Moulder

WEINIG HYDROMAT 23

Condition: used, Year of construction: 1996, Hi Mateusz, Please list the machine described below for sale. Machine description: High-performance Weinig Hydromat 23 planer Weinig Hydromat 23 planer-moulder for four-sided planing and shaping of wood. Original machine specifications, technical modifications reserved. - Spindles: 8 Spindle arrangement: Ppodpfxozf Ur As Aczju 1. Bottom spindle // diameter min 125 mm max 160 mm // 7.5-18.5 kW 1. Right spindle // diameter min 125 mm max 160 mm // 5.5-15 kW 1. Left spindle // diameter min 125 mm max 160 mm // 5.5-15 kW 2. Right spindle // diameter min 125 mm max 160 mm // 5.5-15 kW 1. Top spindle // diameter min 125 mm max 160 mm // 7.5-37 kW 2. Bottom spindle // diameter min 125 mm max 160 mm // 7.5-37 kW 2. Top spindle // diameter min 125 mm max 160 mm // 7.5-37 kW 3. Bottom spindle // diameter min 125 mm max 160 mm // 7.5-37 kW

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: 102940, WEINIG HYDROMAT H23 ELECTRONIC FEED FREQUENCY CONTROLLED (8 – 100 M/MIN). Podezd Tavopfx Aczepu FEED MOTOR 22 KW 50MM SPINDLES WORKING WIDTH MAX. 230 MM WORKING HEIGHT MAX. 160 MM SHORT INFEED WITH 220MM TOP FEED ROLLERS BOTTOM 15KW 6,000 RPM, OUTBOARD BEARING, JOINTER READY RIGHT 11KW 6,000 RPM JOINTER READY LEFT 15KW 8,000 RPM JOINTER READY RIGHT 11KW 8,000 RPM JOINTER READY LEFT 15KW 8,000 RPM, JOINTER READY TOP 18.5KW 6,000 RPM OUTBOARD BEARING, JOINTER READY BOTTOM 11 KW 6,000 RPM OUTBOARD BEARING, JOINTER READY (STRAIGHT JOINTER) + OUTBOARD BEARING TOP 18.5KW 8,000 RPM OUTBOARD BEARING, JOINTER READY (STRAIGHT JOINTER) + OUTBOARD BEARING BOTTOM 22 KW 6,000 RPM OUTBOARD BEARING, JOINTER READY 12X TOP FEED ROLLERS (2X 220MM + 10X 140MM) 7X BOTTOM FEED ROLLERS POSSIBLE TO ADD ADDITIONAL STRAIGHT / PROFILE JOINTERS AS NEEDED AUTOMATIC LUBRICATION SYSTEM FULL DOCUMENTATION INCLUDED MACHINE LENGTH 5.2M

Condition: excellent (used), functionality: fully functional, Working width: 230 mm Working height: 160 mm Number of spindles: 5 Spindle configuration: 1. Bottom 15 kW Psdpex Hzv Tjfx Aczspu 2. Right 11 kW 3. Left 11 kW 4. Top 15 kW 5. Bottom 7.5 kW Spindle speed: 6000 rpm Spindle diameter: 50 mm 3 feed rollers in the work table Feed speed adjustable via inverter up to 60 m/min Feed driven by cardan shaft Pneumatic pressure rollers Technical documentation Machine dimensions: 300x180x170 cm (H) Weight: 3500 kg

Condition: excellent (used), Four-side planer Weinig Hydromat 23C Working width: 230 mm Working height: 160 mm Number of spindles: 7 Spindle arrangement: 1. Bottom 15 kW 2. Right 7.5 kW 3. Left 7.5 kW 4. Top 15 kW 5. Bottom 30 kW (multi-blade saw) 6. Bottom 7.5 kW (hydro support) 7. Top 7.5 kW (hydro support) Spindle speed: 6000 rpm Ppsdpfxexlcufs Aczou Spindle diameter: 50 mm 4 feed rollers in the worktable Feed speed adjustable via frequency inverter up to 36 m/min Feed drive powered by cardan shaft Pneumatic pressure elements Technical documentation

Condition: excellent (used), Year of construction: 1998, Four-side planer Weinig Hydromat 23, finger jointing machine 8 spindles, Working width: 230 mm, Working height: 160 mm, Spindle diameter: 50 mm, Feed: 7.5 kW / 6–36 m/min, Ppsdpfx Asy Uc T Aeczou Spindle arrangement: 1-Bottom (7.5 kW) 2-Right (7.5 kW) 3-Left (7.5 kW) with profile jointer 4-Right (7.5 kW) with profile jointer 5-Top (7.5 kW) with hydraulic clamping 6-Bottom (30 kW) with hydraulic clamping 7-Top (7.5 kW) with hydraulic clamping and straight jointer 8-Bottom (7.5 kW) with hydraulic clamping and straight jointer. Hard coating. Two powered rollers in the table.

Condition: excellent (used), Weinig Hydromat 23C with 6 Spindles. Max width 245mm Max Thickness 160mm Separate electrical panel. Separate remote control panel Automatic lubrication system for bedplates Full heavy duty sound enclosure. 15kW feed motor 100m/min No 1.  11kw - Bottom 6000rpm straight jointer prepared No 2. 11kw - Right 6000rpm straight and profile jointer prepared No 3. 15kw - Left 6000rpm straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 5 . 30kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 6 . 15kw - Bottom 6000rpm + Outboard bearing + straight and profile jointer prepared 50mm spindles Beam 0.55kW Full documentation included. Heavy duty sound enclosure. Possible to supply with hydro tooling if needed. Possible to supply with full mechanisation if needed. Ppjdpfx Aeyl Rmqsczou

Condition: excellent (used), WEINIG Hydromat H23 Line, S/N 87321, year 1999, Ref-No. 103437 WEINIG Cross Conveyor HighMech E-1, equipped with 6 flat chains approx. 2000 x 3500 mm Hydraulic WEINIG Accelerator Model 814 Short infeed table with heavy-duty 4-roller feed unit Planer/moulder with reinforced KASCHWIG three-sided soundproof enclosure • Max. working width: 230 mm • Max. working height: 160 mm • Electronic feed, frequency-controlled, 8–80 m/min • Feed motor 18.5 kW • 1st spindle bottom 11.0 kW • 2nd spindle right 11.0 kW • 3rd spindle left 11.0 kW • 4th spindle right 11.0 kW • 5th spindle left 11.0 kW • 6th spindle top 15.0 kW • 7th spindle bottom 11.0 kW • 8th spindle top 15.0 kW • 9th spindle bottom 15.0 kW • 10th universal spindle 11.0 kW (four-sided) • Spindle speed 6,000 rpm • Spindle diameter ø 50 mm • All spindle motors equipped with NEW motor start/stop brake units • Pneumatically supported top pressure rollers • Feed rollers D=140 mm • 6 driven rollers in the table • Spindles 1 + 6 + 7 + 8 + 9 with counter bearings • Spindles 8 + 9 with straight jointer • Spindles 8 + 9 with profile jointer • Spindles 6 + 8 with pneumatic pressure • Reduced spacing between feed rollers • Hard-chromed table plates • Hard-chromed fences • Pneumatically supported side pressure rollers • Automatic table lubrication • Centralized lubrication points • Free-standing control panel • Connected load approx. 145 kW / approx. 400 A Psdpfx Acswvqklozspu • Free-standing electrical cabinet • Operating instructions, spare parts list and wiring diagram included • Machine sold without cutterheads Machine dimensions approx.: • Length: 6,000 mm • Width: 2,250 mm • Height: 1,800 mm • Weight: approx. 8,500 kg Factory-new WEINIG components installed: NEW horizontal/vertical spindle NEW counter bearings All spindles with HL bearings All motors newly fitted NEW electronic motor soft start/brake devices NEW hard-chromed table plates NEW hard-chromed fences Many other new parts fitted in the machine Condition: see attached photos – technically in excellent condition Infeed mechanization unrefurbished – complete – fully functional Payment: Net cash before loading Delivery time: By arrangement Delivery: EXW Inspection: Anytime by appointment Errors and prior sale excepted.

Condition: used, Year of construction: 1996, Weinig Hydromat 23 Technical data Working width 30 - 230 mm Working height 19 - 200 mm Ppedpsqrt Ekjfx Aczou Spindle down, right, left, up, down u- re-li-o-u.o without infeed machine only Machine is dismantled, immediately available Transport can be organized
