Panel sizing circular saws

ALTENDORF F45

Condition: new, Year of construction: 2025, functionality: fully functional, cutting length (max.): 3,200 mm, cutting width (max.): 1,000 mm, cutting height (max.): 150 mm, table length: 3,200 mm, Basic Configuration - Electrically powered height and tilt adjustment 0-46° for the main saw blade with automatic correction of the cutting height when tilting the saw unit - Control panel at eye level, swiveling - Double roller carriage, carriage length 3,000 mm - Parallel fence, manual adjustment via measuring scale, including manual fine adjustment, cutting width 1,000 mm - Angle fence with fixed 90° position, manually adjustable via measuring scale up to 3,200 mm - Max. saw blade projection 154 mm, max. saw blade diameter 450 mm - Drive power 5.5 kW (7.5 HP) with three speeds (3,000/4,000/5,000 rpm) - AKE tool clamping system for the main saw blade - Working height 91 cm Control System - Electrically powered height and tilt adjustment, also on both sides (+/- 46°)*, for the main saw blade with automatic height correction and digital displays - Electrically powered adjustment of the parallel fence* - Electrically powered adjustment of the CNC miter fence UNO 90* - Automatic size correction on the parallel fence and angle fence when tilting the saw unit - Digital speed display or stepless speed control (VARIO)* - Electrically powered adjustment of the scoring unit, two or three axes* - Stepless fine adjustment of the axes via +/- buttons - Control of vacuum clamping in the double roller carriage* - Easy axis calibration - Machine diagnostics - Operating hours counter - USB interface - Recall of the last dimension entered (back function) - 99 storable cutting programs Bwjdpfx Asxuquljbcow - Grooving: with automatic stepwise positioning of the parallel fence until the groove is complete - Automatic conversion from peak to blunt measurement on the parallel fence and angle fence, taking material thickness and tilt angle into account - Compound angle cut function with automatic calculation of missing angles or dimensions - Advanced tool management · Storage of the scorer position (3-axis scorer)* · Saving of main blade thickness and cutting width · Saving of main tool speed · Max. 100 storable tools - Additional functions · Grooving: with automatic stepwise positioning of the parallel fence until the groove is complete · Chain dimension function: cutting sequences with identical distances on the parallel fence, calculated on both sides of the saw blade · Angle cut: by trimming the oversize, the desired finished size is produced after entering the edge angle · 999 storable cutting programs *optional accessories The following options are included: - Pattern holder - Extended cutting height incl. tilting - Motor 5.5 kW (7.5 HP) VARIO - 2-axis scorer unit - LED lighting - Double roller carriage with a length of 3,200 mm - On/Off switch on double roller carriage - Digital miter fence Digit L - CNC parallel fence 1,300 mm - Front support roller - Duplex 1350

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, cutting length (max.): 3,000 mm, cutting width (max.): 1,050 mm, cutting height (max.): 155 mm, saw blade diameter: 550 mm, height adjustment type: electric, power: 5.5 kW (7.48 HP), TECHNICAL DETAILS Max. cutting length: 3,000 mm Cutting width at parallel fence: 1,050 mm Saw blade diameter: 550 mm Table length: 840 mm MACHINE DETAILS Motor power: 5.5 kW EQUIPMENT Continuously variable speed Bodpfjxt Uqzox Abceww Double roller carriage with 3,000 mm carriage length Mitre fence 90 - 3,200 mm Support rail/second support on double roller carriage

Condition: used, Year of construction: 1990, Carriage length: 2800 mm Cutting width at rip fence: 1000 mm Cutting width at crosscut fence: 2800 mm Cutting depth: Scorer: no Saw blade height adjustment: manual / hydraulic Saw blade tilt adjustment: manual / hydraulic Rip fence adjustment: manual Saw blade angle display: scale Cutting height display: - Bwjdexrbhwspfx Abcjw Rip fence display: scale Crosscut fence display: scale Saw blade diameter: Speeds: 4 Motor power: 5.5 kW Motor brake: yes Extraction connection: 80 mm and 120 mm Machine length: 3000 mm Machine width: 1700 mm Weight: 1000 kg

Condition: used, Year of construction: 2003, Motor 7.5 kW, speeds manually adjustable: 3/4/5/6000 rpm (digital display). Sliding table 3000 mm. Mitre fence up to 3,200 mm (scale). Parallel fence 1,000 mm, manually adjustable. Electromotor-driven height and tilt adjustment. Saw blade diameter max. 500 mm. Extraction ports 120 + 80 mm. Location: supplier. Bwsdpexqd R Sjfx Abcjw

Year of construction: 2008, condition: ready for operation (used), This Altendorf F45 ELMO IV was manufactured in 2008. A robust panel saw featuring a double roller sliding table with a length of 3400 mm and a cutting width of 1300 mm, CNC controlled. It includes a powerful 5.5 kW VARIO drive and can handle a max saw blade diameter of 500 mm. Ideal for precise and versatile cutting tasks. Contact us for more information about this machine. Application Types Sawing (Wood) Bedpfxexp Spas Abcoww

Condition: excellent (used), Altendorf F45 ElmoDrive panel saw, 320 cm sliding table, tilt function on both sides: -45 to +45 degrees, motorized tilt and height adjustment of the saw blade, right-side rip fence, motorized adjustment up to 1340 mm, 3-axis electrically adjustable scoring unit, 5.0 kW vario motor, speed adjustable via frequency inverter, max. blade diameter 450 mm, Bwedpfx Ajxrcxqobcew laser, digital readout on the sliding table, used machine, very good condition, Low operating hours.

Condition: used, Year of construction: 2018, Used machine Year of manufacture 2018 Basic equipment Electric height and tilt adjustment 0-46° with automatic cutting height correction when tilting Control at eye level, pivoting Double sliding table, table length 3,000 mm Parallel stop, manually adjustable via scale, including manual fine adjustment Cutting width 1,000 mm Angle stop with fixed 90° position, manually adjustable via scale up to 3,200 mm Max. sawblade projection 150 mm Max. sawblade diameter 450 mm Drive power 4 kW (5.5 HP) at 4,000 rpm AKE tool clamping system for the main sawblade Working height 91 cm Productivity package Motor 5.5 kW (7.5 HP) with VARIO F45 - Continuously variable speed control from 2000 - 6000 rpm - Precise speed adjustment to the material increases cutting quality and sawblade service life. Extended cutting height for one-sided tilting This option is equipped with a large extraction hood for a max. sawblade diameter of 550 mm and a max. sawblade projection of 204 mm for one-sided tilting. In combination with a scoring unit, the max. sawblade diameter is 500 mm or 179 mm Bwodpoxppv Rsfx Abcsw cutting height. Only in conjunction with a minimum drive power of 5.5 kW (7.5 HP). Two-sided tilting! RAPIDO Plus 3-Axis Scoring Unit With electric height and lateral adjustment, programmable scoring blade height with quick lowering and quick raising, drive motor 0.75 kW (1 HP), 8200 rpm. Retrofitting only possible on machines prepared for a scoring unit. LED Lighting With particularly energy-efficient LED technology, the danger area of the scoring unit is clearly marked. Sliding Table with a Carriage Length of 3000 mm Basic Equipment Sliding Table with a Carriage Length of 3000 mm The Altendorf sliding table is famous for its smooth and precise operation. It can be infinitely locked in any position. The large double rollers, precision-machined from hardened steel, hold the upper carriage in connection with the lower carriage with absolute precision in the respective hard-chrome-plated guide rods. This running quality is maintained even after decades of use and contamination. The carriage is designed as an extremely torsion-resistant and dimensionally rigid multi-cavity system. The table surface is precisely planed and anodized. A hard-chrome-plated round bar, which is positively embedded in the upper carriage, serves as a mount for the cross slide and as an interface for various accessories. The entire unit is low-maintenance and requires no lubrication. DIGIT-L Angle Miter Stop, Cutting to Lengths up to 3500 mm This ALTENDORF-patented stop with integrated length compensation facilitates precise cutting of angles and miters in one function. In both positions, the swivel angle is continuously adjustable by 49° and is digitally displayed. The play-free and robust stop flaps can be easily moved and adjusted as individual flaps over the entire range up to a maximum of 3500 mm. For cutting to lengths up to approx. 1700 mm, the roller-supported, stable telescopic

Condition: used, Year of construction: 1991, functionality: fully functional, Manufacturer: Altendorf Model: F-45 Bjdpfxexqg S Ee Abcjww Year of manufacture: 1991

Condition: used, Year of construction: 2011, Carriage length: 3000 mm Cutting width at rip fence: 1300 mm Cutting width at crosscut fence: 3200 mm Cutting depth: 154 mm Scoring unit: yes Saw blade height adjustment: electric / position controlled Saw blade tilt adjustment: electric / position controlled Rip fence adjustment: electric / position controlled Crosscut fence adjustment: manual Saw blade angle display: digital readout Cutting height display: digital readout Rip fence display: digital readout Crosscut scale display: scale Crosscut fence with mitre function: yes Saw blade diameter: 450 mm Speeds: variable Motor power: 5.5 kW Main motor operating hours: 957 Extraction port: 80 and 120 mm Machine length: 3200 mm Machine width: 2200 mm Bedpfexp Radex Abceww Weight: 1200 kg

Condition: excellent (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: 93-09-128, saw blade diameter: 350 mm, power: 5.5 kW (7.48 HP), sliding table length: 2,800 mm, Panel saw Altendorf F 45, year 1993, with 2800 mm sliding table, max. blade 350 mm, main motor 5.5 kW, scorer motor 0.75 kW, with width extension and length extension. Bedpfx Absxp Rk Nscjww
