CNC panel drilling machine

SCM startech cn v

Condition: new, Year of construction: 2025, Robland products are built by Werkhuizen Landuyt, located at Bruges, Belgium. BM 3000: • Saw aggregate for slot making. Max depth 10 mm • Left 5 mm bit for drilling • 20mm bit for minifix-system • 8 mm spindle for drill and limited milling applications • 35 mm bit for hinges • The thickness of the panels to be processed should be between 12 and 40 mm • The machine is equipped with a drilling head with 4 chucks and an integrated sawblade • Y axis reach/stroke: Drilling: 900 mm Grooving: 860 mm Technical data: Lodpfxsd Hz Nie Af Sjhr • Y axis reach/stroke • Drilling: 920 mm • Grooving with sawblade: 860 mm • axis is supported 3000 mm • Z axis plate thickness from 12 mm up to 40 mm • A axis 360° • Movement speed: 20m/min • Min. dimensions workpiece (X) 300x (Y) x 120 x (Z) 12 mm • the machine is equipped with a bore head with 4 chucks and integrated sawblade. • Max/min diameter bore heads 3 mm – 35 mm • Saw blade operates in the X-axis • Max. Depth saw blade grooving: 10 mm • Motor 1 HP 3*380 V / 3*220 V • Minimal required dust extractor capacity 2300 m³/h

Condition: new, saw blade diameter 350 mm Lhsdpfxofgpdlo Af Ser capacity 90 degrees: round 115 mm capacity 90 degrees: square 95 mm 180 x 95 mm Working height 925 mm saw blade turning speeds 15+30+45+90 U/min total power requirement 1,8/2,5 kW weight of the machine ca. 0,38 t dimensions of the machine ca. 0,8 x 1,0 x 1,85 m Manual vertical circular saw for miter cuts from 60° left to 45° right.

Condition: new, Year of construction: 2025, Suction nozzle diameter: 160mm maximum volume flow: 2000 m³/h nominal volume flow: 1448 m³/h volume flow monitoring: pressure difference display Negative pressure: 3000 pa Filter area: 10,5 m² Residual dust content: less than 0.1 mg/m³ Lhsdek Utq Sspfx Af Ssr Sound pressure level: 64 db Chaff bag volume: 160 l Filter cleaning: mororic Engine power: 3 kW machine length: 1800 mm Machine width: 820 mm Machine height: 2220 mm Weight: 320 kg

Condition: new, saw blade diameter 350 x 32 mm Lhedpfxsxaai No Af Sor capacity 90 degrees: round 120 mm capacity 90 degrees: square 105 mm capacity 90 degrees: flat 180 x 70 mm capacity 45 degrees: round 120 mm links capacity 45 degrees: round 110 mm rechts capacity 45 degrees: square 100 mm links capacity 45 degrees: square 95 mm rechts capacity 45 degrees: flat 135 x 60 mm dimensions of saw-blade 350 x 32 turning speeds 1700 / 3400 U/min capacity 45 degrees: round 120 mm total power requirement 1,5 / 2,2 kW weight of the machine ca. 210 kg dimensions of the machine ca. 1170 x 860 x 1600 mm Description: manual high-performance circular saw for cuts from 45 ° right to 45 ° left in aluminum and lightweight metal alloys, with 2 speeds Furnishing: - with pneumatic vices - The saw head can be tilted by 45 ° on one side - Heavy cast iron construction - ensures vibration-free operation and maximum precision - The head can also be tilted up to 45 ° - Powerful, 2-stage drive with double V-belts - large turntable with bearings - Lubrication device with mechanical diaphragm pump - Extraction nozzle for connecting a chip extractor Scope of delivery: - Adjustable length stop 600 mm - tool kit - Instructions with wiring diagram - Crane eyes for transport * The machine is delivered without a saw blade Special accessories: - including base

Condition: like new (used), functionality: fully functional, CNC drilling machine for precise single-part and series production Drilling head with seven vertical, four horizontal spindles and a groove saw unit Equipment: Roller conveyor for workpiece infeed and outfeed Edge sensor Pressure-boosted Y-axis for processing hard materials Ljdewz Nuyopfx Af Sohr Automatic lubrication Machine operator interface software Maestro CNC Qwerty keyboard for convenient data input

Condition: new, Year of construction: 2024, Aluminum circular saw UK 352 P, manual The UK 352 P semi-automatic circular saw is an "upcut" machine and is used predominantly Used to cut profile materials made of cast aluminium, copper and hard plastics (requires solid material). The machine is characterized by easy handling and fast, convenient changing of the material as well as simple miter angle adjustment. The UK 352 P has an infinitely adjustable miter range left up to 45° and right up to 0° The saw feed takes place automatically at the touch of a button, the material is clamped using two pneumatically controlled vertical clamping cylinders. Connections for a chip extraction system are available on this machine. Lhodpfsidunvjx Af Sjr equipment manual guiding of the saw blade Double miter 30° - 90° - 0°, large support plate, powerful drive motor Clear control panel Two vertical pneumatic clamping cylinders Fixed material positioning jaw, can be used to enlarge the cutting performance can be shifted backwards large protective hood, covers the entire work area minimum lubrication system Air gun to clean the machine Saw blade ø 350 mm workflow 1) Setting the cutting angle 2) Loading the material 3) Bring the clamping cylinder up to 20 mm of material 4) Pneumatic clamping of the material 5) Press the start button to start the saw blade 6) the saw cut must be carried out manually with a hand lever 7) after the end of the cut, the machine is switched off! It is always possible for you to inspect the desired system in our production/demonstration hall. Please do not hesitate to contact us.

Condition: excellent (used), Year of construction: 2021, Technical data: ALKO clean air mobile extraction unit, Type: Mobil-Power Unit APU 120, Ljdpfxsw T U Uzs Af Sohr Motor power: 1.5 kW, Inlet diameter: Ø=120 mm, Sound insulated, Mobile separation drum: 135 l, Manual filter cleaning, Dimensions: L=1,085 mm, W=650 mm, H=1,985 mm, Dust drum volume: 135 liters, Weight: 117 kg, Nominal airflow (after cleaning): 814 m³/h, Location: ex stock 54634 Bitburg - immediately available -

Condition: good (used), Year of construction: 2008, functionality: fully functional, Homag Weeke Optimat BHX 500 20KW Center Machine in excellent condition Lodpjw A R Iqefx Af Sohr Viewable in department 14 Dismantling, loading, and transport at buyer's expense
