Used Mazak Stx 48 Hipro Supercharg for sale (362)

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm C-axis indexing 360° Dcsdpjxd Ay Eofx Ac Hjp Spindle nose A2-6 Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, Year of construction: 2001, x-travel 510 mm y-travel 510 mm z-travel 460 mm control Mazatrol Fusion 640M Main spindle: Max. rpm 12.000 min/-1 power capacity - main spindel 22 / 15 kW tool taper ISO 40 Spindle diameter 80 mm Accelaration 0 - 12.000 min/-1 : 1,7 sec table surface area 500 x 400 mm T-slots 5 x 18 mm T-slot - distance 80 mm distance spindle /table 190 - 650 mm max. workpiece height 500 x 500 x 405 mm max. table load 300 kg Swivel range A-Axis +30 / -120 ° rotation range c-axis +/- 360 ° Tool-Presetter: number of toolpositions 40 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg change-time chip to chip 4,5 sec feeds: feed speeds X/Y/Z: 1 - 50.000 mm/min Dedpstqmqxjfx Ac Hscp rapid traverse X/Y/Z: 50 m/min Indexing A + C: 0,001 ° switching time 90°: A/C: 1,9 / 1,5 sec total power requirement 51 kVA weight of the machine ca. 7,5 t dimensions of the machine ca. 3,4 x 3,7 x 2,8 m CNC-Machining Center Vertical MAZAK - Variaxis 200 - 5-Axis

Condition: reconditioned (used), Year of construction: 2011, MAZAK QUICK TURN NEXUS 250-II M 500U Max. machining diameter: 380 mm Max. machining length: 504 mm Max. milling speed: 4,500 rpm Max. spindle speed: 4,000 rpm Max. bar diameter: 74 mm Machine equipped with: Dodpfx Acowqx Sao Hjcp - CNC control Mazatrol Matrix - KITAGAWA three-jaw chuck B-210, diameter 254 mm - Tool Eye - C-axis - Automatic parts catcher - NC tailstock - Reinforced coolant pump - Chip conveyor, side discharge - 8 static tool holders - 2 driven tool holders

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 600 mm, Mazak Variaxis i-700T Two-shift machine from a family-owned business Five-axis CNC machining center, year of manufacture 2016 Year of manufacture: 2016 Origin: Japan Location: Korea Delivery time: 55 to 65 days Maximum workpiece diameter: 850 mm Maximum workpiece height: 500 mm X-axis travel: 630 mm Y-axis travel: 1100 mm Z-axis travel: 600 mm A-axis swivel range: -120 to +30 degrees C-axis resolution: 0.0001 degrees Spindle taper: HSK 63 Maximum spindle speed: 18,000 rpm Rapid traverse X/Y/Z: 60 m/min / 60 m/min / 56 m/min Rapid traverse A/C axis: 18,000 deg/min Tool magazine: 40 tools Internal coolant supply: 15 bar Linear scales on all axes Scope of Supply – Machine Equipment Standard Equipment - Complete cooling system - Set of manuals and setup tools - Foundation mounting kit with anchor bolts and plates - Mazak standard color: white or black - Y-axis travel 1100 mm - Mazatrol SmoothX CNC with 19-inch LCD touchscreen - Power transformer for export markets - Main spindle motor: AC 30 kW - Spindle speed: 18,000 rpm, ISO 40 - Tool magazine for 30 tools - Spindle orientation in 1-degree steps via M-function - Spindle cooling unit - Manual Tool Eye probe - Prepared for Mazak Monitoring System RMP600 - Maza-Check - Absolute positioning system - Ball screw cooling for X, Y, and Z with roller guideways - Coolant system with 4.5 kg pressure and 30-liter tank capacity - Door switch with safety interlock Dcsdpfx Asxq Rrvjc Hjp - ATC Auto Recovery - APC Auto Recovery - Full machine enclosure with work light - Smooth Standard Software - User macro system with 600 variable pairs - Mazak tapping and drilling function Tornado EIA ISO - EIA ISO program code entry function with expanded EIA ISO features - EIA ISO simultaneous 5-axis function - Inverse Time Feed - Automatic tool length measurement G37 - Block number comparison function - Additional workpiece coordinate system with 300 storage spaces - Thread cutting and polar coordinate function - Direct input of drawing dimensions - EIA pattern cycle for grids and curves - USB interface and LAN connection - Program storage 1 MB plus USB interface - Relocation Detector Optional Equipment - KCS safety monitoring - Spindle speed 18,000 ISO 63 - Tool magazine for 40 HSK tools - Laser tool measuring system with air cleaning - RMP600 wireless probe - Scale feedback system for X, Y, and Z - Workpiece air blow - Oil skimmer RB-200 - Coolant temperature control device for water-based coolant - High-pressure coolant system 15 bar - Automatic shut-off in case of overload - Three-color signal tower, square version - Chip conveyor with rear discharge - Spindle shaper function - 3D coordinate transformation - TBR and MMS in EIA ISO macro - Dry run function without workpiece - Cooler for electronics cabinet - YMK 5-axis CNC Package 2 with Ethernet - Training and commissioning support

Condition: ready for operation (used), Year of construction: 2001, General Data Measurements width 4700 Measurements depth 8600 Measurements height 3550 Machine weight 27000 Control Unit Brand MAZATROL Model 640 M-PC Main Drive Spindle speed range 10000 Spindle motor power 29.8 kW Tool taper SK 50 Number of axis 3 Movement Dsdpfxexg Upqo Ac Hjcp X-Axis Movement 3000 mm Y-Axis Movement 1480 mm Z-Axis Movement 640 mm Tools Slots in storage 60 Media Chip conveyor Yes This 3-axis Mazak FJV 60/120 vertical machining center was manufactured in 2001. It offers robust capabilities for precision machining. If you are looking to get high-quality milling capabilities, consider the Mazak FJV 60/120 machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 2003, Max. Swing – 675mm Swing over carriage – 350 mm Max. Machining dia. – 380 mm Max. Machining lenght – 538 mm X-axis travel – 230 mm Z-axis travel – 575 mm Spindle - Chuck size – 8” Spindle speed – 5000 rpm Turret w/12 stations Control: Mazatrol PC Fusion 640 T Equipped with: Dodpfxev Rnuxe Ac Hecp Barfeeder LNS Eco Load

Condition: used, Year of construction: 1997, travel distance X-axis: 1,300 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: Mazatrol, controller model: M-Plus, overall weight: 36,000 kg, tool weight: 2,200 g, CNC Horizontal Machining Centre with Palletech Table size 800 x 800 mm. Table NCRT. Number of pallets 14. Movement x-Axis 1300 mm. y-Axis 1100 mm. z-Axis 1000 mm. Table indexing 0,001°. Djdpfx Asxd Aruec Hecp Number of tools in magazine 237 pieces. Maximum spindle speed 35-7.000 min. Tool taper DIN 69871A-50. CNC control M-plus If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2000, Serial no. 144416, control unit, type Mazatrol 640M, clamping table 1,500 x 500 mm, travel ranges X/Y/Z 1,120 x 510 x 510 mm, table load max. 800 kg, spindle speed max. 12,000 RPM, 24-position tool changer, 2 high-pressure vices +++ ATTENTION: stored at Stiglitz company in 73614 Schorndorf - to be picked up there! +++ Dcodpfx Acowp E Hbo Hop

Condition: used, Year of construction: 2019, functionality: fully functional, CNC SMOOTH G, travels 730 x 730 x 730 mm, 2 pallets 500 x 500 mm, spindle speed 18,000 rpm, 120-tool magazine, max. workpiece diameter 800 x 1000 mm, rapid traverse 60 m/min, through-spindle coolant 15 bar, RENISHAW preparation, NC rotary table with 360.00 positions, CONCEP conveyor. Djdpfx Acjxcvycj Hscp

Condition: used, Year of construction: 1987, Technical details: Dodpjvc Avbefx Ac Hecp x-travel: 760 mm y-travel: 450 mm z-travel: 500 mm control: Mazatrol CAM M-2 tool changer with: 30 tools (Kettenmagazin) Plätze spindle taper MT: ISO 40 Revolution per minute: 28 - 4500 U/min. feed speeds infinitely variable: X/Y/Z: max. 2.000 mm/min max. torque on the spindle: ca. 23 Nm rapid traverse:: X / Y: 24 m/min rapid traverse:: Z: 15 m/min. bore capacity in steel (diameter): Ø 40 mm table-size: 500 x 1150 mm table load capacity - central/maximum: 700 kp total power requirement: 11 kW (24,4 kVA) kW Weight approx.: 6,8 t dimension machine xH: 3,7 x 2,5 x 2,6 m chip conveyor: L: 3,7 x B: 0,75 x H: 1,35 m ATC tool magazine for 30 tools up to Ø 100mm x 330mm, SK40 Hinged belt chip conveyor Knoll-120S-1 with ejection height of 1130mm Coolant tank with pump, 200liter capacity, 30 l/min. Operation via control panel with boom 2000mm. accessories: cooling lubricant pump Base plates *

Condition: ready for operation (used), Year of construction: 2007, operating hours: 13,536 h, Control Unit Djdpsxb E Nqjfx Ac Hjcp Brand MAZATROL This 5-axis Mazak Integrex 400-IV ST was manufactured in 2007, featuring dual 10-inch chucks and Mazatrol Matrix control. It offers X1 and X2 cross travels of 630 mm, Z1 and Z2 longitudinal travels of 1,585 mm and 1,546 mm respectively, and a Y-axis travel of 230 mm. The milling spindle operates at 12,000 rpm, and the turning spindle at 2,800 rpm. Consider the opportunity to buy this Mazak Integrex 400-IV ST turn-mill centre. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 1994, Turning length 1020 mm Max. turning diameter 410 mm Max. spindle revolutions 3500 rpm X/Z movements 265/1035 mm Number of stations in turret 12 Spindle speeds on rotating tools 2500 rpm. Control: Mazatrol T32-3 Equipped with: Various tool holders Dodpfx Acexdnn Ue Hscp

Condition: good (used), Year of construction: 2008, travel distance X-axis: 630 mm, travel distance Y-axis: 765 mm, travel distance Z-axis: 510 mm, CNC control Mazatrol Matrix 2-fold pallet changing device NC-swivel rotary table 80-fold tool changer high pressure coolant through the spindle 20bar Dcjdjtp Hgzopfx Ac Hsp chip conveyor Technische Daten / technical details: Verfahrweg X / X-Travel 630 mm Verfahrweg Y / Y-Travel 765 mm Verfahrweg Z / Z-Travel 510 mm Schwenkbereich A-Achse / swivel range A-axis -120 - +30 ° Drehbereich C-Achse / rotary range C-axis 360 ° Tischgröße / table size 500x500 mm Werkzeugschaft / spindle taper SK40 Drehzahl / spindle speed 35-12000 UpM /rpm Eilgang / rapid feed 50 m/min Anzahl der Werkzeugplätze / tool places in ATC 80 fach / fold Antriebsleistung Hauptantrieb / drive capacity main drive 26 kW Gewicht der Maschine ca. / weight 17000 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 2004, Serial no. 170473, control unit, type Mazatrol 640M, clamping table 1,500 x 500 mm, travel ranges X/Y/Z 1,120 x 510 x 510 mm, table load max. 800 kg, spindle speed max. 12,000 RPM, 24-position tool changer Dsdpfjwp E Dtjx Ac Hjcp +++ ATTENTION: stored at Stiglitz company in 73614 Schorndorf - to be picked up there! +++

Condition: used, Year of construction: 2008, Mazak QTN 100IIM CNC Lathe Year of manufacture: 2008 C axis, driven tools Chuck: 170 mm Spindle bore: 51 mm Max turning diameter: 280 mm Max turning length: 334 mm Spindle: 35–6,000 RPM Travels: X - 185 mm Z - 385 mm Main spindle motor: 11 kW Max. torque: 184 Nm Spindle nose: A2–5'' Spindle indexing increments: 0.001° - Tailstock - Parts catcher - Measuring probe - Bar feeder interface - Chip tray with pump Dcjdpjxg Iffefx Ac Hep - Machine documentation - 10 standard tool holders - 2 driven tool holders 1/1 Weight: 3,800 kg Dimensions (L x W x H): 2.10 x 1.70 x 2.00 m

Condition: good (used), Year of construction: 2005, Technical data: max. machining diameter: 380mm max. swing diameter over slide: 675mm max. distance between the spindles: 541mm max. bar capacity: 77mm Traverse path X - Y - Z axis: 230 / 100 / 575mm rapid traverse X - Y - Z axis: 30 / 21 / 33mm Main spindle Speed: 4.000min-1 Motor (100% / 30 min.): 22 / 26kW Spindle bore: 88mm Counter spindle Speed: 6.000min-1 Motor (25% ED) 7.5 kW Travel: 585mm Tool turret with driven tools Number of positions: 12 Max. Speed: 4.500min-1 Motor: 5.5kW Tool shank height: 25mm Dcedsufkh Ejpfx Ac Hsp Tool shank diameter: 40mm Machine weight: 5.400kg Footprint L x W x H: 285 x 187 x 187cm Accessories: Loading and unloading robot Mitsubishi RV-12SL-S12 Interface for bar loading magazine Automatic parts catcher Automatic door High pressure cooling 5 bar Chip conveyor

Condition: ready for operation (used), Year of construction: 2006, operating hours: 20,695 h, Control Unit Brand MAZATROL Model Matrix Movement X-Axis Movement 630 Y-Axis Movement 230 Z-Axis Movement 1585 W-Axis Movement 1546 Additional Equipment Djdpfxsxbumfe Ac Hocp Options Screen: Picture available This 5-axis Mazak Integrex 400 IV was manufactured in 2006. It features a Mazatrol Matrix control, a 12-inch chuck, and a steady rest supporting 70-230mm. The machine offers a milling spindle speed of 12000rpm and a turning spindle speed of 2800rpm. If you are looking to get high-quality turn-mill capabilities, consider the Mazak Integrex 400 IV machine we have for sale. Contact us for more information about this machine. Application Types Turning

Condition: used, Year of construction: 2004, Clamping area 630 x 500 mm X axis - 630 mm Y axis - 765 mm Z axis - 510 mm A axis - 0,001 deg. (+30/-120 deg.) C axis - 0,001 deg. (360 deg.) Spindle speeds 35-12000 rpm Djdsxdfiiepfx Ac Hscp Spindle taper ISO 40 Control: Mazatrol 640 M 5X Equipped with: Coolant through spindle (20 bar)

Year of construction: 2012, condition: good (used), Mazatrol Smart CNC control 3-jaw chuck C-axis driven tools 12-fold revolver Tool Eye tail stock coolant device chip conveyor Technische Daten / technical details: max. Umlaufdurchmesser / max. swing diameter 660 mm max. Drehdurchmesser/ max. turning diameter 350 mm max. Drehlänge / max. turning length 532 mm Planweg (x) / cross way (x) 225 mm Längsweg (z) / longitudinal way (z) 560 mm Dcodsiyx Diepfx Ac Hsp Drehzahlbereich / spindle speed 5000 UpM /rpm Drehzahl angetriebene Werkzeuge / speed of driven tools 4500 UpM / rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang X/Z / rapid feed X/Z 30/33 m/min Antriebsleistung Spindel / drive capacity spindle 15 kW Gewicht der Maschine ca. / weight 4500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 2006, Ser.-No. 181504, Control, Type Mazatrol 640M, Clamping table 1,500 x 500 mm, Travel distances X/Y/Z 1,120 x 510 x 510 mm, Table load max. 800 kg, Spindle speed max. 12,000 rpm, 24-position tool changer, 3 high-pressure vices Dcjdpfxewp Ey Ij Ac Hop +++ ATTENTION: stored at company Stiglitz in 73614 Schorndorf - to be collected there! +++

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, Equipment: chip conveyor, documentation/manual, Mazatrol Smart Control Technical Data: Travel Distance X – Y – Z Axis mm 1050 / 530 / 510 Rapid Traverse X – Y – Z Axis m/min 42 / 42 / 42 Table Table Size mm 1300 x 550 Table Load Capacity kg 1,200 Distance Table Surface / Spindle Nose mm 150 – 660 Main Spindle Spindle Speed min-1 12,000 Main Drive Power (5 min. / 30 min.) kW 18.5 / 11 Automatic Tool Changer (ATC) Number of Tool Stations / Tool Taper 30 / SK 40 Max. Tool Diameter mm 80 - with adjacent stations free mm 125 Max. Tool Length mm 350 Max. Tool Weight kg 8 Machine Height mm 2808 Footprint mm 2880 x 2929 Machine Weight kg 7,000 Accessories: Relocation Detector Automatic Tool Length Measuring System Electronic Handwheel Workpiece Air Blowing Device Rapid Traverse at Constant Inclination Angle Form Compensation for Rotating Axes Monitoring System B incl. Renishaw OMP 60 Probe Dcsdexdwhkepfx Ac Hsp Through-Spindle Coolant 15 bar Chip Conveyor

Condition: ready for operation (used), Year of construction: 2000, General Data Measurements width 2100 mm Measurements depth 2200 mm Measurements height 2600 mm Machine weight 5000 – 5500 kg Control Unit Brand MAZATROL Dcjdpfjxg Ul Ssx Ac Hop Main Drive Spindle speed range 12000 Number of axis 3 Movement X-Axis Movement 560 mm Y-Axis Movement 410 mm Z-Axis Movement 410 mm Table Table load 300 kg Tools Max weight 6 kg Max tool length 300 mm Type of tool holder BT40 This 3-axis Mazak fjv 200 was manufactured in 2000. A robust vertical machining center featuring a Mazatrol PC-Fusion CNC 640M control, it offers a table size of 800 × 410 mm with a load capacity of 300 kg. The spindle reaches up to 12,000 rpm, driven by an 11-15 kW AC motor. Consider the opportunity to buy this Mazak fjv 200 vertical machining center. Contact us for more information about this machine. Application Types Milling

Year of construction: 2012, condition: ready for operation (used), Main Drive Laser power 2500 W Max Material Thickness Steel up to 20 mm Dsdpoxirh Aefx Ac Hscp Stainless steel up to 10 mm Aluminium up to 10 mm This Mazak MAZAK HTX510 was manufactured in 2012. A CO₂ laser cutting machine with a working area of 3000 × 1500 mm and laser power of 2500W. It can cut steel up to 20 mm, stainless steel, and aluminium up to 10 mm. Features include an automatic head and nozzle changer and a complete loading and unloading system. Consider the opportunity to buy this Mazak MAZAK HTX510 CO₂ laser cutting machine. Contact us for more information. Application Types Cutting

Year of construction: 2023, operating hours: 2,039 h, condition: ready for operation (used), Control Unit Brand MAZATROL This 3-axis Mazak Quick Turn 200MA L was manufactured in 2023. It features a MAZATROL SmoothC control unit, a maximum machining diameter of Ø360 mm, and a bar capacity of Ø65 mm. The spindle operates at 5,000 rpm with a chuck size of 8 inches. Ideal for precision turning, it has a 12-station drum turret and rapid feedrates of 30,000/33,000 mm/min. Consider the opportunity to buy this Mazak Quick Turn 200MA L horizontal turning machine. Contact us for more information. Dsdpfx Aexgi S Tec Hscp Application Types Turning

Condition: ready for operation (used), Year of construction: 1998, General Data Machine weight 17820 Kg Control Unit Brand MAZATROL Main Drive Spindle speed range 7000 Number of axis 3 Movement Dedpsxcztusfx Ac Hscp X-Axis Rapid Traverse 24000 mm/min Y-Axis Rapid Traverse 24000 mm/min Z-Axis Rapid Traverse 20000 mm/min Table Table load 1200 kg This 3-axis Mazak VTC 30C was manufactured in 1998. It features a Mazatrol M Plus control, rapid traverse rates of up to 24,000 mm/min in X, Y, and 20,000 mm/min in Z. The spindle speed reaches 7,000 rpm, supporting a table load of 1200 kg. If you are looking to get high-quality milling capabilities, consider the Mazak VTC 30C machine we have for sale. Contact us for more information. Application Types Milling
