Air Operated double diaphragm pump
Maximum flow rate : 60 l/min
Connections : G 1/2"
Pump body : PVDF
air diaphragm : santoprene
fluid diaphragm : PTFE
balls : PTFE
ball seats : PVDF
O-Ring : PTFE
Full order code : IMIN-FCMTTFT--
Year : june 2008
Pump is cleaned, tested and in good condition
centrifugal vertical cantilever pump chemcial pump
FIP ALFA 65-40 V2CM
construction of year:2008
Nominal flow 40 m³/h
Nominal head:45 m
p [bar]: 16
T [°C]: -25 ÷ + 140
electrical power 16,5KW
engine speed: 1470
vertical, radially split volute casing pumps sump pump or channel impeller
handling of paint, aggressive and process liquids, even with the presence of solid particles in suspension, in chemicals and petrochemicals i...
We can offer the new cryogenic pump for liquid oxygen, nitrogen and argon (LIN, LOX, LAR) :
300 bar 8,5 l/min,
with control panel and
vaporizer on the frame.
Photos are attached.
If you need any other information please let me know.
Pressure centrifugal pump Vertical centrifugal pump Grundfos CR 90-3 A-F-A-E-EUBE
Vertical, multistage centrifugal pump with suction and discharge ports on the same level. The pump head and base are in cast iron - all other wetted parts are in stainless steel (EN 1.4301)
Rated flow 90 m³/h
Rated head 65.5 m
Max pressure at stated temp 16 bar / 120 °C
Type of connection DIN
Size of inlet connection DN 100
Pumped liquid Water
Liquid temperature range 0 .. 120 °C
Selected liquid tempe...
The first pump is an Elro IP600 peristaltic pump. It has become obsolete and may therefore go. The maximum capacity is 16 m3/h.
Make a good offer!
The second pump is a manure pump from Jurop whose pump housing is broken. Now this motor with switch box and buck may go away. THE pump is from 2017. Make an offer!
The last is a motor with wokkel to dispense solids such as grass, corn, grain and the like. That one is obsolete and may go away. The year of construction is 2015. The pump is from NORD ...
Plant: PEMO pump, sludge pump, chamber filter press feeding pump
Year of construction: 2011
Speed: 2951 rpm
Machine number: 3102
Dimensions: L 1200mm
Application: Designed for very abrasive and/or acidic slurry applications.
Delivery volume: from 1 to 1500 m3/h / depending on the medium
Type: Centrifugal pump for liquid gas
Liquid: LAr, LN2, LO2
Delivery rate: 300 l/min
Speed: 7500 rpm
Power: 22 kw
Insulation/protection class: IP 55 /F
Voltage: 380 V
Speed: 2950 rpm
We have other centrifugal pumps for for liquid oxygen, nitrogen and argon.
Please feel free to ask if you have any questions via Phone or E-mail.
We speak german, english and russian.
Vertical multistage centrifugal pump
Flow rate: 6-14 m3/h
Number of impellers: 11
Serial round flanges, AISI 304
Nominal motor power 5.5 kW
Lifting height: 73-150 m
Pump housing material: cast iron
Impeller material: Stainless steel
Thread. flow. temperature -30...+120 °C
Pressure max: 16 bar
Engine speed: 2900 rpm
Mains voltage 3 380-415 Y V V/Hz
Nominal current consumption: 10.5 A
weight: 70 kg
Membrane for REWA ABEL piston diaphragm pumps.
Diaphragm pumps separate difficult media from the driving pump mechanism. An advantage of the piston diaphragm pump is that the fluid and hydraulic fluid are completely separated and do not come into contact with each other. We supply you with diaphragms (Abel spare parts) for all Abel / REWA pumps in known production quality with an above-average service life. Ask us
System: Used piston - diaphragm pump
Year of construction: 2001
Machine number: 5100074
Capacity: 18 m m³/h
Delivery pressure: 15 bar
Speed: 131 U/min
Temp: MAX 100 ° C
Operating voltage: 380 V
Frequency range: 50 Hz
Motor: 11 kW
Protection class: IP55
Flanges: DN 80
Dimensions: 1.70m L x 1.30m W x 1.60m H
Miscellaneous: forced ventilation 230/400V, 0.11 kW
ABEL molded membrane with valve rod for piston membrane high-pressure pump, filling pumps, chamber filter presses.
We are your ABEL pump supplier, service and spare parts partner for ABEL pumps. Pumps and spare parts available from stock or at short notice.
ABEL valve seats for ABEL piston diaphragm high-pressure pumps.
We are your supplier for ABEL piston diaphragm high-pressure pumps, service and spare parts partner for ABEL pumps. Spare parts available from stock or at short notice.
ABEL ball with steel core for ABEL piston diaphragm high pressure pumps.
We are your supplier for ABEL pumps, service and spare parts partner for ABEL pumps. Spare parts available from stock or at short notice.
ABEL valve ball on valve seat for ABEL piston diaphragm high pressure pumps.
We are your supplier for ABEL piston diaphragm high-pressure pumps, filling pumps, chamber filter presses, service and spare parts partners for ABEL pumps. Spare parts available from stock or at short notice.
Used progressing cavity pump
Machine number: 459933
Year of construction: 2013
Output: 3.50 // 18 m3/h
Speed: 91/288 min1/rpm
Pressure: 16 // 0.10 bar
Are you looking for a specific pump? We have other used pumps in stock - please ask us.
Mixed lot Extenterschneckenpumpen , different manufacturers ( Netzsch, Bornemann, Seepex etc ) for the most part functional - but some not) dismantled from the running screaming.
Only to be sold as a lot
ABEL contact pressure gauge for ABEL piston diaphragm high-pressure pumps.
We are your service and spare parts partner for ABEL pumps. Almost all spare parts are available from stock or at short notice.
ABEL degassing valve for ABEL piston diaphragm high pressure pumps.
We are your supplier for ABEL piston diaphragm high pressure pumps and service and spare parts partner for ABEL pumps. Spare parts available from stock or at short notice.
