Used Cazeneuve Hb 575X1000 for sale (24)

Condition: excellent (used), Distance between points 1000mm Machinable Diameter on Baseplate 575 mm Diameter Machinable on Trolley 300 mm Longitudinal Bed Width 410 mm Machine Speed Range 20- 1600 rpm No. of speeds 16 speeds Head Pitch Ø 52 mm Bws Ia S Sovi Rviohzol Tailstock shank Ø 70 mm Tailstock Stroke 220 mm Main engine power 12 H.P. Machine weight 2200kg Machine dimensions 3300 x 1300 x 1500 mm Machine rebuilt and painted in RAL 7031 color. Main motor winding 380-660V Second hand 315mm chuck Suitable to R.D. 1215/97 with national safety protections of tempered glass. Equipment certified by OCA Authorized Control Body. Instruction book

Condition: used, total height: 1,800 mm, total length: 3,700 mm, total width: 1,400 mm, Empty weight: 3.500 kg Price: On request Lathe, Metal turning machine Model: Conventional Manufacturer: Cazeneuve Type: HB725 Bws Ijvq U H Uja S Shzol Turning diameter: 725mm Turning diameter in gapbed: 900mm Spindle-hole: 80mm Center-distance: 2000mm Spindle speed: 16-1250 rpm Motor-power: 15kW Incl. Digital-Readout Incl. Lunette Incl. Multifix Incl. Three-jaw chuck Machine-weight: 3500kg Machine-dimensions: 3700x1400x1800mm - Documentation available: No - Motor power: 15.0kW - Turning diameter: 725mm - Min. spindle speed: 16rpm - Center distance: 2000mm - Max. spindle speed: 1250rpm - Bore diameter: 80mm - Transport dimensions: 3700mm x 1400mm x 1800mm (l x w x h) - Transport weight [kg]: 3500kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: used, Parallel Lathe CAZENEUVE HB 575 x EP 1500 mm Between points: 1500 mm Maxi Ø on bench: 575 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 51 mm Spindle speed: from 25 to 2000 RPM Turret Multifix 3-jaws chuck Ø 250 mm Threadings: Metric + Whitworth SteadiesFixed + followed TailstockCM5 Scale 2 axes ACU-RITE (Axe X defective) Lubricant pump Voltage: 380 V Length: 300 mm Bwe Ia S Sowgci Ijhzjl Width with tank: 1500 mm Height: 1700 mm Weight: approx 2,5 T

Condition: used, total height: 1,700 mm, total length: 2,900 mm, total width: 1,000 mm, Empty weight: 2.000 kg Lathe, Metal turning machine Model: Conventional Manufacturer: Cazeneuve Type: HB575 Turning-diameter: 575mm Centerdistance: 1500mm Spindle-hole: 51mm Spindle-speed: 20-1600 rpm Machine-dimensions: 2900x1000x1700mm Machine-weight: 2000kg - Documentation available: No - Turning diameter: 575mm - Min. spindle speed: 20rpm - Center distance: 1500mm - Max. spindle speed: 1600rpm - Bore diameter: 51mm - Transport dimensions: 2900mm x 1000mm x 1700mm (l x w x h) - Transport weight [kg]: 2000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Be Iov Umi Aea S Shzjwl Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: ready for operation (used), CAZENEUVE HB 500 LATHE Machine equipped with: 1 fixed bezel + 1 tracing bezel Bwe Iowazrhja S Shzol

Condition: used, Functionality: fully functional, spindle bore: 41 mm, turning length: 1,000 mm, Amutio Cazeneuve Lathe Model HB 500, 1000mm e.p. Max diameter on bed 500 mm, max diameter on cross slide 300 mm, shank hole 41 mm, 18 speeds from 25 rpm to 2000 rpm. With Fagor dimension display, with fixed and mobile rests, with protections, connected to 220 V Bo Isv Rnfqsa S Shzswl

Condition: excellent (used), Distance between points 3000mm Machinable Diameter on Baseplate 575 mm Diameter Machinable on Trolley 300 mm Longitudinal Bed Width 410 mm Machine Speed Range 20- 1600 rpm No. of speeds 16 speeds Head Pitch Ø 52 mm Tailstock shank Ø 70 mm Tailstock Stroke 220 mm Main engine power 12 H.P. Machine weight 2900kg Machine dimensions 4405x 1175 x 1175 x 1345 mm Machine rebuilt and painted in RAL 7031 color. Main motor winding 380-660V Semi-new 315mm chuck (3 jaws) Fixed steady rest and follower steady rest Quick-change turret (6 port) FAGOR 3-axis display Complies with R.D. 1215/97 with national safety guards made of tempered glass. tempered glass Equipment certified by OCA Authorized Control Body. Instruction book Be Ia S Shsvi Rv Nozswl

Condition: repair required (used), turning diameter over bed 400 mm turning diameter over slide rest - mm turning length 1000 mm total power requirement 9 kW weight of the machine ca. 2 t dimensions of the machine ca. 2,5*1,2*1,6 m Machine has been partially overhauled Among other things engine renewed ( 8.000 EUR ) The repair was not completed due to plant closure Be Ia S Shju Tkqijzewl

Condition: used, Parallel Lathe CAZENEUVE HB 725 Between points: 1500 mm Maxi Ø on bench: 725 mm Maxi Ø over saddle: 400 mm Spindle diameter: Ø 80 mm Rotation: from 16 to 1250 RPM Square turret 4-jaws chuck Ø 450 mm Spindle motor power: 13,2 kW Threadings: Metric + Whitworth Tailstock: CM6 Bo Iasv Syqbj S Shzowl Rapid advances Supplied with some sets of hard and soft jaws + one 3 points steady max Ø 250 mm Lubricant tank Lubricant pump Voltage: 220 V Tri Length: 3200 mm Depth with tank: 1600 mm Height: 1800 mm Weight: approx 4,5 T

Condition: used, total height: 1,700 mm, total length: 4,400 mm, total width: 1,000 mm, Empty weight: 3.500 kg Price: On request Lathe, Metal turning machine Model: Conventional Manufacturer: Cazeneuve Type: HB575. Turning-diameter: 575mm Centerdistance: 3000mm Spindle-hole: 51mm Spindle-speed: 12-1000 rpm Incl. chipcontainers (2x) Incl. Lunette Bwe Iev Umhxsa S Shzel Incl. Four-jaw chuck 500mm Incl. Three-jaw chuck 300mm Machine-dimensions: 4400x1000x1700mm Machine-weight: 3500kg - Documentation available: No - Turning diameter: 575mm - Min. spindle speed: 12rpm - Center distance: 3000mm - Max. spindle speed: 1000rpm - Bore diameter: 51mm - Transport dimensions: 4400mm x 1000mm x 1700mm (l x w x h) - Transport weight [kg]: 3500kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: excellent (used), Year of construction: 1990, Cazeneuve lathe model HB 725 of 1000mm between points, turning over bed 725mm, turning over carriage 500mm, turning over neck 900mm, neck length 310mm, speeds from 16 -1250 rpm, diameter of the spindle bore 81mm, has a fixed steady rest, has a plate mounted 3 jaws, 315mm diameter, accessories: it has another 400mm universal chuck with 3 jaws, with a height display, in good condition. Bj Iaoiqyv Ds S Shzewl

Condition: excellent (used), Distance between points 2.000 mm Machinable diameter on bed 725 mm. Diameter machinable on slide 400 mm. Longitudinal bed width 510 mm Machine Speed Range 20- 1.000 rpm. No. of Speeds 18 Speeds Head Pitch Ø 95 mm. Tailstock shank Ø 95 mm. Tailstock stroke 265 mm. Main motor power 15 H.P. Machine weight 3.200 Kg Dimensions 3.300×1.300×1.600 mm UIDO chuck Bwe Ia Sovi Ru Sj Shzol Tools and Accessories INCLUDED Machine rebuilt and painted in RAL 7031 color Motor-variator of the headstock Motor winding at 380-660V Semi-new 315 mm chuck (3 jaws) Semi-new 500 mm chuck (4 jaws) Complies with R.D. 1215/97 with national tempered glass safety guards. Certificate of the equipment by OCA Authorized Control Body. Instruction book

Condition: used, Year of construction: 1989, turning diameter over bed 400 mm turning diameter over slide rest - mm turning length 1000 mm total power requirement 9 kW weight of the machine ca. 2 t Bs Iaou Nmzle S Shzjwl dimensions of the machine ca. 2,5*1*1,6 m

Condition: used, Parallel Lathe CAZENEUVE type HB 575 Between points: 2000 mm Maxi Ø on bench: 575 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 51 mm Rotation: from 20 to 1600 RPM Turret TRIPAN 411 3-jaws chuck Ø 200 mm Bwe Ia Ssv Tv A Nj Shzsl Spindle motor: 15 CV ThreadingsMetric + Whitworth Tailstock CM5 Lubricant tank Lubricant pump Supplied with 3 TRIPAN tool holders Voltage: 380 V Length: 3500 mm Width with tank: 1500 mm Total height: 1400 mm Weight: approx 3 T

Condition: used, total height: 1,700 mm, total length: 2,400 mm, total width: 1,500 mm, Empty weight: 1.000 kg - Documentation available: No - Turning diameter: 575mm - Min. spindle speed: 32rpm - Center height: 255mm - Center distance: 1000mm - Max. spindle speed: 2500rpm - Bore diameter: 42mm - Transport dimensions: 2400mm x 1500mm x 1700mm (l x w x h) - Transport weight [kg]: 1000kg Bo Ia Sev Stmce Shzjwl Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: ready for operation (used), Year of construction: 1987, spindle bore: 81 mm, turning diameter: 725 mm, center width: 3,000 mm, overall weight: 3,000 kg, Heidenhain outdoor electrical cabinet display capacity 3000x725mm Bwj Ia S Shewbrcmjzol glass

Condition: good (used), HBX 360 Distance between centers (mm) 750 Center height (mm) 180 Diameter admitted above the bed (mm) 360 Diameter admitted above the transverse slide (mm) 180 Spindle bore (mm) 37 Maximum stroke of the transverse slide (mm) 180 Width of the transverse slide (mm) 160 Sleeve stroke (mm) 150 Diameter of the tailstock sleeve (mm) 46 Bed width (mm) 335 Small carriage stroke (mm) 110 Bws Ia Sjvlwzde Shzsl Small carriage width (mm) 110 Turret type quick change Spindle taper type Morse taper of the tailstock MT5 Spindle speed (rpm) 50 to 3000 Spindle variator yes (hydraulic) Spindle motor power (Kw) 4.5 Transverse working feed range (m/min) 0.0125 to 5.6 Longitudinal rapid feed range (m/min) 56 to 112 Threading Yes

Condition: ready for operation (used), Year of construction: 1998, spindle bore: 52 mm, center width: 1,500 mm, capacity 1500X575MM spindle bore 52MM external electrical cabinet bezel Bwo Ia Sevl H Ruo Shzol multifix turret several multifix tool holders

Condition: ready for operation (used), Year of construction: 1989, spindle bore: 37 mm, turning diameter: 360 mm, turning length: 750 mm, spindle speed (max.): 3,000 rpm, 2-axis view spindle speed variator max 3000 rpm capacity 750X360MM bore 37MM Bwj Ia S Sjvm Aiiehzjl multifix turret multifix tool holder set weight 1500KGS

Condition: like new (used), Year of construction: 2005, Cazeneuve CNC Lathe Model OPTIMAX 360 Year 2005 Turning length 610 mm Turning diameter 360 mm Bed diameter 360 mm Slide diameter 200 mm Center distance 610 mm X axis 180 mm Z axis 610 mm Spindle nose MT 6 Spindle bore 54 mm Number of turrets - 1 Number of tools - 8 VDI 20 turret Selection of turning tools 16 x 16 mm Boring bar diameter 25 mm Rotation speed 4200 rpm Spindle motor capacity 7.5 kW Bws Ia S Showb Uk Hezjl Dimensions: 1950 x 1320 x 1640 mm Weight 2100 kg

Year of construction: 2013, Condition: good (used), Swing over bed 380 mm Distance between centers 700 mm Spindle speeds -2500 rpm Bwo Iohp Razja S Shzjl Control: SIEMENS Optica Misc. accessories MARCELS MASCHINEN CH

Condition: not inspected (used), Year of construction: 2001, turning length: 4,000 mm, turning diameter: 725 mm, num PLS3 capacity 4000X725MM Bwo Iasvxtt Ae S Shzjl spindle bore 81MM bezel 3-jaw chucks

Condition: excellent (used), Year of construction: 2005, Turning length 610 mm Turning Ø 360 mm Ø on bed 360 mm Ø on carriage 200 mm Distance between centres 610 mm X axis 180 mm Z axis 610 mm Spindle nose CM 6 Spindle bore 54 mm Number of turrets -1 Number of tools - 8 Turret VDI 20 Turning tool selection 16 x 16 mm Boring bar Ø 25 mm Speed 4200 rpm Spindle motor capacity 7.5 kw Bj Iaovc E Rns S Shzowl Dimensions: 1950 x 1320 x 1640 mm Weight 2100 kg

Year of construction: 2000, Condition: excellent (used), Maschinen-Details Lagernummer 1105-03634 Maschinenart Drehmaschine - zyklengesteuert Fabrikat CAZENEUVE Typ OPTICA 360 Baujahr 2000 Steuerungsart CNC Steuerung CNC NUM Lagerort FRANKREICH HAGUENAU Ursprungsland Frankreich Lieferzeit sofort Frachtbasis AB LAGER Technische Details Drehdurchmesser 380 mm Drehlänge 750 mm Steuerung CNC NUM Drehdurchmesser über dem Planschlitten 200 mm Drehdurchmesser über Querführung 280 mm Hauptantriebsmotor 11 kW Spindeldrehzahlen 2 - 3000 U/min Spindeldurchlass 54 mm Futterdurchmesser 160 mm Reitstockkonus MK 4 Gesamtleistungsbedarf 14 kW Be Ijh D H T Uoa S Shzowl Maschinengewicht ca. 2 t Zusatzinformationen TAECH IN CNC MACHINE CAZENEUVE OPTICA 360 FROM 2000 3 BACKEN FUTTER REITSTOCK
