Used Trumpf for sale (408)

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2006, operating hours: 24,314 h, machine/vehicle number: A0230A1231, laser power: 6,000 W, sheet thickness (max.): 25 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 100 mm, No reserve price – guaranteed sale to the highest bidder! Bidding obligates the buyer to collect the machine by 30.04.2026! Due to increased selling pressure, the auction period has been shortened and the reserve price reduced! TECHNICAL DETAILS Travel range X-axis: 3,000 mm Travel range Y-axis: 1,500 mm Travel range Z-axis: 100 mm Laser power: 6,000 W Laser unit: CO2 laser TLF 5000, high-frequency excited Max. workpiece weight: 900 kg Positioning speed (X/Y): 200 m/min Positioning speed simultaneous (X+Y): 300 m/min Max. sheet thickness steel: 25 mm Max. sheet thickness stainless steel: 25 mm Sheet thickness aluminum: 15 mm MACHINE DETAILS Power-on hours: 55,176 h Cutting hours: 24,314 h Control model: Siemens Sinumerik 840D Control features: - Open PC-based control system - Online support - Diagnostic functions - Maintenance logbook - Technology data - Remote maintenance Safety equipment: - Multi-beam light barriers and guard enclosure - Fully enclosed beam path with nitrogen ventilation - Monitoring system - Multi-chamber extraction and compact dust collector Paint finish: white RAL 9002 / gentian blue RAL 5010 Drives: Gantry drive combined with linear direct drives ADDITIONAL EQUIPMENT - Cooling unit - Logbook function - Automatic pallet changer - Laser power control - HI-LAS high-pressure cutting - PMS plasma sensing - Programmable power cycles Iodpfx Aeyynu Njd Eoar - Programmable cutting gas pressure regulation - Laser cutting head with 5" lens and 7.5" lens - Quick-change system for cutting heads - Automatic sheet edge detection - APC capacitive height control and process monitoring - PCS (Process Control System) - Laser diode positioning - Automatic focus adjustment (AutoLas Plus) - Spraying device for safe thick sheet processing - Automatic shutdown - Work area lighting - Fully enclosed machine frame with integrated laser unit

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2008, operating hours: 42,130 h, machine/vehicle number: A0270 A2021, laser power: 6,000 W, sheet thickness steel (max.): 25 mm, sheet thickness aluminum (max.): 15 mm, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 115 mm, Submitting a bid entails an obligation for timely collection by 30.04.2026! Increased pressure to dispose - therefore reduced listing duration and lower minimum price! TECHNICAL DETAILS Travel range X-axis: 6,000 mm Travel range Y-axis: 2,000 mm Travel range Z-axis: 115 mm Workpiece weight: 2,800 kg Speed parallel/simultaneous: 200 / 300 m/min Accuracy Minimum incremental movement: 0.001 mm Positional deviation: ± 0.1 mm Positional repeatability: ± 0.03 mm Laser Model: TruFlow 6000 Power: 300 - 6,000 W Wavelength: 10.6 µm Beam mode: TEM01 Pulse frequency: 0.01 - 10 kHz Gases: CO₂ / N₂ / He Sheet thickness mild steel: 25 mm Sheet thickness stainless steel: 30 mm Isdpfx Adoyynuis Ejar Sheet thickness aluminium: 15 mm MACHINE DETAILS Control system: Siemens Sinumerik 840 D Dimensions & Weight Dimensions (L x W x H): 16.95 x 5.55 x 2.55 m Weight: 16 t Power consumption: 43 - 89 kW Connected load: 109 kVA Operating hours Beam-on time: 21,660 h Laser-on time: 42,130 h Compressed air connection: 7 - 10 bar Nitrogen connection: 30 bar Oxygen connection: 20 bar EQUIPMENT Cooling unit, logbook function Automatic pallet changer Gantry drive combined with linear direct drives Laser power control HI-LAS high-pressure cutting PMS plasma sensor technology Programmable power cycles Programmable cutting gas pressure regulation Laser cutting head with 5" lens and 7.5" lens Quick-change system for cutting heads Automatic sheet edge detection APC capacitive height and process control PCS (Process Control System) Laser diode positioning Automatic focus adjustment (AutoLas Plus) Spray device for safe thick sheet processing Automatic shut-off Work area lighting Open PC-based control system Online assistance Diagnostic functions Maintenance logbook Technology data Remote maintenance Safety Multi-beam light barriers Fully enclosed beam guidance with nitrogen flushing Monitoring system Multi-chamber extraction and compact dust collector Protective enclosure Machine system software

Condition: good (used), Year of construction: 2005, Used 2-meter CNC press brake from Trumpf Model: TrumaBend V85s Capacity: 2050 x 85 tons Control: Delem DA69 Axes: Y1, Y2, X, R, Z1 and Z2 Hydraulic WILA upper and lower clamping Year of manufacture: 2005 Iaodey Dpufopfx Ad Eer

Condition: good (used), Year of construction: 2001, functionality: fully functional, Hydraulic Press Brake Isdpfsy Dr Ibsx Ad Esar Make: TRUMPF Model: TrumaBend V85S Year of manufacture: 2001 Technical details Manufacturer: Trumpf Model: TrumaBend V85 S Year: 2001 Pressing force: 85 t Bending length: 2550 mm Throat depth: 420 mm Stroke: 215 mm Dimensions: L 3.1 x W 1.80 (plus 0.5m support arms) x H 2.40 m Weight: 8.8 t Equipment - Controlled axes: Y1, Y2, X, R, Z1, Z2 - 2 movable support arms - CNC-controlled crowning - Hydraulic tool clamping (top and bottom, Trumpf system) - Pneumatic die shifting - Delem 2D graphic control - CNC-controlled crowning - Tool package: Upper tool, straight H 140mm, R 1 28°, L 2500mm, segmented Lower tool V8, 86°, H 100mm, L = 2500mm, segmented All information subject to change. A demonstration is possible at any time in our showroom.

Condition: used, Year of construction: 2001, functionality: fully functional, operating hours: 80,188 h, power: 3,200 kW (4,350.78 HP), pressing force: 22 t, Equipment: safety light barrier, Description X working area max.: 2585 mm Y working area max.: 1280 mm Control unit: Siemens Sinumerik 840 D Laser power: 2700 watts Operating hours: Laser beam on: 13,817 hrs Laser on: 71,637 hrs Operating hours: 80,188 hrs Standard equipment: Iajdpfxoy Dpnfj Ad Esr - Rigid C-frame - Coordinate guide with integrated linear magazine - Drives: Maintenance-free three-phase servo motors - Programmable hold-down device for repositioning - Sensor-monitored part chute 500x500 mm for punching and laser stations, ejector cylinder on laser chute - Laser unit: High-frequency excited CO2 laser TLF 3200W, vibration-isolated, integrated into machine frame, incl. cooling unit and laser control system - Programmable cutting gas pressure adjustment - Laser cutting head: 5'' lens, quick-change system, distance control Safety: Multi-beam light barriers, fast-acting hydraulic shutoff, extraction system and compact dust extractor, protective device against stray radiation at the cutting head + Laser TLF 3200 + Brush table + Marking / fast ribbing function + Softpunch + Blowing device for small parts + Repositioning cylinder + Bulge detection + Chip conveyor

Condition: ready for operation (used), Year of construction: 2005, operating hours: 30,627 h, pressing force: 133 t, total width: 1,740 mm, total height: 2,375 mm, overall weight: 10,200 kg, travel distance X-axis: 600 mm, product length (max.): 4,060 mm, number of axes: 6, This 6-axis TRUMPF TrumaBend V 1300 was manufactured in 2005. It features a press force of 1300 kN and a bending length of 3230 mm, making it suitable for various bending applications. The machine has a robust weight of 10,200 kg and offers a maximum backgauge range of 860 mm. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V 1300 press brake we have for sale. Contact us for further details. • Free pillar passage: 2690 mm • Throat depth: 420 mm • Table width: 120 mm • Installation height: 385 mm (Standard) / 615 mm (Extended Height) • Working height (with 100 mm die): 1050 mm • Beam stroke: 215 mm (Standard) / 445 mm (Extended Height) • Beam positioning accuracy: 0.005 mm • Beam inclination: ±10 mm • Y-axis rapid/working/return speed: 220 / 0.1–10 / 220 mm/s • X-axis travel: 600 mm; positioning accuracy: 0.04 mm; speed: 0–1000 mm/s; max backgauge range (X): 860 mm • R-axis travel: 250 mm; positioning accuracy: 0.08 mm; speed: 0–330 mm/s Iajdpfx Adoy A Inbo Esr • Z-axis travel: 2400 mm; positioning accuracy: 1.00 mm; speed: 0–1000 mm/s • I-axis: Lower tool displacement (pneumatic or CNC-controlled) • V-axis (crowning): Manual or CNC-controlled • Control: TASC 6000 with 15" TFT screen • Storage: 2 × 40 GB hard drives • Interfaces: Parallel, RS232, USB, Ethernet • Electrical connection (connected load): 23 kVA • Pneumatic connection: 6 ± 1 bar • Hydraulic oil volume: 208 liters • Input voltage (measured): 401 V (target 400 V) • Control voltage (measured): 25.70 V (target 24 V) • After-run travel/time: 5 mm (at 220 mm/s) / 33 ms • Total machine hours (05.03.2026): 57,547 h • Total hydraulic hours (05.03.2026): 30,627 h Additional equipment • BendGuard safety system • Foot switch included • Optional available: ACB Measuring Tools • The Hydraluk cylinder is slightly leaking but still works Technical Specification Bending Length 3230 mm

Condition: excellent (used), Year of construction: 2010, Hours approx. 30,000 h Iodpfx Aoy A Rk Sod Ejar

Condition: ready for operation (used), Year of construction: 1991, punching force: 15 t, overall weight: 4,300 kg, product length (max.): 3,800 mm, CNC punching machine manufactured in 1991. This TRUMPF TRUMATIC 120R features a punching force of 15 tons and a maximum punching diameter of 38 mm. It offers a working area of 1000 x 2000 mm with repositioning and includes a complete set of tools. If you are looking to get high-quality punching capabilities, consider the TRUMPF TRUMATIC 120R machine we have for sale. Contact us for further details regarding this machine. • Maximum sheet thickness: 4 mm • Maximum punching diameter: 38 mm • Working area without repositioning: 1000 x 1000 mm • Working area with one repositioning: 1000 x 2000 mm • X/Y axis speed: not specified • Rotation speed: 360 degrees per second (full rotation) • Maximum stroke rate: 340 strokes per minute • Control system: TRUMAGRAPH CC 200 • Automatic tool change: 9 tool stations Iaedpfx Adjymz Rcj Eor • Power requirement: 15 kVA / 50 Hz • Documentation: Complete documentation included, together with machine history Additional equipment • Large set of tools • Two additional tables to extend the working area

Condition: ready for operation (used), Year of construction: 2001, laser power: 2,400 W, travel distance X-axis: 3,085 mm, number of axes: 2, CO2 laser cutting machine manufactured in 2001. This TRUMPF TRUMATIC TC 600L Y1300 features a punching force of 22 T and a maximum thickness of 8 mm. It offers a maximum format of 3085 x 1370 mm in punching operation and a feed rate of 90 m/min on the X axis. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF TRUMATIC TC 600L Y1300 machine we have for sale. Contact us for further details. • Condition: Good overall condition; fully functional; still in production • Maximum format (combined operation): 2585 x 1280 mm Iedpfjy Anhuex Ad Ejar • Maximum format (LASER operation): 3085 x 1280 mm • Maximum format (punching operation): 3085 x 1370 mm • Power-on hours: 48,746 h • Laser beam operating hours: 2,159 h • Punching force: 22 T • Maximum thickness: 8 mm • Laser source: TLF 2400W turbo • Feed rate X axis: 90 m/min • Feed rate Y axis: 60 m/min

Condition: good (used), functionality: fully functional, Year of construction: 1985, control type: CNC control, actuation type: hydraulic, controller manufacturer: Bosch, controller model: CC 300, sheet thickness (max.): 6 mm, working length: 2,500 mm, working width: 1,300 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,300 mm, feed rate X-axis: 90 m/min, feed rate Y-axis: 60 m/min, workpiece weight (max.): 200 kg, power: 7.5 kW (10.20 HP), input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, compressed air connection: 6 bar, overall weight: 16,800 kg, total length: 5,000 mm, total width: 5,000 mm, total height: 2,600 mm, Equipment: documentation/manual, We offer this good TRUMPF Trumatic 260 Rotation CNC punch, year of construction 1985. manufacturer: TRUMPF model: Trumatic 260 Rotation year of construction: 1985 condition: good category ID: 908 type ID: 1180 type: CNC punch If you have any questions or need more information, feel free to send us a message or give us a call. TRUMPF Trumatic 260 Rotation & Quicksharp ALL TOOLING INCLUDED • Punching Force: 250 kN (approx. 25-30 tons) • Footprint: L x W x H 5000 x 5000 x 2600 mm • Working Range (X x Y): 2500x1300 mm (plus optional repositioning) • Max Sheet Thickness: 6.4 mm • Max Workpiece Weight: 150-200 kg • Tooling: 10 stations (with 360-degree rotation of all tools) • Max Tool Diameter: 76.2 mm • Max Rotation Speed (C-axis): 360°/sec • Traverse Speeds (X/Y): Up to 90 m/min (X), 60 m/min (Y) • Control: Bosch CC 300 (typical) Isdpfx Adsy Ax I Ej Eoar • Machine Weight: Approx. 16,000-16,800kg • Compressed air requirement: 6 bar • Motor Power Hydraulics: 7,5 Kw • Mains Connection: 380 volts, 50 Hz, 35 kVA

Condition: like new (used), Year of construction: 2017, functionality: fully functional, operating hours: 4,500 h, stroke length: 200 mm, Hydraulic Press Brake Manufacturer: TRUMPF Model: TruBend 3066 B26 Year: 2017 As new, only 4,500 operating hours! Technical Data Manufacturer: TRUMPF Model: TruBend 3066 Year of manufacture: 2017 (B26) Bending length: 2040 mm Pressing force: 66 t Operating hours: 4,500h (read off) Clear distance between uprights: 2364 mm Iajdpfxoyz Smfj Ad Eer Throat depth: 400 mm Drive power: 17 kW Stroke: 200 mm Y-axis rapid traverse speed: max. 200 mm/s Y-axis working speed: max. 15 mm/s Dimensions: L 2587 x W 1644 x H 2370 mm Weight: 5650 kg Equipment - Electro-hydraulic top-drive - Block hydraulic system - Controlled axes: Y1, Y2, X, R - 3 backgauge fingers - TRUMPF upper and lower tool clamping system - Self-regulating crowning system - Control: Delem T3500T multi-touch control - Front light barrier BendGuard - Integrated TRUMPF technology data - Foot pedal - Tooling as per photo All information without guarantee. Machine demonstration under power is possible at any time in our showroom.

Condition: used, Year of construction: 1991, Technical details: pressure: 2000 t chamfer lenght: 4100 mm control: - distance between columns: 3200 mm stroke max.: 250 mm total power requirement: 22 kW operating pressure: max. 280 bar table width: 200 mm stroke speed - idle stroke upwards: 100 mm/s Isdpfx Adjy Alw Ho Eear stroke speed - idle stroke downwards: 100 mm/s weight of the machine ca.: 18.000 t dimensions of machine: 5,0 x 2,7 x 3,0 m

Condition: excellent (used), functionality: fully functional, Year of construction: 2015, laser type: fiber laser, Used laser cutting system with 8 kW fiber laser and LiftMaster Compact (Stopa version) Manufacturer: TRUMPF Model: TruLaser 5040 fiber (L69) Year of manufacture: 2015 Operating hours approx.: 67,000 h, Laser on: 40,100 h TECHNICAL DATA: Maximum material thickness: Mild steel O2: 25 mm, Stainless steel N2: 40 mm, Aluminum N2: 25 mm, Copper O2: 10 mm, Copper N2: 5 mm, Brass N2: 10 mm Position deviation: 0.05 mm Max. position scatter Ps max: 0.03 mm Working area: 4,000 x 2,000 mm Laser power: 8,000 watts STANDARD EQUIPMENT Machine: Closed machine frame Torque drive combined with linear direct drives Enclosed beam guidance via fiber optic cable (LLK) Cooling unit Machine cooling unit (water-air) Integrated control cabinets with interior lighting Integrated storage cabinet Automatic longitudinal pallet changer 19" touch color screen Longitudinal conveyor belt TruDisk power supply via the machine Work area illumination Positioning laser diode Spray unit PierceLine FocusLine NitroLine PlasmaLine Automatic nozzle cleaning Copper cutting package (includes cutting data) Brass cutting package (includes cutting data) Transport and assembly device SPECIAL EQUIPMENT: Solid-state laser TruDisk 8001 with 1 fiber output Smart Nozzle Automation (includes nozzle changer, automatic nozzle condition monitoring, and smart skip) BrightLine fiber CoolLine (only with BrightLine fiber) DetectLine: precise sheet position detection (incl. automatic focus measurement) Wide transverse conveyor with tipping container (container to the right of the machine) Cleaning brush Integrated camera (Full HD) for process monitoring and single frame transmission to the network (view of the first 2.5 m) Additional 10 m extension of fiber optic cable between laser and machine Smart Collision Prevention (requires smart-collision-prevention plug-in for TruTops) Machine podium version (without steel structure) Storage interface for STOPA large-scale storage systems (SKL or UL) Safety devices for storage integration incl. 2nd light barrier circuit Storage interface (without storage cart) LiftMaster Compact (STOPA version) TRUMPF Laser: Solid-state laser TruDisk 8001 with one fiber output Fiber optic cable as per standard layout Laser cooling unit (water-air) Excitation via pump diodes Laser power control (The TruDisk laser is subject to international export controls. According to EC Dual-Use Regulation 428/2009 (laser covered under 6A005)) Cutting head: Universal cutting unit with fully adaptive lens system Piercing head strategy Protective glass to prevent lens contamination Protective glass condition check ControlLine: height control and sheet outer edge detection Control system: SINUMERIK 840D SL control Simple workshop programming TruTops Laser via network access Quick re-production Iaodpfx Asy A I Tqsd Esr Integrated TRUMPF technology data Automatic shut-off Programmable cutting gas/pressure selection ContourLine FastLine FlyLine Microweld AdjustLine Teleservice via Internet Data transfer: USB interface RJ-45 network connection Safety: CE marking Light barriers Multi-chamber exhaust system Compact extraction unit Machine enclosure, certified viewing window, door on right Electric roll-up roof This used machine can be inspected under production conditions. All details without guarantee – sale is without any form of warranty or guarantee. Subject to prior sale.

Condition: excellent (used), functionality: fully functional, Year of construction: 2010, operating hours: 44,973 h, laser power: 2,700 W, punching force: 22 t, working range: 2,500 mm, Equipment: cooling unit, safety light barrier, Description X working range max.: 2585mm Y Working range max.: 1280mm Control: Siemens Sinumerik 840 D Laser power: 2700 Watt Laser beam on: 6054 hours Laser on: 29826 hours Operating hours: 44973 hrs. Standard equipment: - Sturdy C frame - Coordinate guide with integrated linear magazine, 21 places for tools and clamping claws - Drives: Maintenance-free three-phase servomotors - Programmable hold-down device for repositioning - Sensor-monitored 500x500mm parts chutes for punching and laser station, ejection cylinder on laser chute - Laser unit: High-frequency excited CO2 laser TLF 2700W, vibration-insulated, integrated in machine frame, incl. cooling unit and DIAS 3 laser controller - HI-Las high-pressure cutting - Fast processing with SprintLas - ContourLas for producing small holes Iaedpfx Adotpguzo Eor - Cutting gas pressure setting programmable - Laser cutting head: 5'' lens, quick-change device, distance control - Sinumerik 840D control system, 10.4'' TFT color screen, simple operation, online help, diagnostic functions, maintenance logbook, technology data, job tables, Teleserice, 3.5'' floppy disk drive, RJ45 network connection Safety: Multi-beam light barriers, quick shut-off hydraulics, suction and compact dust extractor, protective device against stray radiation on the cutting head + TLF 2700 laser + Thread forming function + MultiTool function + Signing / fast beading function + MultiBend function + Rolling technology function + Repositioning cylinder + bulge detection + Chip conveyor automation + Sheetmaster + Gripmaster + Trumasort R4

Condition: used, functionality: fully functional, Year of construction: 2006, Make: TRUMPF Iodpoyyyplefx Ad Esar Model: TruLaser L 3030 – 4 kW Year of manufacture: 2006 Working area: 3,000 x 1,500 x 115 mm Control: Siemens Sinumerik 840 D Laser power: 4,000 Watt Operating hours: Laser On 54,137h, Beam On 18,589h

Condition: used, Year of construction: 2008, Crowning CNC controlled Bending length: 4250mm 6-axis backgauge Work area lighting Park position: 900mm Iaodpfxjyvr Apo Ad Esr Lower tool hydraulic clamping Upper tool hydraulic clamping Lower tool CNC positioning Installation height: 615mm ACB preparation

Condition: used, functionality: fully functional, Year of construction: 2008, Cooling unit Riedel / Trumpf L15/21-TR4-K03.24 Iasdpfx Adstqmigo Eor

Condition: used, Year of construction: 2008, Crowning CNC controlled Bending length 4250 mm 5-axis backgauge Work area lighting Parking position 900 mm Hydraulic lower tool clamping Hydraulic upper tool clamping Iaedpfxeyvr Ewj Ad Eer CNC lower tool displacement Installation height 615 mm ACB preparation

Condition: like new (used), Good parts conveyor belts for TruMatic 7000 / 6000 Iajdpju S Ny Tofx Ad Ejr Very good condition

Condition: reconditioned (used), functionality: fully functional, Year of construction: 2018, laser power: 8,000 W, Manufacturer: TRUMPF Type: TruLaser 3060 fiber (L66) Year of manufacture: 2018 Ijdewl I Tvjpfx Ad Eear Working area 6000 x 2500 x 115 mm Laser power: 8000 watts Control: Siemens Sinumerik 840D SL Standard equipment Machine ⦁ Working area 6000 x 2500 mm ⦁ Closed machine frame ⦁ Integrated cabinet with roller shutter ⦁ Automatic pallet changer in longitudinal direction ⦁ Gantry drive combined with linear direct drives ⦁ Closed beam guidance via laser light cable (LLK) ⦁ Cooling unit ⦁ Integrated control cabinets ⦁ Longitudinal conveyor belt ⦁ Work area lighting ⦁ Positioning laser diode ⦁ Spraying system ⦁ PierceLine ⦁ FocusLine ⦁ NitroLine ⦁ PlasmaLine ⦁ Automatic nozzle cleaning Extended features: ⦁ External TruDisk 8001 solid-state laser with 1 LLK output (includes BrightLine fiber and Fusion Cut Performance Package) ⦁ DetectLine ⦁ Drop & Cut ⦁ Advanced Condition Guide sensors ⦁ Cameras 1+2 ⦁ Cross conveyor ⦁ Wireless Operation Point ⦁ Dust protection for device plate ⦁ High-speed cutting package ⦁ Copper cutting package - O2 and N2 cutting data ⦁ Brass cutting package - N2 cutting data ⦁ Smart Collision Prevention (only in conjunction with TruTops Laser or TruTops Boost)

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Used Welding Cell / Welding Robot (MAG/MIG) – Immediately Available Manufacturer: TRUMPF Model: TruArc Weld 1000 Year of Manufacture: 2021 Standard Features: - Universal Robots UR10e - 3D welding table by Demmeler - Telescopic center separation Iodoy A Iixopfx Ad Eear - Linear axes - Fume extraction - Safety enclosure - Shielding gas connection - Compressed air connection Welding Source: - Fronius high-performance MAG/MIG welding source - Robotic welding torch - 3.25 m MIG/MAG robot torch package - Fronius wire feeder - Wire spool holders - Connection for wire drum Control System: - Robot controller with easy programming - Central control unit Operation: - Foot switch - Control panel for easy programming TECHNICAL DATA: Axis Data Type: Collaborative industrial robot arm Number of axes: 6 Reach: 1300 mm Repeatability: ±0.05 mm Welding Source Type: Fronius TPS 320i C PULSE Welding current range MIG/MAG: 3–320 A Dimensions and Weights Base version (without enclosure, cobot in transport position): 2540 × 2250 × 1600 mm Weight (base version): 1317 kg Cabin dimensions: 3605 × 2454 × 2818 mm Weight incl. enclosure: 2940 kg Working Area[1] Base version: Open area, therefore no physical boundary Enclosure with open center separation: 3200 × 1000 × 1150 mm Enclosure with closed center separation: 1600 × 1000 × 1150 mm [1] The actual component size depends on whether the cobot can reach the welding points. Typical maximum component sizes in the base version without safety enclosure can be, for example, 3000 × 600 × 600 mm or 3800 × 600 × 100 mm. If the part is welded in several steps, even longer components are possible. Data Transfer: - USB interface Safety: - Safety device - CE marking This used machine can be inspected under production conditions. All information is provided without guarantee – sale is without any warranty or guarantee. Subject to prior sale.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 65,000 h, laser power: 3,200 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, number of axes: 3, CO2 laser cutting machine manufactured in 2001. This TRUMPF Trumatic L3030 features a laser power of up to 3208 W in CW mode, providing efficient cutting capabilities. It includes a robust control system (TASC3) and operates on a 3-phase AC supply. If you are looking to get high-quality cutting capabilities, consider the TRUMPF Trumatic L3030 machine we have for sale. Contact us for further details. Iodsyzymgopfx Ad Eear • Electrical • Supply voltage: 400 V • Phases: 3-phase AC • Frequency: 50 Hz • Rated power: 73 kVA • Rated current: 105 A • Maximum fuse protection: 125 A • Control voltage: 24 V DC • Control • Control system: TASC3 • Control software version: 2.4 • Laser performance • CW mode power: • 100%: 3208 W • 85%: 2756 W • 75%: 2407 W • Pulsed (5 kHz) power: • 100%: 3208 W • 75%: 2416 W • 50%: 1610 W • 25%: 810 W • 10%: 328 W • 5%: 157 W • 1%: 0 W • RF/drive • Reflected RF power: 0.3 kW • Maximum CW RF amplitude: 100% • Switching frequency (CW): 50 kHz • Maximum pulse voltage: 10,000 V • Pressure and leakage • Operating pressure limits: 20.01–27.00 kPa • Maximum turbine pressure: 200 hPa • Leakage rate: 0.04 hPa/min • Thermal/CPU • Maximum CPU temperature: 49 °C • Actual CPU temperature: 43 °C • Optics/Alignment • Maximum beam alignment time: 600 s • Hours • Spindle hours: 65,000 h Additional equipment • RIEDEL chiller (cooling system) (2001), Type: L 15/21 TR3 • Supply voltage: 400 V • Phases: 3-phase • Frequency: 50 Hz • Nominal current: 42 A • Protection class: IP54 • Refrigerant: R134a • Refrigerant charge: 11.5 kg • Maximum water pressure: 20.2 bar

Condition: ready for operation (used), Year of construction: 2012, operating hours: 20,118 h, laser power: 6,000,000 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, number of axes: 3, This 3-axis TRUMPF TruLaser 5030 was manufactured in 2012. It features a powerful 6,000 W laser and is equipped with a HANDTE MF-L 2000 extraction system. The machine has been completely freshly serviced and has a total of 20,118 laser hours. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF TruLaser 5030 CO2 laser cutting machine we have for sale. Contact us for further details. • Gesamtantriebsleistung: ca. 11,5 kW (nur Maschine ohne Zusatzausstattung) • Elektrische Ausführung: nach VDE-Richtlinien, Spannung 400 V ± 10 %, 50 Hz mit Nullleiter • Connected load: 400 V / 50 Hz / 12 kVA • Main fuse: 3x160 A • Fehlerstromschutzschalter in der Netzeinspeisung nur als allstromsensitive Ausführung mit 300 mA zulässig • Steuer- und Ventilspannung 24 V-DC • Multitasking Prozesssteuerung mit großem Bedienterminal und übersichtlicher Menüführung • Schaltschrank und Bedienpult frei aufgestellt • Lackierung Grundmaschine: lichtgrau - RAL 7035 • Lackierung Abdeckungen: rotviolett - RAL 4002 • Minimale Abschnittlänge: im automatischen Betrieb ab 10 mm • Mindest-Reststücklängen: ca. 180 mm • Verfahrweg des Nachschubgreifers: 3.000 mm • Gewicht des Schneidgutes: bis max. 4.000 kg • Länge der Maschine: 5.600 mm • Breite der Maschine: 4.300 mm • Höhe der Maschine: 2.550 mm (2.150 mm für Transport), Anlage zum Transport geteilt • Gewicht: ca. 3.100 kg • Materialauflagehöhe: 800 mm • Sägebandspannung: hydraulisch, elektrisch überwacht • Kühlmittelbehälter Fassungsvermögen: ca. 60 l • Kühlmittelpumpe Fördermenge: 40 l/min bei 2,5 m Förderhöhe, Leistung: 115 W • 3RD CNC 6006, Motor 13,1 kW, Spindeldrehzahl 50-5000 U/Min. • Tisch 6100x580 mm, ausgeführt mit Späneförderer • Verfahrwege X/Y/Z 6100x600x450 mm • Pendelbetrieb (Be- und Entladen während Maschine produziert) • Standardausführung inklusive: 15,4” Touchscreen PC und Pentium 5 PC, 8GB RAM, 120GB Festplatte • Grafische Programmierung • Automatische Werkzeuglängenvermessung • Bedienpult extern auf Linearführung • Verkleidung um Maschinenkopf • Laser-Gebietssensor (Pendelbetrieb) • Kühlanlage mit Emulsion • Ethernet-Anschluss für Teleservice • Gemäß Angebot vom 26. Januar 2022 • Inklusive: Tisch 70 mm abgesenkt und Säule 100 mm verlängert, Abstand Spindel-Tisch 295-745 mm • 16-fach Werkzeugwechsler • Elektronisches Handrad für manuelles Verfahren der Achsen • Kühlung durch die Spindel, Arbeitsdruck 4 Bar, ausgeführt mit Drehzufuhrventil geeignet für Kühlung mit nur Luft • Automatisches Tastsystem für die Höhe des Werkstücks (Z-Reader) • Komplette DrillCam CAD/CAM Software zum Konvertieren von 2D DXF, DWG, DSTV, NC, NC1 oder 3D STEP Dateien zu Maschinenprogrammen, auf der Steuerung der Maschine installiert • Safety: Light barrier system • Laser hours: 20,118 h • Condition/Service: Completely freshly serviced • Enclosed machine frame with integrated laser unit • Gantry drive combined with linear drives • Automatic pallet changer • Longitudinal conveyor belt • Cross conveyor (waste conveyor) • Work area lighting • PCS (Process Control System) • Positioning laser diode • Oil spray system • HI-LAS Iasdpfx Aeyrfbced Eor • HI-LAS PLUS • PMS (Plasma Monitoring System) • Trumpf Laser: CO2 laser TFL 6000 • Cooling unit • High-frequency excitation • Laser power control • Programmable cutting gas pressure setting • DIAS III • AutoLas Plus • Oil spray system for safe thick sheet metal processing • Automatic shut-off • Programmable power cycles • Laser logbook function

Condition: used, #200112 Trumpf OW200/S - press brake tools / upper tools 86.00° R4.00 / H=218.30 / 800 kN/m Segment lengths: 2x 25 mm 1x 30 mm Iodpfxjy Anydo Ad Ejar 1x 40 mm 2x 100 mm (reduced body 70 mm 1x left / 1x right) 5x 200 mm 5x 300 mm ----- #200113 Trumpf OW201/S 86.00° R1.00 / H=220.00 / 800 kN/m Segment lengths: 2x 25 mm 1x 30 mm 1x 35 mm 1x 40 mm 1x 45 mm 1x 50 mm 3x 100 mm (2x reduced body 70 mm 1x left / 1x right) 1x 200 mm 7x 300 mm

Condition: excellent (used), functionality: fully functional, Year of construction: 2005, Pressure: 225 t Iaedpeyz S Ngjfx Ad Eer Bending length: 4050 mm Control: DA 69 TW Oil capacity: 400 l Total power requirement: 17 kW Machine weight approx.: 18,100 kg Dimensions: 5700 x 2610 x 3300 mm
