Milling Machines - A portale

FPT Industrie DINOX 350IAT

Condition: like new (used), Year of construction: 2018, operating hours: 5,498 h, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 3,500 mm, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 40 m/min, table length: 2,500 mm, table width: 3,500 mm, spindle speed (max.): 12,000 rpm, table height: 300 mm, table load: 130,000 kg, workpiece weight (max.): 130,000 kg, spindle nose: HSK A100, MOVING GANTRY MILLING MACHINE FPT MOD. DINOX 350 IAT 5 axes Numerical control: Heidenhain TNC 640 X axis: 2,500 mm Dsdpfswzv Tcox Aitokp Z axis (Vertical): 1,300 mm Y axis: 3,500 mm Rapid traverse: 40,000 mm/min Universal head with continuous positioning HSK A100 electrospindle interface Maximum speed: 12,000 rpm A axis: + / - 185° C axis: + / - 270° Table: 3,500 x 2,500 mm, height 300 mm Load capacity: 15t/m^2 Tool changer: 64 positions Total power: 85.13 kW Weight: 51,370 kg Complete with: - Laser probe and software for tool integrity check and tool length and radius measurement - Workpiece probing and alignment sensor - External/internal tool coolant with 1,500 l tank, p=40 bar - Workpiece washing gun with tool coolant, dedicated pump - Internal tool cooling with compressed air, High Speed - Chip conveyor USED MACHINE YEAR 2018

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 3,150 mm, travel distance Y-axis: 1,850 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 24 m/min, spindle speed (max.): 24,000 rpm, torque: 87 Nm, Fidia C20 CNC WORKING AREA X-axis longitudinal travel: mm 3,150 Y-axis transverse travel: mm 1,850 Dksdpfx Aoyw Tddeitsp Z-axis vertical travel: mm 1,000 MAX AXIS SPEEDS X, Y axis feed rate: m/min 30 Z axis feed rate: m/min 24 WORK TABLE Clamping surface: mm 3,000 x 1,600 Maximum permissible load: kg/m² 5,000 T-slots: • Longitudinal 8 H12 + 1 H8 • Width mm 22 • Pitch mm 160 ELECTROSPINDLE Maximum power (S6 60%): kW 55 Spindle speed range: rpm 240 ÷ 24,000 Constant power range: rpm 6,000 ÷ 24,000 Maximum torque: Nm 87.5 Tool holder: HSK-A63 C-axis travel: ± 200° C-axis speed: °/min 2,000 C-axis offset from spindle axis: mm 75 A-axis travel: +95° / -110° A-axis speed: °/min 2,000 Max distance spindle nose – table surface: mm 1,175 Machine equipped with: • 24-position tool magazine • Remote electronic handwheel • HMS system for head calibration • Various equipment included with the machine • User and maintenance manual and CE declaration of conformity

Condition: used, Year of construction: 2017, travel distance X-axis: 435 mm, travel distance Y-axis: 465 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 80 kg, total height: 2,755 mm, total length: 3,360 mm, total width: 3,870 mm, overall weight: 8,500 kg, spindle nose: MAS BBT 40, 5-axis Vertical Machining Centre CNC Control Matsuura G-Tech 31 i Table size ø 130 mm Table load 80 kg Number of pallets 10 max workpiece dia x height 330 x 300 mm Movement X-axis 435 mm Movement Y-axis 465 mm Movement Z-axis 560 mm C-axis (table rotation) 360° A-axis (table tilt) -125/+10° Spindle speed 50 - 15.000 R/min Spindle taper MAS BBT 40 Spindle motor 7,5/5,5 kW Magazin capacity 90 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock. Dodpfx Aoy Ny Akoitekp

Condition: excellent (used), Year of construction: 2014, operating hours: 68,000 h, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 15,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 30 m/min, torque: 167 Nm, overall weight: 35,000 kg, Initial commissioning: December 2014 Control system: Fidia X-axis: approx. 2,200 mm Y-axis: approx. 3,500 mm Z-axis: approx. 1,200 mm A-axis: ± 100° C-axis: ± 275° Machine operating hours: approx. 68,000 h Total spindle hours: approx. 26,500 h Clamping table: 2,000 x 3,500 mm with T-slots 2-axis fork milling head Spindle power: 70 kW Spindle speed: max. 15,000 rpm Torque: max. 167 Nm Tool holder: HSK 100A Tool clamping: hydraulic Linear axis drives Feed rate X, Y, and Z axes: up to 50 m/min / 30 m/min Connection data Voltage: 400 V Frequency: 50 Hz Dimensions, weights Required space for machine without peripherals: approx. 8,000 x 6,000 x 5,000 mm Total weight: approx. 35,000 kg Additional equipment - Coolant system - 26-place tool changer - Work area enclosure - Chip conveyor Available at extra charge: - Wireless touch probe - BLUM laser Dodpfxjyrc Ako Aitjkp Condition of the machine Fully operational, very good condition. Can be inspected under power.

Condition: used, Year of construction: 2018, travel distance X-axis: 2,300 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, table length: 2,300 mm, table width: 1,600 mm, spindle speed (max.): 10,000 rpm, spindle nose: SK 50, Used CNC portal milling machine KRAFT VM-2018B with Heidenhain TNC 620 Year of manufacture: 2018 Storage location: Germany Dsdpswkg T Sefx Aitjkp Delivery time: short term Payment: 100% before loading Warranty: none Machine description The KRAFT VM-2018B is a precise and powerful CNC portal milling machine with HEIDENHAIN TNC 620 control, ideal for heavy-duty and high-precision machining processes. Thanks to its robust design and high-quality components, it is ideal for demanding milling tasks in tool and mold making as well as in series production. Highlights & features Monoblock cast iron bed and cross beam for maximum rigidity and precision FEM-optimized machine design BF gearbox with 26 kW motor for high torque (662 Nm) Feed roller linear guides P-class (very low coefficient of friction 0.003-0.006) C3 ball screws with double nut - high load capacity & accuracy Spindle: SK50, 10. 000 rpm, direct drive Heidenhain TNC 620 control Spindle cooling & IKZ 20 bar Coolant system, oil separator, air conditioning for control cabinet Full enclosure, TÜV-approved, CE-compliant Technical data Travel (X/Y/Z): 2,300 / 2,000 / 1,000 mm Table size: 2,300 × 1,600 mm T-slots: 8 × 22 × 180 mm Max. Table load: 8 t Distance spindle nose - table: 180-1,180 mm Rapid traverse X/Y: 20,000 mm/min Rapid traverse Z: 15,000 mm/min Feed range: 1-10,000 mm/min Positioning accuracy (VDI/DGQ3441): 0.020

Year of construction: 2003, condition: ready for operation (used), - USED - 5-AXIS BRIDGE-TYPE CNC MILLING MACHINE WITH ROTATING TABLE LONGITUDINAL TRAVEL: 2700 mm TRANSVERSAL TRAVEL: 1100 mm Dkedewmxnmspfx Aitep VERTICAL TRAVEL: 1400 mm RAPID FEEDS L-T-V: 24 m/min TABLE SIZE: 1800 x 1800 mm MAX ADMITTED LOAD: 15000 Kg SPINDLE: 240-24000 rpm; 34 kW HEAD: CONTINUOUS A/B AXIS AUTOMATIC ; A-axis -110°+95° C-axis ±200° TOOL MAGAZINE: CHAIN-TYPE ; 42 POS CONTROL UNIT: FIDIA C20 DISTANCE SPINDLE NOSE-TABLE: 1600 mm WEIGHT: 21500 Kg OVERALL DIMENSIONS: 5950 x 5430 x 5220 mm ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL

Year of construction: 2014, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH ROTARY AND SHIFTING TABLE Dodpfewl R Amex Aitokp LONGITUDINAL TRAVEL: 4000 mm TRANSVERSAL TRAVEL: 1600 mm VERTICAL TRAVEL: 3000 mm RAPID FEEDS L-T-V: 30 m/min TRANSVERSAL TRAVEL OF THE TABLE: 1500 mm PALLET: 2000 x 2500 mm; 1200 rpm; 8000 Nm MAX ADMITTED LOAD: 30000 Kg HEAD: A/B AXIS AUTOMATIC ; MILLESIMAL POSITIONING ; ISO 50 ; 6000 rpm; 38 kW TOOL MAGAZINE: CHAIN-TYPE ; 80 POS CONTROL UNIT: HEIDENHAIN iTNC 530 HIGH PRESSURE COOLANT: 20 Bar ACCESSORIES: SWARF CONVEYOR ; TOOL SETTER

Year of construction: 1993, condition: ready for operation (used), - USED - 5-AXIS BRIDGE-TYPE CNC MILLING MACHINE LONGITUDINAL TRAVEL: 2800 mm TRANSVERSAL TRAVEL: 2200 mm VERTICAL TRAVEL: 1500 mm RAPID FEEDS L-T-V: 20 m/min TABLE SIZE: 3000 x 2000 mm MAX ADMITTED LOAD: 20000 Kg HEAD: A/B AXIS AUTOMATIC ; ISO 30 ; A-axis ±100° - B-axis ±185° ; 15000 rpm; 11 kW Dkodpfx Ajwla H Uoitsp TOOL MAGAZINE: CHAIN-TYPE ; 12 POS CONTROL UNIT: FIDIA CXR10 DISTANCE BETWEEN UPRIGHTS: 3600 mm OVERALL DIMENSIONS: 7000 x 4000 x 6485 mm ACCESSORIES: PORTABLE HANDWHEEL

Condition: new, Year of construction: 2026, Technical data Dedpfx Asv Ramgoitokp Control system: multi-axis real-time interpolator with active trajectory prediction. Communication via LAN, EtherCat, sampling time below 1 ms, correction map, RTCP, remote service access. Working area: 1500 – 3000 x 2100 – 12000 mm Z-axis clearance: 500 – 1200 mm Drive system: Servo drives with EtherCat protocol, X and Y axes with hardened, ground helical racks, accuracy class 6; Z axis with ball screw, accuracy class 5. Linear guidance: Trapezoidal rails Travel speed: X, Y up to 45 m/min; C, A up to 6000 degrees/min Software resolution: 0.0005 mm Positioning accuracy: 0.01 mm Gantry drive: Dual-sided master/slave with gantry angle correction Print heads: G.12 with output up to 12 kg/h G.20 with output up to 20 kg/h G.50 with output up to 50 kg/h G.200 with output up to 200 kg/h Construction: welded steel, ribbed, stress-relieved, precision machined We have extensive experience with a variety of materials, including: • Basic materials: PE, PP, ABS, PLA, PA, PC, PET, etc. • Advanced materials: PPS, PEEK, PEKK, etc. • Reinforced materials: carbon fiber, glass fiber, natural fibers.

Condition: excellent (used), Year of construction: 2014, load capacity: 270 kg, arm reach: 2,700 mm, controller manufacturer: KUKA, controller model: KRC4, empty load weight: 1,129 kg, The most popular robot series from KUKA, the KR QUANTEC, is sturdy, sleek, versatile, and outfitted with high performance features. The KUKA KR 270 R2700 F Ultra robot has a repeatability of 0.06 mm.  Frequently used in the following applications: - Palletizing -Depalletizing -Material Handling -Additive Manufacturing -Assembly Dodpfjq Dznbsx Aitokp -Dispensing -Remote TCP. Model: KRC4 KR270 R2700 F Ultra (Foundry) Condition: Refurbished & Tested and also painted Year: 2014 Controller Cabinet: KRC4 Included: Manipulator + KRC4 Control Cabin + All Wire Sets + Teach Pendant Not Included: The Base and gripper PLC MERKEZI Refurbishment Services Include: • Cleaning: The surface of the robot panel and the robot has been cleaned. • Oil Changing: The oils of all axes (6 axes) of the robot have been replaced. • Battery Changing: All batteries have been replaced with the new ones. • Mechanical Maintenance: Gear wheels counter balance are checked and maintained after weight, repeatability tests. • Electronical Maintenance: Includes drivers, electronic boards, teach pendant and PC maintenance. • Polishing and Repainting: After the cleaning the robot gets polished and be painted to its original colour, can be painted to the colour that you desired. As PLC Merkezi EOOD, we have more than 300 robots in our inventory and deal with KUKA, ABB, FANUC and Motoman brands. We also offer custom engineering services and design for your specific production needs.
