Used Optimum Opti S350 G for sale (121)

Condition: used, Technical details: Bwsdpfxjv T Tcmo Aaqsh cutting diameter: 260 mm saw band length: 2925 mm saw band width: 0,9 mm cutting range 90 degrees: round: 270 mm cutting range 90 degrees: flat: 350x240 mm cutting speed: 35/72 m/min height over floor: 1,050 mm total power requirement: 1,9 kW machine weight approx.: 660 kg dimension machine xH: 1,2 x 0,75 x 1,05 m Bandsäge - Halbautomat schwere Industriebandsäge mit Rollenbahn Gehrungsschnitt möglich hydr. Werkstückklemmung i.D. *

Condition: excellent (used), Year of construction: 2003, cutting diameter 128 mm saw band length / mm table height / mm Bwsdpfxexbh Hfj Aaqjh

Condition: like new (used), Year of construction: 2024, As-new polishing machine OPTIMUM OPTIpolish GZ40P with variable-speed conversion featuring Siemens inverter and cyclone extraction system. For polishing wheels with a diameter of up to 350mm, maximum wheel width 35mm, wheel bore 20mm. Suitable for continuous and intensive industrial use. Heavy-duty industrial polishing machine; its high dead weight absorbs the already minimal vibrations. Maintenance-free, long-life induction motor with smooth operation, cast iron housing. Additionally equipped with: Variable speed drive using Siemens Sinamics V20 inverter. Circumferential speed adjustable from 34 m/s down to 6 m/s. Sturdy base with cyclone extraction integrated in the base, thus requiring minimal space. Sound-insulated. Bwodpfx Ajyglkyeaqsh The base must be filled with concrete by the customer. Automatic start/stop feature: When the external device is powered on or off, the extraction system automatically switches on or off with a 2-3 sec delay. There is no need to operate the extraction system separately. According to hazardous substance regulations, residual dust is extracted after the machine shuts down. The machine is located at 71334 Waiblingen-Beinstein and can, of course, be inspected by appointment. Please contact us for further information.

Condition: used, functionality: fully functional, Optimum Gear Drilling Machine B40 GSM MK4 Serial Number: 42194 with Coolant System Bwjdpfxsydc Hmo Aaqeh electrical quill feed thread cutting function integrated machine lamp 400 V 16 A power supply cable motor power: 1.5 kW, 400 V ~50 Hz coolant pump motor: 40 W max. drilling capacity in steel: Ø 35 mm max. thread cutting in steel: M 24 max. drilling capacity in cast iron: Ø 45 mm max. thread cutting in cast iron: M 30 quill stroke: 180 mm throat: 350 mm spindle taper: MK 4 automatic quill feed: 2 steps / 0.1 - 0.2 mm/rev spindle speed: 50 - 1450 rpm number of speeds: 18 steps work table area (L x W): 560 x 560 mm T-slot size: 18 mm max. distance spindle - table: 780 mm base area (L x W): 510 x 500 mm max. distance spindle - base: 1320 mm column diameter: 150 mm dimensions (L x W x H): 730 x 560 x 2220 mm net weight: approx. 580 kg

Year of construction: 2015, condition: used, max. dia. of grinding wheel 150 mm Bjdjwp S U Eepfx Aaqswh turning speeds 2850 U/min total power requirement 0,45 kW dimensions 465 x 316 x 302 mm weight 10,7 kg NEW PRICE: ~ 200.00 EURO Description - Double grinding machines from OPTIMUM - a quality product for trade and industry - Heavy-duty, durable industrial design with maintenance-free motor for continuous use - Extruded aluminum housing - Long service life and smooth running thanks to balanced rotor with high-quality ball bearings - Spark guard on each grinding wheel reduces flying sparks - Stable, adjustable workpiece support - Viewing windows made of shatterproof material - Vibration-damping rubber feet - Two universal corundum grinding wheels

Condition: as good as new (ex-display), Year of construction: 2024, High-quality spindle with precision tapered roller bearings Hardened and ground table guideways Turcite-B coated counter guides for high wear resistance and low friction Bwedpfx Aajw Eay Isqoh Integrated grinding wheel removal device Machine base made of sturdy, torsion-resistant cast iron for maximum rigidity and stability Backlash-free V-flat guide in the Z-axis and flat guides in the X- and Y-axis Trapezoidal threaded spindle in the Y-axis Manual central lubrication All flat guides are finely scraped, guaranteeing high precision of all manual movements LED lamp Safety electrics with 24 V DC voltage Sanding accuracy: 0.005 mm Grit 46 corundum grinding wheel for all common steels included as standard Two-channel safety electrics EMC filter class Significant energy savings thanks to IE3 motor Coolant system with external coolant tank Dimensions and weights Length approx. 1970 mm Width/depth approx. 1300 mm Height approx. 1700 mm Weight approx. 850 kg Electrical data Power drive motor 1.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 200 mm Clamping surface width 500 mm Grinding wheel(s) Outer diameter 200 mm Width 20 mm Bore 31.75 mm Peripheral speed 33 m/s Spindle Speed 2850 min¯¹ Concentricity 0.005 mm X-axis Feed speed Manual

Condition: as good as new (ex-display), Year of construction: 2025, GT 30 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Sanding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Dimensions and weights Length approx. 3200 mm Width/depth approx. 2200 mm Height approx. 2100 mm Weight approx. 3000 kg Electrical data Total connected load 6.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 300 mm Clamping surface width 600 mm Grinding wheel(s) Outer diameter 350 mm Width 40 mm Bore 127 mm Peripheral speed 27 m/s Spindle Speed 1450 min¯¹ Concentricity 0.005 mm X-axis Feed speed 5 - 25 m/min Scope of delivery Bwedpfsw Eazfox Aaqsh Unit of measure: piece Packaging unit: 1 Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Automatic demagnetizing device Parallel dressing device ✔ Coolant device 125 W Work light LED lamp Alignment feet ✔

Condition: as good as new (ex-display), Year of construction: 2025, GT 40 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways Bwjdpfxoxyhvko Aaqjh - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements B9errbkz8v - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Grinding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Dimensions and weights Length approx. 3600 mm Width/depth approx. 2400 mm Height approx. 1900 mm Weight approx. 3600 kg Electrical data Total connected load 7.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 400 mm Clamping surface width 800 mm Grinding wheel(s) Outer diameter 350 mm Width 40 mm Bore 127 mm Peripheral speed 27 m/s Spindle Speed 1450 min¯¹ Concentricity 0.005 mm X-axis Feed speed 5 - 25 m/min Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Demagnetizing device Parallel dressing device ✔ Coolant device 125 W Work light LED lamp Alignment feet ✔

Condition: as good as new (ex-display), Year of construction: 2025, GT25 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability Bedpfxow Eayhj Aaqswh - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Sanding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Technical data: Dimensions and weights Length approx. 2300 mm Width/depth approx. 1600 mm Height approx. 1675 mm Weight approx. 1700 kg Electrical data Total connected load 3 kW Supply voltage 400 V Phase(s) 3 Ph Oc8fv Current type AC Mains frequency 50 Hz Surface grinding table Length 254 mm width 508 mm Grinding wheel(s) Outer diameter 200 mm width 20 mm Bore 31.75 mm Peripheral speed 33 m/s Spindle Speed 2850 min¯¹ Concentricity 0.005 mm X-axis Feed speed 5 - 25 m/min PU 1 Scope of delivery Unit of measure: piece Packaging unit: 1 Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Automatic demagnetizing device Parallel dressing device Coolant device 40 W Work light LED lamp Alignment feet

Condition: new, diameter of brush Ø 250 mm Bodpjxaamnsfx Aaqowh width of brush 40.0 mm turning speed range 2850 U/min voltage 400 Volt total power requirement 1.3 / 1.8 kW weight of the machine ca. 36.0 kg dimensions of the machine ca. 415 x 467 x 356 mm Equipment: - Deburring of individual pieces and small series - Deburring of stretched round, rectangular and square tubes + flat material - Heavy, durable industrial design - with maintenance-free motor - long service life and very smooth running thanks to balanced rotor - with quality ball bearings - storage area for safety glasses - incl. 1x multi-purpose wire brush, wire thickness 0.35 mm - operating instructions

Year of construction: 2016, condition: ready for operation (used), A barely used surface grinding machine Optimum is available. Grinding width: 220mm, grinding length: 470mm, grinding height: 350mm, table dimensions X/Y: 210mm/450mm, max. table spindle center distance: 450mm, grinding wheel dimensions X/Y/Z: 200mm/13mm/31.75mm. Machine dimensions X/Y/Z: approx. 1200mm/1450mm/2000mm, weight: approx. 800kg. Dokumentation vorhanden. An on-site inspection is possible. Bodpfjxx Udlsx Aaqewh

Condition: new, Optimum OPTIdrill DH 40G Universal column gear drilling machine 3034356 TECHNICAL DATA Dimensions and weights Length (product) approx. 590mm Width/depth (product) approx. 700mm Height (product) approx. 2050mm Weight (net) approx. 320kg Drilling capacity Drilling capacity steel (S235JR) 32mm Continuous drilling capacity steel (S235JR) 25mm Tapping capacity steel (S235JR) M 16 Drilling table Drilling table work surface length 500mm Drilling table work surface width 460mm Drilling table T-slot size 14mm Load capacity drilling table 50kg Speed range Speed range 95 - 3200min¯¹ Number of speed ranges 2 x 6 steps Electrical data Drive motor power 1.1 / 1.5kW Supply voltage 400V Mains frequency 50Hz Spindle Quill stroke 120mm Spindle holder MK 4 throat 280mm Drill head rotation 45° Drill head inclination 360 Bwjdpfx Ajt N Ri Eoaqeh Manual quill feed Drill head height adjustment 265mm SCOPE OF DELIVERY Gear rim drill chuck 1-13 mm/B16 Tapered arbor for drill chuck MK4/B16 Tightening rod M 16 Adapter MK4-MK3 Operating tool

Condition: new, Optimum OPTIsaw SD 351 AV Semi-automatic double miter metal band saw With Siemens inverter drive. Professional and robust saw with a cutting capacity of up to 350 mm Description: Heavy industrial design Quiet running Manual or semi-automatic operation Infinitely adjustable saw band speed from 0-80 m/min. High cutting accuracy thanks to vibration-free operation Miter adjustment up to 60° by swiveling the entire saw frame With high-quality bi-metal saw blade as standard End stops adjustable to the degree chip brush Micro switch for automatic limit switch Roller support adjustable for long and heavy workpieces coolant pump Ball-bearing saw band guide with hard metal plates for optimal cutting results Easy adjustment of the lowering speed using the feed control valve on the control panel Generously dimensioned, hydraulic quick-release vice, self-closing, adjustable for large cross-sections Fully equipped machine; The user can work productively immediately after commissioning EMC class C2 2-channel safety chain with emergency stop Converter Siemens Sinamics G110M Functionality semi-automatic operation Closing the vise and activating the motor Lowering the saw frame for cutting The motor stops and the saw arm returns to the starting position Technical specifications: Dimensions and weights: Length (product) approx.: 1935mm Width/depth (product) approx.: 1425mm Height (product) approx.: 1626mm Weight (net) approx.: 600kg Electrical data: Power drive motor: 2.2kW Connection voltage: 400V Mains frequency: 50Hz Engine power hydraulic pump: 1.4kW Engine power coolant pump: 50W Total connection value: 3.8kW Machine data: Saw band speed(s): 15 - 100m/min Speed levels: continuously adjustable Saw band length: 2925mm Saw band width: 27mm Saw band thickness: 0.9mm Cutting angle: -45 – +60° Manual operation: hydraulically via push button Semi-automatic operation: automatic Cutting areas: Cutting range 0° round (solid material): 270mm Cutting range 0° square (full material): 230mm Cutting range 0° standing rectangular (solid material): 230 x 350mm Cutting range -45° round (solid material): 230mm Cutting range -45° square (full material): 170mm Cutting range -45° standing (solid material): 140 x 200mm Cutting range +45° round (solid material): 230mm Cutting range +45° square (full material): 200mm Cutting range +45° standing rectangular (solid material): 210 x 220mm Cutting range +60° round (solid material): 140mm Bedjdc H Ukspfx Aaqjwh Cutting range +60° square (full material):140mm Cutting range +60° standing (solid material): 140 x 220mm

Condition: new, Stylus grinding machine Make: OPTigrind Model: GH 20 T Art.Nr.: 3100125 Condition: new machine Speed: 5.000 rpm Clamping range: 1-12 mm equipped as standard with: -Collets 385E, size 4 / 6 / 8 / 10 / 12 mm -Corundum pot wheel Bjdpfsc I Tzvox Aaqewh -Diamond Cup wheel -Device for the Regrinding of chisel -Device for the sharpening of cutters -Apparatus for the grinding of twist drills -Manual

Year of construction: 2022, condition: new, Motor power: 1,1kW / 230V Cutting area: 100mm x 145mm feed: stepless Bwodpfx Aegulr Asaqsh saw band speed: 22 / 31 / 55 m/min Saw band dimension: 1638 x 13 x 0.65 mm Cutting angle: -45° to 60 Dimension: 1085mm x 498mm x 978mm Weight: 78kg

Condition: excellent (used), Year of construction: 2013, Band saw, Semi-automatic saw, Metal saw, Metal band saw, Frame metal saw Toptech / Optimum GB 4240, Used machine Manufacturer: Toptech / Optimum Type: GB 4240 Year/month of manufacture: 2013/06 Inclusion dimensions: 2200 x 1100 x 2000 mm Electrical data: 400 V / 50 Hz / 4 kW Tape size: 34 x 11 x 4320 mm Belt speed: 19-86 m/min - Hydraulic vise - Adjustable feed Bwjdpfx Aaem Akwzoqeh Material size: 400 x 400 mm

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 460 mm turning diameter over support: 388 mm turning length: 1016 mm centre distance: 1016 mm center height measured in bed: 230 mm Bedeu Ixzbopfx Aaqjwh turning dia. in gap: 640 mm spindle bore of work spindle: 52 mm range of revolution per miute: 30 - 2000 / 12 step U/min feeds:: längs: 0,032 - 0,898 mm/U feeds:: plan: 0,016 - 0,449 mm/U tailstock quill taper MT: 4 tailstock quill adjustment:: 120 mm total power requirement: 3,75 kW weight of the machine ca.: 1,6 t dimension machine xH: 2,1 x 1,1 x 1,5 m Switchable gearbox Quantum 3-way length measuring system Top slide adjustment +/-90° Multifix quick-change steel holder 3-jaw chuck Ø 200mm rotating center in tailstock Threads: Inch thread; Metric thread; Trapezoidal thread; Module thread Accessories: Change gears, machine feet, 1x fixed quill tip *

Condition: ready for operation (used), A small column drilling machine Optimum is available. Drilling capacity steel/cast iron: 30mm/35mm, spindle mount: MK4, speed: 2000rpm, quill stroke: 120mm, quill diameter: 75mm, column diameter: 115mm, table dimensions X/Y: 500mm/420mm. Machine dimensions X/Y/Z: approx. 500mm/500mm/1950mm, weight: approx. 220kg. An on site inspection is possible. Bwsdpsxxbaajfx Aaqjh

Condition: used, bore capacity in steel (diameter) 28 mm throat 200 mm bore stroke 105 mm spindle taper MK 3 number of spindle speeds 12 spindle speed: 35 - 5600 Upm column diameter 92 mm table-size 340 x 360 mm table rotating 360 ° total power requirement 1,5 kW Bwjdpfofbh Akex Aaqsh weight of the machine ca. ca. 170 kg dimensions of the machine ca. ca. 750 x 500 x 1800 mm

Condition: used, Drilling / Milling machine OPTIMUM type OPTI F 40 E Travel X: 500 mm Travel Y: 200 mm Spindle: Ø 80 mm Cone CM3 Spindle exit: 120 mm Spindle speed: from 95 to 3200 RPM Table size: Length 730 mm x Width 210 mm 2 speeds motor Bsdpfx Aoxugnuoaqswh Motor power: 1,5 Kw Straight head Cross table Manual Descent Equipped with: 1 rotary vice Voltage: 380 V Dimensions (L x W x H): 1200 x 900 x 1400 mm Weight: approx 350 KG

Condition: used, Year of construction: 2007, functionality: fully functional, We are offering this used CNC milling machine OPTIMUM F100, year of manufacture 2007, currently located in Spain. Immediately available. Control: CNC SIEMENS Sinumeric 802S Milling Table: 920 x 280 mm T-slots: 16 / 3 / 65 mm Maximum load: 300 kg Travel distances (X, Y, Z): 450, 300, 400 mm Distance spindle center - column: 410 mm Air consumption: 0.1 - 0.15 m³/h at 0.6 MPa Spindle taper: SK 40 Tool holder: see image 2-54.jpg Drawbar M16 for pneumatic tool clamping: see image 2-54.jpg Speed range: 100 - 8000 rpm Spindle motor power: 4 kW Feed axes (stepper motors): Max. feed rate X: 3000 mm/min Max. torque X: 9 Nm Max. feed rate Y: 3000 mm/min Torque Y: 9 Nm Bedsygwudepfx Aaqjwh Max. feed rate Z: 3000 mm/min Max. torque Z: 9 Nm Operating voltage: 3 x 400 V, 50 Hz Rated current: 25 A Total connected load: 5.8 kW Dimensions: 1770 x 1450 x 2150 mm Total weight: 1100 kg

Condition: used, Year of construction: 2002, Drilling capacity: 25 mm, spindle mount: MK 3 Bwjdpfx Aovvi Auoaqsh Storage location: Nattheim

Condition: as good as new (ex-display), Year of construction: 2021, Machine is on display. Optimill F 310 HSC Premium CNC milling machine, directly from the manufacturer. F 310 HSC – The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control stands out for its performance, speed, precision, and long service life. • Heavy-duty design • High productivity • High reliability • Strongly ribbed, torsion-resistant machine base • Profile guideway with roller circulation in all axes for high load capacity • High-torque servo drives, directly mounted to ball screws on all three axes • Precision-ground, preloaded high-performance ball screws for high rapid traverse speeds on all axes • Telescopic guideway covers on all three axes • Main spindle SK40 with spindle speed up to 12,000 rpm with inline spindle • Massive, precision-ground milling table with five T-slots, large dimensions • Portable electronic hand wheel with enabling button and emergency stop switch, significantly simplifies program setup • Tool changer arm gripper with 30 tool positions • Coolant unit with chip flushing system and cleaning pistol • Through-spindle coolant with 20 bar pressure • Belt-type chip conveyor ensures efficient chip removal • Chip trolley • Oil separator • Machine light in the work area • Additional SIEMENS package: material defect warranty and free online/on-site service OSS Plus • 1-year maintenance contract Basic included for DE/AT/CH Control • 15.6" color display • 16:9 format Total package • Safety Integrated • Raw material recognition and processing • ShopMill step programming • Network drive management • 3D simulation • Drawing function Equipment details • Inline spindle • Taper SK 40 / DIN 69871 • Spindle speed 12,000 rpm Dimensions and weights • Length approx. 4319 mm • Width/depth approx. 2300 mm • Height approx. 3000 mm • Weight approx. 7000 kg Rapid traverse speed • X-axis 30 m/min • Y-axis 30 m/min • Z-axis 30 m/min Electrical data • Supply voltage 400 V • Mains frequency 50 Hz • Total connected load 56 kVA Horizontal milling table • Length 1200 mm • Width 600 mm • T-slot size 16 mm Bsdpfx Asycqf Usaqewh • Number of T-slots 5 • T-slot spacing 100 mm • Max. load capacity 800 kg Accuracy • Repeatability ± 0.005 mm • Positioning accuracy ± 0.005 mm Travel • X-axis automated 1050 mm • Y-axis automated 600 mm • Z-axis automated 600 mm Vertical spindle • Spindle taper SK 40 DIN 69871 • Speed range 12,000 rpm • Drive motor output continuous S1 20 kW • Drive motor output S6-30% operation 50.3 kW • Drive motor torque continuous S1 96 Nm • Drive motor torque 30% operation S6 240 Nm Feed force • Feed force X-axis 6.68 kN • Feed force Y-axis 6.68 kN • Feed force Z-axis 10 kN Feed motor torque • X-axis continuous S1 18 Nm • Y-axis continuous S1 18 Nm • Z-axis continuous S1 27 Nm Tool changer • Double arm gripper • Number of tool positions 30 • Maximum tool length 300 mm • Maximum tool weight 8 kg • Tool-to-tool change time 2.5 s

Condition: new, turning diameter 360 mm turning length 1000 mm Bwedpew U U Tmsfx Aaqjh swing diameter over bed slide 360 mm centre height 180 mm turning speeds 70-2400 U/min total power requirement 2,2 kW weight of the machine ca. 680 kg dimensions of the machine ca. 2000x1500x900 mm

Condition: new, turning diameter 420 mm turning length 1500 mm swing diameter over bed slide 250 mm Swingdiameter in the bed bridge 590 mm centre height 210 mm Turning length in the bed bridge 260 mm reus 16 (45-1800) U/min tail stock MK 4 quill stroke 120 mm diameter of quill 50 mm spindle taper DIN ISO 702-2 Nr. 6 spindle bore 52 mm spindle cone MK 6 feed längs 17 / 0,05 - 1,7 m/min feed plan 17 / 0,025 - 0,85 m/min total power requirement 4,6 kW weight of the machine ca. 1340 kg dimensions of the machine ca. 2440 x 915 x 1375 mm Fully equipped master and feed spindle lathes. TH 4215 with digital position indicator DPA 21 / 3462070 - Hardened and ground Z-axis guideway - Spindle mount Camlock DIN ISO 702-2 No. 6 - Precisely crafted slide - Hand wheels with adjustable fine scaling 0.04 / 0.02 mm - Quadruple steel holder - All guides can be adjusted using V-ledges - Adjustment range top slide ± 90° - Guaranteed concentricity of the spindle nose better than 0.015 mm - Main spindle running in oil bath - Smooth-running gear wheels, hardened and ground with 2 adjustable Precision tapered roller bearings - Hand wheels decoupled and tested according to EN 23125 - Two-channel right-left switch tested according to EN 23125 - Switch with life cycle calculation, tested according to EN ISO 13849 - All metric pitches in the range 0.2 to 14mm/rev and all Inch threads in the range of 72 - 2 threads per inch without changing the Change gears adjustable by shift lever in the control panel - Clockwise/counterclockwise rotation can be switched on the bed slide via the switching spindle - Central lubrication in bed slide - Meehanite cast base and machine bed in one piece - Lead screw cover - Emergency stop device with foot control - Safety handwheels with snap-out function in the X and Z axes - Tailstock for taper turning adjustable ± 10 mm - Tailstock quill and hand wheel with adjustable fine scaling 0.025 mm - Quick, easy and tool-free adjustment using a clamping lever - Heavily ribbed prism bed, induction hardened and precision ground cast iron - Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning according to DIN - LED machine lamp in the chip guard Models TH 4210D and TH 4215D with digital readout DPA21 - User-friendly membrane keyboard, splash-proof, closed andglare-free - Glass scales scope of delivery - Fixed bezel passage Ø 15 - 145 mm - Revolving bezel passage Ø 10 - 75 mm - LED machine light - Reducing sleeve MT 6 / MT 4 - Fixed center MK 4 - Change gear set - Position stop with fine adjustment - Initial filling of the machine with quality oil Bsdpek Egrpjfx Aaqowh - Operating tool Incl. special accessory OPTIMUM three-jaw lathe chuck centrically clamping Ø 250 mm Quick change holder SWH5-B set
