Milling Machines - A portale

FPT DINOX 350IAT

Condition: like new (used), Year of construction: 2021, functionality: fully functional, travel distance X-axis: 2,600 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,400 mm, table length: 2,800 mm, table width: 3,100 mm, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, workpiece weight (max.): 52,000 kg, spindle nose: HSK 63A, controller manufacturer: Heidenhain, controller model: 640, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-Axis Gantry Milling Machine PARPAS Model DIAMOND LINEAR 30 Numerical control Heidenhain 640 Cross travel (X): 2,600 mm Longitudinal travel (Y): 3,000 mm Vertical travel (Z): 1,400 mm Feed rates: 60,000 mm/min Continuous orthogonal head (TOE29T) Godpewzv Umsfx Ah Sokd C axis: +/- 370° A axis: +/- 110° Tool holder: HSK-63A Spindle speed: 20,000 rpm Spindle power: 37 kW Table: 3,100 x 2,800 mm Load capacity: 6 t/m² Tool magazine: 60 positions Equipped with: - 2 chip conveyors - HR550FS handwheel USED MACHINE YEAR 2021

Condition: good (used), functionality: fully functional, travel distance X-axis: 4,230 mm, travel distance Y-axis: 2,700 mm, travel distance Z-axis: 700 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 12 m/min, feed rate X-axis: 12 m/min, feed rate Y-axis: 12 m/min, feed rate Z-axis: 12 m/min, table width: 2,400 mm, table length: 4,000 mm, table load: 14,000 kg, overall weight: 38,500 kg, spindle speed (min.): 5,200 rpm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, X-axis travel: 4,230 mm Y-axis travel: 2,700 mm Z-axis travel: 700 mm X-axis feed rate: 12 m/min Y-axis feed rate: 12 m/min Z-axis feed rate: 12 m/min Table length: 4,000 mm Table width: 2,400 mm Spindle speed (min.): 5,200 rpm X-axis rapid traverse: 12 m/min Y-axis rapid traverse: 12 m/min Z-axis rapid traverse: 12 m/min Distance between the stands: 2,800 mm Table load: 14,000 kg Milling head position: Vertical Workpiece weight (max.): 14,000 kg Total weight: 38,500 kg Equipment: - Speed continuously adjustable - Chip conveyor - Internal coolant supply - Tool magazine 40 tools - Tool holder SK 50 Gsdpfovt S Easx Ah Sskd - Heidenhain TNC 530 control

Condition: good (used), Year of construction: 1996, Schütte WU 405 tool grinding machine, Gkedpfxsuachgj Ah Sod year of construction 1996, annual maintenance carried out, NUM control, travel X/Y/Z 540/280/260 mm, travel W/A axis 360°, C grinding head 330°, 2 spindle ends, Spindle speed up to 12,000 rpm, automatic measuring probe, extraction system, CO 2 extinguishing system, belt filter system, Grinding wheel holders, clamping fixtures,

Year of construction: 2017, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD LONGITUDINAL TRAVEL: 3500 mm TRANSVERSAL TRAVEL: 1100 mm VERTICAL TRAVEL: 1500 mm RAPID FEEDS L-T-V: 40 m/min TABLE SIZE: 3800 x 1000 mm HEAD: A/B AXIS AUTOMATIC ; MILLESIMAL POSITIONING ; ISO 50 ; 5000 rpm; 34 kW TOOL MAGAZINE: CHAIN-TYPE ; 40 POS CONTROL UNIT: HEIDENHAIN TNC 640 HIGH PRESSURE COOLANT: 40 Bar WEIGHT: 35020 Kg OVERALL DIMENSIONS: 8760 x 4950 x 3780 mm ACCESSORIES: SWARF CONVEYOR ; LASER TOOL SETTER ; TOUCH PROBE ; PORTABLE HANDWHEEL Gjdpfxewla Hzs Ah Sekd

Year of construction: 2006, condition: ready for operation (used), A Mazak CNC 5-axis turning and milling center with counter spindle is available. Swing diameter: 820mm, machining diameter: 820mm, machining length: 1500mm, max. workpiece weight in chuck/between centers: 650kg/150kg, main spindle speed: 1600rpm, spindle bore: 185mm, power: 30kW/40kW, tailstock force: 15kN, quill stroke: 1466mm, tool holder: BT50, spindle speed: 10000rpm, travel X/Y/Z: 870mm/500mm/1600mm, rapid traverse: 40m/min. Machine dimensions X/Y/Z: approx. 6500mm/3700mm/3200mm, weight: approx. 26000kg, control: Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Gkjdpfx Aexf Ikleh Sjd

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, Heyligenstaedt Heynumill 2700-PF 3/5-axis CNC portal milling machine with integrated C-axis and interchangeable milling heads. Heidenhain TNC 430 control Gkodpfx Aowthz Aeh Ssd X-axis Y-axis Z-axis 3,000 mm 4,000 mm 1,500 mm In 2018, the complete hydraulic system of the Heynumill was renewed, all electrical cables were replaced, the spindle cooling unit and both longitudinal conveyors were renewed, and the heads were fully overhauled. The total refurbishment cost €160,000. In 2020, the milling gearbox was replaced. Further technical data see PDF file.

Condition: excellent (used), Year of construction: 2009, CNC control : FANUC 160i - Accessories available. - Fanuc loading robot - Coolant system (Edge 2 tower from ARO-Technologies) - Oil mist separator (ELBARON SA) Travels: X-axis 650 mm Y-axis 300 mm Z-axis 300 mm Gksdpfx Aher Ha Dvs Sed C-axis swivel angle +150°/ -60° C' axis swivel angle +/- 180° Grinding spindle: Wheel dimensions up to 250 mm Speed 0 - 10,000 rpm. Max. spindle power 26 kW HSK 80 holder Max. Number of disks 6 Workpiece headstock Vmax 180°/s Drive power 1.6 kW ISO 50 mounting Precision (resolution) Resolution linear axes 0.001 mm C-axis 0.001° Dimensions: Length 3100 mm Width 1915 mm height 2190 mm Weight 8'500 kg

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 850 mm, spindle speed (max.): 6,000 rpm, X-axis: 4.230 mm Y-axis: 2.100 mm Z-axis: 850 mm CNC Controller: Heidenhain iTNC 530 Spindle nose: ISO 50 Spindle speed: 6.000 Rpm Toolchanger: 30 pockets Table size: 4.000 x 1.650 mm Distance between columns: 2.300 mm Featured with: - Vertical milling head attachement - Touch probe - Cooling throught spindle Gedpoxd H H Asfx Ah Sskd - Double chip conveyor - Cooling unit - Machine manuals Country of origin: Taiwan Machine LxWxH: 9000 x 3500 x 4000 mm +/- Machine weight: 30.000 kg

Year of construction: 2021, condition: ready for operation (used), - USED - 5-AXIS BRIDGE-TYPE CNC MILLING MACHINE LONGITUDINAL TRAVEL: 3000 mm TRANSVERSAL TRAVEL: 2600 mm VERTICAL TRAVEL: 1400 mm RAPID FEEDS L-T-V: 60 m/min WORKTABLE: 3100 x 2800 mm HEAD: CONTINUOUS A/B AXIS ; HSK-63A ; A-axis ±110° - C-axis ±370° ; 20000 rpm; 39-37 kW; 92-117 Nm TOOL MAGAZINE: CHAIN-TYPE ; 60 POS CONTROL UNIT: HEIDENHAIN TNC640 Gkjdpfswla Hhjx Ah Sjd OVERALL DIMENSIONS: 7530 x 6600 x 5765 mm ACCESSORIES: FRONT AND BACK SWARF CONVEYOR ; PORTABLE HANDWHEEL

Year of construction: 2015, condition: ready for operation (used), - USED - 5-AXIS BRIDGE-TYPE CNC MILLING MACHINE LONGITUDINAL TRAVEL: 2200 mm TRANSVERSAL TRAVEL: 3500 mm VERTICAL TRAVEL: 1400 mm RAPID FEEDS L-T-V: 30 m/min TABLE SIZE: 3500 x 2200 mm HEAD: A/B AXIS AUTOMATIC ; HSK-63A ; A-axis -110°+95° B-axis ±360° ; 24000 rpm TOOL MAGAZINE: CHAIN-TYPE ; 42 POS CONTROL UNIT: FIDIA C40 Vision DISTANCE BETWEEN UPRIGHTS: 4200 mm WEIGHT: 62000 Kg ACCESSORIES: SWARF CONVEYOR ; Gkodpfx Ahowlwg Se Ssd PORTABLE HANDWHEEL
