Overview of AMC TECHNIC

Condition: ready for operation (used), Year of construction: 1996, machine/vehicle number: 755T, functionality: fully functional, cutting length (max.): 3,050 mm, sheet thickness steel (max.): 8 mm, No minimum price – guaranteed sale to the highest bidder! Includes a second Siemens S5 control unit as a spare part! TECHNICAL DETAILS Steel sheet thickness: 8 mm Cutting length: 3,050 mm MACHINE DETAILS Cgjdpfxjzd U R Nj Ahtow Hydraulic pressure: 250 bar Total weight: 10,000 kg EQUIPMENT Cybelec documentation Wiring diagram Second Siemens S5 control unit (spare)

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 796022, overall weight: 2,488 kg, load capacity: 420 kg, arm reach: 3,076 mm, controller model: KRC2, repeat accuracy: 0.06 mm, number of axes: 6, TECHNICAL DETAILS Rated load capacity: 420 kg Reach: 3,076 mm Repeatability (ISO 9283): ±0.06 mm Range of motion A1: ±185° A2: -40° / +110° A3: -184° / +60° A4: ±350° A5: ±118° A6: ±350° Speed at rated load capacity A1: 69 °/s A2: 69 °/s A3: 69 °/s A4: 77 °/s A5: 76 °/s A6: 120 °/s MACHINE DETAILS Controller: KRC2 Number of axes: 6 Cgjdpfx Aszduq Nshtjw Mounting position: Floor Ambient temperature (storage/transport): -40 °C to 60 °C Weight: 2,488 mm EQUIPMENT Manipulator KRC2 control cabinet Complete cable set Teach pendant

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter: 460 mm, spindle speed (max.): 3,500 rpm, spindle bore: 86 mm, bar passage: 78 mm, controller model: Fanuc 32iTB iHMI, center width: 689 mm, CMZ turning and milling center including GL20II gantry loader! TECHNICAL DETAILS Turning diameter over bed: 760 mm Turning diameter over cross slide: 600 mm Maximum turning diameter: 460 mm Distance between centers: 689 mm Travel distance tailstock: 640 mm Travel distance X-axis: 310 mm Travel distance Z-axis: 640 mm Travel distance Y-axis: +70/-50 mm Travel distance B-axis: 640 mm Rapid traverse rates: 30/30/15/30 m/min Spindle speed max.: 3,500 rpm ASA 8" A2 Spindle bearing outer diameter: 200 mm Spindle bearing inner diameter: 130 mm Spindle bore: 86 mm Bar passage: 78 mm Number of tool stations: 12, all driven, 12,000 rpm Tool holder: 25x25 (50) MACHINE DETAILS Operating hours: 43,712 h Cgjdpfx Ahezdrzxetow Total operating hours: approx. 35,000 h Control system: Fanuc 32iTB iHMI Dimensions & Weight Machine dimensions (L x W x H): 2,542 x 1,760 x 1,880 mm Machine weight: 6,500 kg EQUIPMENT Gantry loader

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, machine/vehicle number: 7600-101325, load capacity: 340 kg, arm reach: 2,800 mm, pivoting range: 360 °, warranty duration: 4 months, Equipment: documentation/manual, Robot with a 4-month warranty General overhaul included: - Cleaning: Thorough cleaning of the robot panel and surface. - Oil change: Changing the oils for all six axes. - Battery replacement: All internal batteries were replaced with new batteries. - Mechanical maintenance: Gears and counterweight were inspected and serviced after repeatability and weight tests. - Electronic maintenance: Drivers, electronic boards, teach pendant, and PC components were serviced. - Polishing and repainting: The robot was polished and repainted in the original color or a custom color upon request. TECHNICAL DETAILS Reach: 2800 x 3171 mm Payload: 340 kg Control: IRC5 Axis 1 – Rotation motion: +180° to -180° Axis 2 – Arm motion: +85° to -60° Axis 3 – Arm motion: +60° to -180° Axis 4 – Wrist motion: +300° to -300° Axis 5 – Bend motion: +100° to -100° Axis 6 – Turn motion: ±360° (standard), max. ±67 revolutions Dynamics (max. rotation speed per axis) Axis 1: 75°/s Axis 2: 60°/s Axis 3: 60°/s Axis 4: 100°/s Axis 5: 100°/s Axis 6: 160° °/s Position and Path Precision Position Accuracy (AP): 0.18 mm Repeatability (RP): 0.27 mm Stabilization Time (Pst at ±0.4 mm): 0.18 s Path Accuracy (AT): 2.05 mm Path Repeatability (RT): 0.23 mm FEATURES - 6-axis industrial robot with a high payload class - Large swivel range on axis 6 with up to 67 revolutions - Precise path guidance with repeatability of less than 0.3 mm - High speed of the wrist axes for fast movements Cgodpfxjzdrx Re Ahtow - Perfectly suited for heavy-duty handling and precise motion sequences

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 172087, turning diameter: 660 mm, spindle bore: 76 mm, spindle speed (max.): 5,000 rpm, controller model: MAZATROL Fusion 640 MT, spindle torque (max.): 349 Nm, TECHNICAL DETAILS Maximum turning diameter: 660 mm Main spindle Speed range: 35–5,000 rpm Power (10 min / continuous operation): 22 / 15 kW Maximum torque: 349 Nm Spindle bore: 76 mm Chuck diameter: 210 mm C-axis indexing: 0.0001° Sub-spindle Speed range: 35–5,000 rpm Power (10 min / continuous operation): 18.5 / 15 kW Maximum torque: 326 Nm Chuck diameter: 210 mm C-axis indexing: 0.0001° Cooling Coolant tank volume: 300 l Pump capacity: 20 l/min Pump pressure: 5 bar Compressed air requirement: 5 bar, 500 l/min MACHINE DETAILS Control model: MAZATROL Fusion 640 MT Total power consumption: 66 kVA Operating voltage: 400 V / 50 Hz EQUIPMENT Cedezgufrepfx Ahtjgw Technical documentation Chip conveyor with cooling system 20-position tool magazine B-axis (positioning in 0.001° increments) C-axis Y-axis Milling spindle Angular positioning of the sub-spindle Synchronization of main and sub-spindle Tool setting system (Tool Eye) Interlock for the front door Complete cooling system Interface for IC memory card

Condition: ready for operation (used), functionality: fully functional, turning diameter over cross slide: 402 mm, turning length: 758 mm, turning diameter: 450 mm, spindle speed (max.): 3,000 rpm, turning diameter over bed slide: 582 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum turning diameter: 450 mm Maximum turning length: 758 mm Diameter of rotation over the bed: 582 mm Diameter of rotation over the cross slide: 402 mm Spindle speed: 3,000 rpm Maximum spindle torque: 351 Nm Distance between centers: 744 mm Bar diameter: 81 mm Chuck size: 260 mm (10") Maximum bar diameter: 40 mm Axes: X, Z Number of tool positions in the tool changer: 12 Tool shank size: 25 × 25 mm Travel in the X-axis: 250 mm Csdozgt U Sjpfx Ahtjgw Travel in the Z-axis: 790 mm Rapid traverse rate in the X/Z direction: 30 m/min MACHINE DETAILS Control model: Hurco WinMax Spindle power: 22 kW Power supply: 400 V / 50 Hz (market-dependent) Machine weight: approx. 5,000 kg

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: X2S174, turning diameter over cross slide: 246 mm, turning length: 1,200 mm, spindle speed (max.): 2,700 rpm, turning diameter over bed slide: 400 mm, controller model: Fanuc 0i-TF Plus, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swinging diameter over bed: 400 mm Swinging diameter over cross slide: 246 mm Swinging diameter in the steady rest area: 585 mm Spindle speed range: 1–2,700 rpm Codjzgt Urspfx Ahtogw Distance between centers: 1,200 mm Spindle bore: 55 mm / 80 mm Spindle nose: D1-6 Camlock Chuck size: 250 mm Axes: X, Z MACHINE DETAILS Control model: Fanuc 0i-TF Plus Main motor power: 7.5 kW Machine weight: approx. 2,200–2,500 kg EQUIPMENT Coolant system Manual tailstock Automatic lubrication of guideways and ball screws

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 81 mm, turning diameter: 99 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 240 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum turning length: 81.3 mm Maximum turning diameter: 99.1 mm X-axis: 300 mm Z-axis: 240 mm Spindle head: A2-6 Spindle bore: 33 mm Speed (variable): 4,000 rpm Spindle motor power: 11 kW Number of tools on the turret: 8 Number of driven tools: 10 Cedpezfg E Iofx Ahtsgw MACHINE DETAILS Control: Fanuc 21iT Dimensions & Weight Machine dimensions (including chip conveyor): 290 x 235 cm Machine weight: 4,000 kg Dimensions of transformer station: 65 x 60 cm Weight of transformer station: 150 kg Overall dimensions (L x W x H): 2,600 x 2,300 x 2,400 mm Total weight: 3,900 kg EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, The system consists of the following components: Unwinding station with a lifting device for the rolls and a take-off device Film preheating station KVH 83 Thermoforming machine KMD52BFS TECHNICAL DETAILS Maximum forming area: 520 x 400 mm Minimum forming area: 260 x 250 mm Maximum tool dimensions: 540 x 420 mm Positive forming height: 120 mm Negative forming height: 120 mm Maximum film width: 570 mm Minimum film thickness: 200 µm Maximum film thickness: 1,200 µm Maximum speed: 45 cycles/minute MACHINE DETAILS Operating pressure: 6 bar Maximum air consumption: 50 Nl/cycle Heating power, upper heating: 15 kW Heating power, lower heating: 15 kW Vacuum pump: 100 m³/h Voltage: 3x 400 V AC + N + PE, 50/60 Hz Total connected load: approx. 80 – 90 kVA Csdpfx Ahszfggletsgw EQUIPMENT Forming station for combined forming and in-mold cutting with steel knives Stacking station, including counting and stack ejection A/B stacking function via a second ejector drive, pneumatically operated Winding station for skeleton waste, motorized Note: No molds are included in the scope of supply.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2010, operating hours: 18,948 h, machine/vehicle number: A0215A0087, laser power: 2,000 W, sheet thickness steel (max.): 12 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 75 mm, No minimum price – guaranteed sale to the highest bidder! A maintenance checklist from December 2025 is attached! The defects listed there have been completely rectified (see attached activity report from Trumpf)! TECHNICAL DETAILS Working area X-axis: max. 3,000 mm Working area Y-axis: max. 1,500 mm Working area Z-axis: max. 75 mm Speed X: max. 60 m/min Speed Y: max. 60 m/min Speed Z: max. 60 m/min Simultaneous speed X/Y: max. 85 m/min Sheet metal thickness, steel: max. 12 mm Sheet metal thickness, stainless steel: max. 6 mm Sheet metal thickness, aluminum: max. 5 mm Workpiece weight: max. 575 kg MACHINE DETAILS Control system: B&R Arnco Laser type: TruCoax 2000 Laser power: 2,000 W Dimensions and weight Footprint (L x W x H): 7,400 x 3,300 x 2,300 mm Transport width: 2,464 mm Weight: 9,000 kg Electrical connection: 65 kVA Operating hours (as of December 17, 2025) Operating hours, laser: 18,948 h Laser beam on-time: 3,635 h EQUIPMENT Cgsdpfx Ahezdp Ntetsw Closed machine frame with integrated laser head Motion unit for high-precision machining Drives with maintenance-free three-phase servo motors Sheet metal support accessible from both sides Enclosed beam guidance Fully integrated cooling unit Traveling extraction system Collection container for falling parts under the working area Positioning laser diode FocusLine
