l/min Drum inner diameter

Condition: used, Machine No.: 010.013.04 Year of manufacture: 1999 Drum: max. speed. 2800 min-1 Bljdpfx Ajppa S Rebwef Perm. sediment density: 1,3 kg/dm3

Condition: used, Year of construction: 2018, System: Decanter Type: Flottweg C4E-4/454 Complete dewatering system in container Year of construction: 2018 Sludge throughput: approx. 0-40m3/h Solids capacity: max. 1.2 TS/h Equipment: front double door, side entrance door, fan heater, lighting, sockets, etc. Rotor: max. speed 3650 min-1 Drum diameter: 470 mm System: Container system Interchangeable bridge system for accommodating the downstream system components. Piped and wired ready for operation as a functioning unit. Container system design: Stand construction, clad with sandwich panels and holders for transportation with interchangeable bridge systems. Accessories: FHM preparation station PolyMix 4000SP, measuring equipment, switchgear Feed pump: Seepex BN 52-6LS Discharge conveyor: SS D320 double trough spiral conveyor Dimensions: L 7820mm x W 2500 mm x H 3880 mm Empty weight: 14500 kg Weight in operation: 15000kg Voltage: 400V Power consumption: 142 A Power consumption max.: 70kW Fuse protection: 250 A Frequency: 50 Hz Sludge inlet: DN 100 Centrate drain: DN200 Solids discharge: Spiral conveyor Blsdou R Icmjpfx Abwof Further information: see photos

Condition: used, System: Used decanter / centrifuge Manufacturer: KHD Model: Solid bowl screw centrifuge Type: CP 3054 Machine number: 5574 Year of manufacture: 1995 Maximum speed: 3200 l/min Drum inner diameter: approx. 552 mm Blodjvz H N Ajpfx Abwef Drum wall thickness: 12.0 mm Drum material: ST46.0 Weight: approx. 4660 kg Documentation: yes Purchase and rental possible

Year of construction: 2018, condition: used, Solid bowl screw centrifuge Bsdpfx Abjppa S Ajwolf max. speed. 2200 min-1

Condition: used, Plant: Mobile sludge dewatering plant, decanter / centrifuge mobile Manufacturer: Hiller Model: Solid bowl screw centrifuge Type: DP45-422 Machine No.: H3480 Year of construction: 2006 Bodpfx Aeppa Tgebwjlf Maximum permissible: Drum speed 3800 I/min Inner diameter: Drum 450 mm Drum material: H2/St52 Electric motor: yes Other: steel exchange case with reinforced bottom, accessories: pump for sludge inlet, flocculant suction pump, flocculant release pump Flocculant station 2 chamber system for liquid polymers with agitator , adjustable Double shaft paddle mixer galvanized steel Total mass : approx. 3200 kg Purchase and rent : possible.

Condition: used, System: Used decanter / centrifuge Bljdjvz Ickepfx Abwjf Manufacturer: KHD Type: Solid bowl screw centrifuge Machine number: 4973 Machine type: CP3-2 Year of manufacture: 1991 Max. drum speed: 2600 rpm Drum inner diameter: 614 mm Drum wall thickness: 17 mm Drum material: 1.7218 Max. operating temperature: 50° C Total machine weight: approx. 7030 kg Purchase and rental: possible

Condition: used, System: Mobile dewatering system, decanter, and mobile centrifuge - used Application: Sludge dewatering Type: Alfa Laval DSNX 4250 Year of manufacture: 1996 Bjdpfxswmwrqe Abwslf Operating hours: 29,200 Generator operating hours: 31,640 (see enclosed nameplate)

Condition: used, System: Decanter Type: KHD CP 3044 Year of manufacture: 1992 Machine number: 5787 Drum inner diameter: 448 mm Drum wall thickness: 11.0 mm Bsdpfjv Acqfox Abwjlf Drum material: H2 ST52 Weight: 4000 kg Separation technology: Sludge dewatering using decanting centrifuges (solid bowl screw centrifuges, decanters). The high centrifugal forces separate the fine solids from the suspension due to different densities.

Condition: used, System: Decanter, used Type: KHD SC 4-0.2 Year of manufacture: 1993 Machine number: 5311 Max. drum speed: 2500 rpm Max. operating speed: 2500 rpm Drum inner diameter: 758 mm Drum wall thickness: 20 mm Drum material: 1.7218 Filling volume: 715 dm3 Total weight: 13,500 kg Blodpfsvz R Ehjx Abwof Separation technology: Sludge dewatering using decanting centrifuges (solid bowl screw centrifuges, decanters). The high centrifugal forces separate the fine solids from the suspension due to different densities.

Condition: used, Year of construction: 1993, System: Decanter Type: KHD CP 3-0.1 Year of manufacture: 1993 Machine no.: 5303 Speed: 3200 1/min Drum diameter: 530 mm Drum wall thickness: 12.5 mm Drum material: H2 Separation technology: Sludge dewatering using decanting centrifuges (solid bowl screw centrifuges, decanters). The high centrifugal forces separate the fine solids from the suspension due to different densities. Bjdpfov A Shgsx Abwolf

Condition: used, Year of construction: 2002, Decanter: Used Used decanter with solids chute. Type: Guinard D3LLC30BHP Year of manufacture: 2002 Machine No.: 3285 Speed: 3500-4000 rpm Drum diameter: 340 mm Bledpsq Adn Tofx Abwsf Other: If you have any specific requirements, please contact us. We are your specialist in sludge dewatering with over 40 years of experience.

Condition: used, System: Used decanter / centrifuge Manufacturer: KHD Blsdjvz Icwjpfx Abwof Type: Solid bowl screw centrifuge Machine number: 5445 // 9-8535-0-2672 Machine type: CP3-1.1 Year of manufacture: 1994 Max. drum speed: 2500 rpm Drum inner diameter: 450 mm Drum wall thickness: 11 mm Drum material: H 2 Max. operating temperature: 50° C Total machine weight: approx. 2400 kg Purchase and rental: possible

Condition: used, System: Used decanter / centrifuge Type: KHD S 3-02 Factory number: 9-8531-0-2570 Machine number: 5389 Permissible speed: 2550 Permissible density kg/dm³: 1.3 Drum inside diameter: 650 Drum inside height: 1970 mm Drum wall thickness: 16 mm Drive: Viscotherm hydraulics Material: steel Year of construction: 1994 Bljdpfx Asvz Ic Robwof Total weight: 4400 kg Width: 1960 mm Length: 3630 mm Height: 1300 mm Other: Purchase and rental possible Optional soundproof housing The system is in good condition.
