Milling Machines - A montante mobile

FPT Industrie RONIN

Year of construction: 2016, condition: ready for operation (used), - USED - TRAVELLING COLUMN MILLING MACHINE LONGITUDINAL TRAVEL: 6000 mm TRANSVERSAL TRAVEL: 1500 mm VERTICAL TRAVEL: 2500 mm RAPID FEEDS L-T-V: 35 m/min SPINDLE: 337- 5000 rpm; 42 kW; 1180 Nm WORKTABLE: 300 x 2500 x 7000 mm HEAD: ISO 50 ; MILLESIMAL POSITIONING ; A/B AXIS AUTOMATIC TOOL MAGAZINE: PICK-UP ; 12 POS CONTROL UNIT: HEIDENHAIN TNC 640 HIGH PRESSURE COOLANT: 20 Bar Gbjdpfjx Ru Azex Anxen NOTE: AUTOMATIC HEAD CHANGE; COMPRESSED AIR INSIDE THE TOOL; RTCP; AUTOCAL SOFTWARE FOR AUTOMATIC CALIBRATION

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / 2-machine package: Froriep deep hole drilling machine & Irle finishing machine Perfectly matched duo for deep hole drilling and precise finishing of large workpieces A specialised machine package is available for sale – two perfectly matched systems for the complete machining of long, heavy workpieces with the highest demands on precision and efficiency. MACHINE 1 Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Gbjdpfx Ansuddimexen Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring MACHINE 2 Irle machine – high-precision finishing Power: 129 kW Control: Siemens NC control Speed range: 2 – 300 rpm (stepless) Feed: 3 – 4,500 mm/min (in steps) Centre distance: 11,000 mm Swing diameter over bed: 1,250 mm Clamping range of steady rests: 150 – 1,100 mm Workpiece length: up to 11,000 mm Workpiece weight: up to 10 tonnes Max. outer diameter: 850 mm With up to 50,000 Nm torque, perfect for smooth drilling, honing and demanding finishing processes. Your advantages at a glance - Complete solution from a single source – from pre-drilling to finishing - Large workpieces up to 11 metres and 10 tonnes in weight - High process reliability thanks to perfect machine synchronisation - Ready for immediate use, well maintained and from ongoing operation - Ideal for mechanical engineering, energy, oil & gas, hydraulics and large parts manufacturing

Condition: used, Year of construction: 1965, core drilling diameter max. 50 mm bore depth 2000 mm swing diameter mm drilling capacity diameter max. 110 mm total power requirement 30 kW weight of the machine ca. 10 t Drilling Ø, approx. 2 - 50 mm Boring Ø, approx. 100 mm Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm Stroke of drilling slide, approx. 4,000 mm Distance between the two spindle heads 5,000 mm Height of centres above guideways 350 / 450 mm Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min Quick feed of drilling slide 2,500 mm/min Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm Workspindle drive 24 kW Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW Total electrical load, approx. 60 kW - 380 V - 50 Hz Total length of machine / guideways 7,500 / 5,000 mm Weight, approx. 10,000 kg Accessories / Special Features * Machine consists of the following elements: Main spindle on the left-hand side, followed by the coolant oil supply device. Table group, driven by ball screw spindle. Coolant oil supply device with elevated height of centres. At the end is a headstock, Type B 16, with Gbodpot Hwucefx Anxen drive motor approx. 7.5 kW, n = 900/2400 and 2400/6000. Large coolant device with filter unit. Large selection of accessories and drilling tools with Ø up to 100 mm. * Machine is suitable for working with a rotating workpiece together with a fixed drilling tool (ELB and BTA Process), as well as for a fixed workpiece and a rotating drilling tool. It can work with internal oil feed (Elb) or with external oil feed (BTA). * Complete oil coolant unit with tank and filter and two SIG high pressure pumps. Number of litres can be set: 17 / 40 / 120 or 220 / 500 litres per minute. Capacity approx. 2,500 l. * Feed of main slide is via ball screw spindle and infinitely variable DC motor. Mounted on the main slide is at present a table, approx. 800 x 800 mm, cross-adjustable approx. 500 mm, and suitable for holding cubic and cylindrical workpieces. Electric control via cam rail, approx. 2,500 mm long. End switch for quick feed, feed and return. * 2 closed 3-point steady rests. * FORKHARDT 3-Jaw Chuck, manually operated, Ø approx. 315 mm. * Modernized control panel with speed display, feed setting and display, display for kW, switch for feed, quick feed, right/left, etc. * 2 separate switch cabinets, separate coolant oil display device, bushes, reducers, clamping helps and lots of other accessories. This is a very valuable machine because of all the accessories!

Year of construction: 2007, condition: used, gear hobbing diameter - external 1200 mm gear hobbing diameter - internal 1200 mm gear hobbing width -max. 260 mm control Liebherr PC-NC max. workpiece diameter 1500 mm table diameter 900 mm table bore diameter 320 mm max. table load 95 kN power capacity 30 kW coolant pump 120 l/min Axial distance between thrust spindle - table 0-820 mm Shaping spindle diameter 125 mm tool taper SK 45 DIN weight of the machine ca. 26 t dimensions of the machine ca. 8,073 x 6,183 x 4,375 m Strokes: Gedpow Rf S Ejfx Anxjbn - Stroke length min./max. - 0 mm / 270 mm - Stroke length adjustability - 270 mm - Stroke rate (double strokes) - 10 to 270 DH/min Equipment/accessories: - Chip conveyor - Cutting wheel holder SK 45 DIN - Cooler - Technical documentation

Year of construction: 1981, condition: excellent (used), faceplate diam 1300mm max turning diam 1100mm Gsdpfsk Dz N Iox Anxsbn range of turning diam 460-1250mm

Condition: used, Year of construction: 2004, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,400 mm, CNC HEIDENHAIN iTNC 530 X-AXIS STROKE 6000 MM Y-AXIS STROKE 1400 MM Z-AXIS STROKE (VERTICAL) 2500 MM SPINDLE CONNECTION ISO 50 DIN 69871-B50 SPINDLE SPEED 5000 RPM MOTOR POWER S1 37 KW - S6 56 KW AUTOMATIC INDEX HEAD 1 ° X 2.5 ° TOOL CHANGER 40 PLACES COOLANT TROUGH THE SPINDLE AND EXTERNAL CHIP CONVEYOR ANCHORING PLATE 8000 X 2000 MM Gedsxhqivopfx Anxjbn PERIMETER PROTECTIONS

Condition: used, Year of construction: 2007, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,250 mm, rotational speed (max.): 5,000 rpm, SPINDLE TAPER ISO 50 X LONG. TRAVEL MM.6000 Z SADDLE TRAVEL MM.1250 Y VERTICAL TRAVEL MM.2000 SPINDLE SPEED RPM.5000 FEEDS MM/MIN.8000 SPINDLE MOTOR POWER KW. 37 CNC HEIDENHAIN iTNC 530 REMOTE HAND WEEL FLOOR PLATES 7000x2000- 15 TON/MQ. TABLE 1080 X 7220 X H 820 MM ATC.40 CHIP CONVEYOR ROTATING HEAD IN CONTINUOUS TUPC 0,001°x0,001° COOLANT THROUGH THE SPINDLE 20bar FUNCTION RTCP FPT AUTOCAL EXTERNAL COOLANT TANK HEIGH & LOW PRESSURE WITH PAPER FILTER N.2 AUTOMATIC HORIZONTAL DIVIDERS WITH 2 SUPPORT TABLES N.1 PIECE PROBE Gbsdpfswz H Rfjx Anxon

Condition: excellent (used), Year of construction: 2005, travel distance X-axis: 16,000 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,500 mm, Head Pick up Station TUPC CNC Indexing Micro Head A-Axis 360.000 x 0,001 Gr C-Axis 360.000 x 0,001 Gr SELS Spindle extionsion L=500 mm Gsdpfx Ansxpfkksxebn CTS Internal coolant system ATC Chain Tool changer 60 Positions Hydrostatic guideways Optional T Slotted floorplates 5600 x 1875 (2x) + 4000 x 1875 mm X-Axis: 16.000mm Y-Axis: 3.500mm Z-Axis: 1.500mm Power on spindle: 80kW Spindle speeds: 4000Rpm Spindle Taper: Sk59ISO/Bt/Mk Feed rate X-Axis: 25000mm/min. Feed rate Y-Axis: 25000mm/min. Feed rate Z-Axis: 25000mm/min. Millinghead auto-index:2.5 x 2.5° Length: 24000mm Width: 6500mm Height: 6500mm Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,500 mm, rapid traverse Y-axis: 25 m/min, rapid traverse Z-axis: 25 m/min, feed rate X-axis: 25 m/min, spindle speed (max.): 5,000 rpm, table length: 4,000 mm, table width: 2,000 mm, table height: 250 mm, spindle motor power: 44,000 W, Numerical control Heidenhain TNC530 HSCI with HR 410 handwheel X-axis travel mm 4000 Y-axis travel mm 2500 Z-axis travel mm 1500 Max. speed X,Y,Z axes m/min 25 Max. acceleration X,Y,Z axes m/sec2 0.75 Max. thrust X,Y,Z axes N 10000 X-axis transmission rack (dual drive), Y,Z ball screws Pressurized optical scales Hydraulic system, power supply and wiring 8-pole asynchronous power motor, star-delta connection, water-cooled integrated in the sleeve; double electronic speed range, 6000 W refrigeration unit Hydraulic balancing system Automatic compensation system for the dinghy dynamics Hydropneumatic and Electric (Rittal) floor-standing cabinets - 400 Vac 50 Hz CE Work area lighting; Machine and spindle counter Operator platform on board the machine COMPLETE WITH: -45° universal fixed head KOSMO 3: Front positioning indexed 0.02° Rear positioning indexed 0.02° -Spindle kW 44(35) - Nm 1005(800) - rpm 5000 - ISO 50 -Workpiece holder table mm 4000x2000x250 -Chain tool magazine on board the machine 40 places IS050 with exchanger arm, complete with support and management software -Tool coolant system - external flow (nozzles) low pressure (15 bar) + internal tool high pressure (50 bar) - tank lt 2000 Gbodpfxovcyvlo Anxjn - pump lt/min 42 - 50 bar to the pump - self-cleaning filter um 25 -Conveyor belt chips - longitudinal -Protective fences including panels and sliding door in sheet metal with lexan window, H 2000 mm 4000 mm light for loading/unloading piece USED MACHINE YEAR 2014

Condition: used, Year of construction: 2012, travel -x axis 8.000 mm travel -y axis 2.600 mm travel -z axis 1.500 mm control HEIDENHAIN - iTNC 530 turning speed range 20 - 5.000 U/min numbers of positions in the tool changer 60 tool taper SK50 clamping plate 10.000 x 2.500 mm CNC Milling machine | SORALUCE - FP-8000 equipped with radio measuring probe, 60-way tool changer and clamping plates. Gbsdpfoy E Txkox Anxjn The machine is in good condition and can be inspected under power. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. The machine videos from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: FP8000 | FP 8000
