Deephole Boring Machine

LOCH TB 8-30-600

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 308-600-1716, drilling depth: 600 mm, spindle speed (min.): 1,423 rpm, drill diameter: 65 mm, center height: 299 mm, TECHNICAL DETAILS Boring Unit Boring system: BTA + Ejector Speed steps: 8 or 16 with gear change Feed range: 0 – 500 mm/min Rapid traverse forwards/backwards: 5,000 mm/min Spindle taper: DIN 55022, size 6 Main Drive Three-phase motor: 37 kW, 1,500 rpm Frequency control: available Spindle Speeds Range I: 16/180 – 200/230 – 290/330 – 370/430 rpm Range II: 550/620 – 740/800 – 990/1,120 – 1,280/1,450 rpm Feed Drive Servo motor: 10 Nm, 3,000 rpm Ball screw: MH 50 × 10 × 14 Coolant System Total power requirement: 73 kW Coolant pump: MSDA 40-R38, SMDA 80-R46 Magnetic filter candles: MFK 400 R Liquid cooler: DKL 7 Gap tube filter: 54 572 71 104 Immersion pump: TB 405/390 Centrifuge: Polar U6 MACHINE DETAILS Dimensions and Weight Machine weight: approx. 6,000 kg Paintwork Color: RAL 6011 EQUIPMENT Clamping fixture with movable drill bushing Clamping fixture with drill bushing carrier Clamping fixture with clamping table Clamping fixture with centering tailstock Clamping fixture with centering clamp ZS2 (HICO) Force measuring system KIMISIT 0 – 30 Hydraulic unit HS04-C807-6-0 Chip conveyor SEW RF 430T71D4 Centrifuge Hanning ZG 52x6K.137 Fans Dietz DR 80a 69 Lsdpfxewx E N Ij Af Ssta Lubrication pump Vogel DM7 Control unit for main and feed drives

Condition: excellent (used), Brand: CORREA Model CF-17 Cnc : HEIDENHAIN 360 Table size : 2000 x 700 mm Number of T-slots: 5 x 22 Distance between T-Slots: 125 mm X axis Travel : 2000 mm Y axis travel : 800 mm Z axis travel : 800 mm Rapid traverse: 12.000 mm Spindle nose: ISO 50 Ltsdpfxjxcy D Sj Af Ssa Diameter of front bearing : 85 mm Turning ranges : 20-2750 rpm Range : 5-5000 Spindle power : 17 kw Max. Weight carrying on table : 3.500 kg Machine weight: 9.000 kg

Condition: used, fuel type: diesel, color: red, lifting height: 12,550 mm, axle configuration: 4x4, mast type: telescopic, Year of construction: 2019, operating hours: 5,030 h, Equipment: all wheel drive, Year of manufacture: 2019 Ltodpfsw Afulox Af Sja Empty weight: 9.200 kg Carrying capacity: 3.500 kg GVW: 12.700 kg Dimensions (LxBxH): 586 x 228 x 242 cm Working height: 1.300 cm Boom radius: 8.75 m

Condition: good (used), Year of construction: 2012, Parts shown by hand not come. 12.000 rpm,25 KW, 160Nm Control unit: HEIDENHAIN iTNC 530, 4th axis will come without parts shown by hand. Ltsdpfx Ajx Awzbsf Ssa

Condition: excellent (used), For sale: CNC rotary table from the renowned brand Fadal Engineering (USA), model VH65. Professional 4th axis designed for machining centers, especially Fadal VMC, but integration with other CNC machines is also possible using the appropriate controller. Technical specifications: • Model: VH65 • Table diameter: 165 mm (6.5”) • Gear ratio: 90:1 • Pneumatic brake (M60 ON / M61 OFF) • Industrial multipin connector • Serial no.: 4630298 Condition: used, mechanically functional, normal signs of operation. Solid and heavy construction – ideal for precise 4-axis machining. Ltodpfxew R St Ne Af Sja
