Used filters for food processing for sale (51)

Year of construction: 1986, condition: used, PVPP filter for beer filtration. The system is sterilised by filling the dosing tank with hot water and flushing it with the PVPP tank in a circuit. Finally, the system is rinsed with cold water. After filtration, the PVPP is regenerated with lye. The system consists of the following components: - Stainless steel filter housing, 18.8 hl, upright, closed with clamping screws - Upright agitator tank for mixing PVPP with manhole on the top of the tank - Plate heat exchanger - Various pipes, pumps, valves, measurement technology - Control cabinet with user interface Additional title: beer filtration Filtration capacity appr.: 20000 l/h Gross volume filter housing: 1880 l Max. overpressure filter housing: 6 bar Operation / Control: VIPA 300S+ Material: Filter housing made of stainless steel 1.4541 (AISI 321) Itsdpfx Afoxzquro Ssr Features: Filter housing; mixing tank; plate heat exchanger; various pipes, pumps, valves and measuring technology; control cabinet

Condition: new, Vito 80 mobile oil filtration unit. Motor unit and filter box made of stainless steel, cellulose filter insert Cleaning capacity: up to 80 L/min Suction depth: max. 45 cm Ideal application: e.g., for 4x 20 L fryers (medium contamination, approx. 2.5 kg crumbs per day) Cleaning process can be performed at up to 175°C Filtration cycle time: 4.5 minutes Itodpox Il U Nsfx Af Sor

Year of construction: 2021, operating hours: 220 h, condition: like new (used), functionality: fully functional, machine/vehicle number: B144, HIGH MOISTURE EXTRUSION (HME) Extruder HME is able to create structured, palatable and nutritious products. Possible industries: - Plant-based Food (Clean label products with great texture) - Pet Food Industry (Wet Pet Food Production, Functional treats and chews, Alternative Protein incorporation) - Aquaculture Feed Industry (Structured aquafeeds, Nutrient Enhancement) Iodpfxsx Ac Uto Af Sstr - Nutritional supplement and medical foods (High-Protein Supplements) - Snack and convenience foods (High-Protein snacks, Meat-Free Meal Kits) - Sustainable and Alternative Protein Products (Insect and Algae Protein Texturization, Upcycled Food Products) The package includes: • High-quality Clextral HME Extruder • Additional equipment enabling faster start of production Reason for sale: We tried with the project in Plant-based industry in Slovenia and stopped the project in Jan. 2025. Machine was bought at the end of 2021, started operating in H1 of 2022 and worked for only 220 hours. Attached you can find a document with key information about the machine and additional equipment. The machine is in excellent condition ("like new"), used for only 220 hours and meticulously maintained – guaranteeing flawless operation and immediate usability after installation. A catalogue of plant-based products we have manufactured is also included. If you are interested in HME extrusion, we invite you to explore the technical documentation, photos, and VIDEO content available upon request.

Year of construction: 1988, condition: ready for operation (used), A sheet filter (EK filter) Seitz Orion is available. Plate dimensions X/Y: 600mm/600mm, number of plates: 80, filter area: approx. 22m², filtration capacity: 45hl/h, connection: DN50. Machine dimensions X/Y/Z: approx. 3300mm/1000mm/1500mm, weight: approx. 1250kg. An on site inspection is possible. Itedpfx Ajxyzgief Ser

Condition: like new (used), Filter elements (spare parts) for kieselguhr filter SEITZ - ORION L 1. SS stainless steel plates and frames 40/40. Mounted together on wheels. 2. SS stainless steel plates 60/60. 9 pieces 3. Gaskets 14 pieces Itedpfxoq H Smaj Af Ser 4. Gaskets 16 pieces 5. Gaskets 26 pieces

Year of construction: 2000, condition: used, Della Toffola NF5 mobile kieselgur plate filter 5 m², Aisi 304 - condition: used - location: Bremen - total height: 1.890 mm - total length: 1.200 mm - total width: 2.100 mm - remarks: - Working pressure: +6 Bar; - material in contact w/ medium: Aisi 304; - filter medium: diatoms; 240 l tank with agitator for preparing the diatoms; - agitator arranged eccentrically in the upper bottom; - Agitator element: anchor agitator; - mobile frame on rollers with brake; Iedst Ebizspfx Af Sstr - Weight: 510 KG

Year of construction: 1988, condition: used, Module filter, free-standing with 4 stainless steel feet with adjusting screws Volume: 197 l Operating pressure: 10 bar Max. operating temperature: 121 °C Length: 0,442 m Width: 0,442 m Height: 1,93 m Material: Stainless steel Itedpfoxwy U Hjx Af Sjr Base construction: standing on feet Features: Closure with 12 clamp screws; tank connections DN 50; with all fittings, pressure gauge Height of the sieve pipe: = 0.99 m; diameter of the sieve pipe 47 mm

Condition: excellent (used), Year of construction: 2001, 2 filter presses are being offered. Years of manufacture: 1999 and 2001. For details, see the nameplates. Iedjxbrmcjpfx Af Setr

Condition: new, functionality: fully functional, Year of construction: 2025, overall weight: 31 kg, total height: 350 mm, total length: 430 mm, total width: 350 mm, Plattenfilter FP-10 with Pumpe ist ein compactes, halbprofessionelles Gerät zur Filtration verschiedener Flüssigkeiten, insbesondere pflanzlicher Öle. Mit einer Leistung von bis zu 25 Litern pro Stunde ist es die ideale Lösung für den Hausgebrauch und kleine Manufakturen. Dank seiner geringen Abmessungen und der einfachen Handhabung kann es als tragbares Alltagsgerät verwendet werden, das lediglich eine regelmäßige Reinigung erfordert. Das Herzstück des Geräts ist eine selbstansaugende Drehkolbenpumpe, hergestellt von der italienischen Company ROVER POMPE SNC in NOVAX-Technologie. Diese hocheffiziente Pumpe ist mit einem sternförmigen Rotor ausgestattet, der den Flüssigkeitsfluss in beide Richtungen ermöglicht. Durch ihre spezielle Hydraulikkonstruktion kann die Pumpe auch in Anwesenheit von Luftblasen arbeiten, was einen continuierlichen und stabilen Betrieb gewährleistet. Alle flüssigkeitsberührenden Oberflächen sind sorgfältig bearbeitet, was ihre chemische und mechanische Beständigkeit erhöht und zugleich Lebensmittelsicherheit bietet. Die Pumpe fördert die Flüssigkeit zum Filterblock, in dem die Filterplatten eingesetzt sind. Das System kann 6 bis 10 Filtereinsätze aufnehmen, was die Filtrationsleistung erhöht. Die Platten sind parallel geschaltet, um die Effizienz bei der Entfernung von Verunreinigungen zu maximieren. Für die optimale Filtration von Pflanzenölen wird die Verwendung von Filtern mit einer Durchlässigkeit von 45 Mikrometern empfohlen, sowie das Halten der Öltemperatur bei etwa 35°C, um einen besseren Durchfluss und Reinigungseffekt zu erzielen. Vor dem Filterblock befindet sich ein Manometer, das die Überwachung des Drucks und die Beurteilung des Zustands der Filtereinsätze ermöglicht. Bei einem deutlichen Druckanstieg zeigt das Manometer die Notwendigkeit eines Filterwechsels an. Das FP-10-Set erlaubt das Abtrennen des Schlauchs zwischen Pumpe und Filterblock, sodass die Pumpe auch für andere Aufgaben der Flüssigkeitsförderung verwendet werden kann. FP-10 ist ein zuverlässiges Gerät für die Kleinmengenfiltration von Flüssigkeiten, das Leistung, Benutzerfreundlichkeit und hohe Verarbeitungsqualität vereint. Technische Daten: Länge: 43 cm Breite: 35 cm Höhe: 35 cm Gewicht: 31 kg Product type: Kompakte Industriefilter zur Flüssigkeitsfiltration Einsatzbereiche: Zur Reinigung verschiedener Flüssigkeiten in der Lebensmittel-, Chemie-, Pharma- und Kosmetikindustrie Antriebsart: Elektrisch Leistung: bis zu 25 Liter pro Stunde Itsdpswhw Arsfx Af Sjr Motorleistung: 0.5 kW

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, Equipment: dust extraction, This is a dedusting system with an explosion certificate for hemp dust. The system is installed and the price includes all parts. Isdpfx Afjxpm Aus Sotr

Condition: used, Year of construction: 2003, functionality: fully functional, tank capacity: 164 l, operating pressure: 6 bar, TECHNICAL SPECIFICATIONS - Year: 2003 - 1 housing with 6 cartridges - 2 housings with 3 lenticulars - Housing : BEGEROW - Housing type : M0340650 - Max. working pressure 6 bar Itsdpfswal Dnsx Af Ser - Max. operating temperature : 120 °C - Volume : 164 litres - Inoxpa wine pump - Dosing pump - Automatic

Condition: used, Padovan Green Filter 18 m² mobile Kieselgur stainless steel plate filter, Aisi 304 - condition: used Isdpfx Ajt Eb Azsf Sotr - location: Bremen - total height: 2.950 mm - total length: 2.250 mm - total width: 1.500 mm remarks: - Filter medium: diatoms; - tank with agitator for the preparation of diatoms; - Underbody opening diameter: approx. 400 mm;

Year of construction: 2021, condition: refurbished (used), - Year of construction: 2021 - Filter area: 130m2 - Ceramic modules - Porosity: 0.2micron (standard) Leistung : - White wines: 7000 - 10000 l/h - Red wines: 5000 - 8000 l/h - Grape juice: 4000 - 5000 l/h - Fruit juices: 4500 - 6500 l/h Ijdpfov Niriox Af Sjtr - Filter factory-reconditioned - 12-month factory warranty on mechanical parts - Machine in new condition

Condition: used, Combi filter (kieselgur- and sterilising filter) for beer filtration with hydraulic pressure, 100 x 100 cm filter plates and external risers. Additional title: combination filter Capacity: 120 hl/h Plate size: 100 cm edge length Length: 7000 mm Width: 1500 mm Height: 1500 mm Itedpfx Afevcqlws Ssr Position: horizontal Base construction: mounted on steel frame, standing on feet Features: 31 kieselguhr layers (32 frames), 50 sterilisation layers, 4 pressure manometers (10bar), 6 lanterns, risers, kieselguhr discharge screw (Allweiler), gravity measurement, flow measurement, 3 x turbidity measurement (inlet, outlet Kieselgur filter, outlet 3 x turbidity measurement (inlet, outlet kieselgur filter, outlet sterilisation filter). Spare parts: 295 sealing rings for filter plates, 3 kieselguhr filter support plates

Year of construction: 2017, condition: excellent (used), SCAIME bag pourer with Donaldson stainless steel filter Year: 2017 Iodpforfzdlsx Af Sotr

Condition: good (used), A-1654-Padovan- Brine filter Itodpjh A Hckefx Af Sor Padovan Green Brine filter Please contact us for more information.

Year of construction: 1980, condition: good (used), - Horizontal sieves - 30 filter plates - Filter area : 6 m2 - Max, operating pressure : 6 bar - Capacity : 30 - 120 hl/h - With semi-automatic cleaning Dimensions : - Length : 1800 mm - Width : 850 mm - Height : 2000 mm Itsdpfx Aemn I Nxjf Ssr

Year of construction: 1985, condition: used, Sheet filter with square filter elements hanging vertically, arranged row. Hydraulic filter sheet press. Control of the hydraulics from the built-in electrical control panel. Additional title: Sterilisation filter Operating pressure: 8 bar Number of plates: 100 pcs Plate area: 1 m2 Length: 5,5 m Width: 1,5 m Height: 2,3 m Itjdpfxow Tmtie Af Sjr Operation / Control: Control cabinet with operating buttons Material: Stainless steel Base construction: Frame Features: Hydraulic press; control panel

Year of construction: 1989, condition: used, Additional title: Filtrox ZHF Filter capacity: 200 hl/h Volume: 16 hl Operating pressure: 6 bar Operating temperature: 100 °C Systemic volume: 1620 Liter Iedpfx Ajw Tmtcjf Sotr Width: 1,2 m Height: 2,85 m Weight: 2500 kg Operation / Control: Manual system, mainly with pneumatic valves, operation take splace on the control cabinet panel Material: stainless steel Features: Filter vessel with horizontal filter elements, stack dosing container with agitator, CIP system for regeneration, control cabinet with control panel, pumps, fittings and sensors

Year of construction: 1995, condition: used, This filter system may only be used to filter preclarified products that have normal filterable properties in their composition. Itsdpfovcqv Nsx Af Sor Max. filtration flow: 400 hl/h continuous Permissible operating pressure: 6 bar Permissible operating temperature: 105 °C Volume: 1456 l Current: 10 A Voltage: 220 V Water: cold water: min. 150 hl/h; hot water (max 65 °C): min. 150 hl/h Compressed air: prepared compressed air: 4 - 6 bar; control air: 5 - 8 bar Weight: 3450 kg Base construction: basic frame with control and measuring components and filter container; cleaning module Features: 98 filter cartridges, 3 piston diaphragm pumps (Dosage), centrifugal pump with frequency converter (WT circuit), various analog and digital sensors (flow, pressure, level, temperature, conductance), various valves, control cabinet

Year of construction: 1975, condition: used, Stationary sheet filter with quadratic filter elements in a row. Additional title: sterilisation filter Capacity: 140 hl/h Number of plates: 119 plates Length: 7500 mm Width: 1600 mm Height: 2000 mm Formats: Quadratic filter elements - 100 cm x 100 cm Layer patterns: Vertikale Reihenanordnung der Filterelemente Iedpfxjvcqzlo Af Sjtr

Condition: used, Length: 0,7 m Height: 1,3 m Weight: 200 kg Material: Stainless steel Position: Vertical Itsdpfx Ajvcq A Nof Ssr Base construction: 3 x feet Features: Level indicator (perspex pipe) side-mounted; control cabinet mounted on vessel; Agitator

Year of construction: 2001, condition: used, The Pall CFS system is designed as a single unit and can be installed directly in front of the filling line without the need for a buffer system. It is a completely independent process unit consisting of the following components: filter vessel Piping and connections Membrane cleaning system (CIP) integrity check Switchboard The hygienic design, the simple integrity test and the full automation ensure the microbiological safety of the system and usually allow the operation of the filling staff. Cluster filtering groups filter elements into clusters. Each cluster has its own outlet valve. During filtration, all clusters are open. Cleaning, sterilization and integrity testing are performed per cluster. Advantages of the CFS principle; Longer life Integrity testing on site Integrity diagnostics per cluster Special rinsing High specific flow rate Short flush times Constant flow in all candles Minimal water consumption Quick replacement of filter elements Controlled backwash Minimal beer loss High biological safety Constant availability With this filter system only preclarified products may be filtered, which have normally filterable properties in their composition. Max. filtration flow: 400 hl/h continuous Permissible operating pressure: 6 bar Permissible operating temperature: 105 °C Iedpfxjvcqx Ds Af Sjtr Volume: 1456 l Current: 10 A Voltage: 220 V Water: cold water: min. 150 hl/h; hot water (max 65 ° C): min. 150 hl/h Compressed air: prepared compressed air: 4 - 6 bar; control air: 5 - 8 bar Length: 1,40 m Width: 1,20 m Height: 1,85 m Weight: 3450 kg Base construction: basic frame with control and measuring components and filter container; cleaning module Features: 98 filter cartridges, 3 piston diaphragm pumps (Dosage), centrifugal pump with frequency converter (WT circuit), various analog and digital sensors (flow, pressure, level, temperature, conductance), various valves, control cabinet

Year of construction: 1979, condition: used, Combination Kieselguhr and Sheet filter. Stationary sheet filter with square filter elements in vertical row arrangement. Hydraulic filter layer compression. Control of hydraulics from built-in electrical panel. Additional title: Kieselguhr and sheet filters as a combination design; years of construction 1979 Itjdpfx Aevcqn Ssf Ssr Capacity approx.: 380 hl/h Combination filter - filtration area approx. 76 - 108m2 KG; 18m2 Sheet with beer filtration Operating pressure: 8 bar Power: 6 kW Voltage: 220/380 V Frequency: 50 Hz Length: 10100 mm Width: 1320 mm Height: 1750 mm Formats: Square filter elements Operation / Control: Built-in control panel Material: Stainless steel Position: Horizontal Base construction: Frame Features: Filter plates; Filter frames; collection tray with removal screw; hydraulik filter plate compression; hose pump Layer patterns: Vertical row arrangement

Year of construction: 1975, condition: used, Filter system constructed with horizontally stacked filter elements. Once filtration is completed the kieselguhr is expelled from the vessel by centrifugal force. Capacity: 140 hl/h Vessel volume: 26 hl Length: approx. 4000 mm Iodpfx Asvcqpcjf Sotr Width: approx. 2000 mm Height: approx. 3500 mm Material: Stainless steel1.4541 (vessel) Base construction: on feet Features: Kieselguhr dosing vessel with dosing pump; pumps; fittings, measurement technology
