Dresser

Weinig

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 1.490,14, saw blade diameter: 500 mm, cutting height (max.): 140 mm, cutting width (max.): 350 mm, power: 8 kW (10.88 HP), overall weight: 2,000 kg, TECHNICAL DETAILS Max. saw blade length: 6,100 mm Max. saw blade diameter: 500 mm Saw blade arbor diameter: 35 mm Max. cutting height: 140 mm Max. cutting width: 350 mm Infeed table length: 7,850 mm Outfeed table length: 2,400 mm MACHINE DETAILS Dkjdpfjy Nyd Iex Affjl Main motor power: 5.5 kW Total power: 8.0 kW Voltage: 400 V Fuse: 25 A Dimensions & Weight Dimensions (L x W x H): 11,250 x 800 x 1,600 mm Weight: 2,000 kg EQUIPMENT Automatic feed system

Condition: ready for operation (used), Year of construction: 2004, machine/vehicle number: 102848, functionality: fully functional, operating hours: 3,142 h, empty load weight: 5,000 kg, feed rate X-axis: 33 m/min, number of spindles: 7, TECHNICAL DETAILS Number of spindles: 7 Spindle 1 - Spindle type: Bottom - Motor power: 15 kW - Tooling: Yes Dodpey Nyb Hofx Affskl Spindle 2 - Spindle type: Right - Motor power: 11 kW - Tooling: Yes Spindle 3 - Spindle type: Left - Motor power: 11 kW - Tooling: Yes Spindle 4 - Spindle type: Top - Motor power: 22 kW - Tooling: Yes Spindle 5 - Spindle type: Bottom - Motor power: 15 kW - Tooling: Yes Spindle 6 - Spindle type: Top - Motor power: 30 kW - Tooling: Yes Spindle 7 - Spindle type: Bottom - Motor power: 15 kW Minimum planing width: 20 mm Maximum planing width: 300 mm Minimum planing height: 3 mm Maximum planing height: 160 mm Infeed table length: 1,000 mm Feed roller diameter: 140 mm Extraction nozzle diameter: 160 mm Feed speed: Manual Minimum feed speed: 5 m/min Maximum feed speed: 33 m/min Feed speed regulation: Infinitely variable MACHINE DETAILS Voltage: 400 V Current consumption: 278 A Circuit breaker: 400 A Power: 128 kW Dimensions & weight Dimensions (L x W x H): 5,500 x 2,400 x 2,100 mm Net weight: 5,000 kg Operating hours: 3,142 h EQUIPMENT Driven rollers in the table Powerlock Cutterhead drive: Cardan shaft drive Lubrication system: Automatic

Condition: used, Year of construction: 1997, Beam planer 260 x 160 mm, trailing chamfer unit on the upper spindle, air cushion table with two-axis control for left and upper spindle, factory-new control system (latest Weinig version) Max. working width: 260 mm Max. working height: 160 mm Number of spindles: 6 1st spindle: bottom, spindle diameter 40 mm, clamping length 270 mm, speed 6000 rpm, motor power 11.0 kW 2nd spindle: right, spindle diameter 40 mm, clamping length 170 mm, speed 6000 rpm, motor power 11.0 kW (shared motor with left spindle) 3rd spindle: left, spindle diameter 40 mm, clamping length 170 mm, speed 6000 rpm 4th spindle: top, spindle diameter 40 mm, clamping length 270 mm, speed 6000 rpm, motor power 11.0 kW 5th spindle: bottom, spindle diameter 40 mm, motor power 11.0 kW, speed 6000 rpm, clamping length 270 mm 6th spindle: top, chamfering unit Motor brakes: mechanical Height adjustment of upper spindle: electric Optionally with/without feed Feed brake system: Yes Feed speed infinitely variable up to: 3 – 23 m/min Feed roller pressure: pneumatic Feed power: 4.0 kW Feed drive: cardan Lubricant pump: manual Max. planing depth: 10 mm Jointing cutter on jointer: Yes Powered rollers in table: 1 Control type: PLC control Spindle position display: mechanical numerical display Infeed rollers before jointer: Yes Air cushion table: triple track Central lubrication point: Yes Description: short infeed table 1050 mm with internal lighting Location: Nattheim Dodpfx Aswwwkheffskl

Condition: excellent (used), Catalog number 7289 TECHNICAL DATA - Maximum workpiece width: 230 mm - Maximum workpiece height: 170 mm 6 spindles: 1) Bottom horizontal, 230 mm, 5.5 kW 2) Right vertical, 170 mm 3) Left vertical, 170 mm (spindles 2 and 3), 11 kW 4) Top horizontal, 230 mm, 11 kW 5) Top horizontal, 230 mm, 7.5 kW 6) Bottom horizontal, 230 mm, 11 kW - All spindles adjustable up/down, left/right - Spindles 4 and 5 electrically adjustable up/down - Spindle speed: 8,000 rpm - Spindle diameter: 40 mm - All spindles equipped with electric braking - 6 feed-in, driven, toothed upper rollers, including 1 double - Double exit, driven, rubber-coated upper roller - Double exit, driven, rubber-coated lower roller - Side pressure unit - Feed via Kardana shafts - Pneumatically tensioned rollers - Infinitely variable feed speed: 6–24 m/min - Feed motor: 4 kW - Electric planing thickness adjustment - Body lifting motor: 0.55 kW - Central table lubrication - Extraction nozzle diameter: 6 × 140 mm - Dimensions (L×W×H): 4,900 × 2,400 × 2,000 mm - Weight: approx. 4,000 kg FEATURES – German-made, WEINIG brand – With 6 heads – Not repainted – Used planer, very good condition Original pictures Net price: PLN 142,900 Net price: EUR 34,000 (based on an exchange rate of 4.2 EUR) Dkedpfx Afjy N Ahisfsl (Prices may vary with significant exchange rate fluctuations)

Condition: excellent (used), Tenoning and Slotting Machine WEINIG Type 51 Pivoting studio window device with digital angle display Rolling table with automatic feed rate of 6 m/min. Rolling table length approx. 2,100 mm Pneumatic workpiece clamping Automatic countershaft change Crosscut saw Pneumatically timed 4-station turret Dksdev Tb Hgjpfx Affsl Motor approx. 3 kW / 380/400 V / 50 Hz Saw blade diameter = 350 mm Saw blade speed 2,800 rpm Slotting spindle Diameter D = 50 mm Clamping length 320 mm Spindle motor approx. 11 kW / 380/400 V / 50 Hz Spindle speed 3,000 rpm Tool diameter max. 320 mm Length stop system Machine including operating tools Installation dimensions L x W approx. = 2700 x 2800 mm Weight approx. 2000 kg Note on used machines: • Errors in technical specifications and prior sale excepted. • Prices quoted are for pickup from the location - free shipping! • The machines have been cleaned and function-tested. • All machines are sold as seen without any warranty claims. The buyer is free to inspect the machines on site. • Special agreements are only possible in writing. (We will only respond to inquiries if you provide your address and telephone number!)

Condition: used, Year of construction: 2009, max. workpiece length 4500 mm profile spindle 1 Stück main drive 20 kW Control Siemens Weinig Conturex 2 C 114 ----- Working width: 40-260 mm Working height: 25-110 mm 2 x PowerGrip clamp tables, 2 x 2280 mm Dkodswunwyspfx Affol ----- Workpiece length 200 - 4,500 mm Workpieces over 2,700 mm in length are machined using a repositioning cycle. Main spindle 1: ----- Motor with brake 20 kW HSK 63F Electronically adjustable speed 2,000-18,000 rpm Maximum tool length from flat surface HSK 63 F: 290 mm With C-axis Tool magazine: ----- Number of pockets: 30 mm Pitch between pockets: 100 mm Permanently installed multi-spindle drilling head ----- For horizontal and vertical drilling and milling work without tool changes ----- Price ex-site Prices for disassembly and loading onto customer trucks Transport within Germany and abroad as well as reassembly Commissioning and, if required, new profiles are available upon request! Used tools included (drawings available upon request): ----- Wood: IV 68, 78, 88, opening inside and out, with hinged weatherboard Wood-aluminum: IV 68/68, 78/78, 87/68, 97/78 Lift-and-slide doors IV 68 and 78 Front doors IV 68 and 78 Pivot windows Corner connection: counter/dowel Technical specifications according to the manufacturer - no guarantee! Detailed technical description available upon request!

Condition: used, Year of construction: 2000, Colour: Grey Four-sided planer Weinig Profimat 26 S, 5head Year of construction 2000 min/max Working height 8/120 mm min/max Working width 20/230 mm Working speed 5/24 m/min Spindle speed 6000 rpm Spindle diameter 40mm engines1. Spindle - under 4 kW 2nd/3rd Spindle - left/right 11kW 4. Spindle - above 5.5kW 5. Spindle - under 4 kW Djdpfx Aewnh Eksffekl Feed motor 3kW Main fuse 63 amp. Dimensions 4500 x 1500 x 1700 mm (L x W x H), weight 2500 kg - Year: 2000 - Documentation available: No - CE certificate present: No - Serial number: 89525 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2006, total width: 3,580 mm, total height: 1,840 mm, Colour: Grey Dimensions (LxBxH): 180 x 358 x 184 cm Djdpfxjwnhpvo Affekl Price: On request - Year: 2006 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 106992 - Number of spindles [pcs.]: 4 - └ Spindle 1: - - Motor power [kW]: 5.5 - - Spindle diameter [mm]: 30 - - Max. planing block diameter [mm]: 130 - - Tool present: Yes - └ Spindle 2: - - Motor power [kW]: 7.5 - └ Spindle 3: - - Motor power [kW]: 7.5 - └ Spindle 4: - - Motor power [kW]: 7.5 - Feed table length [mm]: 1780 - Feed roller diameter [mm]: 130 - Feed motor [kW]: 3 - Conveyor drive: Cardan drive - Diameter extraction nozzle [mm]: 140 - Voltage [V]: 400 - Current consumption [A]: 88 - Fuse [A]: 100 - Power [kW]: 41.0 - Transport dimensions: 1800mm x 3580mm x 1840mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2001, total width: 5,440 mm, Colour: Grey Dimensions (LxW): 170 x 544 cm Price: On request - Year: 2001 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 92789 - Voltage [V]: 380 - Current consumption [A]: 85 - Fuse [A]: 100 - Power [kW]: 38.0 Dksdpewnizmefx Affol - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2002, total width: 7,660 mm, total height: 2,090 mm, Colour: Grey Dimensions (LxBxH): 160 x 766 x 209 cm Four-side moulder Weinig Profimat 26 S, 6head Dksdpjwng I Dsfx Affsl Year of construction 2002 Machine number 95514 min/max Working height 8/120 mm min/max Working width 20/230 mm Working speed 5/24 m/min Spindle speed 6000 rpm Spindle diameter 40mm Engines 1. Spindle - under ..kW 2nd/3rd Spindle - left/right .kW 4. Spindle - above 11kW 5. Spindle - above 11kW 5. Spindle - under ..kW Dimensions 3900 x 1800 x 1900 mm (L x W x H), weight 2500 kg - Year: 2002 - Documentation available: No - CE certificate present: No - Transport dimensions: 1600mm x 7668mm x 2090mm (l x w x h) Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels
