Machining center

HOLZ-HER Evolution 7405

Condition: used, Year of construction: 2016, machine/vehicle number: 7405_408, functionality: fully functional, operating hours: 788 h, HOLZ-HER Evolution 7405 White Edition CNC Machining Center For sale is a very well-maintained HOLZ-HER Evolution 7405 White Edition, year of manufacture 2016. The machine is in excellent technical and visual condition and can be demonstrated under power. A particular highlight is the exceptionally low processing time: only 788 hours with active feed. The machine was professionally serviced and completely recalibrated by the manufacturer in 2021. Since then, it has seen only limited use and runs smoothly, precisely, and reliably. Technical Data Manufacturer: HOLZ-HER Model: Evolution 7405 White Edition Year of manufacture: 2016 Serial number: 7405_408 Software / Controls CAMPUS Version: 6.4.4.2 NC-Hops Version: 6.6.2.207 Operating Hours Active feed / Processing hours: only 788 h Machine ON: 6,723 h Features 4-MAT configuration Drilling unit with 15 spindles Saw and grooving unit Milling unit with 6-position tool changer Handheld control device Vertical and horizontal processing Vacuum clamping system Ideally suited for: Furniture production Interior fittings Kitchen construction Joineries Nsdpfx Amsy Sicxjuolc CNC entry or capacity expansion Condition Very well-maintained overall condition Regularly serviced Professionally recalibrated by the manufacturer in 2021 Minimal use since recalibration Immediately ready for operation Runs very cleanly and precisely No known technical defects Machine can be inspected and tested during operation Availability Available from calendar week 25 / 2026 Inspection possible by appointment Support with loading and transport organization available Price Asking price: €43,900 net

Condition: excellent (used), Machining Centre HOLZ-HER EVOLUTION 7405 -used- Continuous feed machining, 4-sided edge routing possible, integrated vacuum pump, automatic positioning of suction cups, hardened, dust-protected prism guides, ball screw drives on all axes, network card for remote maintenance, integrated control cabinet, control cabinet cooling with heat exchanger, manual control device, XL drilling head, saw unit for grooving in the X direction, pick-up tool changer, automatic central lubrication. ----- Technical Specifications ----- Min. workpiece length X: 200 mm, Min. workpiece width Y: 70 mm, Min. workpiece thickness: 8 mm, Max. workpiece length X: 3,200 mm, Max. workpiece width Y: 920 mm, Max. workpiece thickness: 70 mm, Machine control software: CAMOUS HOPS, Main spindle motor power: 6.5 kW, Main spindle speed: 1,000 - 18,000 rpm, Main spindle interface: HSK-F63, Drilling unit motor power: 1.7 kW, Drill spindle interface: M10, H7 fit 11 mm, Number of vertical drilling spindles: 13 pcs, Number of horizontal double drill spindles in X direction: 2 pcs, Number of horizontal double drill spindles in Y direction: 1 pc, Saw blade diameter (saw unit): 120 mm, Number of tools in changer: 6 pcs, Extraction port diameter: 2 x 120mm + 1 x 140 mm, Required air flow rate: 4,100 m³/h, Required static vacuum: 2,500 - 3,000 Pa, Required air velocity: 30 m/s, Compressed air connection: 6 bar, Compressed air consumption: 300 l/min. Quality information: - complete basic cleaning - electrics checked - pneumatics checked - set according to manufacturer’s specifications - ready for immediate use Nledpfx Aeyrp Srjmuec

Condition: new, HOLZ-HER 7405 EVOLUTION CONNECT machining center -Exhibition machine- This offer is an equipment package. The following items and options are already included in the price: - Material support Nljdpfxsu Tid Hs Amuec - Height-adjustable infeed roller conveyor - EVOLUTION diamond formatting cutter set - CAMPUS V8 EVOLUTION CAD/CAM software - Flat screen 21.5", 16:9 - Workpiece length measurement LASER - Milling unit 7830 - 7887 tool changer 6-position magazine pick-up - ECO vacuum system - Air conditioning unit for switch cabinet cooling - Tool changer 7874 - Angular gear 7869 - Adapter for Clamex milling cutters - Tool set - 4-axis CLAMEX - Tool holder HSK-F 63 - Drilling unit XL 7885, 19 spindles - Manual control unit - Tool set - EVOLUTION for XL drilling head 7885 - new exhibition machine -

Condition: ready for operation (used), Year of construction: 2014, The HOLZ-HER EVOLUTION 7405 is a compact yet powerful vertical CNC machining center that delivers complete machining in a single setup—with precise milling on all four edges for perfectly finished parts. The machine processes materials from 8 to 70 mm thick and up to 3200 mm in length, while taking up minimal floor space, making it an extremely flexible and efficient solution for modern furniture and woodworking production. Brand: Holz-Her Model: Evolution 7405 Year of manufacture: 2014 Stock No.: 2002879BXA TECHNICAL DATA Machining dimensions Maximum material thickness: 8 – 70 mm. Vertical through-feed (width): 1,200 mm. Length: Unlimited (1,500 mm without repositioning). Minimum workpiece: approx. 200 x 70 mm. Working dimensions (X, Y, Z) Max board size (without additional support): X: 3,200 mm Nlsdpfjyxbv Rjx Amuoc Y: 920 mm Z: 70 mm Minimum workpiece size: X: 200 mm Y: 70 mm Z: 8 mm Maximum machining In the X direction (without re-clamping): Circular milling/formatting (excl. milling radius): 1,450 mm Complete machining (milling, drilling, milling groove): 1300 mm In the Y-direction: 920 mm Performance & Spindle Spindle power: 7.5 kW (4-axis) / 6.5 kW (standard) / 10.3 kW (optional) HSK mounting. Tool changer: 6-position (standard on 4-sided). Spindle speed: Variable, high-performance. Vector speed: 68 m/min. Features & Equipment 4-sided machining: Complete formatting and edge profiling. Drilling unit: Standard with milling spindle and drill head. Vacuum system: Intelligent, automatic positioning of suction cups. Control system: CAMPUS/NC Hops. Requirements Floor space: Less than 5 m²

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, workpiece length (max.): 3,200 mm, workpiece width (max.): 920 mm, workpiece height (max.): 70 mm, number of slots in tool magazine: 6, actuation type: pneumatic, total height: 2,350 mm, total length: 3,675 mm, total width: 1,660 mm, overall weight: 2,500 kg, year of last overhaul: 2026, Equipment: CE marking, documentation/manual, HOLZ-HER Vertikale CNC Evolution 7405 4mat, Baujahr 2014, Lieferung ab Standort Bearbeitungslänge: 3.200 mm Werkstückabmessungen: X = 200 – 3.200 mm (bei zusätzlicher Auflage auch länger möglich) Y = 70 – 920 mm Werkstückdicke: Z = 8 – 70 mm Maximale Bearbeitungslänge auf X-Achse ohne Umspannen: Nljdpfxsy Ny Uyo Amuoc X = 1.500 mm Z-Achsen-Verfahrweg = 240 mm Maximal programmierbare Geschwindigkeit: Vektorgeschwindigkeit: 68 m/min X = 25 m/min, Y = 60 m/min, Z = 20 m/min Software: CAMPUS V6 – Single Evolution 19-Zoll TFT-Flachbildschirm Höhenverstellbarer Rollentisch zur 4-seitigen Bearbeitung. Komplette Formgebung der Werkstücke durch präzises Fräsen aller vier Seiten möglich. Druckluft-Vakuumsystem Absaugung am Werkzeugkopf 2D Barcode-Scanner Bohraggregat 7883, 15 Spindeln, 1,7 kW Leistung (9 vertikal, 6 horizontal) Performance-Paket, bestehend aus: 7830 Fräsaggregat 6,5 kW (S6) HSK F-63 Werkzeugwechsler 7887 mit 6 Werkzeugplätzen (Pick-up-Typ) Manuelle Schmierung, kombinierter Schmierversorgungspunkt
